3One data ICS5000-E24GP4GS User manual

ICS5000-E24GP4GS
Layer 2 Managed Industrial
Ethernet PoE Switch
Quick Installation Guide
3onedata Co., Ltd.
Address: 3/B, Zone 1, Baiwangxin High Technology
Industrial Park, Xili, Nanshan District, Shenzhen
Website: www.3onedata.com
Tel: [phone]
Fax: [phone]
【Package Checklist】
Please check the integrity of package and accessories while
first using the switch.
1. Industrial Ethernet switch
2. Install components
3. Power line
4. Warranty card
5. Certificate
If any of these items are damaged or lost, please contact our
company or dealers, we will solve it ASAP.
【Product Overview】
This product is a 28-port Gigabit layer 3 TSN industrial
Ethernet switch, and its model is: ICS5000-E24GP4GS (24
Gigabit PoE ports + 4 Gigabit SFP slots, 100~240VAC
power input).
【Panel Design】
Front view
Rear View
1. LED indicator
2. Restore default settings RESET
3. 10/100/1000Base-T(X) Gigabit PoE copper port
4. 1000Base-X Gigabit SFP slot
5. CONSOLE port
6. Grounding screw
7. Terminal blocks for 100~240VAC AC power supply
input
【Mounting Dimension】
Unit: mm
Notice Before Mounting:
Don't place or install the device in area near water or
moist, keep the relative humidity of the device
surrounding between 10%~90% without
condensation.
Before power on, first confirm the supported power
supply specification to avoid over-voltage damaging
the device.
The device surface temperature is high after running;
please don't directly contact to avoid scalding.
【Desktop Mounting】
When the switch is installed on a stable desktop. Please
install the attached rubber foot pads on the four corners of
the bottom of the switch, and then place them at the
designated positions on the desktop, leaving enough
ventilation space for the switch to dissipate heat.
【Rack Mounting】
This product adopts rack-mounting, mounting steps as
below:
Step 1 Select the device mounting location to ensure
enough size.
Step 2 Adopt 4 bolts to install the mounting lugs in the
device position as figure below.
Step 3 Place the device in the rack; adopt 4 bolts to fix
two sides mounting lugs in the rack.

Step 4 Check and confirm the product is mounted firmly
on the rack, mounting ends.
【Disassembling Device】
Step 1 Power off the device.
Step 2 Adopt screw driver to loosen the 4 bolts fixed on
the mounting lugs in the rack.
Step 3 Shift out the device from rack, disassembling
ends.
Notice before power on:
Power ON operation: First insert the power supply
terminal block into the device power supply interface,
then plug the power supply plug contact and power
on.
Power OFF operation: First, remove the power plug,
then remove the wiring section of terminal block.
Please pay attention to the above operation sequence.
Please be aware of the power input range supported
by the device before powering on. Use the
recommended voltage of the device to avoid device
damage.
【Console Port Connection】
Provide 1 program debugging port based on
RS-232 serial port which can conduct device
CLI command management after connecting to
PC. The interface adopts RJ45 port, the RJ45 pin definitions
are as follows:
Pin No.
2
3
5
Pin
TXD
RXD
GND
Definition
【Checking LED Indicator】
As shown above, the device provides LED indicators to
monitor the device working status with a comprehensive
simplified troubleshooting; the function of each LED is
described in the table as below:
Indicator
P
anel ID
Status
Definition
Power
indicator
PWR
Indicator off
The switch is not
powered on.
The Green
light keeps on
The switch is powered
on.
System
indicator
SYS
Indicator off
The system is not
started.
Flashing
green
The system is starting
or the
system has
started successfully
Ethernet
port
indicator
(1
-24)
Link/Act
/Speed
Indicator off
Port is not Link
The orange
light keeps on
Port 10/100M link up
Flashing
orange
Port 10/100M data
transmission
The Green
light keeps on
Port 1000M Link U
p
Flashing
green
Port 1000M data
transmission
SFP
interface
indicator
(25
-28)
Link/Act
Indicator off
Port is not Link
The Green
light keeps on
Port 1000M Link Up
Flashing
Port 1000M port data
green
transmission
PoE
status
indicator
(1
-24)
PoE
In
dicator off
PD is not connected to
the corresponding port
or PoE power is not
provided
The yellow
light keeps on
PD is connected to the
corresponding port and
PoE is powered
normally
Flashing
yellow
PoE power has short
circuit or power has
current overload
【Logging in to WEB Interface】
Support WEB management and configuration. Computer
can access the device via Ethernet interface. The way of
logging in to device’s configuration interface via IE browser
is shown as below:
Step 1 Configure the IP addresses of computer and the
device to the same network segment, and the
network between them can be mutually accessed
Step 2 Enter device’s IP address in the address bar of
the computer browser: 192.168.1.254.
Step 3 Enter device’s username and password in the
login window as shown below.
Step 4 Click “Login” button to login to the WEB interface
of the device.
Note:
The default IP address of the device is
“192.168.1.254”.
The default user name and password of the device are

“admin123”.
Please refer to user manual for specific configuration
method of logging in to WEB interface and other
configurations about network management function.
【Specification】
Panel
Gigabit PoE copper
port
10/100/1000Base-T(X)
self-
adaption or forced mode,
RJ45, Automatic Flow Control,
Full/Half Duplex Mode,
MDI/MDI-X Autotunning, power
supply pins 1/2(+) and 3/6(-),
and the maximum output power
consumption of PoE is 370W
Gigabit SFP 100/1000Base-X self-adaption
or forced mode, SFP slot
Console port CLI command management port
(RS-232), RJ45
RESET
Restore Factory Settings Button
Indicator Power supply indicator, system
indicator, interface indicator,
PoE indicator
Switch Property
Backplane bandwidth
56G
Packet buffer size
4.1Mbit
MAC Address Table
8K
Power Supply
Access terminal block AC 100-240V/50-60Hz 400W
built-in switch power supply
Power Consumption
Full-load
Max: 430W(220V/50Hz)
Working Environment
Working temperature
0
～
45℃
Storage temperature
-40
～
70
℃
Working humidity
10%
～
90% (no condensation)
Protection grade
IP30(metal shell)
