Aaeon ECB-901A User manual

Carrier Board ECB-901A
Quick Installation Guide -1-
Quick
Installation
Guide
Part No. 2007901A12 Printed in Taiwan June.2005

Carrier Board ECB-901A
Quick Installation Guide -2-
Safety Precautions
Always completely disconnect the power cord from
your board whenever you are working on it. Do not
make connections while the power is on, because a
sudden rush of power can damage sensitive
electronic components.
Always ground yourself to remove any static charge
before touching the board. Modern electronic
devices are very sensitive to static electric charges.
Use a grounding wrist strap at all times. Place all
electronic components on a static-dissipative
surface or in a static-shielded bag when they are not
in the chassis

Carrier Board ECB-901A
Quick Installation Guide -3-
1. Location of Connectors and Jumpers
Component Side
CN12 CN26 CN14 CN18
JP14
PCI1
PCI2 PCI3 PCI4
CN3 CN2
CN1
CN9
CN24 JP12
JP13
JP11
CN13 ETX3
JP10
JP9
CN23
JP4
CN11
JP15
JP18
JP17
JP16
CN22
JP8
JP23
JP7
JP3
JP6
CN20
CN21
IDE1
IDE2
CN7 CN8 JP2
CN6 CN4 CN28 CN10
JP1
ETX4 ETX2
ETX1
CN27
JP19
JP5
JP22
JP21
JP20
CN5
JP24

Carrier Board ECB-901A
Quick Installation Guide -4-
2. Mechanical Drawing
0
0
13.29
36.81 53.31
93.45 99.14
122.25 134.75 147.25
7.41
19.53
9.99 8.07
3.23
10.17
163.88 168.36
40.02
41.29
38.11
59.84
88.28
92.72
96.53
120.66
146.49
148.5
150.51
169.56
173.37
177.81
172.1
182.26
204.48
168.21
192.42
203.21 203.85
210.01
304.88
180.35
25.41
41.21
73.67
33.67
8.97
40.09 64.85
16.6
169.63
180
200.32
220.64 240.96
255.17 275.49
295.81
7.07
12.78
17.86
7.07
12.78 15.32
27.39
49.61
184.8
90.25
145.18 162.64 163.28
201.38
184.23
215.35 250.91
Component Side-1

Carrier Board ECB-901A
Quick Installation Guide -5-
288.37
10.17
288.37
165.11
67.39
144.23
163.21
109.3
151.85
87.64
154.95
146.49
97.17
88.91
42.56
38.11
163.88
165.11
163.88
145.18
146.08
55.92
101.72 94.32
135.92
50.92
140.92
46.44
14.05
99.71
171.46
160.03
148.5
150.51
6.4
165.11
36.28
33.03
25.48 37.18
6.4
Component Side-2

Carrier Board ECB-901A
Quick Installation Guide -6-
3. List of Jumpers
The board has a number of jumpers that allow you to configure your system to
suit your application.
The table below shows the function of each of the board's jumpers:
Jumpers
Label Function
JP1
DOC Ad
dress selection
JP2 Compact flash master-slave selection
JP3 ATA cable detection or SPDIAG#
JP5
CMOS Clear
JP6
AT and ATX type power supply selection
JP7 WDT Reset, IOCHCK# selection
JP8 External-internal speaker selection
JP9 LCD Power Selection
JP10 Backlight Power selection
JP11 COM2 RS-232/422/485 Select
JP12 COM2 RS-232/422/485 Select
JP13 COM2 Ring/+5V/+12V Select
JP16 ETX-4 Pin D90 Selection
JP17 ETX-4 Pin D19 Selection
JP18 ETX-4 Pin D35 Selection
JP19 ETX-1 Pin A21 Selection
JP20 ETX-4 Pin D9 Selection
JP21 ETX-4 Pin D26 Selection
JP22 ETX-4 Pin D41 Selection
JP23
Fan Power Select
ion

Carrier Board ECB-901A
Quick Installation Guide -7-
JP24 5VSB For ETX Module
4. List of Connectors
The board has a number of connectors that allow you to configure your system
to suit your application. The table below shows the function of each board's
connectors:
Connectors
Label Function
CN1 ISA connector
CN2 ISA Connector
CN3 ISA Connector
CN4 (LPT2) PRINTER PORT Connector
CN5 (COM3) RS-232 Serial Port Connector
CN6 (COM4) RS-232 Serial Port Connector
CN7 Compact Flash connector
CN8 FLOPPY DRIVER Connector
CN9 SIR Connector
CN10 DIGITAL IO Connector
CN11 TV-OUT Connector
CN12 PS2 KB+MS Connector
CN13 LVDS connector
CN14
(COM1+LPT1+VGA）
RS232+Printer+VGA Connector
CN17 Audio LINE-IN Connector

Carrier Board ECB-901A
Quick Installation Guide -8-
CN18 Audio LINE-OUT connector
CN19 Audio Microphone-IN Connector
CN20 ATX Power Connector
CN21 AT Power Connector
CN22 FAN Connector
CN23 Backlight Power connector
CN24（COM2）RS-232 Serial Port Connector
CN26 USB+RJ45 Connector
CN27 USB 3/4 Connector
IDE1 Primary IDE connector
IDE2 Secondary IDE connector
PCI1 PCI Connector
PCI2 PCI Connector
PCI3 PCI Connector
JP4 Front Panel
JP14 LAN Wake Up

Carrier Board ECB-901A
Quick Installation Guide -9-
5. Setting Jumpers
You configure your card to match the needs of your application by setting
jumpers. A jumper is the simplest kind of electric switch. It consists of two metal
pins and a small metal clip (often protected by a plastic cover) that slides over the
pins to connect them. To “close” a jumper you connect the pins with the clip.
To “open” a jumper you remove the clip. Sometimes a jumper will have three
pins, labeled 1, 2 and 3. In this case you would connect either pins 1 and 2 or 2
and 3.
12
3
Open Closed Closed 2-3
A pair of needle-nose pliers may be helpful when working with jumpers.
If you have any doubts about the best hardware configuration for your
application, contact your local distributor or sales representative before you make
any change.
Generally, you simply need a standard cable to make most connections.

Carrier Board ECB-901A
Quick Installation Guide -10 -
6. DOC Address Selection (JP1)
The DiskOnChip 2000 occupies an 8 K byte window in the upper
memory address range of CC00 to DC00. You should ensure this
does not conflict with any other device's memory address.
These addresses might conflict with the ROM BIOS on some of the
other peripheral boards. Please select appropriate memory address
to avoid memory conflict.
7. CompactFlash™Master-Slave Selection (JP2)
JP2 Function
1-2ON Master
1-2OFF Slave (Default)
Address
Address
cc00
D000
D400
D800
DC00

Carrier Board ECB-901A
Quick Installation Guide -11 -
8. IDE2 ATA Cable Detection or PDIAG# Selection (JP3)
JP3 Function
1-2ATA Cable Detection (Default)
2-3PDIAG#
Remark: When IDE2 and CN7 have devices installed, select 2-3 for proper
operation.
9. Clear CMOS Selection (JP5)
JP5 Function
1-2Protect (Default)
2-3Clear CMOS
10. AT and ATX type power supply selection (JP6)
JP6 Function
1-2AT
2-3ATX (Default)
11. WDT Reset IOCHCK# Selection (JP7)
JP7 Function
1-2IOCHCK#
2-3WDT Reset (Default)
12. External-Internal Speaker Selection (JP8)
JP8 Function
1-4External Speaker
3-4Internal Speaker (Default)

Carrier Board ECB-901A
Quick Installation Guide -12 -
13. LCD Power Selection (JP9)
JP9 Function
1-25V
2-33.3V (Default)
14. LCD Backlight Power Selection (JP10)
JP10 Function
1-212V (Default)
2-3+5V
15. COM 2 RS-232/422/485 Selection (JP11 & JP12)
JP11 JP12 Function
1-2, 4-5, 7-8, 10-11 1-2RS-232 (Default)
2-3, 5-6, 8-9, 11-12 3-4RS-422
2-3, 5-6, 8-9, 11-12 5-6RS-485
16. COM 2 Ring/+5V/+12V Selection (JP13)
JP13 Function
1-2+12V
3-4+5V
5-6Ring (Default)

Carrier Board ECB-901A
Quick Installation Guide -13 -
17. ETX-4 Pin D90 Selection (JP16)
JP16 Function
1-2LAN Wakeup (LWAKE)
2-3Primary IDE ATA33/100 Detect (PD_80P) (Default)
18. ETX-4 Pin D19 Selection (JP17)
JP17 Function
1-2OVCR# (USB) (Default)
2-3DACK2#
19. ETX-4 Pin D35 Selection (JP18)
JP18 Function
1-2Primary IDE ATA33/100 Detect
2-3Secondary IDE ATA33/100 Detect (SD_80P) (Default)
20. ETX-1 Pin A21 Selection (JP19)
JP19 Function
1-2 ON DRQ2
1-2 OFF N.C. (Default)
21. ETX-4 Pin D9 Selection (JP20)
JP20 Function
1-2 ON CPU FAN (Default)
1-2 OFF N.C.

Carrier Board ECB-901A
Quick Installation Guide -14 -
22. ETX-4 Pin D26 Selection (JP21)
JP21 Function
1-2 ON CPU FAN
1-2 OFF N.C. (Default)
23. ETX-4 Pin D41 Selection (JP22)
JP22 Function
1-2 ON Secondary IDE ATA33/100 Detect
1-2 OFF N.C. (Default)
24. Front Panel Connector (JP4)
JP4 Function
1-2 Power Button
3HDD LED -4HDD LED +
5Speaker -6Speaker +
7Power LED -8Power LED +
9-10 Reset Button
25. LAN Wake up Connector (JP14)
Pin Signal
1+5VSB
2LWAKE
3GND

Carrier Board ECB-901A
Quick Installation Guide -15 -
26. Fan Power Selection (JP23)
JP23 Function
1-2 5V
2-312V
OFF 5V
27. 5VSB For ETX Module (JP24)
JP24 Function
ON Standby 5V(5VSB) for ETX Module
OFF
No Standby 5V(5VSB) for
ETX
M
odule
28. RS-232 Serial Port Connector (CN5, CN6 & CN24)
Pin
Signal Pin
Signal
1
DCD
2
RXD
3TXD 4DTR
5GND 6DSR
7RTS 8CTS
9RI 10 N.C.
29. CompactFlash™Disk Connector (CN7)
Pin
Signal Pin
Signal
1
GND
26
GND
2SDD3 27 SDD11
3SDD4 28 SDD12
4SDD5 29 SDD13

Carrier Board ECB-901A
Quick Installation Guide -16 -
5SDD6 30 SDD14
6SDD7 31 SDD15
7SDCS#1 32 SDCS#3
8GND 33 GND
9GND 34 SDIOR#
10 GND 35 SDIOW#
11 GND 36 +5V
12 GND 37 IRQ15
13 +5V 38 +5V
14 GND 39 CSEL#
15 GND 40 N.C.
16 GND 41 SEC_IDERST#
17 GND 42 SIORDY
18 SDA2 43 N.C.
19 SDA1 44 +5V
20 SDA0 45 DASP#
21 SDD0 46 PDIAG#
22 SDD1 47 SDD8
23 SDD2 48 SDD9
24 N.C. 49 SDD10
25 GND 50 GND
30. Floppy Drive Connector (CN8)
Pin
Signal Pin
Signal
1
GND
2
#DENSITYSEL
3GND 4N.C.
5GND 6#DS1

Carrier Board ECB-901A
Quick Installation Guide -17 -
7GND 8#INDEX
9GND 10 #MOTORA
11 GND 12 #DRIVE SELECT B
13 GND 14 #DRIVE SELECT A
15 GND 16 #MOTOR B
17 GND 18 #DIR
19 GND 20 #STEP
21 GND 22 #WRITE DATA
23 GND 24 #WRITE GATE
25 GND 26 #TRACK0
27 GND 28 #WRITE PROTECT
29 GND 30 #READ DATA
31 GND 32 #HEADSEL
33 GND 34 #DISK CHANGE
31. IR Connector (CN9)
Pin Signal
1+5V
2N.C.
3IRRX
4GND
5IRTX
6N.C.

Carrier Board ECB-901A
Quick Installation Guide -18 -
32. Digital IO Connector (CN10)
Pin
Signal Pin
Signal
1
OUT0
2
OUT1
3OUT2 4OUT3
5OUT4 6OUT5
7OUT6 8OUT7
9GND 10 GND
11 IN0 12 IN1
13 IN2 14 IN3
15 IN4 16 IN5
17 IN6 18 IN7
19 +5V 20 +12V
33. TV Out Connector (CN11)
Pin
Signal Pin
Signal
1
Y
2
CVBS
3GND 4GND
5C6NC
7GND 8CSYNC
34. Keyboard & Mouse Connector (CN12)
Pin
Signal Pin
Signal
1KB_DATA 7MS_DATA
2MS_DATA 8N.C.
3GND 9GND

Carrier Board ECB-901A
Quick Installation Guide -19 -
4+5VSB 10 +5VSB
5KB_CLK 11 MS_CLK
6MS_CLK 12 N.C.
35. AAEON LVDS Connector (CN13)
Pin
Signal Pin
Signal
1Backlight Enable 2Backlight Control
3PPVCC 4GND
5#LCLK 6LCLK
7PPVCC 8GND
9#LDATA0 10 LDATA0
11 #LDATA1 12 LDATA1
13 #LDATA2 14 LDATA2
15 #LDATA3 16 LDATA3
17 SMBDATA 18 SMBCLK
19 #UDATA0 20 UDATA0
21 #UDATA1 22 UDATA1
23 #UDATA2 24 UDATA2
25 #UDATA3 26 UDATA3
27 PPVCC 28 GND
29 #UCLK 30 UCLK

Carrier Board ECB-901A
Quick Installation Guide -20 -
36. VGA Display + Printer + COM Connector (CN14)
Pin
Signal Pin
Signal
A1#STROBE A14
#AFD
A2 Printer DATA0 A15
#ERROR
A3 Printer DATA1 A16
#INIT
A4 Printer DATA2 A17
#SLIN
A5 Printer DATA3 A18
GND
A6 Printer DATA4 A19
GND
A7 Printer DATA5 A20
GND
A8 Printer DATA6 A21
GND
A9 Printer DATA7 A22
GND
A10
#ACK A23
GND
A11
BUSY A24
GND
A12
PE A25
GND
A13
SELECT
B1DCD B2RXD
B3TXD B4DTR
B5GND B6DSR
B7RTS B8CTS
B9RI
C1RED C2GREEN
C3BLUE C4NC
C5GND C6GND
C7GND C8GND
