Abilica Stream FC VIII User manual

Stream FC VIII
Art.nr. 300 021
Model
KH
-
741
A2

2
INNHOLD / INNEHÅLL / CONTENTS
3
Deletegning / Sprängskiss / Parts drawing
4
Monteringsdeler / Parts details
5
Deleliste / Dellista / Parts List
10
Montering / Assembly
16
Viktig informasjon
17
Betjening av computeren
21
Reklamasjonsvillkår
22
Kontaktinformasjon
23
Viktig information
24
Betjäning av datorn
28
Reklamationsvillkor
29
Kontaktinformation
30
Important information
31
Operating the console
35
Warranty regulations
36
Conatct information

3
DELETEGNING / SPRÄNGSKISS / EXPLODED VIEW
8
7
9
318 22
17
274
31
9b 20
7
6
33
103
9a
25L
5R
35
62
12R
23L
7113 75 840 63
12L
51
958934
50
70 47
85 56
63
74A 74B
4172
42
32L
2173
727259
100
93R
66147678388376
404641
869
7
9
79 39
24 6188
32R
54 1581679
52R
52L
10
9
7
6
57
1
43 96 26
68
87
55
53
84
63
67
25 30 29
93L
11L
65
11R
19
90
77
82
58
104
63
100
80R
23R
100
100
63
91 82
104
98
97
9
7
6
72
26
28
64
101
9
7
6
9c
14 7 59 5858 59
40 8
80L
105
37
99
36L 36R
92 99
49
45
106102
4844 86
108

4
MONTERINGSDELER / MONTERINGSDELAR / ASSEMBLY PARTS
12
19
3
21
18
10 12L&R
67& 68
64
23L&R
49
11L&R
93L&R
74A&B
52L&R
x1
x1 x1
x2
x1
x1
x1 x1
x1
x1
x1
x2 x2 x2
x1
M8*90L
M8*80L
9
9a
9b
40
ST4*15L
63
M5*15L
100
M8*20L
73 M6*15L
D26*D19.5
M8*20L
D21*D16
x2
x2
D21*D8.5
D22xD8.5
D15.4xD8.2
M8x15L
D24*D10*0.4T
8
71
59
6
20
7
41
x4
x6
x20
x2
x2
x8
D25xD8.5
46
x4
x15
x8
x2
x2
x24
x20
x1
x2
x1
x2
22
81
x1
104
ST4*15L
x2

5
DELELISTE / DELLISTA / PARTS LIST
PART NO. DESCRIPTION MATERIAL SPECIFICATION Q’TY
1 Main frame 1
2 Front stabilizer Q195 D76*1.5T*580L 1
3 Sliding beam 2
4 Oval cap PE 40*80*33 2
5L Left movable foot cap PP D76*120L 1
5R Right movable foot cap PP D76*120L 1
6 Curved washer Q235A D22xD8.5x1.5T 20
7 Spring washer 70# D15.4xD8.2x2T 32
8 Flat washer Q235A D21*D8.5*1.5T 12
9 Allen bolt 35# M8x1.25x20L 24
9a Square neck bolt 35# M8x1.25x90L 2
9b Square neck bolt 35# M8*1.25*80L 2
9c Allen bolt 35# M8x1.25x15L 4
10 Handlebar post tube 1
11L Supporting tube for left pedal 1
11R Supporting tube for right pedal 1
12L Supporting tube for left movable
handlebar
1
12R Supporting tube for right movable
handlebar
1
13 Bearing GCr15 #99502ZZ 4
14 Flat washer Q235A D16xD8.5x1.2T 8
15 Mushroom side cap PVC D1 1/4"*29L 2
16 Idle wheel PP D23.8xD38x24 1
17 Nut Q235A M10*1.5*10T 2
18 Slide beam connecting tube 1
19 Rear stabilizer 1
20 Cup nut Q235A M8x1.25x15L 4
21 Pedal set PP 350*140*60 2

6
22 Adjustable round wheel Q235A+ABS D59*M10*40L 2
23L Left upper cover ABS717 80*55*87 2
23R Right upper cover ABS717 80*50*87 2
24 Anti-loose nut 35# M10*1.25*7T 2
25 Motor 1
26 C ring 65Mn D22.5*D18.5*1.2T 2
27 Lock sheet Q235A 44.8*9*2.5T 2
28 Adjustable round wheel Q235A+ABS D27*M8*25L 2
29 Upper computer cable 800L 1
30 Lower computer cable 800L 1
31 Round side cap PVC D60*11,DOP40% 2
32L Left pedal welding set 1
32R Right pedal welding set 1
33 Crank welding set 2
34 Nut Q235A M8*1.25*8T 1
35 Poly belt 460 PJ6 1
36L Left chain cover HIPS 757.3*558.1*73.6 1
36R Right chain cover HIPS 757.3*558.1*69.2 1
37 Magnetic system D274*120 1
38 Movable wheel D71.5*24 2
39 Side cap PVC D36x14 2
40 Hex bolt 35# M8x1.25x20 6
41 Flat washer NL66 D10*D24*0.4T 6
42 Axle Q235A D19*44L 2
43 Bearing #6004ZZ 2
44 Adaptor 9VA 1
45 Round magnet M02 1
46 Flat washer Q235A D25xD8.5x2T 2
47 Flat washer NL66 D10*D24*0.4T 2
48 Tension cable D1.5x400 1

7
49 Upper protective cover ABS 1
50 Plastic cap PVC D3*30L 2
51 Anti-loose nut Q235A 3/8"-26UNFx6.5T 2
52L Left handlebar set 1
52R Right handlebar set 1
53 Foam (HDR) NBR D30x3Tx500L 2
54 Foam (HDR) NBR D30x4Tx125L 2
55 Mushroom side cap PVC D1 1/4"*45L 2
56 Spring 72A D3*D17*59L 1
57 Hex bolt 35# M6x1.0x15L 4
58 C ring 65Mn D21.5xD17.5x1.2T 6
59 Waved washer 65Mn D26*D19.5*0.3T 6
60 Bushing F101J D20*D14*11.5T 1
61 Crank axle welding set 1
62 Poly belt NL+fiber D305x19.5 1
63 Screw 10# ST4*1.41*15L 15
64 Computer SM-2580-71 1
65 Handle pulse PE18 2
Handle pulse cable 600L 2
66 Allen bolt 35# M8x1.25x50L 2
67 Left computer bracket HIPS 113.5*60*252.1 1
68 Right computer bracket HIPS 113.5*63.5*252.1 1
69 Bearing box for pedal 2
70 Idle wheel fixing plate Q235A 154*62.2*5T 1
71 Waved washer 65Mn D21xD16x0.3T 2
72 Bushing D19.15x(D25.6x32)xL(17+3) 14
73 Bolt Q235A M6*1*15L 4
74A Cardan axle cover (left) PS 91.5*37*72 2
74B Cardan axle cover (right) PS 91.5*40*72 2
75 C ring 65Mn S-16(1T) 2

8
76 Cone Washer Fe D14*D8*4 4
77 Flat washer Q235A D26*D21*1.5T 1
78 Bearing GCr15 608 ZZ 4
79 Crank cover PS 356.6*197 2
80L Reinforcing plate for left pedal 1
80R Reinforcing plate for right pedal 1
81 Handlebar 1
82 Nut Q235A M8*1.25*8T 3
83 Bushing Fe D17.9*10L 2
84 cable cap PVC D4*D12*13 2
85 Nut Q235A M10x1.5x10T 1
86 Sensor cable 150L 1
87 Computer fixing plate NL 120*110*2.5T 1
88 Nut Q235A M6x1.0x6T 4
89 Nut Q235A M8*1.25*6T 1
90 Axle cover PVC D42x11.3 2
91 Allen bolt 35# M8*1.25*45L 1
92 Pin ABS D6*26.5*7.7 4
93L Rear axle cover (left ) PS 91.5*37*72 2
93R Rear axle cover (right) PS 91.5*41*72 2
94 Hex bolt 35# M8*25 1
95 Flat washer Q235A D21*D8.5*1.5T 1
96 Waved washer 65Mn D27*D21*0.3T 1
97 Pedal axle cap TPR D42*20L 4
98 Wheel axle cover D32.5*20L 4
99 Screw 10# ST4.2x1.4x20L 8
100 Bolt Q235A M5*0.8*15L 8
101 Bolt M5*0.8*10L 4
102 Screw 10# ST4.2x1.4x15L 4
103 Screw 10# ST4*1.41*15L 4

9
104 Screw 10# ST4*1.41*15L 2
105 Inner tube PE D71.5*108L 1
106 Electric cable 150L 1
108 Bolt Q235A M5*0.8*15L 2
Allen spanner 35# M6 2
Spanner Q235A 121*D6 1

10
MONTERING / ASSEMBLY
8
7
9
3
18 22
19
9a
2
1
6
7
20
9b 20
7
619
9
7
6
X 4
M8*20L
M8*90L
M8*80L
M8*20L
X 6
X 2
X 2
9
9
9a
9b
SET-1
9
7
6
8
6
6
