ABB TGS 40 User manual

Operating Instructions
42/14-50 EN
Position Transmitter TGS 40 (RAM)

2 Position Transmitter TGS 40 (RAM) 42/14-50 EN
Position Transmitter TGS 40 (RAM)
Operating Instructions
Document no. 42/14-50 EN
Date of issue: 10.05
Manufacturer:
ABB Automation Products GmbH
Borsigstr. 2
63755 Alzenau
Germany
Tel: [phone]
Fax: [phone]
[email protected]
© Copyright 2005 by ABB Automation Products GmbH
Modifications reserved
This document is subject to copyright. It is intended to help the user operate the equipment safely and efficiently.
The content may not be copied or reproduced either in part or in full without the prior consent of the copyright
owner.

42/14-50 EN Position Transmitter TGS 40 (RAM) 3
Table of contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page
Important information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.1 General safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.2 Safety instructions applicable to all device variants . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.3 Declaration of conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.1 Application. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.2 Function and system design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.3 Functional diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.4 Connection diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.5 Dimensional drawings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Safety instructions
4 Position Transmitter TGS 40 (RAM) 42/14-50 EN
Important information
Symbols
In order that you can make the best use of this document and to ensure safety during commissioning, operation
and maintenance of the equipment, please note the following explanation of the symbols used.
Explanation of the symbols used.
As well as the instructions in this document, you must also follow the generally applicable accident prevention
and safety regulations.
If the information in this document is insufficient in any situation, please contact our service department, who will
be happy to help you.
Please read this document carefully before installation and commissioning.
1 Safety instructions
1.1 General safety instructions
The devices were designed, produced and tested in accordance with IEC 1010-1 (corresp. to EN 61010-1 and
DIN VDE 0411 Part 1 "Safety requirements for electrical measurement, control and laboratory equipment"), CE-
certified, and delivered in a safe condition.
CAUTION
When handling these devices (during transport, storage, installation, commissioning, operation, main-
tenance, and de-commissioning) observe these operating instructions and the information on all type
plates, labels and safety instructions attached to the devices.
The regulations, standards and directives referred to in these operating instructions are applicable in Germany.
When using the devices in other countries, the relevant national regulations, standards and directives must be
observed.
1.2 Declaration of conformity
The requirements of the European directive 94/9/EC are met.
The product conforms with the European Directive (EMC) 89/336/EEC and its amendments and the Low-Voltage
Directive 73/23/EEC.
Symbol Signal Word Definitions
DANGER DANGER indicates an imminently hazardous situation which, if not avoided,
will result in death or serious injury.
(High level of risk.)
WARNING WARNING indicates a potentially hazardous situation which, if not avoided,
could result in death or serious injury.
(Medium level of risk.)
CAUTION CAUTION indicates a potentially hazardous situation which, if not avoided,
could result in minor or moderate injury.
(Low level of risk.)
NOTICE NOTICE indicates a potentially harmful situation which, if not avoided,
may result in damage of the product itself or of adjacent objects.
(Damage to property)
IMPORTANT IMPORTANT indicates useful hints or other special information which, if not
observed, could lead to a decline in operating convenience or affect the
functionality.
(Does not indicate a dangerous or harmful situation.)

Description
42/14-50 EN Position Transmitter TGS 40 (RAM) 5
2 Description
2.1 Application
Conversion of the angular position of a shaft into a load-independent DC signal e. g. for position measurement
on relief valves with high temperature.
2.2 Function and system design
The angular position is transmitted from the sensor shaft, e.g. of a relief valve, by a magnetic coupling in a non-
contacting manner to the transmitter. The magnetic coupling consists of a magnet, mounted on the sensor shaft
and an iron loop situated in the instrument. The loop is attached to a shaft which rotates in 2 ball bearings and
follows the rotation of the magnet and thus the angular position of the shaft. A mechanical coupling transmits the
rotation of the shaft of the iron loop to the shaft of the angular position transmitter, which produces a DC signal
of 0...20 mA or 4...20 mA proportional to the angular position.
The sensor system consists of an ASIC with integral Hall elements to convert the rotary motion of an external
permanent magnet into a proportional sine-cosine output signal for the range of 360°.
Integral electronic circuits of different layouts transform this signal into digital or analog data for transmission to
displays or control units.
RAM36
RAM series has no moving parts within its housing. The system is activated by an external stainless steel actu-
ator incorporating a small permanent magnet. The actuator must be fixed to the driving shaft of a rotating device.
This layout has no friction. It requires no individual torque. The housings are in aluminium.
2.3 Functional diagram
Fig. 2-1 Functional diagram
Mounting specification
Position tolerances for the magnet.
• Vertical deviation: ≤ 1± 0.1 mm
• Coaxial deviation: ≤0.1 mm
• A sloping position of the actuator will impair
the measurement signal.
• After removing the actuator the encoder will
deliver an arbitry measurement signal.
Hall Sensor
Magnet
NS
D
A
Sine-Cosine Signal
Interpolator
+V
s
±
10 V
0...10 V
4...20 mA
0...20 mA
- V (0 V)
s

Description
6 Position Transmitter TGS 40 (RAM) 42/14-50 EN
2.4 Connection diagrams
Fig. 2-2 Connection diagram
2.5 Dimensional drawings (dimensions in mm)
2 x Büschelstecker/Brush pin 4 mm (schwarz/black)
Bürklin-Bestellnr./Order No.: 15 F 230
1 x Kupplung/Coupling
∅
∅4 mm (schwarz/black)
Bürklin-Bestellnr./Order No.: 20 F 100
Kabellänge / cable length: 0.5 m
(Bestell-Nr./Order No.: 92 F 6751)
Ansicht auf die Lötanschlussenden des Steckereinsatzes
Rear view of connector soldering lugs
HAN 7D
Stecker STH8GS10 / Buchse
Connector STH8GS10 / Socket
HAN 7D
Stecker STH8GP09 / Stifte
Connector STH8GS09 / Pin
nicht belegt / not connected
nicht belegt / not connected
nicht belegt / not connected
nicht belegt / not connected
nicht belegt / not connected
weiß + braun
white + brown
grün / green
gelb / yellow
(0 V)
(24 V DC)
(I )
mA
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
-U
S
+U
S
+I
A
(- V )
S
(+ V )
S
(+ I )
0
6
5
4
1
7
8
2
3
6
5
41
78
2
3
ø18
103
149
34
12
69 181
284.5
10
16.5
54
ø34 H8 ø34 H8
ø40 r7 ø40 r7
ø56r6 ø75
52
4
4
14.5
284
291
Z-17681 EN
Pressure jack
Pressure jack
version SWR
Pressure jack
version HMN and DWR
Flange 1
Flange 2
Direction of sight for
direction of ratation
Plug connestor HAN 7 D
Harting Co.
Mounting position
Mounting position A1) Iron loop Mounting position B1)
vertical
1) Looking towards the flange
Position of the mag-
net and of the
plug with
IA= 0 or 4 mA
horizontal
vertical

Technical data
42/14-50 EN Position Transmitter TGS 40 (RAM) 7
3 Technical data
Analog outputs
0 (4) ...20 mA, – 9 Bit/360°
The electro-magnetic sensor system of the encoder is complet-
ed by a 9 Bit D/A concverter to transform the angular position
into an analog signal of either 0 (4) to 20 mA. If not otherwise
specified the transducer will be supplied with a measuring
range of 0 to 360° and CW signal sense, i.e. increasing out-
put signal with view on shaft end, when turning clockwise.
Electrical data of all outputs
Resolution
9 Bits/360°
Measuring range
360° , 180° or 90°
(other ranges upon request)
Output signals
A: 0...20 mA
B: 4...20 mA
Linearity
< ±2 % based on 360°
Temperature drift
0.02 %/K typ.
Code sense
CW* (CCW at option)
Supply voltage ranges
outputs A, B 24...30 V DC
Supply current
50 mA typ./70 mA max.
* Increasing signal when turning clockwise with view on flange side.
Current ouputs A and B
Tolerances 0 mA ±150 µA typ./±250 µA max.
4 mA ±150 µA typ./±250 µA max.
20 mA ±150 µA typ./±250 µA max.
Load resistance
0...1000 Ω(US= 24 V DC ...30 V DC)
Mechanical data
Environmental data
Series RAM36
Diameter of shaft n.a.
Magnetic actuator for
shaft diameters 5.1 + 0.05 mm
Operating speed 20.000 rpm
Mass including lead and
D-sub plug
100 g approx.
+ 12 g actuator
Lead exit and
lead diameter
radially
∅5 mm approx.
Series RAM36
Behavior within
magnetic fields
Up to = 0.1 Tesla
without influence (all 3axis)
Operating temperature
range
- 25 °C...+ 85 °C
(+ 125 °C at option)
Storage temperature range - 20 °C...+70 °C
(dependent on packing material)
Resistance against shock 2000 m/s2; 11ms
to DIN EN 60068-2-27
Resistance against vibra-
tion
10 Hz...2000 Hz; 500 m/s2
to DIN EN 60068-2-6
Protection grades Front plate IP 68
Housing IP 64
