ZTE Z862VL
User Manual
1
Your phone at a glance
Receiver
Light/proxi ity
sensor
Back
key
Ho e key
Menu
key
SIM card tray
Touch
s
creen
Front
ca era
Volu e
key
Power
key
Headset jack
Noise
-
reduction MIC
Back
ca era
Flash
USB
type
-
C
port
Speaker
Microphone

2
Inserting the SIM card
1. Insert the end of the eject tool into the hole of
the card tray and press fir ly until the tray
pops out.
2. Put the nano-SIM card into the tray.
3. Push the card tray back into the phone.
Note:
Your phone supports a nano-SIM card ONLY.
Di ensions of a nano-SIM card: 9 *12
3
Inserting the e ory card
1. Re ove the back cover..
2. Insert the e ory card into the e ory card
slot.
3. Install the back cover.

4
Charging the battery
Connect the phone to the power outlet using the
included USB cable and power adapter.
5
Power on
Long press the Power key to power on the obile
phone.

6
Health and safety
4FCC Regulations:
This obile phone co plies with part 15 of the FCC
Rules. Operation is subject to the following two
conditions: (1) This device ay not cause har ful
interference, and (2) this device ust accept any
interference received, including interference that
ay cause undesired operation.
This obile phone has been tested and found to
co ply with the li its for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These li its are
designed to provide reasonable protection against
har ful interference in a residential installation. This
equip ent generates, uses and can radiated radio
frequency energy and, if not installed and used in
accordance with the instructions, ay cause har ful
interference to radio co unications. However,
there is no guarantee that interference will not occur
in a particular installation If this equip ent does
cause har ful interference to radio or television
reception, which can be deter ined by turning the
equip ent off and on, the user is encouraged to try
to correct the interference by one or ore of the
following easures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equip ent and
receiver.
-Connect the equip ent into an outlet on a circuit
different fro that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV
technician for help.
7
FCC Note:
Caution: Changes or odifications not expressly
approved by the party responsible for co pliance
could void the user‘s authority to operate the
equip ent.
4RF exposure infor ation (SAR)
This phone is designed and anufactured not to
exceed the e ission li its for exposure to radio
frequency (RF) energy set by the Federal
Co unications Co ission of the United States.
During SAR testing, this device was set to trans it at
its highest certified power level in all tested
frequency bands, and placed in positions that
si ulate RF exposure in usage against the head with
no separation, and near the body with the separation
of 10 . Although the SAR is deter ined at the
highest certified power level, the actual SAR level of
the device while operating can be well below the
axi u value. This is because the phone is
designed to operate at ultiple power levels so as to
use only the power required to reach the
network. In general, the closer you are to a wireless
base station antenna, the lower the power output.
The exposure standard for wireless devices
e ploying a unit of easure ent is known as the
Specific Absorption Rate, or SAR.
The SAR li it set by the FCC is 1.6W/kg.
This device is co plied with SAR for general
population /uncontrolled exposure li its in
ANSI/IEEE C95.1-1992 and had been tested
inaccordance with the easure ent ethods and
procedures specified in IEEE1528. This device has
been tested and eets the FCC RF exposure
guidelines when tested with the device directly
contacted to the body.
The FCC has granted an Equip ent Authorization for
this odel phone with all reported SAR levels

8
evaluated as in co pliance with the FCC RF exposure
guidelines. SAR infor ation on this odel phone is
on file with the FCC and can be found under the
Display Grant section of www.fcc.gov/oet/ea/fccid
after searching on FCC ID: SRQ-Z862VL
For this device, the highest reported SAR value for
usage against the head is 0.63 W/kg, for usage near
the body is 1.34 W/kg.
While there ay be differences between the SAR
levels of various phones and at various positions,
they all eet the govern ent require ents.
SAR co pliance for body-worn operation is based on
a separation distance of 10 between the unit and
the hu an body. Carry this device at least 10
away fro your body to ensure RF exposure level
co pliant or lower to the reported level. To support
body-worn operation, choose the belt clips or
holsters, which do not contain etallic co ponents,
to aintain a separation of 10 between this
device and your body.
RF exposure co pliance with any body-worn
accessory, which contains etal, was not tested and
certified, and use such body-worn accessory should
be avoided.
This device does not support V.O.I.P. function. It
eans that the functions of WLAN and Bluetooth do
not have voice capability in the held to ear ode for
phone service.
WARNING: This product contains a che ical known
to the State of California to cause cancer, birth
defects or other reproductive har .
4CTIA
a) Do not disasse ble or open crush, bend or defor ,
puncture or shred.
b) Do not odify or re anufacture, atte pt to insert
foreign objects into the battery, i erse or expose
to water or other liquids, expose to fire, explosion or
9
other hazard.
c) Only use the battery for the syste for which it is
specified.
d) Only use the battery with a charging syste that
has been qualified with the syste per CTIA
Certification Require ents for Battery Syste
Co pliance to IEEE 1725. Use of an unqualified
battery or charger ay present a risk of fire,
explosion, leakage, or other hazard.
e) Do not short circuit a battery or allow etallic
conductive objects to contact battery ter inals.
f ) Replace the battery only with another battery that
has been qualified with the syste per this standard,
IEEE-Std-1725. Use of an unqualified battery ay
present a risk of fire, explosion, leakage or other
hazard.
g) Pro ptly dispose of used batteries in accordance
with local regulations.
h) Battery usage by children should be supervised.
i ) Avoid dropping the phone or battery. If the phone
or battery is dropped, especially on a hard surface,
and the user suspects da age, take it to a service
center for inspection.
j ) I proper battery use ay result in a fire,
explosion or other hazard.
For those host devices that utilize a USB port as a
charging source, the host device’s user anual shall
include a state ent that the phone shall only be
connected to CTIA certified adapters, products that
bear the USB-IF logo or products that have
co pleted the USB-IF co pliance progra .
