Aaeon PFM-620S User manual

PC/104 Module PFM-620S Rev.B
PFM-620S Rev. B
Intel
®ULV Celeron®
400 / 650 MHz Processor
PC/104 CPU Module
With LCD, Ethernet,
COM, USB Ports
PFM-620S Manual Rev. B 1st Ed.
Nov. 2005

PC/104 CPU Module PFM-620S Rev.B
i
Copyright Notice
This document is copyrighted, 2005. All rights are reserved. The
original manufacturer reserves the right to make improvements
to the products described in this manual at any time without
notice.
No part of this manual may be reproduced, copied, translated,
or transmitted in any form or by any means without the prior
written permission of the original manufacturer. Information
provided in this manual is intended to be accurate and reliable.
However, the original manufacturer assumes no responsibility
for its use, or for any infringements upon the rights of third
parties that may result from its use.
The material in this document is for product information only
and is subject to change without notice. While reasonable
efforts have been made in the preparation of this document to
assure its accuracy, AAEON assumes no liabilities resulting
from errors or omissions in this document, or from the use of the
information contained herein.
AAEON reserves the right to make changes in the product
design without notice to its users.

PC/104 CPU Module PFM-620S Rev.B
ii
Acknowledgments
All other products’ name or trademarks are properties of their
respective owners.
 Award is a trademark of Award Software International, Inc.
 CompactFlash™ is a trademark of the Compact Flash
Association.
 Intel®, Pentium®and Celeron®are trademarks of Intel®
Corporation.
 Microsoft Windows®is a registered trademark of Microsoft Corp.
 IBM, PC/AT, PS/2, and VGA are trademarks of International
Business Machines Corporation.
Please be notified that all other products’ name or trademarks
not be mentioned above are properties of their respective
owners.

PC/104 CPU Module PFM-620S Rev.B
iii
Packing List
Before you begin installing your card, please make sure that the
following materials have been shipped:
• 1 PFM-620S Rev.B CPU Card
• Cable Kit (IDE, Serial Port x 2, RS-422/485, Parallel
Port, Keyboard/Mouse, VGA, RJ-45 Conversion Cable,
USB Cable, Power Cable)
• 1 Quick Installation Guide
• 1 CD-ROM for manual (in PDF format) and drivers
If any of these items should be missing or damaged, please
contact your distributor or sales representative immediately.

PC/104 CPU Module PFM-620S Rev.B
iv
Contents
Chapter 1 General Information
1.1 Introduction................................................................1-2
1.2 Features....................................................................1-3
1.3 Specifications............................................................1-4
Chapter 2 Quick Installation Guide
2.1 Safety Precautions....................................................2-2
2.2 Location of Connectors and Jumpers .......................2-3
2.3 Mechanical Drawing..................................................2-5
2.4 List of Jumpers..........................................................2-7
2.5 List of Connectors .....................................................2-8
2.6 Setting Jumpers ......................................................2-10
2.7 Extended -12V and -5V (CN1)................................2-11
2.8 Power Connector (CN2)..........................................2-11
2.9 KB/Mouse Connector (CN3) ...................................2-11
2.10 Parallel Port Connector (CN4) ..............................2-12
2.11 IR Connector (CN5)...............................................2-12
2.12 10/100Base-TX Ethernet Connector (CN6) .......... 2-13
2.13 PC 104 Connector (CN7)......................................2-13
2.14 IDE Connector (CN8)............................................2-13
2.15 CompactFlash™ slot (CN9)..................................2-14
2.16 VGA Connector (CN11) ........................................2-15
2.17 LVDS Panel Connector (CN18) ............................2-15

PC/104 CPU Module PFM-620S Rev.B
v
2.18 USB Connector (CN14).........................................2-16
2.19 COM1 Port Connector (CN15)..............................2-16
2.20 COM2 Port Connector (CN16)..............................2-17
2.21 AC97 Connector (CN17)....................................... 2-17
2.22 HDD LED Connector (JP2)...................................2-17
2.23 Reset Switch (JP3)................................................2-17
2.24 Speaker (JP4) .......................................................2-18
2.25 Power LED (JP5)...................................................2-18
2.26 LAN Link LED (JP6)..............................................2-18
2.27 RS-422/485 Connector (JP10).............................. 2-18
2.28 PCI-104 PLUS (PCI1) ...........................................2-18
2.29 CPU FAN Connector (FAN1)................................2-19
2.30 SODIMM Socket (DIMM1) ....................................2-19
2.31 Clear CMOS (JP1) ................................................2-19
2.32 PCI-104 VIO Power Selection (JP7).....................2-19
2.33 LVDS Panel Power Selection (JP13)....................2-19
2.34 COM1 RI and +5V Selection (JP9) .......................2-20
2.35 COM2 RI and +5V Selection (JP11).....................2-20
2.36 RS-232/422/485 Selection (JP12).........................2-20
Chapter 3 Award BIOS Setup
3.1 System Test and Initialization. ..................................3-2
3.2 Award BIOS Setup....................................................3-3
Chapter 4 Driver Installation
4.1 Installation.................................................................4-3

PC/104 CPU Module PFM-620S Rev.B
vi
Appendix A Programming The Watchdog Timer
A.1 Programming ............................................................A-2
Appendix B I/O Information
B.1 I/O Address Map.......................................................B-2
B.2 1st MB Memory Address Map ...................................B-2
B.3 IRQ Mapping Chart...................................................B-3
B.4 DMA Channel Assignments......................................B-3

PC/104 CPU Module PFM-620S Rev.B
Chapter 1 General Information 1 - 1
General
Chapter
1
Information

PC/104 CPU Module PFM-620S Rev.B
Chapter 1 General Information 1 - 2
1.1 Introduction
The PFM-620S Rev.B has the highest processor performance level
among AAEON’s current PC/104 CPU Modules. It features Intel®
Ultra Low Voltage Celeron®400/650MHz processor and delivers
excellent performance with low power consumption.
More options for your extension
The PFM-620S Rev.B offers a PC/104+ expansion bus, which has
excellent ability for expansion to fulfill your application needs. The
PC/104+ expansion bus can work with add-on devices such as
Gigabit LAN, USB 1.1 or IEEE 1394.
Marvelous Graphic Accelerator
The VIA VT8606 built-in 2D / 3D Graphics Accelerator offers a
high-resolution display quality and supports 18-bit LVDS LCD
displays. The VIA VT82C686B is a superior chipset with many
integrated features such as Audio (via daughter board), USB, Serial
port, Parallel port and etc. This provides excellent functionality for
almost any purpose.
High performance and Low power consumption
PFM-620S Rev.B provides an operating environment with low
power consumption and multi-functionality. The compact size and
flexible expansion interfaces make it the best choice for embedded
applications with limited space or industrial environments.

PC/104 CPU Module PFM-620S Rev.B
Chapter 1 General Information 1 - 3
1.2 Features
• Supports Intel®Ultra Low Voltage Celeron®400/650
Processor
• One SODIMM Socket Supports Up To 512MB
SDRAM
• Supports ATA33 and CFD Storage
• One 10/100Base-TX Fast Ethernet
• Supports 18-bit LVDS LCD Panel
• 2 USB1.1 Ports/ 1 Parallel Port/ 2 Serial Ports/ 1 IrDA
Port
• PC/ 104 Plus Socket
• Watchdog Timer 1~255 sec.

PC/104 CPU Module PFM-620S Rev.B
Chapter 1 General Information 1 - 4
1.3 Specifications
System
 CPU: Intel®Ultra Low
Voltage Celeron®400/650MHz
Processor
 Memory: 144-pin SDRAM SODIMM x 1,
Max. 512MB (PC-100/133)
 Chipset: VIA VT8606 / VT82C686B
 BIOS: AWARD Plug & Play ISA BIOS
256KB ROM
 Ethernet: Realtek RTL8100BL,
10/100Base-TX RJ-45
connector x 1
 Watchdog Timer: Generates a time-out system
reset
 H/W Status Monitoring: Supports power supply voltage
and temperature monitoring
 SSD: Type I CompactFlash™ Slot x 1
 Expansion Interface:PC/104+, PC/104 for Fanless
Model
 Battery: Lithium battery
 Power Requirement: AT power connector, +5V only
input
 Board Size: 4.53”(L) x 3.78”(W) (115mm x

PC/104 CPU Module PFM-620S Rev.B
Chapter 1 General Information 1 - 5
96mm)
 Gross Weight: 0.66lb(0.3kg)
 Operating Temperature:32oF~140oF(0oC~60oC)
32oF~122oF (0oC ~50oC) for
Fanless Model
Display
 Chipset VIA VT8606
 Memory size: Shared system memory up to 32
MB
 Resolutions: Up to 1280 x 1024 @ 24bpp
colors for CRT; Up to 1024 x
768 @ 18bpp colors for LCD
 LCD Interface: 18-bit LVDS LCD
I/O
 MIO: EIDE (UDMA33) x 1, Keyboard
+ Mouse x 1, RS-232 x 1,
RS-232/422/485 x 1 (+5V output
option on RI signal), Parallel x 1
 IrDA: One IrDA Tx/Rx header
 Audio: MIC-in, Line-in, Line-out
(optional Audio Decoder
Daughter Board required)
 USB: One 5x2 pin header supports 2
USB 1.1 ports

2 - 1
PC/104 CPU Module PFM-620S Rev.B
Chapter 2 Quick Installation Guide
Quick
Installation
Chapter
2
Guide
Notice:
The Quick Installation Guide is derive
d
f
rom Chapter 2 of user manual. For othe
r
chapters and further installation
instructions, please refer to the use
r
manual CD-ROM that came with th
e
p
roduct.
Part No. 2007620S20 Printed in Taiwan Nov. 2005

PC/104 CPU Module PFM-620S Rev.B
Chapter 2 Quick Installation Guide 2 - 2
2.1 Safety Precautions
Always completely disconnect the power cord
from your board whenever you are working on
it. Do not make connections while the power is
on, because a sudden rush of power can
damage sensitive electronic components.
Always ground yourself to remove any static
charge before touching the board. Modern
electronic devices are very sensitive to static
electric charges. Use a grounding wrist strap at
all times. Place all electronic components on a
static-dissipative surface or in a static-shielded
bag when they are not in the chassis

PC/104 CPU Module PFM-620S Rev.B
Chapter 2 Quick Installation Guide
2 - 3
2.2 Location of Connectors and Jumpers
Component Side
1
ABCDEFGHJKLMN P RTUVW
Y
12
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
A
BCDEF
G
HJ
K
LMNPRTU
VWYAAACAD
AEAF
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
ABCDEFGHJKLMNPRTU
VWY
AAABACADAEAF
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
A1
B1
A32
D1
C1 C20
D20
25 26
12
43 44
12A1
B1
C1
D1
A30
B30
C30
D30
12
910
2
1
910
12
910
12
910
12
15 16
4
5
29
30
14
13
20
21
1
2
9
10
2
29
16
2
6
5
30
1
1
2
3
4
2
5
6

PC/104 CPU Module PFM-620S Rev.B
Chapter 2 Quick Installation Guide 2 - 4
Solder Side

PC/104 CPU Module PFM-620S Rev.B
Chapter 2 Quick Installation Guide
2 - 5
2.3 Mechanical Drawing
Component Side
30
5
62
61
29
2
10
9
2
1
21
20
13
14
30
29
5416
15
2
1
109
21 10
9
2
1109
12
10
9
21
D30
C30
B30
A30
D1
C1
B1
A1
2
1
44
43
2
1
2625 D20
C20C1
D1
A32
B1
A1
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1AFAEADAC
AB
AA
YWV
UTRP
N
M
L
K
J
HGF
EDC
B
A
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
AF AE ADAC AA Y WV UTRPNMLKJH
GFE D C B A
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
43
2
1Y
WVUT
R
PNM
LK
J
HGFEDCB
A
1
1
1
26
5
3
4
2
3-view Drawing

PC/104 CPU Module PFM-620S Rev.B
Chapter 2 Quick Installation Guide 2 - 6
Solder Side

PC/104 CPU Module PFM-620S Rev.B
Chapter 2 Quick Installation Guide
2 - 7
2.4 List of Jumpers
There are a number of jumpers in the board that allow you to
configure your system to suit your application.
The table below shows the function of each jumper in the board:
Jumpers
Label Function
JP1 Clear CMOS
JP7 PCI-104 VIO power Selection
JP13 LVDS Panel Power Selection
JP9 COM1 RI and +5V Selection
JP11 COM2 RI and +5V Selection
JP12 RS-232/422/485 Selection

PC/104 CPU Module PFM-620S Rev.B
Chapter 2 Quick Installation Guide 2 - 8
2.5 List of Connectors
There are a number of connectors in the board that allow you to
configure your system to suit your application. The table below
shows the function of each connector in the board:
Connectors
Label Function
CN1 Extended –12V and –5V power
CN2 Power Connector
CN3 KB/MS Connector
CN4 Parallel Port Connector
CN5 IR Connector
CN6 10/100Base-TX Ethernet Connector
CN7 PC104 Connector
CN8 IDE Connector
CN9 CompactFlashSlot
CN11 VGA Connector
CN18 LVDS Panel Connector
CN14 USB Connector
CN15 COM1 Port Connector
CN16 COM2 Port Connector
CN17 AC97 Connector
JP2 HDD LED
JP3 RESET SWITCH
