ACME Diamonds LS-1010 RGB User manual




Diamonds







LS‐1010RGB

UserManual
Pleasereadtheinstructioncarefullybeforeuse

1A
MENU

1.SafetyInstructions...........................................................................................................................2
2.TechnicalSpecifications...................................................................................................................3
3.Installation.......................................................................................................................................3
4.HowtoSettheUnit.........................................................................................................................4
4.1ControlPanel.................................................................................................................................4
4.2MainFunction................................................................................................................................4
5.HowtoControltheUnit..................................................................................................................6
6.DMX512Configuration....................................................................................................................6
7.DMX512Connections......................................................................................................................8
8.Troubleshooting...............................................................................................................................9
9.FixtureCleaning.............................................................................................................................10



2A
1.SafetyInstructions

WARNING

PleasekeepthisUserGuideforfutureconsultation.Ifyouselltheunittoanotheruser,besurethat
theyalsoreceivethisinstructionbooklet.
Unpackandcheckcarefullythereisnotransportationdamagebeforeusingtheunit.
Beforeoperating,ensurethatthevoltageandfrequencyofpowersupplymatchthepower
requirementsoftheunit.
It’simportanttogroundtheyellow/greenconductortoearthinordertoavoidelectricshock.
Theunitisforindooruseonly.Useonlyinadrylocation.
Theunitmustbeinstalledinalocationwithadequateventilation,atleast50cmfromadjacentsurfaces.
Besurethatnoventilationslotsareblocked.
Disconnectmainpowerbeforereplacementorservicing.
Makesuretherearenoflammablematerialsclosetotheunitwhileoperatingasitisfirehazard.
Usesafetycablewhenfixesthisunit.DONOThandletheunitbytakingitsheadonly,butalwaysby
takingitsbase.
MaximumambienttemperatureisTa:40℃.DONOToperateitwherethetemperatureishigherthan
this.
Unitsurfacetemperaturemayreachupto85℃.DONOTtouchthehousingbare‐handduringits
operation.Turnoffthepowerandallowabout15minutesfortheunittocooldownbeforereplacing
orserving.
Intheeventofseriousoperatingproblem,stopusingtheunitimmediately.Nevertrytorepairtheunit
byyourself.Repairscarriedoutbyunskilledpeoplecanleadtodamageormalfunction.Pleasecontact
thenearestauthorizedtechnicalassistancecenter.Alwaysusethesametypespareparts.
Pleasereadcarefullytheinstruction,whichincludesimportant
informationabouttheinstallation,usageandmaintenance.

3A
DONOTtouchanywireduringoperationashighvoltagemightbecausingelectricshock.

2.TechnicalSpecifications
Fourcontrolmodes:ILDA/DMX/SoundActive/AutoPlay;
Voltage:AC100V~240V，50/60Hz
Laserpowerconsumption:10W
Powerconsumption:102W
Scanningsystem：40KScanner
Scanningangle:±40°
Fuse:F3.15A
Dimension:373X370X193mm
Weight:12.5Kgs




3.Installation
Theunitshouldbemountedviaitsscrewholesonthebracket.Alwaysensurethattheunitisfirmly
fixedtoavoidvibrationandslippingwhileoperating.Andmakesurethatthestructuretowhichyouare
attachingtheunitissecureandisabletosupportaweightof10timesoftheunit’sweight.Alsoalways
useasafetycablethatcanhold12timesoftheweightoftheunitwheninstallingthefixture.
Theequipmentmustbefixedbyprofessionals.Anditmustbefixedataplacewhereisoutofthe
touchofpeopleandhasnoonepassbyorunderit.


4A
4.HowtoSettheUnit
4.1ControlPanel




○
1OLEDDisplay○ 2Knob
○
3SDCardPort○ 4KeySwitch:TheunitworkswhensetRUN.
○
5PowerInput/output○ 6Fuse
○
7MIC○ 8ILDAPort
○
9DMXInput/Output○ 10 PowerIndicator(Red);LaserIndicator(Green)
○
11 LightOutput


4.2MainFunction
TurntheknobPUSH/DIAL,selectanyofthegivenfunctions,presstheknobuntiltherequiredfunctionis
showingonthedisplay.Themainfunctionsareshownoverleaf:

5A

DMXFunctions
PresstheknobwhentheDMXFUNCTIONSshowonthedisplay,usetheknobtoselectDMXAddress,
DMXstateorExit.EnterDMXAddress,turntheknobtochangetheaddress,presstheknobtoconfirm.
EnterDMXState,selecttheHOLD/BlackOut/ShowMode,whenselectShowMode,theunitpreference
tosoundactive.Ifthesoundactivefunctionisclosed,theunitwillautorunbuilt‐inshow.ILDAsignal
controlpriortoDMXsignalcontrol.PressEXITtobacktothemenu.

ShowFunctions
PresstheknobwhentheShowFunctionsshowonthedisplay,usetheknobtoselectShoworExit.Enter
Show,turntheknobtoselectshow0toshow9,presstheknobtoconfirm.(Showfunctiononlyisvalid
whenselectShowModeinDMXfunctions.)SDcardshowpriortobuilt‐inshow.PressEXITtobackto
themenu.

SoundFunctions
PresstheknobwhentheSoundFunctionsshowonthedisplay,usetheknobtoselectSoundModeor
SoundSenseorExit.EnterSoundMode,usetheknobtoselectOnoroff,presstheknobtoconfirm.
ILDAsignalandDMXsignalcontrolpriortosoundactivemode.PressEXITtobacktothemenu.


6A
SDFunctions
PresstheknobwhentheSDFunctionsshowonthedisplay,usetheknobtoselectSDMode,SDFileor
Exit.EnterSDMode,usetheknobtoselectILDShow,PRGShoworNoSD,presstheknobtoconfirm.
EnterSDFile,selectthefileorfolder,presstheknobtoconfirm.PressEXITtobacktothemenu.

FigureFunctions
PresstheknobwhentheFigureFunctionsshowonthedisplay,usetheknobtoselectSize,PhaseSetor
Exit.EnterSize,usetheknobtoselectfiguresizefrom10to100,presstheknobtoconfirm.EnterPhase
Set,setthepositonofthefigure.PressEXITtobacktothemenu.

FixtureFunctions
PresstheknobwhentheFixtureFunctionsshowonthedisplay,usetheknobtoselectBackLights,
FixtureHours,Defaults,VersionorExit.EnterBacklights,usetheknobtoselectonoroff,pressthe
knobtoconfirm.EnterFixtureHours,therunningtimeoftheunitwillbeshowonthedisplay.Enter
Defaults,usetheknobtoselectYesornotorestorefactorysettingsornot.EnterVersion,theversionof
thesoftwarewillbeshowonthedisplay.PressEXITtobacktothemenu.

5.HowtoControltheUnit
1.ByILDA;
ConnecttheunittothecomputerwithILDAwireandcontrolthesoftwarebycomputerlaser;
Prioritytocontroltheunit:ILDA﹥DMX﹥Soundactive﹥Autoplay
2.ByuniversalDMXcontroller;
SettheDMXaddress,theunitwillbereadytoreceiveDMXsignal.
3.Soundactive;
Theunitwillrunshowbythesoundactive.
4.Autoplay;
Theunitwillautoplaywhennosignal.
6.DMX512Configuration
DMXChannel:

7A
ChannelValueFunction



1



Choose
Mode
0‐9Blackout
10‐49PRGMode
50‐99ILDMode
100‐149SoundactiveMode
150‐199AutoplayMode
200‐255ManualMode
2
Pattern/File
Select

0‐255
ManualModePRG/ILDMode
Patternchange
(Changepatternevery
3values)
Selectfile
3
Strobe/File
Select
0‐10NostrobeAutoPlayFileSelect
11‐255Autostrobe
4
PanMoving0‐125Positionselect
126‐155Repeatmovingfromlefttoright
156‐185Repeatmovingfromrighttoleft
186‐225Repeatmovingfromlefttoright
226‐245Autoplay
246‐255Soundactiveplay
5
TiltMoving0‐125Positionselect
126‐155Repeatmovingfromlefttoright
156‐185Repeatmovingfromrighttoleft
186‐225Repeatmovingfromlefttoright
226‐245Autoplay
246‐255Soundactiveplay
6
Zoom0‐10Noeffect
11‐87Manualadjust
188‐150Zoomin
151‐200Zoomout
201‐255Repeatzooming
7
Pan
Rotation
0Norotation
1‐128Manualadjust
129‐255Autorotation


8
Tilt
Rotation
0Norotation
1‐128Manualadjust
129‐255Autorotation


9
Centre
Rotation
0Norotation
1‐128Manualadjust
129‐192Counter‐clockwiserotation
193‐255Clockwiserotation


10
Slow
Drawing
0‐11Nofunction
12‐74Manualadjust
75‐104Autoslowdrawingfromslowtofast
105‐144Autoslowdrawingfromfasttoslow

8A
145‐184Repeatslowdrawing
185‐224Repeatslowdrawingfromslowtofastendtoend
225‐255Repeatslowdrawingfromfasttoslowendtoend


11
PanWaving0‐10Nofunction
11‐69Smallwave
70‐129Middlewave
130‐189Bigwave
190‐255Thebiggestwave


12
TiltWaving0‐10Nofunction
11‐69Smallwave
70‐129Middlewave
130‐189Bigwave
190‐255Thebiggestwave
13

ShowMode
0‐63NormalShowMode
64‐127LightspotShowMode
128‐191DivisionShowMode
192‐255SpotShowMode
14



Color 








RGB
0‐16White
17‐33Red
34‐50Green
51‐67Blue
68‐84Yellow
85‐101Purple
102‐118Cyan
119‐135White/Red/Green/Bluedivision
136‐152Blue/Yellow/Purple/Cyandivision
153‐169White/Red/Green/Blue/Yellow/Purple/Cyan
division
170‐186White/Red/Green/Blueflow
187‐203Blue/Yellow/Purple/Cyanflow
204‐220White/Red/Green/Blue/Yellow/Purple/Cyan
flow
221‐237Divisionshowaccordingtothebreakpoint
238‐255Soundactivechangecolor
15R
Dimmer
0‐5Fulllight
6‐255Brighttodim
16G
Dimmer
0‐5Fulllight
6‐255Brighttodim
17B
Dimmer
0‐5Fulllight
6‐255Brighttodim
7.DMX512Connections


9A

1. Ifyouusingacontrollerwith5pinsDMXoutput,youneedtousea5to3pinadapter‐cable.
2. Connecttheunittogetherina`daisychain`byXLRplugfromtheoutputoftheunittotheinputof
thenextunit.Thecablecannotbranchedorsplittoa`Y`cable.DMX512isaveryhigh‐speedsignal.
Inadequateordamagedcables,solderedjointsorcorrodedconnectorscaneasilydistortthesignal
andshutdownthesystem.
3. TheDMXoutputandinputconnectorsarepass‐throughtomaintaintheDMXcircuit,whenoneof
theunits’powerisdisconnected.
4. Eachlightingunitneedstohaveanaddresssettoreceivethedatasentbythecontroller.The
addressnumberisbetween0‐511(usually0&1areequalto1).
5. TheendoftheDMX512systemshouldbeterminatedtoreducesignalerrors.
6. 3pinXLRconnectorsaremorepopularthan5pinXLR.
3pinXLR:Pin1:GND,Pin2:Negativesignal(‐),Pin3:Positivesignal(+)
5pinXLR:Pin1:GND,Pin2:Negativesignal(‐),Pin3:Positivesignal(+),Pin4/Pin5:Notused.

8.Troubleshooting
Followingareafewcommonproblemsthatmayoccurduringoperation.Herearesomesuggestions
foreasytroubleshooting:
A.Theunitdoesnotwork,nolightandthefandoesnotwork
1. Checktheconnectionofpowerandmainfuse.
2. Measurethemainsvoltageonthemainconnector.
3. CheckthepoweronLED.
B.NotrespondingtoDMXcontroller
1. DMXLEDshouldbeon.Ifnot,checkDMXconnectors,cablestoseeiflinkproperly.

10A
2. IftheDMXLEDisonandnoresponsetothechannel,checktheaddresssettingsandDMXpolarity.
3. IfyouhaveintermittentDMXsignalproblems,checkthepinsonconnectorsoronPCBoftheunit
orthepreviousone.
4. TrytouseanotherDMXcontroller.
5. CheckiftheDMXcablesrunnearorrunalongsidetohighvoltagecablesthatmaycausedamageor
interferencetoDMXinterfacecircuit.
C.Oneofthechannelsisnotworkingwell
1. ThesteppermotormightbedamagedorthecableconnectedtothePCBisbroken.
2. Themotor’sdriveIConthePCBmightbeoutofcondition.

9.FixtureCleaning
Thecleaningofinternalandexternalopticallensesand/ormirrorsmustbecarriedoutperiodicallyto
optimizelightoutput.Cleaningfrequencydependsontheenvironmentinwhichthefixtureoperates:
damp,smokyorparticularlydirtysurroundingcancausegreateraccumulationofdirtontheunit’s
optics.
Cleanwithsoftclothusingnormalglasscleaningfluid.
Alwaysdrythepartscarefully.
Cleantheexternalopticsatleastevery20days.Cleantheinternalopticsatleastevery30/60days.











11A



























