Aaeon ETX-700 User manual

ETX CPU Module ETX-700 Rev.B
ETX-700 Rev.B
AMD Geode
LX Processors
ETX CPU Module
With LCD, Ethernet,
Audio,PCI
ETX-700 Manual Rev. B 2nd Ed.
Sept. 2010

ETX CPU Module ETX-700 Rev.B
i
Copyright Notice
This document is copyrighted, 2010. All rights are reserved. The
original manufacturer reserves the right to make improvements
to the products described in this manual at any time without
notice.
No part of this manual may be reproduced, copied, translated,
or transmitted in any form or by any means without the prior
written permission of the original manufacturer. Information
provided in this manual is intended to be accurate and reliable.
However, the original manufacturer assumes no responsibility
for its use, or for any infringements upon the rights of third
parties that may result from its use.
The material in this document is for product information only
and is subject to change without notice. While reasonable
efforts have been made in the preparation of this document to
assure its accuracy, AAEON assumes no liabilities resulting
from errors or omissions in this document, or from the use of the
information contained herein.
AAEON reserves the right to make changes in the product
design without notice to its users.

ETX CPU Module ETX-700 Rev.B
ii
Acknowledgments
All other products’ name or trademarks are properties of their
respective owners.
zAward is a trademark of Award Software International, Inc.
zCompactFlash™ is a trademark of the Compact Flash
Association.
zAMD, the AMD Arrow logo and combinations thereof are
trademarks of Advanced Micro Devices, Inc.
zMicrosoft Windows®is a registered trademark of Microsoft Corp.
zITE is a trademark of Integrated Technology Express, Inc.
zIBM, PC/AT, PS/2, and VGA are trademarks of International
Business Machines Corporation.
Please be notified that all other products’ name or trademarks not be
mentioned above are properties of their respective owners.

ETX CPU Module ETX-700 Rev.B
iii
Packing List
Before you begin installing your card, please make sure that the
following materials have been shipped:
•1 ETX-700 Rev.B CPU Module
•1 CD-ROM for manual (in PDF format) and drivers
If any of these items should be missing or damaged, please
contact your distributor or sales representative immediately.

ETX CPU Module ETX-700 Rev.B
iv
Application Notes
1. ISA IRQ resource:
If you use the ISA card, you have to disable the COM3 and COM4 in
the BIOS due to the IRQ resource limitation. It will release the IRQ to
the ISA card.
2. VGA through PCI graphic add-on card:
If you use a PCI graphic add-on card, you have to use the onboard
VGA first. Then, adjust the PCI graphic add-on card to be the
primary in the OS. After re-booting, you can use the VGA through
PCI graphic add-on card normally.
For more details, please contact with AAEON AE Department for help.

ETX CPU Module ETX-700 Rev.B
v
Contents
Chapter 1 General Information
1.1 Introduction................................................................1-2
1.2 Features....................................................................1-3
1.3 Specifications............................................................1-4
Chapter 2 Quick Installation Guide
2.1 Safety Precautions....................................................2-2
2.2 Location of Connectors and Jumpers .......................2-3
2.3 Mechanical Drawing..................................................2-4
2.4 List of Jumpers..........................................................2-5
2.5 List of Connectors .....................................................2-5
2.6 LCD Clock Selection (JP1)........................................2-6
2.7 CompactFlash Disk Slot (CFD1)...............................2-6
2.8 ETX-1 Connector (J2) ...............................................2-8
2.9 ETX-2 Connector (J3) ...............................................2-9
2.10 ETX-3 Connector (J4).............................................2-10
2.11 ETX-4 Connector (J5).............................................2-11
Chapter 3 Award BIOS Setup
3.1 System Test and Initialization. ..................................3-2
3.2 Award BIOS Setup....................................................3-3
Chapter 4 Driver Installation
4.1 Software Drivers ......................................................4-2

ETX CPU Module ETX-700 Rev.B
vi
4.2 Necessary to know ..................................................4-3
4.3 Installing VGA Driver ...............................................4-4
4.4 Installing AES Driver ................................................4-5
4.5 Installing PCI to ISA Bridge Driver ..........................4-6
4.6 Installing Ethernet Driver .........................................4-7
4.7 Ethernet Software Configuration .............................4-7
4.8 Installing Audio Driver ..............................................4-8
Appendix A Programming The Watchdog Timer
A.1 Programming .........................................................A-2
A.2 W83627EHG Watchdog Timer Initial Program......A-6
Appendix B I/O Information
B.1 I/O Address Map....................................................B-2
B.2 1st MB Memory Address Map ................................B-3
B.3 IRQ Mapping Chart................................................B-3
B.4 DMA Channel Assignments...................................B-4

ETX CPU Module ETX-700 Rev.B
Chapter 1 General Information 1 - 1
General
Chapter
1
Information

ETX CPU Module ETX-700 Rev.B
Chapter 1 General Information 1 - 2
1.1 Introduction
AAEON announced the new Embedded Technology eXtended
(ETX) product – ETX-700 Rev.B, which is based on the AMD LX
processor combined with AMD CS5536 chipset.
ETX-700 Rev.B can provide common PC peripheral functions such
as graphics, USB, serial, parallel ports, keyboard/mouse, Ethernet,
and IDE. The baseboard designer can optimize exactly which and
how these functions are implemented physically.
All of AAEON's ETX modules have a standard form factor and a
standard connector layout that carry a specified set of signals. By
adopting this standardization, the designers can create a single
system of carrier board that can accept present and future ETX
modules in terms of their needs. In another word, AAEON will have
different ETX solutions so that customers can upgrade the module
without having to change their carrier board.
The ETX-700 Rev.B was designed specially to improve the quality
and speed of your product development. AAEON ETX series
represent features of scalability, reliability and qualified services. It
provides more compact size and more flexibility for your various
applications as well.

ETX CPU Module ETX-700 Rev.B
Chapter 1 General Information 1 - 3
1.2 Features
 ETX Form Factor
 AMD Geode LX Series Processors
 AMD CS5536 (Southbridge)
 Non-ECC DDR 333/400 Memory
 CRT/ LVDS LCD/ TTL LCD
 10/100 Base-TX Ethernet
 AC97 Audio CODEC
 One IDE Channel
 One CompactFlash Type I Slot
 +5V Operating Voltage

ETX CPU Module ETX-700 Rev.B
Chapter 1 General Information 1 - 4
1.3 Specifications
System
 CPU Onboard AMD Geode LX Series
Processor
 Memory One DDR SODIMM, supports non-ECC
DDR 333/400 up to 1GB
 Chipset AMD CS5536
 Ethernet Realtek RTL8139DL, 10/100Base-TX
 BIOS PLCC type, 1MB ROM
 Watchdog Timer Generates a Time-out System Reset
 H/W Status Monitoring Supports Power Supply Voltages, Fan
Speed and Temperatures Monitoring
 Wake on LAN Yes
 OS Support Windows 32-bit XP Pro
WinCE5.0/6.0
Linux Red Hat
 Expansion Interface 8-bit/16-bit ISA (ITE IT8888G-L, PCI to
ISA bridge chip)
32-bit PCI x 4
CompactFlash Type I Slot x 1
SMBus x 1
I2C x 1
 Power Supply Voltage +5V DC
 Board Size 4.5”(L) x 3.75”(W) (114mm x 95mm)

ETX CPU Module ETX-700 Rev.B
Chapter 1 General Information 1 - 5
 Gross Weight 0.66lb (0.3kg)
 Operating Temperature 32°F~140°F (0°C~60°C)
Display
 Chipset AMD LX processor integrated
 Memory Shared system memory up to 254MB
 Resolution Up to 1920x1440@32bpp at 85Hz
(CRT); Up to 1600x1200@32bpp at
100Hz (CRT); Up to 1600x 1200
@32bpp at 60Hz (LCD)
 LCD Interface TF-ETX-700-B10: 18/24-bit TTL
TF-ETX-700-B10-01: 18-bit LVDS
TF-ETX-700-B10-02: 24-bit LVDS
I/O
 Chipset Winbond W83627HG
 IDE IDE Channel x 1
 Parallel Port/FDD 1 (Configured by BIOS)
 Serial Port COM1/2 (TTL output)
 IrDA 1
 Audio Realtek ALC203
 USB USB2.0 x 4

ETX CPU Module ETX-700 Rev.B
Chapter 2 Quick Installation Guide 2 - 1
Quick
Installation
Chapter
2
Guide
Notice:
The Quick Installation Guide is derived from Chapter 2 of
user manual. For other chapters and further installation
instructions, please refer to the user manual CD-ROM that
came with the product.

ETX CPU Module ETX-700 Rev.B
Chapter 2 Quick Installation Guide 2 - 2
2.1 Safety Precautions
Always completely disconnect the power cord
from your board whenever you are working on it.
Do not make connections while the power is on,
because a sudden rush of power can damage
sensitive electronic components.
Always ground yourself to remove any static
charge before touching the board. Modern
electronic devices are very sensitive to static
electric charges. Use a grounding wrist strap at
all times. Place all electronic components on a
static-dissipative surface or in a static-shielded
bag when they are not in the chassis

ETX CPU Module ETX-700 Rev.B
Chapter 2 Quick Installation Guide 2 - 3
2.2 Location of Connectors and Jumpers
Component Side
Solder Side

ETX CPU Module ETX-700 Rev.B
Chapter 2 Quick Installation Guide 2 - 4
2.3 Mechanical Drawing
Component Side
Solder Side

ETX CPU Module ETX-700 Rev.B
Chapter 2 Quick Installation Guide 2 - 5
2.4 List of Jumpers
Jumpers allow users to manually customize system configurations
to their suitable application needs. The following chart consist the
list of each jumper function:
Label Function
JP1 LCD Clock Selection
2.5 List of Connectors
The board has a number of connectors that allow you to configure
your system to suit your application. The table below shows the
function of each board's connectors:
Label Function
CFD1 Compact Flash Disk
J2 PCI / USB / Audio
J3 ISA
J4 VGA / LCD / Video out / COMs / LPT / FDD / IrDA / Mouse
/ Keyboard
J5 IDE 1 / IDE 2 / Miscellaneous
Caution:
In order to properly clear the CMOS when using this ETX module with
ECB-901A, please ensure to turn off the main switch on the power supply
before taking actions. That should include both AT and ATX power supply.
Fail to turn off the main switch of power supply might result in unsuccessful
CLEAR CMOS action.

ETX CPU Module ETX-700 Rev.B
Chapter 2 Quick Installation Guide 2 - 6
2.6 LCD Clock Selection (JP1)
JP1 Function
1-2 Normal (Default)
3-4 Shift Clock
2.7 CompactFlash Disk Slot (CFD1)
Pin Signal Pin Signal
1 Ground 26 Ground
2 D3 27 D11
3 D4 28 D12
4 D5 29 D13
5 D6 30 D14
6 D7 31 D15
7 CS#0 32 CS#1
8 Ground 33 Ground
9 Ground 34 IOR#
10 Ground 35 IOW#
11 Ground 36 +5 Volt.
12 Ground 37 IRQ14
13 +5 Volt. 38 +5 Volt.
14 Ground 39 CSEL#
15 Ground 40 N/C
16 Ground 41 RESET#
17 Ground 42 IORDY

ETX CPU Module ETX-700 Rev.B
Chapter 2 Quick Installation Guide 2 - 7
18 DA2 43 DREQ
19 DA1 44 DACK#
20 DA0 45 DASP#
21 D0 46 PDIAG#
22 D1 47 D8
23 D2 48 D9
24 IO16# 49 D10
25 Ground 50 Ground

ETX CPU Module ETX-700 Rev.B
Chapter 2 Quick Installation Guide 2 - 8
2.8 ETX-1 Connector (J2)
Pin Signal Pin Signal Pin Signal Pin Signal
1 GND 2GND 51 VCC 52 VCC
3 PCICLK3 4 PCICLK4 53 PAR 54 SERR#
5 GND 6 GND 55 PERR# 56 NC
7 PCICLK1 8 PCICLK2 57 PCI_PME 58 USB2N
9 REQ3# 10 GNT3# 59 PLOCK# 60 DEVSEL#
11 GNT2# 12 3V 61 TRDY# 62 USB3N
13 REQ2# 14 GNT1# 63 IRDY# 64 STOP#
15 REQ1# 16 3V 65 FRAME# 66 USB2P
17 GNT0# 18 NC 67 GND 68 GND
19 VCC 20 VCC 69 AD16 70 CBE2#
21 SERIRQ 22 REQ0# 71 AD17 72 USB3P
23 AD0 24 3V 73 AD19 74 AD18
25 AD1 26 AD2 75 AD20 76 USB0N
27 AD4 28 AD3 77 AD22 78 AD21
29 AD6 30 AD5 79 AD23 80 USB1N
31 CBE0# 32 AD7 81 AD24 82 CBE3#
33 AD8 34 AD9 83 VCC 84 VCC
35 GND 36 GND 85 AD25 86 AD26
37 AD10 38 LIN_L 87 AD28 88 USB0P
39 AD11 40 MIC_IN 89 AD27 90 AD29
41 AD12 42 LIN_R 91 AD30 92 USB1P
43 AD13 44 VCCAUD 93 PCIRST# 94 AD31
45 AD14 46 LOUT_L 95 INTC# 96 INTD#
47 AD15 48 GNDAUD 97 INTA# 98 INTB#
49 CBE1# 50 LOUT_R 99 GND 100 GND
