Aaeon AQ7-BT User manual

Qseven Module AQ7-BT
AQ7-BT
Intel®Atom™/Celeron® Processor SoC
Onboard 2GB Memory
SATA x 2
USB 2.0 x 6 USB 3.0 x 1
LVDS, LCD, DP, HD Audio
AQ7-BT Rev.A Manual 1st Ed.
May 14, 2015
www.texim-europe.com

Qseven Module AQ7-BT
Copyright Notice
This document is copyrighted, 2015. All rights are reserved. The
original manufacturer reserves the right to make improvements to the
products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in this
manual is intended to be accurate and reliable. However, the original
manufacturer assumes no responsibility for its use, or for any in-
fringements upon the rights of third parties that may result from its
use.
The material in this document is for product information only and is
subject to change without notice. While reasonable efforts have been
made in the preparation of this document to assure its accuracy,
AAEON assumes no liabilities resulting from errors or omissions in
this document, or from the use of the information contained herein.
AAEON reserves the right to make changes in the product design
without notice to its users.
i
www.texim-europe.com

Qseven Module AQ7-BT
Acknowledgments
All other products’ name or trademarks are properties of their
respective owners.
AMI is a trademark of American Megatrends Inc.
Freescale™ is a trademark of Freescale Semiconductor, Inc.
Microsoft Windows®is a registered trademark of Microsoft Corp.
ITE is a trademark of Integrated Technology Express, Inc.
IBM, PC/AT, PS/2, and VGA are trademarks of International
Business Machines Corporation.
Please be notified that all other products’ name or trademarks not be
mentioned above are properties of their respective owners.
ii
www.texim-europe.com

Qseven Module AQ7-BT
Packing List
Before you begin installing your card, please make sure that the
following materials have been shipped:
•1 AQ7-BT CPU Module
•1 DVD-ROM for drivers and manual (in PDF format)
•2 M2.5 Screws
If any of these items should be missing or damaged, please
contact your distributor or sales representative immediately.
iii
www.texim-europe.com

Qseven Module AQ7-BT
China RoHS Requirements
产品中有毒有害物质或元素名称及含量
AAEON Main Board/ Daughter Board/ Backplane
部件名称
有毒有害物质或元素
铅
(Pb)
汞
(Hg)
镉
(Cd)
六价铬
(Cr(VI))
多溴联苯
(PBB)
多溴二苯醚
(PBDE)
印刷电路板
及其电子组件
×
○
○
○
○
○
外部信号
连接器及线材
×
○
○
○
○
○
O：表示该有毒有害物质在该部件所有均质材料中的含量均在
SJ/T 11363-2006
标准规定的限量要求以下。
X
：表示该有毒有害物质至少在该部件的某一均质材料中的含量超出
SJ/T 11363-2006
标准规定的限量要求。
备注：此产品所标示之环保使用期限，系指在一般正常使用状况下。
iv
www.texim-europe.com

Qseven Module AQ7-BT
Contents
Chapter 1 General Information
1.1 Introduction................................................................ 1-2
1.2 Features .................................................................... 1-3
1.3 Specifications............................................................ 1-4
Chapter 2 Quick Installation Guide
2.1 Safety Precautions.................................................... 2-2
2.2 Mechanical Drawings................................................2-3
2.3 List of Jumpers..........................................................2-6
2.4 AT/ATX Setting Switch (SW1)................................... 2-6
2.5 List of Connectors .....................................................2-7
2.6 QSeven MXM Pin Definitions.................................... 2-8
2.7 QSeven MXM Pin Assignments................................ 2-10
Chapter 3 AMI BIOS Setup
3.1 System Test and Initialization ...................................3-2
3.2 AMI BIOS Setup........................................................3-3
Chapter 4 Driver Installation
4.1 Installation .................................................................4-3
Appendix A Programming the Watchdog Timer
A.1 Watchdog Timer Initial Program ............................A-2
Appendix B I/O Information
v
www.texim-europe.com

Qseven Module AQ7-BT
B.1 I/O Address Map....................................................B-2
B.2 Memory Address Map............................................B-4
B.3 IRQ Mapping Chart................................................B-6
Appendix C Programming Digital I/O
C.1 Digital I/O Programming ....................................... C-2
C.2 Digital I/O Register................................................ C-3
C.3 Digital I/O Sample Program.................................. C-4
vi
www.texim-europe.com

Qseven Module AQ7-BT
General
Information
Chapter
1
Chapter 1 General Information 1 - 1
www.texim-europe.com

Qseven Module AQ7-BT
1.1 Introduction
Measuring 70mm x 70mm, the AQ7-BT is a Qseven module with
Qseven Rev.2.0 specification and equips Intel® Atom™ E3800
Series Processor SoC (and the N2807 Processor) with 2GB of
onboard DDR3L memory.
It accommodates PCI-Express[x1] slots, SMBus, I2C bus, and
SDIO interface for expansion; 18/24-bit single-channel LVDS and
Digital Display Interface which can convert to DP/HDMI or other
digital display format (may need certain bridge IC); Intel®’s
I211/I210 for Ethernet (depending on SKU); and USB 3.0/2.0, SATA
II, and serial ports for I/O
Users may also acquire AAEON’s ECB-970 carrier board
separately for evaluating and testing the module.
Chapter 1 General Information 1 - 2
www.texim-europe.com

Qseven Module AQ7-BT
1.2 Features
Intel®Atom™ E3800 Series Processor SoC, N2807 Processor
Onboard DDR3L 2GB Memory
Gigabit Ethernet x 1
18/24-bit Single-Channel LVDS, DP/HDMI
High Definition Audio Interface
SATA x 2, one share with onboard SATA SSD. (SLC/MLC, up
to 32GB)
USB 3.0 x 1, USB 2.0 x 6
PCI-Express [x1] x 3
Qseven Rev. 2.0, 70mm x 70mm
Chapter 1 General Information 1 - 3
www.texim-europe.com

Qseven Module AQ7-BT
1.3 Specifications
System
Form Factor Q7
Processor Intel®Atom™ Processor SoC
E3845: 4C/ 1.91GHz/ 10W
E3825: 2C/1.33GHz/6W
N2807: 2C/1.58GHz
System Memory Onboard DDR3L 2GB
Chipset Intel® Atom SoC
Ethernet Intel® I211/I210 (depending on SKU) for
10/1000/1000Base-TX
BIOS AMI BIOS, Legacy free BIOS
Wake On LAN Yes
Watchdog Timer ITE IT8528VG
H/W Status Monitoring ITE IT8528VG
Expansion Interface PCI Express [x1] x3
SMBUS x1
SPI x 1
I2C x1
GPIO: 8-bit
SDIO x 1
Chapter 1 General Information 1 - 4
www.texim-europe.com

Qseven Module AQ7-BT
UART x 1
Power Requirement DC 5V
Power Consumption (Typical) E3845: 2.7A@5V (Whole system under
100% loading)
Board Size 70mm x 70mm (2.75" x 2.75")
Gross Weight 0.2kg (0.44 lbs)
Operating Temperature 0 °C ~ 60 °C (32 °F ~ 140 °F) or
-40°C ~ 85°C (-40°F ~ 185°F) (Optional by
SKU)
Storage Temperature -40°C ~ 80°C (-40°F ~ 176°F)
Operation Humidity 0% ~ 90% relative humidity, non-condensing
Display
Chipset Intel®Atom™ Processor SoC
Memory －
Resolution LCD: Up to 1920 x 1200
DP/HDMI: Up to 1920 x 1080 (Optional)
LCD Interface Up to 24-bit Dual-Channel LVDS
I/O
Storage SATA 2 x 1, onboard 4GB~16GB nanoSSD
Chapter 1 General Information 1 - 5
www.texim-europe.com

Qseven Module AQ7-BT
(optional by request)
USB USB 3.0 x 1
USB 2.0 x 6
Serial Port 4-wire UART x 1
Audio High Definition Audio
Chapter 1 General Information 1 - 6
www.texim-europe.com

Qseven Module
A Q 7 - BT
Chapter 2 Quick Installation Guide 2-1
Quick
Installation
Guide
Chapter
2
www.texim-europe.com

Qseven Module
A Q 7 - BT
Chapter 2 Quick Installation Guide 2-2
2.1 Safety Precautions
Always completely disconnect the power cord
from your board whenever you are working on
it. Do not make connections while the power is
on, because a sudden rush of power can
damage sensitive electronic components.
Always ground yourself to remove any static
charge before touching the board. Modern
electronic devices are very sensitive to static
electric charges. Use a grounding wrist strap at
all times. Place all electronic components on a
static-dissipative surface or in a static-shielded
bag when they are not in the chassis
www.texim-europe.com

Qseven Module
A Q 7 - BT
Chapter 2 Quick Installation Guide 2-3
2.2 Mechanical Drawings
Board
Component Side Solder Side
Component Side Solder Side
www.texim-europe.com

Qseven Module
A Q 7 - BT
Chapter 2 Quick Installation Guide 2-4
Heat Spreader
Heat Sink
www.texim-europe.com

Qseven Module
A Q 7 - BT
Chapter 2 Quick Installation Guide 2-5
Cooler
www.texim-europe.com

Qseven Module
A Q 7 - BT
Chapter 2 Quick Installation Guide 2-6
2.3 List of Jumpers
The board has a jumper that allows you to configure your system to suit
your application.
The table below shows the function of the board's jumper:
Label
Function
SW1
AT/ATX Setting Switch
2.4 AT/ATX Setting Switch (SW1)
Switch
On
Off
1
AT
ATX
2
Factory use only
FW_WP (Default)
*By default, both switches are set to Off
*Switch 2 “On”position is for factory use only. Users are strongly advised not to
perform this setting.
www.texim-europe.com

Qseven Module
A Q 7 - BT
Chapter 2 Quick Installation Guide 2-7
2.5 List of Connectors
The board has a connector that allows you to configure your system to
suit your application.
The table below shows the function of the board's connector:
Label
Function
BAT1A
RTC Battery Connector
