Zte Blade A33s User manual

Quick Start Guide
Quick Start Guide

1
Quick Start Guide (en)…………………….….……2
Guida rapida all’uso (it) ………...………….……14
Kurzanleitung (de) …………………....…….……26
HızlıBaşlangıç Kılavuzu (tr) .....…….……….….32
Guía de inicio rápido (es) ……….…….…………38
Guia de início rápido (pt) …….…..….….……….44
Priročnik za hitro nastavitev (sl) ……..….………50
Vodičza brzi početak (sr)….….….….…….….……56
Vodičza brzi početak (bs) …….….….….….……62
Rövid üzembehelyezési útmutató (hu) ....…......68
Stručný návod k použití (cs) ….…...….…..……74
Kratke upute (hr) ……….…………………..……80
Ръководство за бърз старт (bg) …….……..…86
Ghid rapid (ro) ………….…….………………..…92
Οδηγός γρήγορης εκκίνησης (el) …..…...…..…98
Instrukcja obsługi (pl) ……..…..…….…....……104
Stručný návod na obsluhu (sk) …..…………….117

2
Getting to Know Your Phone
Front camera
Touch screen
Earpiece
Volume ke
y
Power key
Charging/
micro-USB jack
Headset
j
ack
Back camera
Speaker
Flash
Back cover
Quick Start Guide (en)

3
Setting Up Your Phone
The nano-SIM card(s) can be installed or removed while
the phone is turned on.
Power off your phone before removing or replacing the
battery.
WARNING!
To avoid damage to the phone, do not use any other kind
of SIM cards, or any non-standard nano-SIM card cut
from a SIM card. You can get a standard nano-SIM card
from your service provider.
1. Place your finger into the slot at the lower left of the
back cover, and gently lift and remove the cover.
2. Install the nano-SIM card(s) as shown.

4
NOTE:
If two nano-SIM cards are installed, both cards can
connect to the 4G, 3G, or 2G network, and either card can
be used for mobile data.
3. Install the microSDXC™ card (optional) as shown.
4. Insert the battery, making sure the connectors align.
5. Replace the back cover.
Charging the Phone
Your phone’s battery should have enough power for the
phone to turn on, find a signal, and make a few calls. You
should fully charge the battery as soon as possible.

5
WARNING!
Use only ZTE-approved chargers and USB cables. The
use of unapproved accessories could damage your
phone or cause the battery to explode.
1. Connect the adapter to the charging jack. Ensure that
the adapter is inserted in the correct direction.
2. Connect the charger to a standard AC power outlet.
3. Disconnect the charger when the battery is fully
charged.
NOTE:
If the battery is extremely low, you may be unable to
power on the phone even when it is being charged. In this
case, try again after charging the phone for at least 20
minutes. Contact the customer service if you still cannot
power on the phone after prolonged charging.
Powering On/Off Your Phone
Make sure the battery is charged before powering on.
Press and hold the Power key to turn on your phone.
To power off, press and hold the Power key until the
power off/restart menu appears, and then touch
>.
NOTE:
If the screen freezes or takes too long to respond,
reinstall the battery and power on again.

6
Waking Up Your Phone
Your phone automatically goes into sleep mode when it is
not in use for some time. The display is turned off to save
power and the keys are locked to prevent accidental
operations.
You can wake up your phone by turning on the display
and unlocking the keys.
1. Press the Power key to turn the screen on.
2. Swipe up on the screen.
NOTE:
If you have set a face verification, an unlock pattern, a
PIN or a password for your phone, you’ll need to use your
face, draw the pattern, or enter the PIN/password to
unlock your screen.

7
LEGAL INFORMATION
Copyright © 2023 ZTE CORPORATION.
All rights reserved.
No part of this publication may be quoted, reproduced,
translated or used in any form or by any means,
electronic or mechanical, including photocopying and
microfilm, without the prior written permission of ZTE
Corporation.
Notice
ZTE Corporation reserves the right to make modifications
on print errors or update specifications in this guide
without prior notice.
We offer self-service for our smart terminal device users.
Please visit the ZTE official website (at
https://ztedevices.com) for more information on the full
quick start guide, user manual, self-service and
supported product models. Information on the website
takes precedence.
Disclaimer
ZTE Corporation expressly disclaims any liability for
faults and damages caused by unauthorized
modifications of the software.
Images and screenshots used in this guide may differ
from the actual product. Content in this guide may differ
from the actual product or software.
Trademarks
ZTE and the ZTE logos are trademarks of ZTE
Corporation.
Android™ is a trademark of Google LLC.
The Bluetooth®word mark and logos are registered
trademarks owned by the Bluetooth SIG, Inc. and any use
of such marks by ZTE Corporation is under license.
microSDXC Logo is a trademark of SD-3C,
LLC.
Other trademarks and trade names are those of their
respective owners.

8
Product Safety Information
Don’t make or receive phone calls while driving.
Never text while driving.
Keep your phone at least 5 mm away from your
body while making calls.
Small parts may cause choking.
Your phone can produce a loud sound.
To prevent possible hearing damage, do not
listen at high volume levels for long periods.
Exercise caution when holding your phone near
your ear while the loudspeaker is in use.
Avoid contact with anything magnetic.
Keep away from pacemakers and other
electronic medical devices.
Turn off when asked to in hospitals and medical
facilities.
Turn off when told to on aircraft and at airports.
Turn off when near explosive materials or
liquids.
Don’t use at gas stations.
Your phone may produce a bright or flashing
light.
Don’t dispose of your phone in fire.
Avoid extreme temperatures.
Avoid contact with liquids. Keep your phone
dry.
Do not attempt to disassemble your phone.

9
Only use approved accessories.
For pluggable equipment, the socket-outlet
shall be installed near the equipment and shall
be easily accessible.
Don’t rely on your phone as a primary device
for emergency communications.
Specific Absorption Rate (SAR)
Your mobile device is a radio transmitter and receiver. It
is designed not to exceed the limits for exposure to radio
waves recommended by international guidelines. These
guidelines were developed by the independent scientific
organization ICNIRP and include safety margins
designed to assure the protection of all persons,
regardless of age and health.
The guidelines use a unit of measurement known as
Specific Absorption Rate, or SAR. The SAR limit for
mobile devices is 2 W/kg and the highest SAR value for
this device when tested at the head was 0.24 W/kg*, and
when tested at the body was 1.45 W/kg* with 5 mm
distance. As mobile devices offer a range of functions,
they can be used in other positions, such as on the body
as described in the user manual**.
As SAR is measured utilizing the device’s highest
transmitting power, the actual SAR of this device while
operating is typically below that indicated above. This is
due to automatic changes to the power level of the device
to ensure it only uses the minimum power required to
communicate with the network.
* The tests are carried out in accordance with EN 50360,
EN 50566, EN 50663, EN 62209-1 and EN 62209-2.
** Please see body worn operation in the user manual.

10
Specification
EUT tested
radios application
GSM 900/1800 MHz
WCDMA Band 1/5/8
FDD LTE Band 1/3/5/7/8/20
TDD LTE Band 38
802.11 b/g/n
Bluetooth 4.2
GPS/Galileo/GLONASS
Maximum RF
output power
GSM 900: 34.00 dBm
GSM 1800: 31.00 dBm
WCDMA Band 1: 24.00 dBm
WCDMA Band 5: 24.00 dBm
WCDMA Band 8: 24.00 dBm
FDD LTE Band 1: 24.00 dBm
FDD LTE Band 3: 24.00 dBm
FDD LTE Band 5: 24.00 dBm
FDD LTE Band 7: 24.00 dBm
FDD LTE Band 8: 24.00 dBm
FDD LTE Band 20: 24.00 dBm
TDD LTE Band 38: 24.00 dBm
802.11b/g/n EIRP: 18 dBm
Bluetooth EIRP: 6.5 dBm

11
CE Caution
Battery Caution
There is a risk of explosion if battery is replaced by
an incorrect type.
Dispose of used batteries according to the
instructions.
Do not dispose of a battery into fire or a hot oven, or
mechanically crush or cut a battery. Doing so can
result in an explosion.
Leaving a battery in an extremely high temperature
surrounding environment can result in an explosion
or the leakage of flammable liquid or gas.
A battery subjected to extremely low air pressure
may result in an explosion or the leakage of
flammable liquid or gas.
USB Port
This product shall only be connected to a USB interface
of version USB 2.0.
Proper Use
As described in this guide, your device can be used only
in right location. If possible, please do not touch the
antenna area on your device.
Do not expose your device to extreme temperatures
lower than -10 °C and higher than +40 °C.

12
Disposal of Your Old Appliance
1. When this crossed-out wheeled bin
symbol is attached to a product, it
means the product is covered by the
European Directive 2012/19/EU.
2. All electrical and electronic products
should be disposed of separately from
the municipal waste stream via
designated collection facilities
appointed by the government or the
local authorities.
3. The correct disposal of your old
appliance will help prevent potential
negative consequences for the
environment and human health.
For this product’s recycling information based on WEEE
directive, please send an e-mail to [email protected]

13
EU DECLARATION OF CONFORMITY
Hereby, ZTE Corporation declares that the radio
equipment type ZTE Blade A33s is in compliance with
Directive 2014/53/EU.
The full text of the EU declaration of conformity is
available at the following Internet address:
https://certification.ztedevices.com
ErP Conformity
The external power supply of this product conforms to the
Energy-related Product Directive (ErP) 2009/125/EC of
the European Parliament and the Council.
The detailed ErP information is available on ZTE website
https://certification.ztedevices.com.

14
Presentazione del telefono
Fotocamera
anteriore
Touchscreen
A
uricolare
Tasto del
volume
Tasto di
acce
n
s
i
o
n
e
Ingresso del
caricabatteria/
micro-USB
In
g
resso cuffia
Fotocamera
posteriore
A
ltoparlante
Flash
Scocca
posteriore
Guida rapida all’uso (it)

15
Impostazione del telefono
La scheda nano-SIM può essere installata o rimossa
mentre il telefono è acceso.
Spegnere il telefono prima di rimuovere o sostituire la
batteria.
AVVERTENZA
Per evitare di danneggiare il telefono, non utilizzare altri
tipi di schede SIM né formati di schede nano-SIM che
non siano standard. Rivolgersi al proprio provider di
servizi per richiedere una scheda nano-SIM standard.
1. Inserire il dito nell'apposita fessura in basso a sinistra
della scocca posteriore per sollevarla e rimuoverla.
2. Installare la scheda (o le schede) nano-SIM come
mostrato.

16
NOTA:
Se sono installate due schede nano-SIM, entrambe le
schede possono connettersi alla rete 4G, 3G o 2G ed
entrambe possono essere utilizzate per i dati mobili.
3. Installare la scheda microSDXC™ come mostrato.
4. Inserire la batteria, assicurandosi che i connettori
siano allineati.
5. Riposizionare la scocca posteriore.

17
Ricarica del telefono
La batteria del telefono deve essere sufficientemente
carica per consentire l’accensione del telefono, la ricerca
di un segnale e la possibilità di effettuare un numero
limitato di chiamate. Ricaricare completamente la batteria
prima possibile.
AVVERTENZA!
Utilizzare solo cavi USB e caricabatterie approvati da
ZTE. L'utilizzo di accessori non approvati può
danneggiare il telefono o provocare l'esplosione della
batteria.
1. Collegare l'adattatore alla presa del caricabatteria.
Assicurarsi di aver inserito l’adattatore nella direzione
giusta.
2. Collegare il caricabatteria a una presa di corrente CA
standard.
3. Scollegare il caricabatteria quando la batteria è
completamente carica.
NOTA:
Se la batteria è molto scarica, potrebbe non essere
possibile accendere il telefono anche durante la carica. In
tal caso, provare di nuovo dopo aver ricaricato il telefono
per almeno 20 minuti. Contattare il servizio clienti se non
si riesce ad accendere il telefono anche dopo un periodo
prolungato di ricarica.

18
Accensione/spegnimento del telefono
Prima dell’accensione, accertarsi che la batteria sia
carica.
Per accendere il telefono, tenere premuto il tasto di
accensione.
Per spegnere il telefono, tenere premuto il tasto di
accensione fino a quando non si apre il menu di
spegnimento/riavvio, quindi toccare premere
nuovamente .
NOTA:
Se lo schermo si blocca o richiede troppo tempo per
rispondere, reinstallare la batteria e accendere di nuovo.
Riattivazione del telefono
Il telefono passa automaticamente in modalità
sospensione se non viene utilizzato per un certo periodo
di tempo. Il display viene disattivato per risparmiare
energia e i tasti vengono bloccati per evitare operazioni
accidentali.
Per riattivare il telefono, accendere il display o sbloccare i
tasti.
1. Premere il tasto di accensione per attivare lo
schermo.
2. Far scorrere il dito sullo schermo.
NOTA:
Se è stato impostato il riconoscimento facciale, una
sequenza di sblocco, un codice PIN o una password, è
necessario utilizzare il volto, disegnare la sequenza o
immettere il codice PIN/la password per sbloccare lo
schermo.
