Zte Blade V8 LIite User manual

ZTE BLADE V8
Quick Start Guide
LEGAL INFORMATION
Copyright © 2017 ZTE CORPORATION.
All rights reserved.
No part of this publication may be quoted,
reproduced, translated or used in any form
or by any means, electronic or mechanical,
including photocopying and microlm, without
the prior written permission of ZTE Corporation.
Notice
ZTE Corporation reserves the right to make
modications on print errors or update
specications in this guide without prior notice.
We offer self-service for our smart terminal
device users. Please visit the ZTE ofcial
website (at www.ztedevice.com) for more
information on self-service and supported
product models. Information on the website
takes precedence.
Visit http://www.ztedevice.com to download
the user manual. Just click Support from the
home page and then select your location,
product type, and name to search for related
support information.
Disclaimer
ZTE Corporation expressly disclaims any
liability for faults and damages caused by
unauthorized modications of the software.
Images and screenshots used in this guide
may differ from the actual product. Content in
this guide may differ from the actual product or
software.
Trademarks
ZTE and the ZTE logos are trademarks of ZTE
Corporation.
Google and Android are trademarks of Google,
Inc.
The Bluetooth® trademark and logos are owned
by the Bluetooth SIG, Inc. and any use of
such trademarks by ZTE Corporation is under
license.
microSDXC Logo is a trademark of SD-
3C, LLC.
Qualcomm®Snapdragon™ processors are
products of Qualcomm Technologies, Inc.
Qualcomm and Snapdragon are trademarks
of Qualcomm Incorporated, registered in the
United States and other countries. Used with
permission.
Manufactured under license from Dolby
Laboratories. Dolby, Dolby Audio, and the
double-D symbol are trademarks of Dolby
Laboratories.
Manufactured under license from Dolby
Laboratories. Dolby, Dolby Atmos, and the
double-D symbol are trademarks of Dolby
Laboratories.
Other trademarks and trade names are the
property of their respective owners.
Version No.: R1.0
Edition Time : January 11, 2017
Manual No.: 079584508626
Getting to Know Your Phone Installing the nano-SIM Card and
the microSDXC™ Card (Optional)
The nano-SIM card can be installed or removed
while the phone is turned on.
WARNING!
To avoid damage to the phone, do not use any
other kind of SIM cards, or any non-standard
nano-SIM card cut from a SIM card. You can
get a standard nano-SIM card from your service
provider.
1. Insert the tip of the tray eject tool into the
hole next to the card tray.
2. Pull out the card tray and place the nano-
SIM card and the microSDXC card on the
tray, as shown. Carefully slide the tray back
into place.
nano-SIM
card slot 1
nano-SIM
card slot 2/
microSDXC
card slot
NOTES:
 Slot 1 only supports nano-SIM card. Slot
2 supports nano-SIM card or microSDXC
card.
 The two nano-SIM slots support 4G/3G/2G
networks. When one nano-SIM card is set
to connect with 4G/3G networks, the other
installed nano-SIM card can only connect
with 3G/2G networks.
Charging the Phone
Your phone’s battery should have enough
power for the phone to turn on, nd a signal,
and make a few calls. You should fully charge
the battery as soon as possible.
WARNING!
Do not remove the back cover. The battery
is not removable. Removal may cause re or
explosion.
NOTE:
If the battery is extremely low, you may be
unable to power on the phone even when it
is being charged. In this case, try again after
charging the phone for at least 20 minutes.
Contact the customer service if you still cannot
power on the phone after prolonged charging.
NOTE:
If the screen freezes or takes too long to
respond, try pressing and holding the Power
key for about 10 seconds to restart the phone.
Product Safety Information
Don’t make or receive phone
calls while driving. Never text
while driving.
Keep your phone at least 5
mm away from your body while
making calls.
Small parts may cause choking.
Your phone can produce a loud
sound.
To prevent possible hearing
damage, do not listen at high
volume levels for long periods.
Avoid contact with anything
magnetic.
Light & proximity
sensor
Indicator light
Front ash
Touch screen
Back key Recent apps
key
Home key /
Fingerprint
sensor
Power key
Volume key
Front camera
Earpiece
Dual-lens
camera
Back ash
Charging/
micro-USB jack
Speaker
nano-SIM /
microSDXC
card slot
Dual-lens
camera
Headset jack

Specic Absorption Rate (SAR)
Your mobile device is a radio transmitter and
receiver. It is designed not to exceed the limits
for exposure to radio waves recommended
by international guidelines. These guidelines
were developed by the independent scientic
organization ICNIRP and include safety margins
designed to assure the protection of all persons,
regardless of age and health.
The guidelines use a unit of measurement
known as Specic Absorption Rate, or SAR.
The SAR limit for mobile devices is 2 W/kg and
the highest SAR value for this device when
tested at the head was 0.374 W/kg*, and when
tested at the body was 1.500 W/kg* with 5 mm
distance. As mobile devices offer a range of
functions, they can be used in other positions,
such as on the body as described in the user
manual**.
As SAR is measured utilizing the device’s
highest transmitting power, the actual SAR of
this device while operating is typically below
that indicated above. This is due to automatic
changes to the power level of the device to
ensure it only uses the minimum power required
to communicate with the network.
* The tests are carried out in accordance with
EN 50360, EN 50566, EN 62479, EN 62209-1
and EN 62209-2.
** Please see body worn operation in the user
manual.
Specication
EUT supports
Radios
application
GSM B2/B3/B5/B8
WCDMA Band B1/B5/B8
FDD LTE B1/B3/B5/B7/B8/
B20
802.11b/g/n
Bluetooth V4.1
GPS
WCDMA Version Rel.8
LTE Version Rel.10
Maximum RF
Output Power
GSM900:32.5dBm
GSM1800:29.5dBm
WCDMA Band 1:23.2dBm
WCDMA Band 8:23.1dBm
FDD LTE Band1:23.4dBm
FDD LTE Band3: 23.4dBm
FDD LTE Band7: 22.5dBm
FDD LTE Band8: 23.5dBm
FDD LTE Band20: 23.2dBm
802.11b/g/n: 15.3dBm
Bluetooth EDR:7.2dBm
Bluetooth LE:0.5dBm
GPS(RX Only)
CE Caution
Battery Caution
Risk of explosion if battery is replaced by
an incorrect type. Dispose of used batteries
according to the instructions.
USB Port
This product shall only be connected to a USB
interface of version USB 2.0.
Proper Use
As described in this guide, your device can be
used only in right location. If possible, please
do not touch the antenna area on your device.
Do not expose your device to extreme
temperatures lower than – 10 °C and higher
than + 55 °C.
Hereby, ZTE Corporation declares that this
device is in compliance with the essential
requirements and other relevant provisions of
Directive 2014/53/EU.
Declaration of RoHS Compliance
To minimize the environmental impacts and
take more responsibilities to the earth we
live on, this document shall serve as a formal
declaration that ZTE BLADE V8 manufactured
by ZTE CORPORATION is in compliance with
the Directive 2011/65/EU of the European
Parliament - RoHS (Restriction of Hazardous
Substances) with respect to the following
substances:
1. Lead (Pb)
2. Mercury (Hg)
3. Cadmium (Cd)
4. Hexavalent Chromium (Cr (VI))
5. Polybrominated biphenyls (PBBs)
6. Polybrominated diphenyl ethers (PBDEs)
ZTE BLADE V8 manufactured by ZTE
CORPORATION meets the requirements of
Directive 2011/65/EU.
Disposal of Your Old Appliance
1. When this crossed-out
wheeled bin symbol is
attached to a product,
it means the product is
covered by the European
Directive 2012/19/EU.
2. All electrical and
electronic products
should be disposed
of separately from the
municipal waste stream
via designated collection
facilities appointed by the
government or the local
authorities.
3. The correct disposal of
your old appliance will
help prevent potential
negative consequences
for the environment and
human health.
For this product’s recycling information based
on WEEE directive, please send an e-mail to
[email protected]
Keep away from pacemakers
and other electronic medical
devices.
Turn off when asked to in
hospitals and medical facilities.
Turn off when told to on aircraft
and at airport.
Turn off when near explosive
materials or liquids.
Don’t use at gas stations.
Your phone may produce a
bright or ashing light.
Don’t dispose of your phone in
re.
Avoid extreme temperatures.
Avoid contact with liquids. Keep
your phone dry.
Do not attempt to disassemble
your phone.
Only use approved accessories.
Don’t rely on your phone as a
primary device for emergency
communications.
EU DECLARATION OF
CONFORMITY
Hereby, ZTE Corporation declares that the
radio equipment type ZTE BLADE V8 is in
compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity
is available at the following internet address:
http://certication.ztedevice.com
