ZOLL Aed Plus User manual

Service Manual
™
9650-0308-01 Rev. A
March 2005

An issue date and revision level for this manual appear on the front cover.
If more than three years have elapsed since this date, contact ZOLL Medical Corporation to determine if
additional product information updates are available.
ZOLL and stat•padz are registered trademarks, and AED Plus, AED Pro, CPR-D•padz,pedi•padz,pro•padz,
PowerCharger, Preconnect, RescueNet, Smart Alarms, and v•pak are trademarks of ZOLL Medical
Corporation. All other trademarks and registered trademarks are property of their respective owners.
Copyright © 2005 ZOLL Medical Corporation. All rights reserved.

9650-0308-01 Rev. A ZOLL AED Plus Service Manual i
Table of Contents
Preface
Related Documentation .........................................................................................................iv
Conventions...........................................................................................................................iv
Symbols ..................................................................................................................................v
Safety Considerations............................................................................................................vi
Warranty ................................................................................................................................vi
Technical Service..................................................................................................................vii
Returning a Unit for Service ..........................................................................................vii
Chapter 1 Maintenance Tests
Preparations for Testing ...................................................................................................... 1-2
Test Equipment ................................................................................................................... 1-2
1.0 Physical Inspection.................................................................................................. 1-3
2.0 Preventive Maintenance Test .................................................................................. 1-4
3.0 Manual Self-Test ..................................................................................................... 1-9
Chapter 2 Troubleshooting
Troubleshooting the AED Plus Unit .................................................................................... 2-2
AED Plus Error Log Messages ........................................................................................... 2-4
Appendix A Maintenance Tests Checklist
Instructions .........................................................................................................................A-2
ZOLL AED Plus Maintenance Tests Checklist ....................................................................A-3
Index

TABLE OF CONTENTS
ii www.zoll.com 9650-0308-01 Rev. A

9650-0308-01 Rev. A ZOLL AED Plus Service Manual iii
Preface
ZOLL Medical Corporation provides this manual for technicians who service the AED Plus™
device or diagnose malfunctions. This manual contains the following sections:
Preface — Provides safety warnings and an overview of the manual’s contents. Review this
section thoroughly before servicing an AED Plus unit.
Chapter 1, "Maintenance Tests" — Provides the recommended procedures for evaluating the
condition and performance of the AED Plus unit.
Chapter 2, "Troubleshooting" — Describes possible problems and solutions and lists the
error log messages that indicate the unit requires technical service.
Appendix A, "Maintenance Tests Checklist" — Provides a checklist for recording the results
of maintenance tests.
Note: The AED Plus contains no user-replaceable parts.

PREFACE
iv www.zoll.com 9650-0308-01 Rev. A
Related Documentation
In addition to this service manual, the following manuals are available for the AED Plus unit:
•AED Plus Operator’s Guide (9650-0300-01) — Describes what the rescuer sees, hears, and
does while operating the unit.
•AED Plus Administrator’s Guide (9650-0301-01) — Describes the features and functions of
the unit and the procedures for configuring and maintaining it.
•AED Plus Simulator Operator’s Guide (9651-0800-01) — Describes the AED Plus
simulator, which you can use to test the AED Plus unit’s response to various simulated
cardiac rhythms.
Conventions
This manual uses uppercase italics for audible prompts and for text messages displayed on the
screen (for example DON’T TOUCH PATIENT, ANALYZING).
WARNING! Warning statements alert you to conditions or actions that can result in personal injury
or death.
Caution Caution statements alert you to conditions or actions that can result in damage to the unit.
!Within test or troubleshooting procedures, this symbol indicates an audible prompt or
message; for example:
!UNIT OK

Symbols
9650-0308-01 Rev. A ZOLL AED Plus Service Manual v
Symbols
Symbols used in this manual or on the equipment include the following:
Class II equipment
Defibrillation-protected Type BF patient connection
ATTENTION: Refer to the operator’s guide for more information
WARNING: Dangerous voltage
New battery cells
Not new battery cells
Push button
Do not push button
VARTA
Recommended manufacturer
Do not use this manufacturer
Unit equipped to treat adult and pediatric patients
Conformité Européenne Complies with medical device directive 93/42/EEC.

PREFACE
vi www.zoll.com 9650-0308-01 Rev. A
Safety Considerations
Only qualified personnel should service or disassemble an AED Plus unit. Before using this
device, read the AED Plus Administrator’s Guide. Before servicing or disassembling any
equipment, review these safety considerations and read this manual carefully.
WARNING! The AED Plus unit can generate as much as 2250 volts with sufficient current to cause
lethal shocks.
Before discharging the defibrillator, warn everyone near the equipment to “STAND CLEAR.”
Use only Type 123A lithium manganese dioxide batteries from manufacturers recommended
by ZOLL. Discard used batteries properly.
Do not recharge, disassemble, or dispose of batteries in fire. Batteries might explode if
mistreated.
This device is protected against interference from radio frequency emissions typical of the
two-way radios and cellular telephones used in emergency service and public safety activities.
You should assess the device’s performance in your typical operating environment to determine
the likelihood of radio frequency interference (RFI) from high-power sources.
Warranty
For warranty information, refer to the AED Plus Administrator’s Guide.
To maintain the warranty, strictly follow the instructions and procedures in this service manual.
Unit failure that is attributable to the use of accessories that are not manufactured by ZOLL
might void the ZOLL warranty.

Technical Service
9650-0308-01 Rev. A ZOLL AED Plus Service Manual vii
Technical Service
If the AED Plus unit requires service, contact the ZOLL Technical Service Department or your
local distributor.
Telephone: [phone] (U.S.A. customers only)
1-978-421-9655
Fax: [phone]
When requesting service, please provide the following information to the service
representative:
•Unit serial number
•Description of the problem
•Department where the equipment is used and the name of the person to contact
•Purchase order to allow tracking of loan equipment
•Purchase order for a unit with an expired warranty
Returning a Unit for Service
Before sending a unit to the ZOLL Technical Service Department for repair, obtain a service
request (SR) number from the service representative.
Remove all batteries from the unit. Pack the unit in its original container or equivalent
packaging. Be sure the assigned service request number appears on the package.
For customers Return the unit to
In the U.S.A. ZOLL Medical Corporation
269 Mill Road
Chelmsford, MA 01824-4105
Attention: Technical Service Dept. [ SR number ]
In Canada ZOLL Medical Canada
Unit #15
5266 General Road
Mississauga, Ontario
L4W 1Z7
Attention: Technical Service Dept. [ SR number ]
Telephone: [phone]
In other locations The nearest authorized ZOLL Medical Corporation representative.
To locate an authorized service center, contact the International Sales
Department at
ZOLL Medical Corporation
269 Mill Road
Chelmsford, MA 01824-4105
Telephone: [phone]

PREFACE
viii www.zoll.com 9650-0308-01 Rev. A

9650-0308-01 Rev. A ZOLL AED Plus Service Manual 1–1
Chapter 1
Maintenance Tests
This chapter describes the procedures for routine testing of the AED Plus unit.
A test typically consists of multiple steps, each of which requires a pass/fail rating. For each
step, perform the specified action and then verify that the expected results occur. If all expected
results occur, assign a “Pass” rating to the step; otherwise, assign it a “Fail” rating.
This chapter includes the following inspection and test procedures:
•“1.0 Physical Inspection” on page 1-3
•“2.0 Preventive Maintenance Test” on page 1-4
•“3.0 Manual Self-Test” on page 1-9

CHAPTER 1MAINTENANCE TESTS
1–2 www.zoll.com 9650-0308-01 Rev. A
Preparations for Testing
•Gather the required equipment listed in the next section.
•Perform all the steps within each test procedure in the order specified.
If testing results indicate that the batteries must be replaced, you will need a set of 10 fully
charged Type 123A batteries.
Test Equipment
For some tests, you need one or more of these items:
•ZOLL universal adapter cable
•Fluke®Impulse 4000 Defibrillator/Pacer Performance Analyzer (Fluke Biomedical/
DNI Nevada) with 1.06 software or higher
The following items are optional:
•ZOLL AED Plus Simulator —
When connected to an AED Plus unit, the simulator can send it various simulated cardiac
rhythms (ventricular fibrillation, normal sinus rhythm, or asystole) and optional simulated
chest compression readings (rate and depth), so that you can test the unit’s response.
•ZOLL Administration Software (ZAS) —
When installed on a personal computer or personal digital assistant that has an IrDA®
(wireless infrared) interface, the ZAS application can communicate with an AED Plus unit
in nonrescue mode to retrieve its usage history, hardware and software configuration, and
error log. You can also use ZAS to view or modify the unit’s configurable settings and to
retrieve event data.
For ZOLL part numbers, refer to the accessories list in the AED Plus Administrator’s Guide.

Physical Inspection
9650-0308-01 Rev. A ZOLL AED Plus Service Manual 1–3
1.0 Physical Inspection
Use this procedure to ensure that the unit shows no signs of damage or excessive wear.
Tools Needed
None.
Test Setup
None.
Test Procedure
Observe the following: Pass Fail
1.1 Is the unit clean? !!
1.2 Are all signs of wear reasonable and not excessive? !!
1.3 Are the top panel and housing undamaged and free of cracks? !!
1.4 Are input connectors clean and undamaged? !!
1.5 If electrodes are preconnected, is the cable free from damage, are the pads
sealed within the packaging, and are the electrodes within the expiration
date shown on the packaging?
!!

CHAPTER 1MAINTENANCE TESTS
1–4 www.zoll.com 9650-0308-01 Rev. A
2.0 Preventive Maintenance Test
Use this test to verify that the AED Plus unit is working properly and ready for use.
For an alternative test using the AED Plus Simulator, refer to the AED Plus Administrator’s
Guide.
Note: To verify that the delivered energy for the first, second, and third shocks corresponds
to the unit’s preconfigured adult energy levels, use the ZOLL Administration Software
(ZAS) to obtain the current configuration of the unit.
Tools Needed
•Fluke Impulse 4000 Defibrillator/Pacer Performance Analyzer or equivalent
•Universal adapter cable
Test Setup
•Turn off the AED Plus unit, remove the cover, and unplug the preconnected electrodes.
Keep the electrodes so they can be reconnected later.
•Connect the universal adapter cable to the AED Plus unit and to the analyzer.
•Turn on the analyzer and set its function to VF (ventricular fibrillation).
Variations in Messages
When verifying messages in the test results, please be aware of the following issues:
•The wording of some messages is configurable. The following table shows equivalent
messages.
•The message that reports the detected electrode type can be either ADULT PADS or
PEDIATRIC PADS.
•Some messages are issued only if the unit is configured to do so. If an optional message is
not issued during a test, do not consider this a failure.
•In some cases a text message on the display screen is abbreviated or otherwise differs
slightly from the associated voice message.
CHECK RESPONSIVENESS CHECK PATIENT
CHECK CIRCULATION CHECK PULSE
IF NO CIRCULATION START CPR IF NO PULSE START CPR
IF NO CIRCULATION CONTINUE CPR IF NO PULSE CONTINUE CPR
TREATMENT ADVISED SHOCK ADVISED
NO TREATMENT ADVISED NO SHOCK ADVISED
PRESS TREATMENT BUTTON PRESS SHOCK BUTTON
RELEASE TREATMENT BUTTON RELEASE SHOCK BUTTON
TREATMENT DELIVERED SHOCK DELIVERED
NO TREATMENT DELIVERED NO SHOCK DELIVERED

Preventive Maintenance Test
9650-0308-01 Rev. A ZOLL AED Plus Service Manual 1–5
Test Procedure
Test Action Expected Result(s) Pass Fail
2.1 Turn on the AED Plus unit. !UNIT OK
!ADULT PADS
!DON’T TOUCH PATIENT,
ANALYZING
!TREATMENT ADVISED
(or SHOCK ADVISED)
!DON’T TOUCH PATIENT.
!PRESS TREATMENT BUTTON
(or PRESS SHOCK BUTTON)
!!
2.2 Press the Treatment button
(first shock).
•Analyzer indicates a defibrillator
discharge at the configured
first-shock energy level (120, 150
or 200 joules ±15%).
!TREATMENT DELIVERED
(or SHOCK DELIVERED)
•An updated shock count appears
on the display (SHOCKS: 1).
!DON’T TOUCH PATIENT,
ANALYZING
!TREATMENT ADVISED
(or SHOCK ADVISED)
!DON’T TOUCH PATIENT.
!PRESS TREATMENT BUTTON
(or PRESS SHOCK BUTTON)
!!

CHAPTER 1MAINTENANCE TESTS
1–6 www.zoll.com 9650-0308-01 Rev. A
2.3 Press the Treatment button
(second shock).
•Analyzer indicates a defibrillator
discharge at the configured
second-shock energy level (120,
150 or 200 joules ±15%).
!TREATMENT DELIVERED
(or SHOCK DELIVERED)
•An updated shock count appears
on the display (SHOCKS: 2).
!DON’T TOUCH PATIENT,
ANALYZING
!TREATMENT ADVISED
(or SHOCK ADVISED)
!DON’T TOUCH PATIENT.
!PRESS TREATMENT BUTTON
(or PRESS SHOCK BUTTON)
!!
2.4 Press the Treatment button
(third shock).
•Analyzer indicates a defibrillator
discharge at the configured
third-shock energy level (120, 150
or 200 joules ±15%).
!TREATMENT DELIVERED
(or SHOCK DELIVERED)
•An updated shock count appears
on the display (SHOCKS: 3).
These three prompts are optional:
—OPEN AIRWAY
—CHECK BREATHING
—GIVE TWO BREATHS
!CHECK CIRCULATION
(or CHECK PULSE)
!IF NO CIRCULATION START CPR
(or IF NO PULSE START CPR)
!!
Test Action Expected Result(s) Pass Fail

Preventive Maintenance Test
9650-0308-01 Rev. A ZOLL AED Plus Service Manual 1–7
Turn off the AED Plus unit.
Set the analyzer to NSR (normal sinus rhythm).
2.5 Turn on the AED Plus unit. !UNIT OK
!ADULT PADS
!DON’T TOUCH PATIENT,
ANALYZING.
!NO TREATMENT ADVISED
(or NO SHOCK ADVISED)
These three prompts are optional:
—OPEN AIRWAY
—CHECK BREATHING
—GIVE TWO BREATHS
!CHECK CIRCULATION
(or CHECK PULSE)
!IF NO CIRCULATION START CPR
(or IF NO PULSE START CPR)
!!
2.6 Lift the puck that is attached to the
universal adapter cable. Move the
puck up and down very slightly
(no more than 1 inch or 2 cm) and
continue to do so.
If the unit has a display, prevent
the bar on the chest compression
gauge from extending into the
area between the lower two lines.
•Unit emits spaced tones as a guide
for performing chest compressions
at the proper rate.
!PUSH HARDER
!!
2.7 Increase the vertical motion of the
puck (about 2 to 3 inches or 5 to
8 cm).
If the unit has a display, make
sure the bar on the chest
compression gauge extends into
the area between the lower two
lines.
•Unit emits spaced tones as a guide
for performing chest compressions
at the proper rate.
!GOOD COMPRESSIONS
The following prompt is optional:
—IF NO CIRCULATION CONTINUE
CPR
(or IF NO PULSE CONTINUE
CPR)
!STOP CPR
!!
Test Action Expected Result(s) Pass Fail

CHAPTER 1MAINTENANCE TESTS
1–8 www.zoll.com 9650-0308-01 Rev. A
Put the puck down and turn off the AED Plus unit.
Disconnect the universal adapter cable from the AED Plus unit.
2.8 Wait 10 seconds and then turn on
the AED Plus unit. !PLUG IN CABLE
This prompt is optional:
—STAY CALM
!CHECK RESPONSIVENESS
(or CHECK PATIENT)
This prompt is optional:
—CALL FOR HELP
These three prompts are optional:
—OPEN AIRWAY
—CHECK BREATHING
—GIVE TWO BREATHS
!CHECK CIRCULATION
(or CHECK PULSE)
!PLUG IN CABLE
!!
2.9 Check the expiration date on the
previously connected defibrillation
electrodes.
If the electrodes have not expired,
reconnect them to the unit;
otherwise, connect a fresh
package of defibrillation
electrodes.
!ADULT PADS
(or PEDIATRIC PADS)
!!
Turn off the AED Plus unit.
2.10 After 90 seconds, check the
Status indicator on the unit.
•The Status indicator shows a green
check.
!!
Test Action Expected Result(s) Pass Fail

Manual Self-Test
9650-0308-01 Rev. A ZOLL AED Plus Service Manual 1–9
3.0 Manual Self-Test
Use this test to initiate the unit’s self-diagnostic procedure, which verifies the following:
•Battery usage since last reset.
•Defibrillation electrodes are properly connected.
•ECG signal acquisition and processing circuitry is functional.
•Defibrillator charge and discharge circuitry (operational at 2 joules) is functional.
•Microprocessor hardware and software are functional.
•CPR monitoring circuitry and compression depth sensor are functional (when CPR-D•padz
are attached).
•Audio output circuitry is functional.
•Display screen (if present) is functional.
Tools Needed
•None.
Test Setup
•Turn off the AED Plus unit.
•If they are not already in place, preconnect defibrillation electrodes to the unit.
Test Procedure
Test Action Expected Result(s) Pass Fail
3.1 Press and hold the ON/OFF
button for at least 5 seconds.
•Within 10 seconds after the unit is
turned on, the Status indicator
displays a green check.
•On the top panel, the indicator
lights for the rescue actions
illuminate in sequence.
!UNIT OK
!!
If an IrDA connection is established, turn off the unit;
otherwise, the unit shuts down automatically.

CHAPTER 1MAINTENANCE TESTS
1–10 www.zoll.com 9650-0308-01 Rev. A
