3One data IES3016L Series User manual

IES3016L Series
Unmanaged Industrial
Ethernet Switch
Shenzhen 3onedata Technology Co.,Ltd.
Address: 2F, 3B, Jiuxiangliang Industrial District, Xili
Town, Nanshan District, Shenzhen, 518055, China
Website: www.3onedata.com
Phone: [phone]
Fax: [phone]
【Brief Introduction】
IES3016L series is unmanaged industrial Ethernet switch
which includes IES3016L-P (12/48VDC) and IES3016L-4F-P
(12/48VDC). All the ports support auto-negotiation, 10/100Mbps,
and F/H duplex, etc. All components chosen for the switch are
industrial level to ensure high performance.IES3016L series
switch provides widen voltage to the device.
【Packing List】
Please check the package and all the components inside are
in good condition before you use the switch.
3onedata Ethernet switch*1
User manual
CD
Warranty card
【Features】
Support 16 ports (16-FE);
Support MAC address auto-learning;
8K MAC address
System switching bandwidth 3.2 Gbps
Support 1 alarm output;
0-60℃working temperature;
No fan, low consumption design
IP40 protection
【Panel Layout】
IES3016L-P (12/48VDC):
1. Grounding screw
2. Relay output (2 bits)
3. Power input
4. Console port (RS-232 serial
Port, RJ45)
5. Reset
6. DIN-Rail kit
7 company logo and product name
8. Port indicator
9. System indicator
10. Alarm indicator
11. Power indicator
12. 10Base-T /100Base-TX port
IES3016L-4F-P (12/48VDC):

1. Grounding screw
2. Relay output (2 bits)
3. Power input
4. Console port (RS-232 serial
Port, RJ45)
5. Reset
6. DIN-Rail kit
7. Company logo and product name
8. Port indicator
9. System indicator
10. Alarm indicator
11. Power indicator
12. 100Base-FX port
13. 10Base-T /100Base-TX port
【Dimension】
Unit (mm)
【Power Input】
Top view Front view
IES3016L series switch provides 4 bits terminal blocks
(V1-, V1+, V2-, and V2+).
Notice: 1. power on: please connect the power line to the
switch before you plug in the power plug.
2. Power off: please unplug the switch then
remove the power line from the terminal.
【Console Port】
IES3016L series switch provides 1 console port (based on
serial port).the console port is RJ45 connector in top panel. It is
used to connect the PC for program updating by using a
connecting cable along with the switch.
【Relay Contact】
The input terminal block of relay is in top panel of the switch.
It is the contact of alarm relay. It will be open circuit when alarm
happens, or it will be always closed circuit. IES3016L series
switch supports 1 alarm output to connect alarm indicator or
alarm buzzer to remind of operator in time in case of something
happened.
【Communication Port】
10/100BaseT(X) Ethernet port
10/100BaseT(X) Ethernet port is in front panel of the device.
The connector type is RJ45 and its pin definition is shown
below. The pinout of RJ45 port display as below, connect by
UTP or STP. The connect distance is no more than 100m.
100Mbps is used 100Ωof UTP 5 , 10Mbps is used 100Ωof UTP
3,4,5.
RJ 45 port supports automatic MDI/MDI-X operation. It
can connect the PC, Server, Converter and HUB. Corresponding
connection of Pin 1,2,3,6 in MDI: 1→1, 2→2, 3→3, 6→6;
corresponding connection of pin 1,2,3,6 in MDI-X: 1→3, 2→6,
3→1, 6→2. the definition of Pin in the table as below.
PIN MDI MDI-X
1TX+RX+
2TX-RX-
3RX+TX+
6RX-TX-
4, 5, 7, 8 — —
Note：“TX±”transmit data ±，“RX±”receive data ±，“—” no use。
MDI (straight-through cable)
18

MDI-X (crossover cable)
100Base-FX Fiber Port
100Base-FX fiber port needs to be used in pairs. TX is
transmission side to connect to receiving side RX in remote
switch;
Suppose: If you make your own cable, we suggest labeling
the two sides of the same line with the same letter (A-to-A and
B-to-B, shown as below, or A1-to-A2 and B1-to-B2).
【LED Indicator】
LED indictor is in the front panel of IES3016L. The function
of each LED is described in the table as below.
System indication LED
LED state Description
PWR1
ON Power 1 is working.
OFF PWR1 is not connected or does
not run normally.
PWR2
ON Power 2 is working.
OFF PWR2 is not connected or run
normally.
Alarm
ON Power or port link is broken or
failure.
OFF power and port link is working
well
SYS
ON/OF
FDevice does not run normally
Blink Device runs well.
Link1~16
ON Network connection of the port
is valid
Blink Data is being transmitted
OFF Network connection of the port
is invalid
【Installation】
Before installation, please confirm that the work
environment meet the installation requirement, including the
power needs and abundant space, whether it is close to the
connection equipment and other equipments are prepared or not.
Examine the cables and plugs that installation requirements.
Examine whether the cables be suitable or not (less than 100m)
according to reasonable scheme.
Screw, nut, tool provided by yourself.
Power need: Redundant, dual 24VDC power
inputs(12~48DC）
Environment: -40°C to 75°C
Relative humidity 5% to 95%
Wiring Requirements
Wiring need to meet the following requirements:
It is needed to check whether the type, quantity and
specification of cable match the requirement before
cable laying;
It is needed to check the cable is damaged or not, factory
records and quality assurance booklet before cable
laying;
The required cable specification, quantity, direction and
laying position need to match construction requirements,
and cable length depends on actual position;
All the cable cannot have break-down and terminal in
the middle;
Cables should be straight in the hallways and turning;
Cable should be straight in the groove, and cannot
beyond the groove in case of holding back the inlet and
outlet holes. Cables should be banded and fixed when
they are out of the groove;
User cable should be separated from the power lines.
Cables, power lines and grounding lines cannot be
overlapped and mixed when they are in the same groove
road. When cable is too long, it cannot hold down other
cable, but structure in the middle of alignment rack;
Pigtail cannot be tied and swerved as less as possible.
Swerving radius cannot be too small (small swerving
causes terrible loss of link). Its banding should be
moderate, not too tight, and should be separated from
other cables;
It should have corresponding simple signal at both sides
of the cable for maintaining.

【Specification】
Technology
Standard: IEEE802.3, IEEE802.3u, IEEE802.3x
Transmit mode: store and forward
Flow control: IEEE802.3x, back-pressure control
MAC address: 8K
System switching bandwidth: 3.2G
Cache: 256K
Interface
RJ45 port: 10Base-T/100Base-TX, auto-flow control, F/H
duplex and support MDI/MDI-X connection
Fiber port: 100Base-FX, SC/ST optional, support single mode
(20/40/60/80Km optional), multimode (2/5Km
optional) fiber, wavelength is 1310nm
Console port: Serial port
Alarm: 1 alarm information input;
Overload current: 1A@24VDC
Indicator
Run: SYS
Link: Link1~16
Power: PWR
Alarm: Alarm
Power
Input Voltage: 12～48VDC
Input type: 2 bits terminal blocks
Overload current protection: 4.0A (DC))
Support reverse polarity protection
¾IES3016L (DC):
No-load power: 2.0W@24VDC
Full-load power: 4.6W@24VDC
¾IES3016L-4F (DC):
No-load power: 4.8W@24VDC
Full-load power: 7.0W@24VDC
Mechanical:
Shell: IP40
Weight: 1.1kg
Installation: DIN-rail
Dimension (L*W*H): 160mm*130mm*70mm
Environmental
Working temperature: 0～60℃
Storage temperature: -40～85℃
Ambient Relative Humidity: 5%～95%(no condensing)
Approvals
EMI：FCC Part 15，CISPR (EN55022) class A
EMS：EN61000-4-2 (ESD)，Level 4
EN61000-4-3 (RS)，Level 3
EN61000-4-4 (EFT)，Level 4
EN61000-4-5 (Surge)，Level 4
EN61000-4-6 (CS)，Level 3
EN61000-4-8，Level 5
Shock: IEC 60068-2-27
Free fall: IEC 60068-2-32
Vibration: IEC 60068-2-6
Warranty: 5years
Certification
CE、FCC、RoHS
