2N Analog Vario User manual



Installation manual 2N®
Analog Vario

v.1.6
www.2n.com






Installation manual 2N® Analog Vario
2 / 77
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Content:
1. Product Overview
1.1 Components andAssociated Products
1.2 Terms and Symbols Used
2. Description and Installation
2.1 Before You Start
2.2 Mechanical Installation
2.3 Electrical Installation
2.4 Camera Installation
2.5 Extending Module Connection
2.6 Buttons Labels - Insertion, Replacement
2.7 Mounting - Completion
3. Function and use
3.1 Programming
3.2 Full Parameter Chart
3.3 Function Description
3.4 Section for Advanced Users
3.5 Maintenance
3.6 Downloads
4. Technical Parameters
4.1 Obecné výkresy
5. Supplementary Information
5.1 Troubleshooting
5.2 Directives, Laws and Regulations
5.3 General Instructions and Cautions

Installation manual 2N® Analog Vario
3 / 77
•
•
•
•
•
•
•
•
•
•
•
1. Product Overview
In this section, we introduce the2N®Analog Varioproduct, outline its application options and
highlight the advantages following from its use.
Here is what you can find in this section:
1.1 Components andAssociated Products
1.2 Terms and Symbols Used
The2N®Analog Variodoor communicator replaces a traditional door entry system which would
traditionally have to have a whole cabled distribution infrastructure behind it. The connectivity
of the unit is flexible in that as standard the unit can connect to any telephone system via either
an analogue extension or trunk port. The 2N®Analog Variocan also connect to any network
provider's analogue telephone line.
2N®Analog Variois also easy to use. Just press the desired call button and2N®Analog
Variowill automatically 'dial' the number pre-stored in the respective memory. The number of
buttons is flexible asitis a modular unit.
2N®Analog Varioalso has a switch that controls the electric lock by using any telephones
keypad (by tone-dialling the password).
In addition to the buttons, you can use a numerical keypad, which is used as a code lock. Using
the keypad, you can operate the device as a button telephone and dial the required numbers
directly or retrieve them from any of the 54 memories available. You can disable non-desired
functions.
2N®Analog Varioprovides improved and feature rich options compared with standard door
entry systems, this is because you can make use of functions such as call redirection if not
answered, or have a day and night mode set up for automatic redirection of the call for instance
after normal working hours.
The2N®Analog Varioparameters meet all technical requirements mandatory for devices
designed for the PSTN (public switched telephone network) connection.
Basic Features
Exclusive design – high-grade stainless steel finish.
Water resistant
Exclusive white button backlight – white LEDs
Modularity – up to 54 buttons + keypad
Up to 16 buttons per unit
Each basic unit has a space for camera and card reader build-in modules
Telephone-controlled electronic lock switch
Detection of all standard tones - hangs up automatically
Easy, voice menu based remote programming via telephone.

Installation manual 2N® Analog Vario
4 / 77
•
•
•
•
•
•
•
•
•
•
•
Applicable as a standard telephone and code lock (keypad version)
Advantages of Use
Flat design – installation no need to cut into mounting surface
Hermetically sealed, solid state buttons
Electronics is separated from name plates
Electronic volume and Hands-Free control – no need to open cover
Operates on any analogue telephone line
Stable line power feeding
High acoustic quality
Special functions includes automatic dialling of multiple numbers, silent dialling,
departure/arrival, day/night mode, second switch delay
1.1 Components andAssociated Products
Main and Extender Units
Part No. 9135110E
Main unit
1 button
•
Caution
These products have been removed from sale after June 1, 2023.


Installation manual 2N® Analog Vario
5 / 77
•
•
Part No. 9135130E
Main unit
3 buttons

Installation manual 2N® Analog Vario
6 / 77
•
•
•
•
Part No. 9135160E
Main unit
3 × 2 buttons
Part No. 9135110KE
Main unit
1 button + keypad

Installation manual 2N® Analog Vario
7 / 77
•
•
•
•
Part No. 9135130KE
Main unit
3 buttons + keypad
Part No. 9135160KE
Main unit
3 × 2 buttons + keypad

Installation manual 2N® Analog Vario
8 / 77
•
•
•
•
•
Part No. 9135310E
Info panel
backlit button-less panel
used for the telephone directory, house number, etc.
Part No. 9135181E
Extender unit
8 buttons

Installation manual 2N® Analog Vario
9 / 77
•
•
•
•
•
•
•
Part No. 913582E
Extender unit
8 × 2 buttons
Part No. 9135311E
Info panel – name plate
Replaces four name plates with one cover.
Enables the use of one half of the extender unit for the telephone
directory, opening hours, etc.
Part No. 9135301E
Spare button name plate
Part No. 9135302E
Spare double-button name plate

Installation manual 2N® Analog Vario
10 / 77
•
•
•
•
•
All the above-mentioned units can be wall mounted without requiring any additional
accessories. All the main units can be complemented with a camera, proximity reader (see later)
and display (under preparation). Additional accessories (see later) are needed for outdoor flush
mounting purposes.
Installation Accessories
Part No. 9135331E
Surface 1-module roof
Dimensions: (103 × 218 × 60) mm (W × H × D)
Part No. 9135351E
Wall mounting box with 1-module frame
Dimensions: (125 × 235 × 46) mm (W × H × D)
Wall hole: (110 × 220 × 50) ±5 mm

Installation manual 2N® Analog Vario
11 / 77
•
•
•
Part No. 9135361E
Wall mounting box with 1-module roof
Roof dimensions: (129 × 240 × 41) mm (W × H ×
D)
Wall hole: (110 × 220 × 50) ±5 mm

Installation manual 2N® Analog Vario
12 / 77
•
•
•
•
•
•
•
•
Part No. 9135332E
Surface 2-module roof
Dimensions: (203 × 218 × 60) mm (W × H × D)
Part No. 9135352E
Wall mounting box with 2-module frame
Dimensions: (225 × 235 × 46) mm (W × H × D)
Wall hole: (210 × 220 × 50) ±5 mm
Part No. 9135362E
Wall mounting box with 2-module roof
Roof dimensions: (229 × 240 × 41) mm (W × H ×
D)
Wall hole: (210 × 220 × 50) ±5 mm
The mounting accessories are made of "marine grade" stainless steel. For outdoor applications,
the use of the roof is required unless weather protection is provided otherwise. The box with
frame (without roof) allows for installation of2N®Analog Varioin indoor applications so that
the unit does not practically stick out (up to 1 mm).

Installation manual 2N® Analog Vario
13 / 77
•
•
•
•
•
GSM and VOIP Connection Accessories
Part No.501333E
2N®EasyGate PRO - GSM gateway
Video Accessories
Part No. 9135200E
In-built colour CCD camera
PAL, resolution 420 TV rows, sensitivity 2 lux.
Camera can be built in any basic unit. In the case of poor
light, the camera switches into the monochrome mode
automatically. Supplementary infrared light.
Horizontal/vertical tilting option.
Electric Locks
Part No. 932070E
BEFO 1211 12 V / 600 mA
Part No. 932080E
BEFO 1221 with momentum pin

Installation manual 2N® Analog Vario
14 / 77
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Part No. 932090E
BEFO 1211MB with mechanical blocking
Other Accessories
Part No. 9135250E
Part No. 9135251E
Additional switch (9135250E)
Switching and breaking contact option
time-unlimited switching
up to 48 V / 2 A
Additional switch with exit button feature (9135251E)
NO/NC contacts
time-unlimited switching
up to 48V/ 2A
Exit button time adj.1 - 6 sec
Part No. 932928
12 V Transformer
230 V / 12 V
Part No. 91341481E
12 V / 2 A adapter
A stabilised power supply must be used if a camera is
installed. It can also feed the lock and backlight.

Installation manual 2N® Analog Vario
15 / 77
•
•
•
•
•
•
•
•
•
•
•
•
•
Part No. 9134148E
SIEMENS®adapter
This adapter is required when connecting to a
Siemens HiPath Telephone system
1.2 Terms and Symbols Used
Terminology
Line pick-up/seizure/off-hook– call start, line locked, busy.
Line hang-up/clear– call end, handset hang-up.
DTMF– dual tone multi-frequency signalling.
PSTN– public switched telephone network.
Outgoing call–2N®Analog Vario-telephone connection made, e.g. by a pressing a
button.
Incoming call– telephone-2N®Analog Varioconnection.
Programming mode–2N®Analog Varioprogramming mode accessible from by dialling
into the intercom only.
Code lock– mode for entering the password for switch 1 or 2 activation using a numerical
keypad.
Telephone mode– you can make a call, dial a number and hang up using the numerical
keypad.
DTMF transmission during call– for outgoing calls only, numbers are tone-dialled by a
numerical keypad button.
Button substitution– the numerical keypad can be used instead of a number pre-stored
under a button memory.

Installation manual 2N® Analog Vario
16 / 77
Manual Symbols
The following symbols and pictograms are used in the manual:
•
Safety
Always abide by this information to prevent persons from injury.

•
Warning
Always abide by this information to prevent damage to the device.

•
Caution
Important informationfor system functionality.

•
Tip
Useful informationfor quick and efficient functionality.

•
Note
Routines or advice for efficient use of the device.


Installation manual 2N® Analog Vario
17 / 77
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
2. Description and Installation
This section describes the2N®Analog Varioproduct and its installation.
Here is what you can find in this section:
2.1 Before You Start
2.2 Mechanical Installation
2.3 Electrical Installation
2.4 Camera Installation
2.5 Extending Module Connection
2.6 Buttons Labels - Insertion, Replacement
2.7 Mounting - Completion
2.1 Before You Start
Product Completeness Check
Please check the contents of your delivery:
1×2N®Analog Variounit
1× Quick installation guide
1× User Manual on a CD
1× Hexagonal wrench 2/5
1× Transparent name plate foil of size A5
1× Spare name plate
2× Screws
2× Dowels
2.2 Mechanical Installation
Overview of Installation Types
An overview of the installation types and the list of the required components are provided in the
table below.
•
Note
If you have bought a complete 'packet', the delivery may contain additional items
including instructions for use and lists of available parts.


Installation manual 2N® Analog Vario
18 / 77
Installation type Symbol What you need for installation
Indoor, on surface 2N®Analog Vario only
Indoor, flush mounting 2N®Analog Vario box with 1-module frame
9135351E or box with 2-module frame
9135352E
Outdoor, on surface 2N®Analog Vario Surface 1-module roof
9135331E or Surface 2-module roof
9135332E
Outdoor, flush mounting 2N®Analog Vario Wall mounting box with 1-
module roof 9135361E or Wall mounting box
with 2-module roof 9135362E
Indoor application means Indoor areas with a low relative air humidity
(e.g., hallways, offices and other heated
rooms).
Indoor areas where humidity condenses on
walls but never flows down the walls
(porches, storage areas, industrial areas,
e.g.).
Outdoor areas where protection against
rain and water flowing down the wall is
provided (sheds, passages. e.g.).
Outdoor application
means
Environments where the product is exposed
to rain or where water may flow down the
walls (fence, outer wall of a building, e.g.).
•
Caution
The warranty shall not apply to product failures and defects caused by improper
installation (contrary to these instructions). The manufacturer is neither liable for
damages caused by theft within an area that is accessible after the attached


Installation manual 2N® Analog Vario
19 / 77
1.
Surface Mounting
Drill holes according to the template included in the2N®Analog Variosupply. Insert the
included dowels in the wall holes.
electric lock is switched. The product is not designed as a burglar protection
device except when used in combination with a standard lock, which has the
security function.

Installation manual 2N® Analog Vario
20 / 77
2.
3.
Use the hexagon key wrench included in the supply and remove the2N®Analog
Variometal cover. Remove the screw in the lower part of the metal cover and fold out the
cover.
Use a cross-head screwdriver to remove the plastic cover and demount the cover.
•
Warning
Never remove the main board or camera electronics from under the lower
cover while installing 2N®Analog Vario. Do not disconnect the camera flat
cable from the main board. Do not bend and press upon the flat cable either.

