ZTE V6000
User Manual

-1-
Using your phone
Thanks for choosing the ZTE V6000. It’s a WCDMA digital mobile
phone, which we’ll simply call ‘phone’ from now on.Under Android
operating system, the mobile phone supports 3G high-speed
Internet access, which brings you brandnew experiences.
And don’t worry if the pictures we use to demonstrate your phone’s
functions look a little different from what you see on its screen. It’s
the functions they show that matter.
This quick start guide is designed to help you familiarise yourself
with the mobile phone’s basic functions. For details, please refer to
the User Manual.

-2-
Starting Up
How to insert the SIM card
Insert the SIM card as follows:
1. Switch off your phone and disconnect any
external power.
2. Remove the back cover and then the battery.
3. Hold your SIM on the cut corner, and slide it
face down into the card holder.
4. Insert the battery.
5. Replace the back cover.
Inserting and removing a memory card
Note: Removing or inserting a memory card when your phone is
turned on could not only damage it and your phone, but also
destroy any data saved on the card.
1. Remove the back cover and insert the
memory card at the side of the phone.
2. Push tightly until the card is installed in the
right position and replace the back cover.
3. Before you take out the card, please open
the back cover and press the card inward
to unlock.

-3-
Battery
The lithium ion battery of the mobile phone can be immediately
used after unpacking. A new battery performs best after perfoming
a full charge/discharge 3 times.
Installing the battery
1. Open the battery cover on the back of your phone.
2. Align the battery's contact points with those of the phone and
gently press the battery down into place.
3. Replace the battery cover clicking it back into position.
Removing the battery
1. Switch off your phone.
2. Open the battery cover.
3. Lift the battery up and out of your phone.

-4-
How to charge the battery
The rechargeable Li-ion battery that comes with
your phone is ready to use, but is not charged.
That’s easy to do. We’ll show you how below.
1. Connect the charger to your phone, and plug
it into an 110V/220V socket.
2. The battery indicator in the corner of the screen will scroll to
show you it’s charging.
3. When fully charged, the battery indicator will stop scrolling.
Disconnect the charger from your mobile, and unplug.
Powering On/Off
Powering On
Press the End/Power key until the power-on icon appears.
Note:You may need to enter the Personal Identification Number
(PIN) or Draw unlock pattern if you have set a PIN or unlock
pattern.
Powering Off
Long press the End/Power key to display the menu Phone options
and select Power off.

-5-
My Phone
End/power ke
y
Back key
Home ke
y
Menu key
OK key
Side key
s
Fn ke
y
SYM key
Delete key
Receiver
Camera
Speaker
USB interface Headset jack
End/power ke
y
Press the key to turn
on/off the display, and
hold the key to turn
on/off the phone.
Side keys
A
djust the
volume

-6-
Idle screen
When you turn on the phone, it enters the idle screen. The
following indicators notify you with the phone status and alerts.
Icons Descriptions Icons Descriptions
Signal strength No signal
Battery is full In charging
Battery is low In call
3G connected GPRS connected
Edge connected You have unread
message.
Speakerphone is on You have unheard voice
mail.
Call forwarding is on You have unread email.
Call on hold Connected to a PC
Vibrate mode Music playing
Ringer is silenced New calendar reminder
Flight mode A clock alarm is active.
Missed call WLAN function on
Bluetooth is on Receiving location data
from GPS

-7-
Text Input
Using the keypad
As the slide is opened, you could use the keypad to input.
Switch input method: Press the key.
Insert a space: Press the key.
Delete: Press the key to delete the input before the
cursor.
Switch caps lock: Press the key.
Line feed: Press the key.
Input letters and common symbols: There are two symbols
on the keys. In abc/Abc/ABC method, press the key to input
the symbol located on the left part of the key; press the
key and then press the key to input the symbol located on the
right part of the key; press the key twice and then press
the key to continuously input the symbol located on the right
part of the key.
In Smart abc/Abc/ABC method, your phone predicts the word
as you enter it, so you need input only the first few letters of
the word.
Input numbers: In 123 method, press the numeric keys to
input the corresponding numbers.
Input symbols: During the text input, press key to display
symbol lists, press the Navigation keys to select the symbol,
and press OK to confirm.

-8-
Using Virtual keyboard
Your phone supports the Android keyboard input method and the
TouchPal keyboard input method. Android keyboard supports
multiple language inputs; TouchPal keyboard supports English
and Spanish.
On the text screen, touch and hold the space where you usually
write your text until the Input method is displayed,and touch it
and select the input options.
Android Keyboard
XT9 Text Input
XT9 Text Input can speed up text input by replacing the key
tapping motion of input with a tracing gesture where you move
your finger from letter to letter without lifting the finger until you
reach the end of the word.
Delete a
character before
Insert a smiley.
Change between lowercase
and uppercase.
Change to symbol/number
mode. Tap again to change
Select input method Insert space

-9-
Basic Operation
Make and answer calls
Make a call
Directly make a call
On the home screen, press the numeric keys to input the
telephone numberand press the button to make a call.
Making a call from Contacts
In the Launcher, press the Contacts icon to display the list of
contacts, select the desired contact and press button to
make a call.
Making a call from Calls
In the Launcher, press Contacts >Calls to select the desired
call log and press button to make a call.
Make an international call
Long press “0” key until “+” appears on the screen, and then
dial the country code or region code, city code and phone
number.
Dial from Messaging
1. In the Launcher, press the Messaging icon to open the
message interface.
2. Select and open one message or conversation.
3. Long press the message text to pop up the Message

-10-
options. If the message contains other numbers, the
Message options will list all numbers. You can select the
number you want to dial.
Receiving a call
Your phone will ring or vibrate (depends on the current mode and
settings) upon an incoming call.
- On the incoming call reminder interface, drag the button to
the right to answer the call.
- If the earphone is inserted, press the key on the earphone to
answer the call.
Reject a call
- Press the End key to reject an incoming call.
- You can also drag the button to the left to reject the call.
End a call
- Press the End key to hang up the call during the conversation.
- You can also press the button to hang up the call.
Adjusting the volume
In a call, you can raise or lower the volume by using the side
keys.
Turn the speaker on or off

-11-
In a call, press the button to turn on the speaker, and
press it again to restore the normal conversation.
Conference call
In a call, press the button to have a conference call.
This function requires the support of network operator.
Open the dialer
In a call, you can press the button to open the dialer for
entering additional numbers.
Contacts
In Contacts you can view or manage your contacts.
In the Launcher, press Contacts icon to open Contacts.
The contacts interface can be divided into the following tab
pages:
- Phone: display the dialing keypad.
- Calls: view all call logs.
- Contacts: view the list of contacts.
- Favorites: display the list of favorites.
All of your contacts are displayed alphabetically in a scrolling list.
You can slide your finger up or down to scroll quickly. A tab
briefly appears to the right of the list, which you can drag up and
down to scroll very quickly.

-12-
Add new contact
1. In Contacts, press the Menu key to select New contact.
2. Input all contact information. Slide up to move to the next field.
Press the button to add more than one entry for that
category.
3. Press the icon to select a picture for the contact.
4. Press Done to save your contact.
Delete a contact
1. In Contacts, touch the contact you want to delete.
2. Press the Menu key and then select Delete contact.
3. Press OK on the pop-up window.
Tip:
You can also long press the contact you want to delete and then select
Delete contact from the pop-up window.
Delete contacts
1. In Contacts, press the Menu key and then select Delete
contacts.
2. Select the contacts you want to delete, and press Delete
contacts > OK.
Edit contact details
1. In Contacts, press and hold the contact whose details you
want to edit.
2. In the menu that opens, press Edit contact.

-13-
3. Edit the contact information.
Search contacts
1. In Contacts, press the Menu key and then select Search.
2. Input the key word of contacts’ names, the phone will
automatically list all matched contacts.
Add to favorites
1. In Contacts, scroll the list to search your desired contact.
2. Long press the contact until the contact’s shortcut menu
appears.
3. Press Add to favorites.
Accounts
You can synchronize contacts information to your phone from
multiple Google Accounts, Microsoft Exchange ActiveSync
accounts or other kinds of accounts, depending on the
applications installed on your phone.
In Contacts, press the Menu key and then select Accounts.
Import/Export contacts
1. In Contacts, press the Menu key >More > Import/Export.
2. You can select Import from SIM card, Export to SIM card, or
Share visible contacts.
Share a contact
You can share a contact with someone.
1. In Contacts, tap the contact you want to share.

-14-
2. Press the Menu key and then press Share.
3. Select share with message or share with application (Bluetooth,
Email, or Gmail).
Messaging
In Messaging, you can send or receive text messages and
multimedia messages.
In the Launcher, press the Messaging icon to open.
Send messages
1. In Messaging, press New message.
2. Input your desired telephone number in To.
You can also press the button to select a phone number
from the Contacts.
3. Input some text in “Type to compose”. You can press the
Menu key to select:
- Add subject: convert to multimedia message and add a subject
for the message.
- Attach: convert to multimedia message and add an attachment
to the message. You could send Pictures, Videos, Audio,
Slideshow, etc.
- Insert phrases: insert the preset message.
- Insert smiley: insert the smiley.
4. After that, press Send to send the message.
Receive messages

-15-
1. In idle mode, you will be reminded by the new messages in the
notification area. Slide down to open the notification panel to
view.
2. Directly input the text to reply the message.
3. Long press the text to pop up the Message options menu to
directly call back, call the number in the text message, delete the
message, etc.
Message thread
The messages from one same contact or number will be aligned
in one message thread in chronological order. You can manage
these threads in the messaging interface.
Press one thread on the Messaging screen, and press the Menu
key to select:
- Call: call the sender’s number.
- Add subject: to add a message subject.
- Attach: to open a menu where you can touch the kind of media
file to attach to the message.
- Insert phrases: insert the preset message.
- Insert smiley: insert the smiley.
- More: you can select to delete thread, delete all threads, etc. If
the sender’s number is not saved in your contacts, you can add
the number to Contacts.
Settings
In Messaging, press the Menu key and then press Settings to
perform relevant settings.

-16-
Storage settings
Delete old messages: delete old messages as limits are
reached.
Text message limit: limit the maximum number of text
messages in each conversation.
Multimedia message limit: limit the maximum number of
multimedia messages in each conversation.
Text message (SMS) settings
Delivery reports: request a delivery report for each text
message you send.
Manage SIM card messages: manage messages stored on
your SIM card.
Modify phrases: modify and look over phrases.
Multimedia message (MMS) settings
Delivery reports: request a delivery report for each multimedia
message you send.
Read reports: request a read report for each multimedia
message you send.
Auto-retrieve: automatically retrieve messages.
Roaming auto-retrieve: automatically retrieve messages while
roaming.
Notification settings

-17-
Notifications: display message notifications in status bar.
Select ringtone: select the notification ringtone upon the receipt
of messages.
Vibrate: select Vibrate on upon the receipt of messages.
Network Applications
Network connection
Your phone can connect to the Internet, so you may need to pay
for some data service. For details, please consult your network
service provider.
Network connection mode
There are two kinds of network connection methods:
GSM/WCDMA or Wi-Fi.
Your phone’s default network is GSM/WCDMA. You can use it
directly without any settings. WLAN mode is disabled by default.
Tip:
On the home screen, use your finger to slide to the first screen,
press the button to enable /disable the data connection.
Wi-Fi
Turn on/off Wi-Fi
1. On the home screen, press the Menu key and then press
Settings > Wireless & networks.
2. Check the box for Wi-Fi to turn on Wi-Fi. Uncheck to turn off
Wi-Fi.

-18-
Connect to Wi-Fi
1. On the home screen, press the Menu key and then press
Settings > Wireless & networks.
2. Check the box for Wi-Fi to turn on Wi-Fi.
3. Press Wi-Fi settings. Your phone will automatically search for
all nearby Wi-Fi networks.
4. Select the network you would like to connect to from the list.
- If you’ve selected an open network, your phone will
automatically connect to it.
- If you’ve selected a security network, you need to input the
password.
Browser
You can use Browser to view webpages and to search for
information on the web.
Open Browser
1. In the Launcher, press the Browser icon to open Browser.
2. Press the URL field at the top to input a web address.
3. Press Go.
You can press the Menu key > Bookmarks to select the
bookmark you want to open, or press Most visited or History to
open other web pages.
Browse web
After opening the web pages, you could use the navigation keys
or slide your finger on the screen to view other parts of the page.

-19-
Zoom in or out
1. Slide your finger slightly on the screen to reveal the Zoom
control .
2. Press the plus or minus side of the Zoom control to zoom in or
out.
Quickly zoom
1. Double-tap on the section of the webpage, the webpage
zooms in.
2. To return to de default zoom level, double-tap again.
Browse options
When you browsing the web pages, press the Menu key to
select:
-New window: open a new window.
-Exit: close all windows.
-Bookmarks: enter the bookmarks interface and add the web
pages to bookmarks.
-Windows: view opened windows.
-Refresh: refresh the currently opening web pages.
-More: you can perform more operations such as Add
bookmark, Find on page, Select text, Page info, Share page,
etc.
Settings
You can set page content, privacy and security preferences to
suit your browse style.
