ACME MINI ELLIPSOIDAL 10 User manual

Specifications:
Power Voltage:
AC 85~127V, 50/60Hz
AC 175~264V, 50/60Hz
Power Consumption: 15W (E-10)
30W (E-40)
Light Source:
E-10 CW DXX: LTAW1202-012-007-5500
E-10 WW DXX: LTAW1202-012-007-3150
E-40 CW DXX: C117C1206-036-001
E-40 WW DXX: C117W1206-036-001
Color temperature:CW(5600K±150K)/WW(3200K±150K) (optional)
Beam Angle: 19°/26°/36°/50°
CRI≥95
Dimension/Weight: 273x128x194mm, 1.3kgs
10.7”x5”x7.6”in, 2.9lbs
273 128
194
1D

Photometric diagram:
Change The Gobo
At first, put the gobo by hand as the arrow into the gobo gel splint, and
insert the gobo gel splint into the slot of the unit, please turn the hand
knob to left or right in order to take out gobo gel splint.
Distance(m)
2 4 6 8
3375 858 375 211
19
。
26
。
Diameter(m) 0.68 1.34 2.01 2.68
1980 490 220 124
Diameter(m) 0.94 1.85 2.78 3.70
2D

The Color Gel Splint Installation
At first, please push the Lock Cap button by hand as the arrow, and move
away the Lock as the arrow, then insert the color gel splint into the inside
slot from topside, and fasten the lock.
Installation
Screw the clamp to the bracket via the screw and nut. Pull the safety-rope
through the fixture and over the trussing system or a safe fixation spot.
3D

Troubleshooting
The fixture does not work, no light
1. Check the connection of power and main fuse.
2. Measure the mains voltage on the main connector.
Fixture Cleansing
The cleaning must be carried out periodically to optimize light output.
Cleaning frequency depends on the environment in which the fixture
operates: damp, smoky or particularly dirty surrounding can cause greater
accumulation of dirt on the unit’s optics.
Clean with soft cloth using normal glass cleaning fluid.
Always dry the parts carefully.
Clean the external optics at least every 30 days.
4D

5D

Declaration of Conformity
We declare that our products (lighting equipments) comply with the
following specification and bears CE mark in accordance with the provision
of the Electromagnetic Compatibility (EMC) Directive 2014/30/EU.
EN 55032: 2015; EN 61000-3-2: 2014;
EN 61000-3-3: 2013; EN 55103-2: 2009.
&
Harmonized Standard
EN 60598-2-17: 1989+A2: 1991; EN 60598-1: 2015; EN 62471: 2008;
EN 62493: 2015; EN 62031: 2008+A1: 2013+A2: 2015.
Safety of household and similar electrical appliances
Part 1: General requirements
6D
