Ackuretta SOL User manual

Quick Start Guide
2021/06
www.ackuretta.com
Setting Up Wi-Fi
You can easily operate your SOL from your computer. You can upload prints directly,
and track print status. To set up your Wi-Fi connection:
1. Go to Network. The Wi-Fi tab is selected by default.
2. Press the Choose a Network button, select a network and key in the password.
The IP address appears on screen.
3. Make a note of the printer IP Address.
4. Select your Wi-Fi network.
Updating Firmware
Ackuretta is always adding new resins and improving functionality. If you are connected to
the Internet, check for the latest firmware:
1. Go to Settings
2. Select Update
3. Press Update firmware online
Print
You can print either over Wi-Fi or from your USB device.
1. Go to Print
2. Select USB or Computer, depending on your
location of your file
3. Choose your IBF file
4. Change your material setting, if necessary
5. Press Print
Documentation and Support
For the full set of SOL documentation, go to:
https://ackuretta.com/sol/
For community feedback, see our Ackuretta’s User Group on Facebook:
https://www.facebook.com/groups/2164055477166718/

Package Contents
Ethernet Cable
Vat (×2)
Build Platform
Hex Key
Wi-Fi Dongle
SOL 3D Printer
Power Cable
Product Specifications
Machine Size 271.3 mm (W) x 292 mm (L) x 416.8 mm (H)
Weight 15 kg approx.
Print Size 128 x 80 x 140 mm
XY Resolution 49 μm
Slice Thickness 30 - 150μm
Resin Wavelength 385 - 405 nm
Power Supply 110 - 240V AC, 50-60Hz
Monochrome LCD Panel
3D Print Technology
Setup Guide
Environment
Operate your SOL in a temperature-
controlled room, between 18°- 25°C (64°- 77°F).
Ackuretta also recommends using UV-filtered LED lights in
your workspace for both printing and cleaning.
Warning
Do not allow any resin or residue to come into contact with the hood on your printer
because 3D printing resins have a corrosive effect on acrylic.
Software
Download and install the Alpha 3D software from the
Ackuretta website:
https://ackuretta.com/sol/
Unboxing
1. Remove the cables, hex key, two boxes, and
packaging from the top and put them in a
safe place.
2. Lift your printer out by the handles.
3. Secure your printer by the base to remove it
from its internal packaging.
Side Boxes
There are four small boxes in the package with the
following contents:
VAT:2x vats (one vat in place on the printer and another
with the accessories)
CABLE and TOOLS:1x ethernet cable, 1x power cable and
1x hex key (Allen wrench)
