ACME Ellipsoidal User manual

CONTENTS
1. Safety Instructions ......................................................................................... 2
2. Technical Specifications ................................................................................. 4
3. How To Set The Unit....................................................................................... 7
3.1 Control Panel ........................................................................................... 7
3.2 The Unit Construction .............................................................................. 8
3.3 Installation ............................................................................................... 8
4. Main Function................................................................................................ 9
5. Control By Universal DMX Controller ........................................................... 14
5.1 DMX512 Connection.............................................................................. 14
5.2 Address Setting ...................................................................................... 15
5.3 DMX512 Configuration........................................................................... 16
6. Troubleshooting........................................................................................... 17
7. Fixture Cleaning ........................................................................................... 17
1G

1. Safety Instructions
WARNING
Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that
they also receive this instruction manual.
Important:
Damages caused by the disregard of this user manual are not subject to warranty. The dealer will
not accept liability for any resulting defects or problems.
Unpack and check carefully that there is no transportation damage before using the unit.
This product is for indoor use only. Use only in a dry location.
DO install and operate by qualified operator.
DO NOT allow children to operate the fixture.
Use safety chain when fixing the unit. Handle the unit by carrying its base instead of head only.
The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent
surfaces.
Be sure that no ventilation slots are blocked, otherwise the unit will be overheated.
Before operating, ensure that the voltage and frequency of power supply match the power
requirements of the unit.
It’s important to ground the yellow/green conductor to earth in order to avoid electric shock.
Minimum ambient temperature TA: 0℃. Maximum ambient temperature TA: 40℃.
DO NOT connect the device to any dimmer pack.
Make sure there are no flammable materials close to the unit while operating to avoid fire
hazard.
Examine the power wires carefully; replace them immediately if there is any damage.
Avoid any inflammable liquids, water or metal objects entering the unit. Once it happens, cut
off the mains power immediately.
DO NOT operate in dirty or dusty environment, do clean fixtures regularly.
DO NOT touch any wire during operation as there might be a hazard of electric shock.
Avoid power wires together twist other cables.
Please read the instruction carefully which includes important information about
the installation, usage and maintenance.
2G

Disconnect mains power before fuse replacement or servicing.
Replace fuse only with the same type.
In the event of serious operating problem, stop using the unit immediately.
Never turn on and off the unit time after time.
The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly damaged.
DO NOT open the unit as there are no user serviceable parts inside.
Never try to repair the unit by yourself. Repairs carried out by unskilled people can lead to
damage or malfunction. Please contact the nearest authorized technical assistance center if
needed.
Disconnect the mains power if the fixture is has not been used for a long time.
DO use the original packing materials before transporting it again.
DO NOT look directly at the light while the LED is on.
DO NOT start on the unit without LED enclosure or when housing is damaged.
Installation:
The fixture should be mounted via its Omega Quick Release Clamp bracket. Always ensure that the
unit is firmly fixed to avoid vibration and slipping while operating and make sure that the structure
to which you are attaching the unit is secure and is able to support a weight of 10 times of the
fixtures weight. Always use a safety cable that can hold 12 times of the weight of the fixture when
installing.
The equipment must be installed by professionals. It must be installed in a place where is out of the
reach of people and no one can pass by or under it.
3G

2. Technical Specifications
Power Voltage:
AC 100~240V, 50/60Hz
Power Consumption:
335W
Light Sources:
HD320-B (E-300 MB CW)
HD320-A (E-300 MB WW)
HD320 (E-300 MB NW)
Color Temperature:
5600±200K/3100±150K/4000K±150
Optical:
CRI: WW≥90, CW≥85
CQS: WW≥91, CW≥88
TLCI: WW≥94, CW≥90
Control:
DMX Channel: 1/2D /2 Channels
Protocols: DMX, Primary/Secondary, manual dimmer
Firmware Upgrade via DMX link
Construction:
Display: LCD display
Data In/Out: 3-pin & 5-pin XLR
Power In/Out: Power connector in/out
Protection Rating: IP20
Features:
Lens Options: 5°/11°/14°/19°/26°/36°/50°/70°
Super smooth and uniform flat light
Clear image and sharp edge
Smooth dimmer from 0% to 100%; Strobe effect and gradients effect
High-efficient cooling system to expand LED lifespan
Low noise under 25dB @1m
4G

Dimension/Weight:
5°: 378x1155x524mm, 9.6kgs
14.9"x45.5"x20.6"in, 21.2lbs
11°/14°/19°: 276x872x524mm, 9.6kgs
10.9"x34.3"x20.6"in, 21.2lbs
26°/36°: 276x712x524mm, 9.1kgs
10.9"x28"x20.6"in, 20.1lbs
50°/70°: 276x637x524mm, 9.1kgs
10.9"x25"x20.6"in, 20.1lbs
5G

Photometrics Diagram:
6G

3. How To Set The Unit
3.1 Control Panel
1. DISPLAY: To show the various menus and the selected function
2. LED:
PRIMARY
On
Primary Mode
SECONDARY
On
Secondary Mode
DMX
On
DMX input present
3. Button:
MENU
To enter into move backward or leave the menu
UP
To go backward to move up in the menu
DOWN
To go forward to move down in the menu
ENTER
To perform the desired functions
4. DIMMER: Manually adjust the dimmer value
5. MAINS IN: To connect to supply power
6. MAINS OUT: To connect to the next fixture
7. POWER SWITCH: Turns on/off the power
8. FUSE(T 6.3A): Protects the unit from over-voltage or short circuit
9. DMX IN:For DMX512 link, use 3/5-pin XLR cable to link the unit and DMX controller
10. DMX OUT: For DMX512 link, use 3/5-pin XLR cable to link the next units
11. ETHERNET: Transfers fixture’s information to a main controller
7G

3.2 The Unit Construction
3.3 Installation
1 2
Loosen the two screws on the Main Body (MB) and put the Framing System into the MB, then turn
the Framing System right .Tighten the two screws to fix the Framing System.
1. Lens Module
2. Framing System
3. Bracket
4. Main Body
5. Clip for Gel Holder
(Standard/Optional)
6. Gobo Slot
8G

3 4
Put the Lens Module into the Framing System and tighten the Lens Module into the Framing System
with two screws.
4. Main Function
Turn on the unit, press the MENU button into menu mode, and press the UP/DOWN button until
the required function is shown on the monitor. Select the function by the ENTER button. Use the
UP/DOWN button to choose the submenu, press the ENTER button to store and automatically
return to the last menu. Press the MENU button or let the unit idle 30 seconds to exit menu mode.
The main functions are shown below:
9G

10G

DMX Address
To select the DMX Address, press the ENTER button to confirm. Use the DOWN/UP button to adjust
the address from 1 to 512. Once the address has been selected, press the ENTER button to setup, to
go back to the functions without any changes, press the MENU button again. Hold and press the
MENU button for one second or wait for 30 seconds to exit the menu mode.
DMX Channel
To select the DMX Channel, press the ENTER button to confirm. Use the DOWN/UP button to select
1 Ch, 2D Ch or 2 Ch.Once selected, press the ENTER button to setup, to go back to the functions
without any changes, press the MENU button again. Hold and press the MENU button for one
second or wait for 30 seconds to exit the menu mode.
Dimmer Speed
To select Dimmer Speed, press the ENTER button to confirm. Use the DOWN/UP button to select
Fast (dimmer open fast) or Smooth (dimmer open smooth). Once selected, press the ENTER button
to setup, to go back to the functions without any changes, press the MENU button again. Press and
hold the MENU button about one second or wait for 30 seconds to exit the menu mode.
Dimmer Curve
To select Dimmer Curve, press the ENTER button to confirm. Use the DOWN/UP button to select
Mode1, Mode 2, Mode 3 or Mode 4. Once selected, press the ENTER button to setup, to go back to
the functions without any changes, press the MENU button again. Press and hold the MENU button
about one second or wait for 30 seconds to exit the menu mode.
Optically Linear: The increase in light intensity appears to be linear as DMX value is increased.
Square Law:Light intensity control is finer at low levels and coarser at high levels.
Inverse Square Law: Light intensity control is coarser at low levels and finger at high levels.
S-Curve: Light intensity control is finger at low levels and high levels and coarser at medium levels.
11G

Pri./Sec. Mode
To select the Pri./Sec. Mode, press the ENTER button to confirm. Use the DOWN/UP button to
select Primary or Secondary.Once the mode has been selected, press the ENTER button to setup,
to go back to the functions without any changes, press the MENU button again. Hold and press the
MENU button for one second or wait for 30 seconds to exit the menu mode.
No DMX Status
To select the No DMX Status, press the ENTER button to confirm. Use the DOWN/UP button to
select Pri.Sec., Blackout or Last State. Once selected, press the ENTER button to setup, to go back
to the functions without any changes, press the MENU button again. Hold and press the MENU
button for one second or wait for 30 seconds to exit the menu mode.
Display Setting
To select the Display Setting, press the ENTER button to confirm. Use the DOWN/UP button to
select Backlight Intensity, Contrast Ratio, Backlight Auto Off, Display Inverse or Language.
Backlight Intensity
Select Backlight Intensity, press ENTER button to confirm. Use the DOWN/UP button to adjust
backlight intensity from 1 (dark) to 10 (bright), press ENTER button to store. Press MENU button
back to the last menu or let the unit idle 30 seconds to exit menu mode.
Contrast Ratio
Select Contrast Ratio, press ENTER button to confirm. Use the DOWN/UP button to adjust the
contrast ratio from 1to 30, press ENTER button to store. Press MENU button back to the last menu
or let the unit idle 30 seconds to exit menu mode.
Backlight Auto Off
Select Backlight Auto Off, press ENTER button to confirm. Use the DOWN/UP button to select No
(display always on) or Yes (display goes off 30 seconds after exiting menu mode), press ENTER
button to store. Press MENU button back to the last menu or let the unit idle 30 seconds to exit
menu mode.
12G

Display Inverse
Select Display Inverse, press ENTER button to confirm. Use the DOWN/UP button to select No
(normal display) or Yes (inverse display), press ENTER button to store. Press MENU button back to
the last menu or let the unit idle 30 seconds to exit menu mode.
Language
Select Language, press ENTER button to confirm. Use the DOWN/UP button to select English or
Chinese, press ENTER button to store. Press MENU button back to the last menu or let the unit idle
30 seconds to exit menu mode.
Manual Mode
To select the Manual Mode, press the ENTER button to confirm. Use the DOWN/UP button to select
the Strobe or Dimmer Value. Once selected, press the ENTER button to setup, use the DOWN/UP
button to change the value (0~255). Once selected, press the ENTER button to setup, go back to the
functions without any change, press the MENU button again. Press and hold the MENU button
about one second or wait for 30 seconds to exit the menu mode.
Fixture Information
To select Fixture Information，press the ENTER button to confirm. Use the DOWN/UP button to
select the LED Temp., Fixture Time or Firmware version.
LED Temp.
To select the LED Temp., press the ENTER button to confirm, and the display will show the
temperature of the fixture. To go back to the functions without any changes press the MENU button
again. Hold and press the MENU button for one second or wait for 30 seconds to exit the menu
mode.
Fixture Time
To select the Fixture Time, press the ENTER button to confirm and the display will show the number
of working hours of the unit. To go back to the functions without any changes press the MENU
button again. Hold and press the MENU button for one second or wait for 30 seconds to exit the
menu mode.
13G

Firmware Version
To select the Firmware Version, press the ENTER button to confirm and the display will show the
software version of the unit. To go back to the functions without any changes press the MENU
button again. Hold and press the MENU button for one second or wait for 30 seconds to exit the
menu mode.
Factory Setting
To select the Factory Setting, press the ENTER button to confirm, use the DOWN/UP button to
select No (keep the present setting) or Yes (the fixture will reset to factory settings and exit menu
mode). To go back to the functions without any changes press the MENU button again. Hold and
press the MENU button for one second or wait for 30 seconds to exit the menu mode.
5. Control By Universal DMX Controller
5.1 DMX512 Connection
14G

1. At last unit, the DMX cable has to be terminated with a terminator. Solder a 120-o h m 1/4 W
resistor between pin 2(DMX-) and pin 3(DMX+) into a 3-pin XLR-plug and plug it in the DMX-output
of the last unit.
2. Connect the unit together in a “daisy chain” by XLR plug cable from the output of the unit to
the input of the next unit. The cable cannot be branched or split to a “Y” cable. DMX 512 is a very
high-speed signal. Inadequate or damaged cables, soldered joints or corroded connectors can easily
distort the signal and shut down the system.
3. The DMX output and input connectors are pass-through to maintain the DMX circuit, when one
of the units’ power is disconnected.
4. Each lighting unit needs to have a DMX address to receive the data by the controller. The
address number is between 1-512.
5. The end of the DMX 512 system should be terminated to reduce signal errors.
6. 3 pin XLR connectors are more popular than 5 pins XLR.
3 pin XLR: Pin 1: GND, Pin 2: Negative signal (-), Pin 3: Positive signal (+)
5 pin XLR: Pin 1: GND, Pin 2: Negative signal (-), Pin 3: Positive signal (+), Pin4, Pin5 not used.
5.2 Address Setting
If you use a universal DMX controller to control the units, you have to set DMX address from 1 to
512 so that the units can receive DMX signal.
Press the MENU button to enter menu mode, select DMX Address, press the ENTER button to
confirm, the present address will blinking the display, use the UP/DOWN button to adjust the
address from 001 to 512, press the ENTER button to store. Press the MENU button back to the last
menu or let the unit idle 30 seconds to exit menu mode.
Please refer to the following diagram to address your DMX512 channel for the first 4 units.
Channel mode
Unit 1
Address
Unit 2
Address
Unit 3
Address
Unit 4
Address
1 channels 1 2 3 4
2D channels 1 3 5 7
2 channels 1 3 5 7
15G

5.3 DMX512 Configuration
Please refer to below configurations to control the fixtures
Attentions:
1. The unit will maintain the last condition until reset if you cut-off the DMX signal.
2. For the channel Function, keep the value for about 3 seconds, then the corresponding function
will take into effect.
1 Channel (Mode 1):
CHANNEL VALUE FUNCTIONS
1
000-255
DIMMER
0%

100%
2D Channels (Mode 2):
CHANNEL VALUE FUNCTIONS
1
000-255
DIMMER
0%

100%
2 000-255 DIMMER FINE
2 Channels (Mode 3):
CHANNEL VALUE FUNCTIONS
1
000-255
DIMMER
0%

100%
2
000-007
008-015
016-131
132-139
140-181
182-189
190-231
232-239
240-247
248-255
STROBE
Off
Open
Strobe Slow to Fast
open
Slow Open Fast Close
Open
Slow Close Fast Open
Open
Random strobe
Open
16G

6. Troubleshooting
Following are a few common problems that may occur during operation. Here are some
suggestions for easy troubleshooting:
A. The unit does not work, no light and the fan does not work
1. Check the connect power and main fuse.
2. Measure the mains voltage on the main connector.
3. Check the power on LED to see if it can be light up or not.
B. Not responding to DMX controller
1. DMX LED should be on. If not, check DMX connectors, cables to see if they are linked properly.
2. If the DMX LED is on and no response to the channel, check the address settings and DMX
polarity.
3. If you have intermittent DMX signal problems, check the pins on connectors or on PCB of the
unit or the previous one.
4. Try to use another DMX controller.
5. Check to see if the DMX cables run near or run alongside to high voltage cables that may cause
damage or interference to DMX interface circuit.
C. One of the channels is not working well
1. The stepper motor might be damaged or the cable connected to the PCB is broken.
2. The motor’s drive IC on the PCB might be out of condition.
7. Fixture Cleaning
The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically
to optimize light output. Cleaning frequency depends on the environment in which the fixture
operates: damp, smoky or particularly dirty surrounding can cause greater accumulation of dirt on
the unit’s optics.
Clean with soft cloth and use normal glass to clean liquid.
Always dry the parts carefully.
Clean the external optics at least every 20 days.
17G

18G

Innovation, Quality, Performance
