Zte MF286C User manual
MF286C
Let’s go
Getting started with your device.
LEGAL INFORMATION
Copyright © 2019 ZTE CORPORATION.
All rights reserved.
No part of this publication may be excerpted, reproduced, translated or
utilized in any form or by any means, electronic or mechanical, including
photocopying and microlm, without the prior written permission of ZTE
Corporation.
The manual is published by ZTE Corporation. We reserve the right to
make modications on print errors or update specications without prior
notice.
Version No. : R1.0
Installing the (U)SIM card (optional)
Hold the (U)SIM card with the cut corner oriented as shown and slip it
into the card slot until you hear a click.
WARNINGS!
• Before installing the (U)SIM card, power o your device and remove
the external power adapter.
• Your device does not support micro-SIM and nano-SIM card or any
other nonstandard (U)SIM cards. To avoid device damage, please
do not use them or any card holders.
1
5
Getting to Know Your Device
External View
NOTE:
Please use the original external antenna if necessary.
Indicators
Indicator State Description
POWER
Blue on Power is on and external power
supply is working normally.
O Power is o or external power
supply is working abnormally.
Getting Started With Your Device
Connecting Your Device
Follow the number to connect your device.
If you select a dierent operation mode, the connection of the LAN port
will be dierent. Please refer to the chapter “Accessing the Internet”. If
you want to use the mobile network to connect to the Internet, you need
to insert your (U)SIM card rst.
2
6
Indicator State Description
WIFI
Blue on Wi-Fi works normally with no data
transmission.
Blue Blinking Wi-Fi works normally with data
transmission.
O Wi-Fi works abnormally or the Wi-Fi
function is disabled.
3G/4G
Red
The device is turned on but not
registered to the mobile network.
No (U)SIM card is inserted or there
is no network service available.
Blue Blinking
The device is connected to the
4G/LTE network and data is being
transferred.
Blue Solid The device is registered to the 4G/
LTE network.
Green Blinking
The device is connected to the
2G/3G network and data is being
transferred.
Green Solid The device is registered to the
2G/3G network.
Starting Your Device
CAUTION:
Your device must be placed in a well-ventilated environment. Do not
cover the device.
Slide the on/o switch to start your device. After the device is initialized,
make sure the LED indicators are in normal status.
Conguring Your PC
The following procedure describes how to congure the Internet
Protocol in Windows for your Wi-Fi connection.
1. Right-click Network and select Properties.
2. Select
Change adapter settings.
3. Right-click Wireless Network Connection and select Properties.
NOTE:
If you use a network cable to connect your PC to your device, you need
to right-click Local Area Connection and select Properties.
4. Select Internet Protocol Version 4 (TCP/IPv4) and click
Properties.
5. Select Obtain an IP address automatically and Obtain DNS
server address automatically, and click OK.
3
7
Indicator State Description
SIG Blue on Signal level panel. Strength is from
weak to strong.
O There is no signal or no (U)SIM
card is inserted.
Buttons
Button Description
RESET Press and hold for about 3 seconds to restore
factory default congurations.
WLAN Press to turn o/on the Wi-Fi function.
WPS Press to activate the WPS function.
Accessing the Internet
Before accessing the Internet, please make sure that the following
operations are nished.
• Your device is connected to the terminal device via a network cable
or Wi-Fi.
• The terminal device is set to obtain an IP address automatically.
To access the Internet:
1. Launch the Internet browser and enter http://192.168.0.1 in the
address bar. The login page appears.
4
8
ZTE CORPORATION
NO. 55, Hi-tech Road South, Shenzhen, P.R.China
Postcode: 518057
MF286C
Let’s go
Getting started with your device.
LEGAL INFORMATION
Copyright © 2019 ZTE CORPORATION.
All rights reserved.
No part of this publication may be excerpted, reproduced, translated or
utilized in any form or by any means, electronic or mechanical, including
photocopying and microlm, without the prior written permission of ZTE
Corporation.
The manual is published by ZTE Corporation. We reserve the right to
make modications on print errors or update specications without prior
notice.
Version No. : R1.0
Installing the (U)SIM card (optional)
Hold the (U)SIM card with the cut corner oriented as shown and slip it
into the card slot until you hear a click.
WARNINGS!
• Before installing the (U)SIM card, power o your device and remove
the external power adapter.
• Your device does not support micro-SIM and nano-SIM card or any
other nonstandard (U)SIM cards. To avoid device damage, please
do not use them or any card holders.
1
5
Getting to Know Your Device
External View
NOTE:
Please use the original external antenna if necessary.
Indicators
Indicator State Description
POWER
Blue on Power is on and external power
supply is working normally.
O Power is o or external power
supply is working abnormally.
Getting Started With Your Device
Connecting Your Device
Follow the number to connect your device.
If you select a dierent operation mode, the connection of the LAN port
will be dierent. Please refer to the chapter “Accessing the Internet”. If
you want to use the mobile network to connect to the Internet, you need
to insert your (U)SIM card rst.
2
6
Indicator State Description
WIFI
Blue on Wi-Fi works normally with no data
transmission.
Blue Blinking Wi-Fi works normally with data
transmission.
O Wi-Fi works abnormally or the Wi-Fi
function is disabled.
3G/4G
Red
The device is turned on but not
registered to the mobile network.
No (U)SIM card is inserted or there
is no network service available.
Blue Blinking
The device is connected to the
4G/LTE network and data is being
transferred.
Blue Solid The device is registered to the 4G/
LTE network.
Green Blinking
The device is connected to the
2G/3G network and data is being
transferred.
Green Solid The device is registered to the
2G/3G network.
Starting Your Device
CAUTION:
Your device must be placed in a well-ventilated environment. Do not
cover the device.
Slide the on/o switch to start your device. After the device is initialized,
make sure the LED indicators are in normal status.
Conguring Your PC
The following procedure describes how to congure the Internet
Protocol in Windows for your Wi-Fi connection.
1. Right-click Network and select Properties.
2. Select
Change adapter settings.
3. Right-click Wireless Network Connection and select Properties.
NOTE:
If you use a network cable to connect your PC to your device, you need
to right-click Local Area Connection and select Properties.
4. Select Internet Protocol Version 4 (TCP/IPv4) and click
Properties.
5. Select Obtain an IP address automatically and Obtain DNS
server address automatically, and click OK.
3
7
Indicator State Description
SIG Blue on Signal level panel. Strength is from
weak to strong.
O There is no signal or no (U)SIM
card is inserted.
Buttons
Button Description
RESET Press and hold for about 3 seconds to restore
factory default congurations.
WLAN Press to turn o/on the Wi-Fi function.
WPS Press to activate the WPS function.
Accessing the Internet
Before accessing the Internet, please make sure that the following
operations are nished.
• Your device is connected to the terminal device via a network cable
or Wi-Fi.
• The terminal device is set to obtain an IP address automatically.
To access the Internet:
1. Launch the Internet browser and enter http://192.168.0.1 in the
address bar. The login page appears.
4
8
ZTE CORPORATION
NO. 55, Hi-tech Road South, Shenzhen, P.R.China
Postcode: 518057
