3One data IES6306 Series User manual

IES6306 Series
Managed Industrial Ethernet Switch
Quick Installation Guide
3onedata Co., Ltd.
Address: 3/B, Zone 1, Baiwangxin High Technology
Industrial Park, Xili, Nanshan District, Shenzhen
Website: www.3onedata.com
Tel: [phone]
Fax: [phone]
【
Package Checklist
】
Please check the integrity of package and accessories while
first using the switch.
1.
Industrial Ethernet switch
2.
Certification
3.
Quick installation guide
4.
Warranty card
5.
DIN-Rail mounting attachment
6
CD
If any of these items are damaged or lost, please contact our
company or dealers, we will solve it ASAP.
【
Product Overview
】
This series product is Gigabit managed DIN-Rail industrial
Ethernet switch. The model is:
Model I. IES6306-4GT2HS-2P48 (4 Gigabit Copper Ports
+ 2 2.5G SFP + 2 12~48 Power Supplies)
Model II. IES6306-4GP2HS-2P48-120W (4 Gigabit PoE
Copper Ports + 2 2.5G SFP + 2 48VDC PoE
Power Supplies)
【
Panel Design
】
Top view, bottom view and rear view
Front View
Model I Model II
1. Power input terminal (P1, P2)
2. Relay alarm output terminal block
3. DIP switch
4. Console port
5. Grounding screw
6. Location hole for wall mounting
7. DIN-Rail mounting kit
8. Power input status indicator P1-P2
9. Relay alarm indicator ALM
10. Device running indicator RUN
11. 2.5G SFP slot (5-6)
12. Copper port (1-4)
13. Ethernet interface status indicator (1-6)
14. Gigabit PoE port (1-4)
15. PoE status indicator (1-4)
【
Mounting Dimension
】
Unit: mm
Notice Before Mounting:
Don't place or install the device in area near water or
moist, keep the relative humidity of the device
surrounding between 5%~95% without condensation.
Before power on, first confirm the supported power
supply specification to avoid over-voltage damaging the
device.
The device surface temperature is high after running;
please don't directly contact to avoid scalding.
【
DIN-Rail Mounting
】
The product adopts 35mm standard DIN-Rail mounting which
is suitable for most industrial scenes, mounting steps as
follows:

Check if the DIN-Rail mounting kit is installed firmly.Step 1
Insert the bottom of DIN-Rail mounting kit (one sideStep 2
with spring support) into DIN-Rail, and then insert
the top into DIN-Rail.
Tips:
Insert a little to the bottom, lift upward and then insert
to the top.
Check and confirm the product is firmly installed onStep 3
DIN-Rail, then mounting ends.
【Disassembling DIN-Rail】
Power off device.Step 1
After lifting the device upward slightly, first shift outStep 2
the top of DIN-Rail mounting kit, and then shift out
the bottom of DIN-Rail, disassembling ends.
Notice before power on:
Power ON operation: First insert the power supply
terminal block into the device power supply interface,
and then plug the power supply plug contact and power
on.
Power OFF operation: First, remove the power plug,
and then remove the wiring section of terminal block.
Please pay attention to the above operation sequence.
【Power Supply Connection】
Model I
This Model I device provides 6-pin 5.08mm pitch input
terminal blocks, including 4 pins power supply terminal blocks
on the left side. It provides two
independent DC power supply
systems of P1 and P2. The power
supply supports non-polarity and
anti-reverse connection, which can
ensure the normal operation of the
device after it’s reversely connected. Voltage range
12~48VDC.
Model I
This Model II device provides 6-pin
5.08mm pitch input terminal blocks,
including 4 pins power supply
terminal blocks on the left side. It
provides two independent DC
power supply systems of P1 and P2.
The power supply supports anti-reverse connection, which
can prevent device from damage after it’s reversely connected,
but it cannot be powered on. Voltage range is as below:
Voltage range without using PoE function: 12~48VDC
Rated voltage: 48VDC
Maximum voltage range: 44VDC-55VDC
【Relay Connection】
This series device provides 6-pin
5.08mm pitch input terminal blocks,
and the relay occupies the right 2
pins. Relay terminals are a set of
normally open contacts of the
device alarm relay. They are open
circuit in the state of normal non
alarm, closed when any alarm information occurs. For
example, they are closed when powered off, and send out
alarm. The switch supports 1 relay alarm information output
that can output DC power supply alarm information or network
abnormality alarm. It can be connected to alarm light or alarm
buzzer or other switching value collecting devices, which can
timely inform operators when the alarm occurs.
【DIP Switch Settings】
Provide 4 pins DIP switch for function settings,
where "ON" is enable valid terminal. The device
needs to be powered on again to change the
status of DIP switch.
DIP switches definition as follows:
DIP
Definition
Operation
1
Restore
Factory
Settings
Set the DIP switch to ON, the device
will root automatically and restore to
factory settings, then turn off the DIP
switch.
2
Reserved
-
3
Reserved
-
4
Reserved
-
【Checking LED Indicator】
The device provides LED indicators to monitor the device
working status with a comprehensive simplified
troubleshooting; the detailed status of each LED is described
in the table as below:
LED
Indicate
Description
P1
ON
P1 is connected and running
normally
OFF
P1 is disconnected and running
abnormally
P2
ON
P2 is connected and running
normally
OFF
P2 is disconnected and running
abnormally
ALM
ON
Power supply link has alarm
OFF
Power supply link have no alarm
RUN
ON The device is powered on or the
device is abnormal.
OFF The device is powered off or the
device is abnormal.
Blinking
Blinking 1 time per second, the
device is running well.
Link/Act
(1-6)
ON
The Ethernet interface has
established a valid network

connection.
Blinking
The Ethernet interface is in a
network activity state.
OFF
The Ethernet port has not
established a valid network
connection
PoE(1-4)
ON
PoE port is powering PD normally
Blinking PoE port is in the detection or fault
state
OFF
PoE port is not connected to PD
【
Specification
】
Panel
2.5G SFP slot 100/1000 Base-X self-adaption
or 100/1000/2.5G Base-X
forced mode, SFP slot
Gigabit copper port 10/100/1000 Base-T(X)
self-adapting RJ45 port, half/full
duplex self-
adaption or forced
working mode, support MDI/
MDI-X self-adaption
Gigabit PoE port 10/100/1000 Base-T(X)
self-adapting RJ45 port, half/full
duplex self-
adaption or forced
working mode, support MDI/
MDI-X self-adaption; the single
port supports up to 30W PoE
output power, PoE power
supply pin: V+, V+, V-, V-
correspond to Pin 1, 2, 3, 6
Console port CL
I command management
port (RS-232), RJ45
Alarm interface 6-
pin 5.08mm pitch terminal
blocks, alarm occupies 2 pins
and 1 relay alarm information
output is supported, the current
load capability is 1A@30VDC or
0.3A@125VAC
Indicator Power supply indicator, run
indicator, interface indicator,
alarm indicator
, PoE interface
indicator
Switch Property
Backplane bandwidth
30G
Packet buffer size
4Mbit
MAC Address Table
8K
Power Supply
Model I 12~48VDC
Support dual power supply
redundancy, non-polarity and
anti-reverse connection
Model II 
Voltage range without
using PoE function:
12~48VDC;
Rated voltage: 48VDC;
Maxim
um voltage range:
44VDC-55VDC;
Support dual power supply
redundancy, anti-reverse
connection
Access terminal block 6-pin 5.08mm pitch terminal
blocks, power supply occupies 4
pins
Power Consumption
Model I No-load: 3.74W@48VDC
Full-load: 9.6W@48VDC
Model II No-load: 4.03W@48VDC
Full-load: <130W@48VDC
Working Environment
Working temperature
-40
～
75
℃
Storage temperature
-40
～
85
℃
Working humidity
5%
～
95% (no condensation)
Protection grade
IP40 (metal shell)
