ACME TB-1010QW II User manual

TB-1010QW II
User Manual
Please read the instruction carefully before use

CONTENTS
1. Safety Instructions ..................................................................................................2
2. Technical Specifications ..........................................................................................3
3. How To Set The Unit ...............................................................................................4
3.1 Control panel .................................................................................................... 4
3.2 Main Functions ................................................................................................. 5
4. How to Control the Unit ....................................................................................... 10
4.1 DMX 512 Connections .................................................................................... 10
4.2 DMX Controller............................................................................................... 11
4.3 DMX 512 Configurations.................................................................................12
5. Troubleshooting.................................................................................................... 15
6. Fixture Cleaning.................................................................................................... 16
1A

1. Safety Instructions
WARNING
Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they
also receive this instruction booklet.
Unpack and check carefully there is no transportation damage before using the unit.
Before operating, ensure that the voltage and frequency of power supply match the power
requirements of the unit.
It’s important to ground the yellow/green conductor to earth in order to avoid electric shock.
The unit is for indoor use only. Use only in a dry location.
The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent surfaces.
Be sure that no ventilation slots are blocked.
Disconnect main power before replacement or servicing.
Make sure there are no flammable materials close to the unit while operating as it is fire hazard.
Use safety cable when installing this unit. DO NOT handle the unit by taking its head only, but always by
taking its base.
Maximum ambient temperature is Ta: 40 degrees C. DO NOT operate it where the temperature is
higher than this.
Unit surface temperature may reach up to 70 degrees C. DO NOT touch the housing with bare-hands
during its operation. Turn off the power and allow about 15 minutes for the unit to cool down before
replacing or serving.
In the event of a serious operating problem, stop using the unit immediately. Never try to repair the
unit by yourself. Repairs carried out by unskilled people can lead to damage or malfunction. Please
contact the nearest authorized technical assistance center. Always use the same type spare parts.
DO NOT touch any cables during operation as high voltage may cause electric shock.
Please read the instructions carefully which includes important
information about the installation, operation and maintenance.
2A

Warning:
To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or moisture.
The housing and lenses must be replaced if they are visibly damaged.
Installation:
The fixture should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly
fixed to avoid vibration and slipping while operating and make sure that the structure to which you are
attaching the unit is secure and is able to support a weight of 10 times of the fixtures weight. Always use
a safety cable that can hold 12 times of the weight of the fixture when installing. The equipment must be
installed by professionals and it must be installed in a place where is out of the reach of people and no
one can pass by or under it.
2. Technical Specifications
Power Supply: AC 100~240V, 50/60Hz
Power Consumption: 130W
Power Cable Daisy Chains: 18 Fixtures Max. (230V, 50Hz)
10 Fixtures Max. (120V, 60Hz)
Light Source: 10×15W RGBW LEDs
Beam Angle: 10°
Weight: 10Kgs
Dimension: 953 × 104 × 112mm
112 mm
104 mm
3A

Distance(m)
2468
9227 4374 1025 57710 Lux°
Diameter(m)
1 0°
Photometrics Diagram
0 32.0 63.0.96 1 28.
3. How To Set The Unit
3.1 Control panel
1. DMX IN:
Water proof 3-pin XLR connectors for DMX 512 operation;
2. POWER IN:
Water proof connectors for power input;
3. Function Display:
Show the various menus and the selected functions;
4. Button:
MENU To select the programming functions
DOWN To go backward in the selected functions
4A

UP To go forward in the selected functions
ENTER To confirm the selected functions
5. POWER OUT:
Water proof connectors for power output;
6. DMX OUT:
Water proof connectors for DMX 512 operation, 3-pin XLR cable to output DMX signal;
3.2 Main Functions
To select any functions, press the MENU button until the required one is shown on the display. Select the
function by the ENTER button and the display will blink. Use the DOWN/UP button to change the mode.
Once the required mode has been selected, press the ENTER button to setup or it will automatically
return to the main functions without any change after idling one minute. Back to the functions without
any change press the MENU button.
The main functions are shown below:
Once you set to , after running in show mode for 5 minutes
without any change or restarting the unit, the key board become locked. Press the
ENTER button to enable the menu, the display will show , press the
UP/DOWN button until it shows , then press the ENTER to unlock.
5A

MENU
DMXADDRESS
CHANNEL MODE
SHOW MODE
BLACKOUT MODE
MANUAL TEST
WHITE BALANCE
PASSWORD
LOCK
DISPLAY INVERSION
NORMAL
AUTO TEST
LED DISPLAY
FIXTURE TEMPERATURE
FIXTURE USE HOURS
FIRMWARE VERSION
DIMMER SPEED
6A

DMX 512 ADDRESS
To select , press the ENTER button to show DMX ADDRESS on the display. Use the DOWN/UP
buttons to adjust the address from 1 to 512. Once the address has been selected, press the ENTER button
to setup. To go back to the functions without any changes press the MENU button again. Press and hold
the MENU button for about one second or wait for 7 seconds to exit the menu mode.
CHANNEL MODE
To select , press the ENTER button to show CHANNEL MODE on the display. Use the DOWN/UP
button to select 4, 4D, 4C or 40 channel modes. Once the mode has been selected, press the ENTER
button to setup. To go back to the functions without any changes press the MENU button again. Press
and hold the MENU button for about one second or wait for 7 seconds to exit the menu mode.
SHOW MODE
To select , press the ENTER button to show SHOW MODE on the display. Use the DOWN/UP
buttons to select (show 1) or … (show 16), and then press the ENTER button to confirm,
the (fade time) will blink on the display, use the DOWN/UP button to adjust the fade time (0 ~
255); and press the ENTER button again, the will blink to display, use the DOWN/UP button to
adjust the wait time (0 ~ 255). Press and hold the MENU button for about one second or wait for 7
seconds to exit the menu mode.
BLACKOUT MODE
To select , press the ENTER button to show BLACKOUT MODE on the display. Use the DOWN/UP
buttons to select (blackout) or (normal) mode. Once the mode has been selected, press
the ENTER button to setup. To go back to the functions without any changes press the MENU button
again. Press and hold the MENU button for about one second or wait for 7 seconds to exit the current
mode.
7A

MANUAL TEST
To select , press the ENTER button to show MANUAL TEST on the display. Use the DOWN/UP
button to select (red), (green), (blue), (white), (dimmer) or
(strobe) on the display. Once the mode has been selected, press the ENTER button to confirm. Use the
DOWN/UP buttons to specify a value for the chosen effect from 0to 255. To go back to the functions
without any changes press the MENU button again. Press and hold the MENU button for about one
second or wait for 7 seconds to exit the menu mode.
WHITE BALANCE
To select , press the ENTER button to show WHITE BALANCE on the display. Use the DOWN/UP
button to select (red), (green) or (blue). Once selected, press the ENTER button to
confirm .Use the DOWN /UP buttons to change its value (125 to 255). Once the address has been
selected, press the ENTER button to setup. To go back to the functions without any changes press the
MENU button again. Press and hold the MENU button for about one second or wait for 7 seconds to exit
the menu mode.
PASSWORD
To select , press the ENTER button to show PASSWORD on the display. Use the DOWN/UP buttons
to change the password (000 to 9999). Once the address has been selected, press the ENTER button to
setup. To go back to the functions without any changes press the MENU button again. Press and hold the
MENU button for about one second or wait for 7 seconds to exit the menu mode.
LOCK
To select , press the ENTER button to show LOCK on the display. Use the DOWN/UP buttons to
select (blackout) or (normal) mode. Once the mode has been selected, press the
ENTER button to setup. To go back to the functions without any changes press the MENU button again.
Press and hold the MENU button for about one second or wait for 7 seconds to exit the current mode.
8A

DISPLAY INVERSE
To select , press the ENTER button to show DISPLAY INVERSE on the display, and press the ENTER
button again, it will show the (inversion). To go back to the functions without any changes press
the MENU button.
AUTO TEST
To select , press the ENTER button to show AUTO TEST on the display and the unit will run a
self-test . To go back to the functions without any changes press the MENU button again. Press and hold
the MENU button for about one second or wait for 7 seconds to exit the current mode.
LED DISPLAY
To select , press the ENTER button to show LED DISPLAY on the display. Use the DOWN/UP button
to select (LED on) or (LED off) mode. Once the mode has been selected, press the
ENTER buttons to setup. To go back to the functions without any changes press the MENU button again.
Press and hold the MENU button for about one second or wait for 7 seconds to exit the current mode.
FIXTURE TEMPERATURE
To select , press the ENTER button to show the FIXTURE TEMPERATURE on the display and the
display will show the temperature of the unit. To go back to the functions without any changes press the
MENU button again. Press and hold the MENU button for about one second or wait for 7 seconds to exit
the menu mode.
FIXTURE USE HOURS
To select , press the ENTER button to show FIXTURE USE HOURS on the display and the display
will show the number of working hours of the unit . To go back to the functions without any changes
press the MENU button again. Press and hold the MENU button for about one second or wait for 7
9A

seconds to exit the current mode.
SOFTWARE VERSION
To select , press the ENTER button to show SOFTWARE VERSION on the display and the display
will show the version of software of the unit . To go back to the functions without any changes press the
MENU button again. Press and hold the MENU button for about one second or wait for 7 seconds to exit
the current mode.
4. How to Control the Unit
4.1 DMX 512 Connections
The DMX512 is widely used in intelligent lighting control, with a maximum of 512 channels.
1. Connect the fixture together in a “daisy chain” by XLR plug cable from the output of the fixture to the
input of the next fixture. The cable cannot be branched or split to a “Y” cable. Inadequate or
damaged cables, soldered joints or corroded connectors can easily distort the signal and shut down
the system
2. The DMX output and input connectors are pass-through to maintain the DMX circuit when one of the
units’ power is disconnected.
10A

3. At last fixture, the DMX cable has to be terminated with a terminator to reduce signal errors. Solder a
120Ω, 1/4W resistor between pin 2(DMX-) and pin 3(DMX+) into a 3-pin XLR-plug and plug it in the
DMX-output of the last fixture.
4. Each lighting fixture needs to have an address set to receive the data sent by the controller. The
address number is between 0-511 (usually 0 & 1 are equal to 1).
5. 3 pin XLR connectors are more popular than 5 pins XLR.
3 pin XLR: Pin 1: GND, Pin 2: Negative signal (-), Pin 3: Positive signal (+)
4.2 DMX Controller
Use universal DMX controller to control the units, you have to set DMX address from 1 to 512 channels so
that the units can receive DMX signal.
Press the MENU button, and the will blink on the display. Use the DOWN/UP button to change
the DMX512 address. Once the address has been selected, press and keep ENTER button pressed up to
when the display stops blinking or storing automatically one minute later. To go back to the functions
without any change press the MENU button again.
If you use please refer to the following diagram to address your DMX512 channel for the first 4 units.
11A

4.3 DMX 512 Configurations
4 Channels Mode:
CHANNEL VALUE FUNCTION
1
000-255
RED
0% ~ 100%
2
000-255
GREEN
0% ~ 100%
3
000-255
BLUE
0% ~ 100%
4
000-255
WHITE
0% ~ 100%
5 Channels Mode:
CHANNEL VALUE FUNCTION
1
000-255
RED
0% ~ 100%
2
000-255
GREEN
0% ~ 100%
3
000-255
BLUE
0% ~ 100%
4
000-255
WHITE
0% ~ 100%
5
000-255
DIMMER
0% ~ 100%
12A

7 Channels Mode:
CHANNEL VALUE FUNCTION
1
000-255
RED
0% ~ 100%
2
000-255
GREEN
0% ~ 100%
3
000-255
BLUE
0% ~ 100%
4
000-255
WHITE
0% ~ 100%
5
000-007
008-015
016-023
024-030
031-038
039-046
047-054
055-061
062-069
070-077
078-085
086-092
093-100
101-108
109-116
117-123
124-131
132-140
140-147
148-154
155-162
163-170
171-178
179-185
186-193
195-201
202-209
210-216
217-224
225-232
233-240
COLOR
OFF
Color 1
Color 2
Color 3
Color 4
Color 5
Color 6
Color 7
Color 8
Color 9
Color 10
Color 11
Color 12
Color 13
Color 14
Color 15
Color 16
Color 17
Color 18
Color 19
Color 20
Color 21
Color 22
Color 23
Color 24
Color 25
Color 26
Color 27
Color 28
Color 29
Color 30
13A

241-247
248-255
Color 31
Color 32
6
000-255
DIMMER
0% ~ 100%
7
000-007
008-015
016-131
132-139
140-181
182-189
190-231
232-239
240-247
248-255
STROBE
OFF
Open
Strobe, slow fast
Open
Slow open, fast close
Open
Slow close, fast open
Open
Random strobe
Open
40 Channels Mode:
CHANNEL VALUE FUNCTION
1
000-255
RED1
0% ~ 100%
2
000-255
GREEN1
0% ~ 100%
3
000-255
BLUE1
0% ~ 100%
4
000-255
WHITE1
0% ~ 100%
5
000-255
RED2
0% ~ 100%
6
000-255
GREEN2
0% ~ 100%
7
000-255
BLUE2
0% ~ 100%
8
000-255
WHITE2
0% ~ 100%
…
…
…
37
000-255
RED10
0% ~ 100%
38
000-255
GREEN10
0% ~ 100%
14A

39
000-255
BLUE10
0% ~ 100%
40
000-255
WHITE10
0% ~ 100%
5. Troubleshooting
Following are a few common problems that may occur during operation. Here are some suggestions for
easy troubleshooting:
Problem Possible Cause Action
The unit does not work,
no light.
Incorrect power cable
connection.
Check the connection of
power.
Incorrect mains voltage.
Measure the mains
voltage
on the main connector.
The unit does not
respond properly to the
DMX control.
Incorrect DMX cable
connection.
Check DMX connectors
and cables to see if link
properly. Repair or
replace damaged wires.
Incorrect address
assignment to the units.
Check the addresses of
the units and the protocol
settings.
Unfinished data
connection.
Insert a terminal plug in
the output jack of the last
unit of the connection.
It has been set up an
operating mode different
from the DMX mode
used.
Check the operating
mode set up.
Try to use another DMX
controller.
15A

6. Fixture Cleaning
The cleaning must be carried out periodically to optimize light output. Cleaning frequency depends on
the environment in which the fixture operates: damp, smoky or particularly dirty surrounding can cause
greater accumulation of dirt on the unit’s optics.
Clean with soft cloth using normal glass cleaning fluid.
Always dry the parts carefully.
Clean the external optics at least every 30 days.
16A

17A

Declaration of Conformity
We declare that our products (lighting equipments) comply with the
following specification and bears CE mark in accordance with the provision
of the Electromagnetic Compatibility (EMC) Directive 89/336/EEC.
EN55103-1: 2009 ; EN55103-2: 2009; EN62471: 2008;
EN61000-3-2: 2006 + A1:2009 + A2:2009; EN61000-3-3: 2008.
&
Harmonized Standard
EN 60598-1:2008 + All:2009; EN 60598-2-17:1989 + A2:1991;
EN 62471:2008; EN 62493: 2010
Safety of household and similar electrical appliances
Part 1: General requirements
18A

Innovation, Quality, Performance
