ABB SCC-C User manual

SCC-C Sample Gas Cooler
Operator’s Manual 42/2355 EN Rev. 1

2 SCC-C Sample Gas Cooler Operator’s Manual 42/23-55 EN Rev. 1
Contents
Page
Preface 3
General Safety Information 4
Safety Tips for Handling Electronic Measurement Devices 5
Chapter 1 Preparing the Installation
Normal Operation 6
Requirements for the Installation Site 6
Power Supply 7
Sample Gas Inlet Conditions 7
Scope of Delivery 7
Dimensional Drawing 8
Chapter 2 Sample Gas Cooler Installation and Start-Up
Sample Gas Cooler Installation 9
Sample Gas and Condensate Pipe Connection 10
Reagent Dosing Connection 11
Electrical Line Connection 12
Power Supply Activation, Lead Time 13
Chapter 3 Maintenance
Removing and Installing Heat Exchangers 14
Replacing Peristaltic Pump Hoses 16
Replacing Peristaltic Pump Pressure Rollers and Springs 18
Clean Condenser Fins 20
Troubleshooting 21
Chapter 4 Sample Gas Cooler Shutdown and Packing
Sample Gas Cooler Shutdown 22
Sample Gas Cooler Packing 23
Appendix
Sample Gas Cooler Applications and Functions 24
Description 25
Operating Specifications 27
Index 27

42/23-55 EN Rev. 1 SCC-C Sample Gas Cooler Operator’s Manual 3
Preface
Content of the
Operator’s Manual
This operator’s manual contains all the information you will need to safely and
efficiently install, start-up, operate and maintain the SCC-C Sample Gas Cooler.
This operator’s manual contains information on all the functional units in the
sample gas cooler. The delivered sample gas cooler may differ from the version
described.
Additional Document Data Sheet “System Components and Accessories for Sample Gas Conditioning”,
Document No. 10/23-5.20 EN
This publication can be ordered from your authorized ABB representative or from
ABB Automation Products GmbH, Analytical Division, Marketing Communication,
Fax: [phone], E-mail: [email protected]
Further Information
on the Internet
You can find further information on ABB Analytical products and services on the
internet: “http://www.abb.com/analytical”.
Identifies safety information to be heeded during unit operation in
order to avoid risks to the operator.
Identifies specific information on operation of the unit as well as on
the use of this manual.
Symbols and
Typefaces
1, 2, 3, ... Identifies reference numbers in the figures.
This Operator’s Manual is protected by copyright. The translation, duplication and distribution in any form,
even in a revised edition or in extracts, in particular as a reprint, by photomechanical or electronic repro-
duction or in the form of storage in data processing systems or data networks are prohibited without the
consent of the copyright holder and will be prosecuted under civil and criminal law.

4 SCC-C Sample Gas Cooler Operator’s Manual 42/23-55 EN Rev. 1
General Safety Information
Requirements for
Safe Operation
In order to operate in a safe and efficient manner the instrument should be properly
handled and stored, correctly installed and started, properly operated and correctly
maintained.
Personnel
Qualifications
Only persons familiar with the installation, set-up, operation and maintenance of
comparable equipment and certified as being capable of such work should work
on the instrument.
Special Information
and Precautions
These include
•The content of this operator’s manual.
•The safety information affixed to the instrument.
•The applicable safety precautions for installing and operating electrical devices
•Safety precautions for working with gases, acids, condensates, etc.
National Regulations The regulations, standards and guidelines cited in this operator’s manual are
applicable in the Federal Republic of Germany. The applicable national regulations
should be followed when the instrument is used in other countries.
Instrument Safety
and Safe Operation
The instrument is designed and tested in accordance with EN 61010 Part 1,
“Safety Provisions for Electrical Measuring, Control, Regulation and Laboratory
Instruments” and has been shipped ready for safe operation.
To maintain this condition and to assure safe operation, read and follow the safety
information identified with the symbol in this manual. Failure to do so can put
persons at risk and can lead to instrument damage as well as damage to other
systems and instruments.
Additional
Information
If the information in this operator’s manual does not cover a particular situation,
ABB Service is prepared to supply additional information as needed.
Contact your local ABB Service representative or
ABB Service, Telephone: [phone], Telefax: [phone]
E-mail: callcenter[email protected]

42/23-55 EN Rev. 1 SCC-C Sample Gas Cooler Operator’s Manual 5
Safety Tips for Handling Electronic Measurement Devices
Protective Lead
Connection
The protective lead should be attached to the protective lead connector before
any other connection is made.
Risks of Loss of
Protective Lead
Continuity
The instrument can be hazardous if the protective lead is interrupted inside or
outside the instrument or if the protective lead is disconnected.
Proper Operating
Voltage
The instrument voltage must be set to match the line voltage before the power
supply is activated.
Risks Involved in
Opening the Covers
Current-bearing components can be exposed when the covers or parts are
removed, even if this can be done without tools. Current can be present at some
connection points.
Risks Involved in
Working with an
Open Instrument
The instrument must be disconnected from all power sources before any mainte-
nance work is performed. Work on an instrument that is open and connected to
power should only be performed by trained personnel who are familiar with the
risks involved.
Charged Capacitors The instrument capacitors can retain their charge even when the instrument is
disconnected from all power sources.
Use of Proper Fuses Only fuses of the specified type and rated current should be used as replacements.
Never use patched fuses. Do not short-circuit the fuse holder contacts.
When Safe Operation
can no Longer be
Assured
If it is apparent that safe operation is no longer possible, the instrument should be
taken out of operation and secured against unauthorized use.
The possibility of safe operation is excluded:
•If the instrument is visibly damaged
•If the instrument is no longer operational
•After prolonged storage under adverse conditions
•After severe transport stresses

6 SCC-C Sample Gas Cooler Operator’s Manual 42/23-55 EN Rev. 1
Chapter 1 Preparing the Installation
Normal Operation
Normal Operation The SCC-C sample gas cooler is designed for cooling the sample gas and for
separating and removing the condensate.
The SCC-C sample gas cooler must not be used in hazardous areas. The model of
sample gas cooler featuring stainless-steel heat exchangers is suitable for use with
flammable sample gases.
Requirements for the Installation Site
Short Gas Paths The sample gas cooler should be installed as close as possible to the gas analyzer.
Adequate Air
Circulation
Ensure adequate natural air circulation around the sample gas cooler. Avoid heat
accumulation.
Protection against
Adverse Environ-
mental Conditions
The sample gas cooler should be protected from
•cold,
•radiated heat, e.g. from the sun, kilns or boilers,
•temperature fluctuations,
•strong air movement,
•dust deposits and dust penetration,
•corrosive atmosphere,
•vibration.
Climatic Conditions Ambient temperature During operation: +10 to +50 °C
Storage and transport: –25 to +60 °C
Relative humidity ≤75 % year-round average, ≤95 % on 30 days
per year, occasional light condensation
permissible

42/23-55 EN Rev. 1 SCC-C Sample Gas Cooler Operator’s Manual 7
Power Supply
Power Supply Input Voltage 230 VAC or 115 VAC, –15 to +10 %, 50 to 60 Hz
Power Consumption max. 200 VA
Starting Current 2.5 A at 230 VAC
Sample Gas Inlet Conditions
Sample Gas Pressure pabs
without with
Heat
Exchanger
Material Peristaltic Pump
Glass 50 to 200 kPa
(0.5 to 2.0 bar)
50 to 150 kPa
(0.5 to 1.5 bar)
PVDF 50 to 250 kPa
(0.5 to 2.5 bar)
50 to 150 kPa
(0.5 to 1.5 bar)
Sample Gas
Inlet Conditions
Sample Gas Pressure
Stainless
Steel
0.05 to 1 MPa
(0.5 to 10 bar)
Sample Gas Flow 1 x 250 l/h or 1 x 125 l/h or 2 x 125 l/h,
assuming sample gas pressure pabs = 100 kPa
(1 bar) and 25 °C
Sample Gas Inlet Temperature 140 °C
Sample Gas Inlet Dew Point 70 °C, max. 60 °C for heat exchanger HE250
where sample gas flow > 200 l/h
Scope of Delivery
Quantity Description
1 Sample gas cooler
2 Operator’s manuals (in English and in German language)
Scope of Delivery
for the model with glass heat exchanger:
GL coupling nuts with inset 6 x 4 x 1 threads for a hose or pipe
(2 per heat exchanger)
The fixing brackets are fitted in the factory.

8 SCC-C Sample Gas Cooler Operator’s Manual 42/23-55 EN Rev. 1
Dimensional Drawing
Fig. 1
Dimensional Drawing
(Dimensions in mm)
3.0
13
266
220
326.5
46
246
263
37.8 190.5
1
2
3
4
1Temperature Controller
2Condensate Outlet (in the Model with Peristaltic Pumps)
3Heat Exchanger Sample Gas Connections
4Passages for the (Fixed) Electrical Connection Cables
•You must take the additional space requirement into account
•Adjacent to the instrument on the right-hand side for the cooling air inlet, and
in front of the instrument for the cooling air outlet (approx. 10 cm in each case),
•in front of and underneath the instrument for connecting the condensate pipes
and
•above the instrument for connecting the sample gas lines and the electrical
leads.
•The fixing brackets are fitted in the factory, with about 2.5 cm projection to the
rear wall.
•Slope max. 5°.

42/23-55 EN Rev. 1 SCC-C Sample Gas Cooler Operator’s Manual 9
Chapter 2 Sample Gas Cooler Installation and Start-Up
WARNING!
The sample gas cooler should always be transported and stored with the gas
ports up. Otherwise the oil in the compressor circuit could leak from the
compressor cap.
The sample gas cooler must stand in its operating position for about 24 hours
prior to commissioning.
•If there is shipping damage which points to improper handling file a damage
claim with the shipper (railway, mail or freight carrier) within seven days.
•Make sure that none of the enclosed accessories are lost during unpacking (see
the “Scope of Delivery” section, page 7).
•Keep the shipping box and packaging material for future shipping needs.
Sample Gas Cooler Installation
Step Action
Fit the sample gas cooler to the wall using 4 M6 screws.
The fixing brackets required for this purpose are secured at the rear
entry of the side walls in the factory.
Sample Gas Cooler
Installation on the Wall 1
To enable the cooling air to also pass unobstructed out of the
sample gas cooler to the rear, the projection of the mounting
brackets of around 2.5 cm to the rear wall, which is set up in
the factory, must not be reduced.
Step Action
1 Unscrew the mounting brackets from the rear of the side covers and
screw them securely at the front of the side covers, flush with the
front cover, using the drill holes provided for this purpose.
Sample Gas Cooler
Installation in a
19-Inch Cabinet /Rack
2 Install the sample gas cooler in a 19-inch cabinet /rack using 4 M6
screws.
Step Action
Compressor
Transportation
Restraints Release 1 Using a Ph2 cross-head screwdriver, turn the two screws counter-
clockwise through the holes in the base plate up to the point at which
resistance can be felt.
Installation of
Sample Gas Cooler
and Sample Gas Feed
Unit Side-by-Side
Installation of sample gas cooler and sample gas feed unit side-by-side is
described in the SCC-F sample gas feed unit operator’s manual (publication no.
42/23-51 EN).

10 SCC-C Sample Gas Cooler Operator’s Manual 42/23-55 EN Rev. 1
Sample Gas and Condensate Pipe Connection
Condensate Outlet
Heat Exchanger
Material
Sample Gas Inlets
and Outlets Heat Exchanger Peristaltic Pump
Glass Hose/pipe thread
GL18
Pipe nipple
GL25
DN 4/6 mm
PVDF Pipe 6 x 1 mm G 3/8 inch DN 4/6 mm
Sample Gas and
Condensate
Connections
Stainless steel G 1/4 inch G 3/8 inch DN 4/6 mm
Sample Gas Pipe
Connection
Connect sample gas pipes to the sample gas inlets and outlets on the top side of
the heat exchangers. The sample gas pipes should be made from material that is
suited to the measuring task.
•The connections for sample gas inlet and outlet must be connected the right
way round. The connections are identified by arrows on the heat exchangers.
•Glass heat exchangers: Before fitting the GL coupling nuts you should check
that the PTFE/silicone compression fittings are not damaged. The compression
fittings should be fitted with their white PTFE surface facing the glass.
•PVDF and stainless-steel heat exchangers: Screw suitably-sized pipe/hose
connectors onto the pipe nipples.
•Make sure that the compression fittings and sealing rings are assembled in the
right order
•When tightening the screw joints you should relieve the strain on the connection
pieces, for example by using a spanner to counteract the rotation. Failure to
protect the connection pieces in this way may result in them twisting and the
seals consequently being impaired.
•It is important to observe the sample gas inlet conditions (see page 7).
Condensate Pipe
Connection
Connect the condensate pipe to the condensate outlet on the heat exchanger or
peristaltic pump.
•Glass heat exchangers: Before fitting the GL coupling nuts you should check
that the PTFE/silicone compression fittings are not damaged. The compression
fittings should be fitted with their white PTFE surface facing the glass.
•PVDF and stainless-steel heat exchangers: Screw in a suitably-sized pipe/hose
screw connection. Only use screw connections conforming to DIN 2999/1 with
a tapered R thread in conjunction with a suitable sealing tape/sealing fluid.
•Peristaltic pump: Connect the condensate pipe to the DN 4/6 mm pipe/hose
screw connection.
•To avoid any restriction to the removal of condensate, the specified cross
sections of removal pipes should not be reduced.
WARNING!
The condensate that accumulates is often acidic. Appropriate precautions
should be taken when removing the condensate, and relevant regulations on
disposal should be complied with.

42/23-55 EN Rev. 1 SCC-C Sample Gas Cooler Operator’s Manual 11
Reagent Dosing Connection
Peristaltic Hose Pump
for Reagent Dosing
The peristaltic hose pump for reagent dosing is installed as an option
•either in the sample gas cooler (Catalog No. 23070-0-xxxx3xxx0000)
•or in the sample gas feed unit (Catalog No. 23212-0-xx1xxx000000).
When the peristaltic pump is installed in the sample gas feed unit it is turned off
when a “condensate” failure occurs. When the pump is installed in the sample gas
cooler this is not possible.
The pump’s feed performance is 15 ml/hour.
Material Needed When the sample gas cooler has been ordered in the version “with dosing unit”
(Catalog No. 23070-0-x1xxxxxx0000) the following material is delivered with the
instrument:
Quantity Description
1 T-piece
1 Hose, length 500 mm (reagent supply bottle – pump)
1 Hose, length 800 mm (pump – T-piece)
1 Hose, length 400 mm (T-piece – cooler sample gas inlet)
Fig. 2
Reagent Dosing
Connection
(Example: Peristaltic
hose pump for reagent
dosing installed in the
sample gas feed unit)
SCC-CSCC-F
1.6/4.8 mm, 800 mm 1.6/4.8 mm, 400 mm
1.6/4.8 mm, 500 mm
Reagent Supply Bottle
Sample Gas
Reaction Line

12 SCC-C Sample Gas Cooler Operator’s Manual 42/23-55 EN Rev. 1
Electrical Line Connection
WARNING!
Follow all applicable national safety regulations for the preparation and
operation of electrical devices as well as the following safety precautions.
The sample gas cooler operating voltage must be set to match the line
voltage before the power supply is connected.
The protective lead should be attached to the protective lead connector
before any other connection is made.
The sample gas cooler can be hazardous if the protective lead is interrupted
inside or outside the sample gas cooler or if the protective lead is
disconnected.
You should route the signal lines separately from the power supply lines.
Connecting
Signal Lines
The signal lines (temperature monitoring status signal) should be connected in
accordance with the numbering of the wires (see Fig. 3).
Fig. 3
Signal Lines
2 C
3 NO
1 N
C
Connecting the
Sample Gas Cooler
to the Sample Gas
Feed Unit
In case the SCC-C sample gas cooler is used in conjunction with the SCC-F
sample gas feed unit, it is possible to connect the power supply and the tempera-
ture monitoring status signal (temperature alarm) of the sample gas cooler to the
sample gas feed unit.
If a temperature alarm occurs in the sample gas cooler the diaphragm pumps in
the sample gas feed unit are turned off.
Electrical connection of the sample gas cooler to the sample gas feed unit is
described in the SCC-F sample gas feed unit operator’s manual (publication no.
42/23-51 EN).
Continued on next page

42/23-55 EN Rev. 1 SCC-C Sample Gas Cooler Operator’s Manual 13
Electrical Line Connection, continued
Step Action
Make sure the voltage shown on the rating plate matches the
line voltage.
1
The operating voltage cannot be switched over.
2 Make sure the power supply leads have an adequately dimensioned
protective device (breaker).
3 Install a switched outlet or a breaker in the power supply wiring near
the sample gas cooler. This should allow the sample gas cooler and
all switches to be completely disconnected from the power supply if
necessary. The disconnection device should be identified in such a
way that its relationship to the equipment that it is designed to
disconnect can be clearly seen.
Connect the power supply wiring to the power supply.
Connecting the
Power Supply
4
The sample gas cooler may start when the power supply is
connected.
Power Supply Activation, Lead Time
WARNING!
Before activating the power supply check once again that the operating
voltage setting matches the line voltage (see rating plate)
The sample gas flow should only be started after the lead time period.
Power Supply
Activation
Activate the power supply using the externally installed breaker or the switched
outlet.
The peristaltic pumps start to run (counterclockwise).
Lead Time The lead time is approx. 15 minutes. This allows the sample gas outlet tempera-
ture of +3 °C, which is set in the factory, to be reached.
Status Signal During the lead time the monitor will output the temperature alarm signal.
Readiness At the end of the lead time period the sample gas cooler is ready for operation.
Sample Gas Supply The sample gas must not be switched on until the sample gas outlet temperature
lies within the limit values set in the factory, i.e. when it has fallen below +6 °C.

14 SCC-C Sample Gas Cooler Operator’s Manual 42/23-55 EN Rev. 1
Chapter 3 Maintenance
WARNING!
The operations described in this chapter require specialized knowledge, and
sometimes involve the necessity of working on the sample gas cooler with
its cover open and live. They must therefore only be carried out by qualified
and specially trained persons.
Removing and Installing Heat Exchangers
Cleaning the
Heat Exchanger
The heat exchanger must be removed and re-installed when it is dirty and requires
cleaning.
WARNING!
Residual condensate may be present in the heat exchanger. The condensate
is often acidic. Appropriate precautions should be taken, and relevant
regulations on disposal should be complied with.
Step Action
1
Stop the sample gas supply and shut off the sample gas cooler
power supply.
Remove the heat exchanger:
2 Disconnect sample gas and condensate pipes from connections 1
and 2respectively of the heat exchanger.
3 Turn the heat exchanger slightly and draw it upwards to remove it
from the cooling block 3.
Prepare for installation of the heat exchanger:
4 Using a cloth, clean and dry the opening in the cooling block and the
heat exchanger.
5 Use some adhesive tape to close off the condensate outlet on the heat
exchanger in order to prevent the ingress of thermal conductive paste
into the heat exchanger during installation.
Removing and
Installing the
Heat Exchanger
(see Fig. 4)
6 Spread an even thin coating of thermal conductive paste over the en-
tire surface of the opening in the cooling block and the heat exchanger
in order to ensure good thermal transition.
Continued on next page

42/23-55 EN Rev. 1 SCC-C Sample Gas Cooler Operator’s Manual 15
Removing and Installing Heat Exchangers, continued
Step Action
Install the heat exchanger:
7 Insert the heat exchanger in the opening in the cooling block 3and,
turning it slightly, push it downwards right to the limit stop.
8 Remove the adhesive tape from the condensate outlet on the heat
exchanger and remove any thermal conductive paste that has been
squeezed out.
Connect the sample gas and condensate pipes to connections 1and
2respectively of the heat exchanger.
9
Note the following points when installing a glass heat exchanger:
Before fitting the GL coupling nuts you should check that the
PTFE/silicone compression fittings are not damaged. The com-
pression fittings should be fitted with their PTFE surface facing
the glass. The GL coupling nuts should be hand-tightened.
10 Ensure that the temperature sensor 4is inserted in the cooling block
all the way to the limit stop.
Start the sample gas cooler again:
11 Verify the integrity of the open gas path.
12 Switch power supply to sample gas cooler back on.
13 The sample gas flow should only be restarted after the lead time
period.
Fig. 4
Sample Gas Cooler,
Front View, with
Front Cover Open
1
4
3
2
1Heat Exchanger Sample Gas Connections
2Condensate Connections of the Heat Exchangers
3Cooling Block
4Temperature Sensor

16 SCC-C Sample Gas Cooler Operator’s Manual 42/23-55 EN Rev. 1
Replacing Peristaltic Pump Hoses
When should the
Hoses be Replaced?
Depending on the operating cycle, the peristaltic pump hoses should be replaced
at least every 5 months.
WARNING!
The hoses on the peristaltic pumps should never be lubricated.
The hoses can contain condensate residue. These materials can flow out
when the hose connections are opened. Take appropriate measures where
needed to collect residual condensates.
The condensate is often acidic. Appropriate precautions should be taken,
and relevant regulations on disposal should be complied with.
Step Action
1
Stop the sample gas supply and shut off the sample gas cooler
power supply.
Remove the old hose:
2 Remove the hoses from the hose connections 4.
3 Using the handles, press the moving belt 1together and turn the
S-clip 2in a clockwise direction as far as its limit stop.
4 Remove the moving belt 1from the pump head and pull the old hose 3
by the hose connections 4to release it from the moving belt’s guides.
5 Press the pressure rollers 5together and check the spring pressure; if
it is too weak, then the pressure springs and possibly rollers should be
replaced (see page 18).
Fit a new hose:
6 Insert a new hose 3with hose connections in the guides on the
moving belt 1.
7 Insert moving belt 1with the new hose in the dovetail guide 6in the
pump head; using the handles, press the moving belt together while at
the same time turning the S-clip 2counterclockwise until it engages.
Screw hoses to the hose connections 4.8
Take care not to kink or crush the hoses.
Restart the sample gas cooler:
9 Switch on power supply to sample gas cooler.
Replacing Peristaltic
Pump Hoses
(see Fig. 5)
10 The sample gas flow should only be restarted after the lead time
period.
Continued on next page

42/23-55 EN Rev. 1 SCC-C Sample Gas Cooler Operator’s Manual 17
Replacing Peristaltic Pump Hoses, continued
Fig. 5
Peristaltic Pump,
Peristaltic Pump
Hose and Pump Head
with Roller Mounting
1
2
1
3
4
5
6
1Moving Belt
2S-clip
3Peristaltic Pump Hose
4Hose Connections
5Pressure Rollers
6Dovetail Guide

18 SCC-C Sample Gas Cooler Operator’s Manual 42/23-55 EN Rev. 1
Replacing Peristaltic Pump Pressure Rollers and Springs
When do the Pressure
Rollers and Springs
need to be Replaced?
The pressure rollers in the peristaltic pumps must be replaced when their surface
is damaged.
The pressure springs in the peristaltic pumps must be replaced when they are
broken.
Step Action
1
Stop the sample gas supply and shut off the sample gas cooler
power supply.
Remove the hose from the peristaltic pump:
2 Using the handles, press the moving belt 1together and turn the S-
clip 2in a clockwise direction as far as its limit stop; then remove the
moving belt and peristaltic pump hose from the pump head.
Dismantle the pump head:
3 Unscrew the two nuts 3that secure the pump head (spanner size 5.5).
4 Pull the pump head 4off the roller bearing axle, and remove the roller
support 5from the pump head.
Replace pressure rollers and springs:
5 Remove the pressure springs 6from the hole in the roller support 5
and from the retaining slot in the roller axle 7. Remove the roller axle
from the roller support and pull the pressure roller 8off the roller axle.
6 Push the new pressure roller 8onto the roller axle 7and secure with
new pressure springs 6in the roller support 5.
Fit the pump head:
7 Insert the roller support 5in the pump head 4, and push both
components together onto the roller support axle. During this
process, check to endure that the roller support axle and roller
support fit together properly.
Secure the pump head 4with the two nuts 3.8
It is expedient to open the front cover forwards: this enables the
pump’s base plate with the fastening screws to be secured
from inside.
Refit the peristaltic pump hose:
9 Insert moving belt 1with the peristaltic pump hose in the pump head;
using the handles, press the moving belt together while at the same
time turning the S-clip 2counterclockwise until it engages.
Start the sample gas cooler again:
10 Switch power supply to sample gas cooler on.
Replacing Pressure
Rollers and Springs
(see Fig. 6)
11 The sample gas flow should only be restarted after the lead time
period.
Continued on next page

42/23-55 EN Rev. 1 SCC-C Sample Gas Cooler Operator’s Manual 19
Replacing Peristaltic Pump Pressure Rollers and Springs, continued
Fig. 6
Peristaltic Pump,
Roller Support
3
4
1
2
5
7
6
8
1Moving Belt
2S-Clip
3Nuts for Securing the Pump Head (x 2)
4Pump Head
5Roller Support
6Pressure Springs (x 4)
7Roller Axle
8Pressure Roller (x 2)

20 SCC-C Sample Gas Cooler Operator’s Manual 42/23-55 EN Rev. 1
Clean Condenser Fins
When Should the
Condenser Fins be
Cleaned?
Cooling performance is reduced by the accumulation of dust on the condenser
fins.
For this reason the condenser fins should be inspected regularly and cleaned if
any dust deposits are visible.
Step Action
1
Stop the sample gas supply and shut off the sample gas cooler
power supply.
2 Undo the 4 fastening screws on the front cover and open it forwards
(the front cover remains attached in the rebate of the base plate).
3 Undo the 8 fastening screws on the covering hood, release the cable
lug of the protective leads from the quick terminal on the inside of the
covering hood, then lift the covering hood off.
4 Carefully blow compressed air onto the condenser fins 1.
5 Press the cable lug of the protective leads onto the quick terminal on
the inside of the covering hood, put the covering hood in place (taking
care not to trap any cables or hoses), and secure it in place with the 8
screws.
6 Close front cover (taking care not to trap cables or hoses), and fasten
it with the 4 screws.
7 Switch power supply to sample gas cooler on.
Cleaning the
Condenser Fins
(see Fig. 7)
8 The sample gas flow should only be restarted after the lead time
period.
Fig. 7
Condenser
1
1Condenser Fins
