Find the Acromag / Xembedded / Xycom VPX4810CC at our website: Click HERE

VPX4810 / VPX4810CC / VPX4810REDI
VPX PCIe PMC/XMC 3U Carrier
USER’S MANUAL
ACROMAG INCORPORATED
30765 South Wixom Road
Wixom, MI 48393-2417 U.S.A.
Tel: [phone]
Fax: [phone]
Copyright 2017, Acromag, Inc., Printed in the USA.
Data and specifications are subject to change without notice.
8500908G

VPX4810 PCIe PMC/XMC 3U Carrier
USER’S MANUAL
Acromag, Inc. Tel: [phone] - 1 -
http://www.acromag.com
- 1 -
www.acromag.com
Table of Contents
GENERAL INFORMATION.....................................................................................................3
Key Features........................................................................................................................3
Software Support.................................................................................................................3
References...........................................................................................................................4
PREPARATION FOR USE.......................................................................................................5
Unpacking and Inspecting ....................................................................................................5
Card Cage Considerations ....................................................................................................5
Backplane..................................................................................................................................................... 6
Non-Isolation Considerations...............................................................................................6
Jumper Settings ...................................................................................................................6
Jumper Settings ........................................................................................................................................... 6
PMC Connector Pinout.........................................................................................................7
PMC Site Connector J1................................................................................................................................. 7
PMC Site Connector J2................................................................................................................................. 9
PMC Site Connector J3............................................................................................................................... 10
PMC Site Connector J4............................................................................................................................... 11
XMC Connector Pinout.......................................................................................................12
XMC Connector P5..................................................................................................................................... 12
VPX Backplane Connector Pinouts......................................................................................13
VPX P0 Connector-Power and System Controls......................................................................................... 13
VPX P1 Connector –PCIe ........................................................................................................................... 13
VPX P2 Connector –Rear I/O...................................................................................................................... 14
JTAG Connector –JTAG Header ..........................................................................................15
Installing and Removing PMC/XMC Modules......................................................................17
VPX4810 Air-Cooled................................................................................................................................... 17
VPX4810CC Conduction Cooled................................................................................................................. 19
VPX4810REDI VITA 48 ................................................................................................................................ 21

VPX4810 PCIe PMC/XMC 3U Carrier
USER’S MANUAL
Acromag, Inc. Tel: [phone] - 2 -
http://www.acromag.com
- 2 -
www.acromag.com
THEORY OF OPERATION................................................................................................... 23
Operation of the VPX4810 .................................................................................................23
I2C Bus and Temperature sensor........................................................................................23
LED’s ........................................................................................ Error! Bookmark not defined.
SERVICE AND REPAIR ........................................................................................................ 24
Preliminary Service Procedure ...........................................................................................24
Where to Get Help.............................................................................................................24
SPECIFICATIONS.................................................................................................................. 25
PHYSICAL...........................................................................................................................25
POWER REQUIREMENTS ....................................................................................................25
ENVIRONMENTAL ..............................................................................................................26
VPX Specifications .............................................................................................................27
PMC Specifications ............................................................................................................27
XMC Specifications ............................................................................................................27
Reliability Prediction..........................................................................................................27
Certificate of Volatility.......................................................................................................28
REVISION HISTORY ............................................................................................................ 29
All trademarks are the property of their respective owners.
You must consider the possible negative effects of power, wiring, component, sensor, or software failure in the design of
any type of control or monitoring system. This is very important where property loss or human life is involved. It is
important that you perform satisfactory overall system design and it is agreed between you and Acromag, that this is your
responsibility. The information of this manual may change without notice. Acromag makes no warranty of any kind
with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a
particular purpose. Further, Acromag assumes no responsibility for any errors that may appear in this manual and
makes no commitment to update, or keep current, the information contained in this manual. No part of this manual
may be copied or reproduced in any form without the prior written consent of Acromag, Inc.

VPX4810 PCIe PMC/XMC 3U Carrier
USER’S MANUAL
Acromag, Inc. Tel: [phone] - 3 -
http://www.acromag.com
- 3 -
www.acromag.com
GENERAL INFORMATION
The VPX4810 series is a 3U VPX Non-Intelligent XMC/PMC carrier board designed for 4x/8x PCIe bus
connection. The carrier card uses a PLX Technology® PCIe Switch Chip (PEX 8624) and PLX Technology®PCIe to
PCI Bridge Chip (PEX 8114) to interface between the VPX bus and one XMC/PMC mezzanine I/O module card.
Model VPX4810 is an air-cooled product which can be used for front and rear I/O XMC/PMC mezzanine I/O
modules.
Model VPX4810CC is an extended temperature conduction-cooled product which supports all Acromag
FPGA modules. It only supports Rear I/O.
Model VPX4810REDI is a VITA 48 Ruggedized Enhanced Design Implementation (REDI) model that does not
support Front I/O and will only fit in REDI chassis.
Key Features
•PCIe x4 or x8 lane VITA 46.4 Backplane Compliance: The VPX4810 supports either a 4 or 8 lane PCIe 2.0
connection to the backplane.
•Supports either 1 PMC or XMC module –The VPX4810 supports 1 PMC module complaint to PCI 3.0 -- 32
or 64 bits at 33 or 66MHz or PCI-X 1.0b 64 bits at 66MHz, 100MHz, or 133MHz. Alternatively it supports
one XMC module compliant with PCI Express 2.0 up to 8 lanes.
•ESD Strip - The VPX4810 board has been designed to provide electrostatic discharge (ESD) capability by
using an ESD strip on the board.
•Injector/Ejector Handle - The VPX4810 uses a modern injector/ejector handle, which pushes the board
into the rack during installation and has a positive self-locking mechanism so it cannot be unlocked
accidentally. This handle is fully IEEE 1101.10 compliant and is needed to give leverage to install and
remove the board.
•EMC Front Panel - The VPX4810 uses the preferred EMC 1” front panel per VITA 48 specification.
•Conduction Cooled Frame - The VPX4810CC board has a custom conduction cooled assembly consisting of
a conduction cooled frame, thermo bars, ejector/injectors and wedge-locks designed to thermally conduct
heat away from the Conduction Cooled XMC/PMC modules.
•REDI Frame - The VPX4810REDI board has a custom conduction cooled and full shield assembly complaint
to VITA 48.0. The assembly consists of a conduction cooled frame, thermo bars, ejector/injectors, wedge-
locks, and a full bottom and top face plate designed to thermally conduct heat from and to protect from
ESD the XMC/PMC modules.
•Compatible with OPEN VPX VITA 65.0
Software Support
The VPX4810 family of modules is intended to be used as a non-intelligent bridge between the system PCIe
bus and the XMC/PMC module. No software is required to operate the board. However all XMC/PMC modules
will require support drivers specific to your operating system. Refer to your XMC/PMC modules manufacturer
for information on PCIe drivers.

VPX4810 PCIe PMC/XMC 3U Carrier
USER’S MANUAL
Acromag, Inc. Tel: [phone] - 4 -
http://www.acromag.com
- 4 -
www.acromag.com
References
The following two whitepapers related to VPX are available for download on Acromag’s website or by
contacting your sales representative.
Introduction to VPX: VITA 46, 48, and 65.
Will Acromag’s VPX4810 work in my system?

VPX4810 PCIe PMC/XMC 3U Carrier
USER’S MANUAL
Acromag, Inc. Tel: [phone] - 5 -
http://www.acromag.com
- 5 -
www.acromag.com
PREPARATION FOR USE
Unpacking and Inspecting
Upon receipt of this product, inspect the shipping carton for evidence of mishandling during transit. If the
shipping carton is badly damaged or water stained, request that the carrier's agent be present when the carton
is opened. If the carrier's agent is absent when the carton is opened and the contents of the carton are
damaged, keep the carton and packing material for the agent's inspection.
For repairs to a product damaged in shipment, refer to the Acromag Service Policy to
obtain return instructions. It is suggested that salvageable shipping cartons and packing
material be saved for future use in the event the product must be shipped. WARNING:
This board utilizes static sensitive components and should only be handled at a static-
safe workstation.
This board is physically protected with packing material and electrically protected with an anti-static bag
during shipment. However, it is recommended that the board be visually inspected for evidence of mishandling
prior to applying power.
Card Cage Considerations
Refer to the specifications section for loading and power requirements. Be sure that the system power
supplies are able to accommodate the power requirements of the system boards, plus the installed Acromag
board, within the voltage tolerances specified.
Each of Acromag’s VPX carriers are in a different pitch as determined by the cooling technique. The VPX4180 is
a 1.0” pitch board, the VPX4810CC is 1.0” pitch, and the VPX4810REDI is a 1.00” pitch board. Verify your
chassis compliance to accommodate the various board pitches.
In an air cooled assembly, adequate air circulation must be provided to prevent a temperature rise above the
maximum operating temperature and to prolong the life of the electronics. If the installation is in an industrial
environment and the board is exposed to environmental air, careful consideration should be given to air-
filtering.
IMPORTANT: Adequate air circulation of 100 LFM must be provided to prevent a temperature rise above the
maximum operating temperature in the VPX4810.
In a conduction cooled assembly, adequate thermo conduction must be provided to prevent a temperature
rise above the maximum operating temperature.
IMPORTANT: If the VPX4810CC is not installed in a conduction cooled chassis, air circulation of 200 LFM must
be provided to prevent a temperature rise above the maximum operating temperature in the VPX4810CC.
A REDI assembly must be installed in a REDI complaint chassis since conduction is the only method for cooling
the board.
IMPORTANT: The VPX4810REDI should not be operated under air cooled conditions.

VPX4810 PCIe PMC/XMC 3U Carrier
USER’S MANUAL
Acromag, Inc. Tel: [phone] - 6 -
http://www.acromag.com
- 6 -
www.acromag.com
Backplane
This board is design to work with a Backplane profile of BKP3-DIS06-15.2.7-n. Failure to use a
compatible backplane could result in damage to this product or others in the chassis. For more information on
backplane compatible please refer to the Acromag VPX4810 Compatibility Whitepaper.
WARNING: THE VPX4810 CAN ONLY BE USED ON A 3U BACKPLANE. PLUGGING THIS MODULE INTO
A 6U BACKPLANE MAY RESULT IN DAMAGE TO THIS BOARD DUE INCOMPATIBLE POWER SUPPLIES.
Non-Isolation Considerations
The board is non-isolated, since there is electrical continuity between the VPX bus and PMC module grounds.
As such, the field I/O connections are not isolated from the system. Care should be taken in designing
installations without isolation to avoid noise pickup and ground loops caused by multiple ground connections.
The model VPX4810 carrier field I/O connections are made through the rear via J4 for a single PMC mezzanine
I/O module card.
Jumper Settings
The VPX4810 has two jumpers for selecting the number of PCIe lanes used from the backplane and another to
control how the chassis ground is connected. Note that the jumpers are in the same location on each model
regardless of metalwork.
Jumper Settings
The following section describes the VPX4810 jumpers with their default positions and functions.
SW-1, SW-2, SW3 and SW-4 are reserved.
SW1-5
VPX Uplink Port
Select
OPEN
Uplink is VPX Fat Pipe B
CLOSED(default)
Uplink is VPX Fat Pipe or Double Fat Pipe A
SW1-6
PCIe Link
Speed Select
OPEN (default)
GEN 1 & GEN 2 SUPPORTED
CLOSED
FORCE GEN 1 SPEED ON ALL CONNECTIONS
SW1-7
VPX PORT
Select
OPEN (default)
VPX PCIE connection is 1 x 8 Double Fat Pipe
CLOSED
VPX PCIE connection is 2 x 4 Fat Pipes
SW1-8
PCIe Clock
Select
OPEN (default)
NON-COMMON CLOCK
CLOSED
100MHz COMMON CLOCK FROM P0 REFCLK PINS
Best system stability may be achieved with the use of a 100MHz common clock connection from the SBC,
especially at Gen 2 link speeds. If the system does not provide a common clock then non-common clock mode
must be used.

VPX4810 PCIe PMC/XMC 3U Carrier
USER’S MANUAL
Acromag, Inc. Tel: [phone] - 7 -
http://www.acromag.com
- 7 -
www.acromag.com
SW2
FRU & Temp
Sensor Voltage
1-2 (default)
USES 3.3V
2-3
USES 3.3V_AUX
SW2
Orb/Chassis
Ground
4-5 (default)
FRONT PANEL TIED TO GND
5-6
FRONT PANEL ISOLATED
SW3
JTAG REF
Voltage
1-2 (default)
VREF is 3.3V
2-3
VREF is 2.5V
4,5 and 6
NOT USED
PMC Connector Pinout
The following tables list all the board connections to the 4 PMC connectors J1 to J4.
PMC Site Connector J1
This connector contains PCI bus signals and power for PMC modules.
PIN
Signal
PIN
Signal
1
TCK
2
-12V
3
Ground
4
INTA*
5
INTB*
6
INTC*
7
BUSMODE1*
8
+5V
9
INTD*
10
PCI-RSVD*
11
Ground
12
PCI-RSVD*
13
CLK
14
Ground
15
Ground
16
GNT*
17
REQ*
18
+5V
19
V(I/O)
20
AD(31)
21
AD(28
22
AD(27)
23
AD(25)
24
Ground
25
Ground
26
C/BE(3)*
27
AD(22)
28
AD(21)
29
AD(19)
30
+5V
31
V(I/O)
32
AD(17)
33
FRAME*
34
Ground
35
Ground
36
IRDY*
37
DEVSEL*
38
+5V
39
Ground
40
LOCK*
41
SDONE*
42
SBO*

VPX4810 PCIe PMC/XMC 3U Carrier
USER’S MANUAL
Acromag, Inc. Tel: [phone] - 8 -
http://www.acromag.com
- 8 -
www.acromag.com
43
PAR
44
Ground
45
V(I/O)
46
AD(15)
47
AD(12)
48
AD(11)
49
AD(09)
50
+5V
51
Ground
52
C/BE(0)*
53
AD(06)
54
AD(05)
55
AD(04)
56
Ground
57
V(I/O)
58
AD(03)
59
AD(02)
60
AD(01)
61
AD(00)
62
+5V
63
Ground
64
REQ64*
* Indicates that the signal is active low.

VPX4810 PCIe PMC/XMC 3U Carrier
USER’S MANUAL
Acromag, Inc. Tel: [phone] - 9 -
http://www.acromag.com
- 9 -
www.acromag.com
PMC Site Connector J2
This connector contains PCI bus signals and power for PMC modules.
PIN
Signal
PIN
Signal
1
+12V
2
TRST*
3
TMS
4
TDO
5
TDI
6
Ground
7
Ground
8
PCI-RSVD*
9
PCI-RSVD*
10
PCI-RSVD*
11
BUSMODE2*
12
+3.3V
13
RST*
14
BUSMODE3*
15
+3.3V
16
BUSMODE4*
17
PCI-RSVD*
18
Ground
19
AD(30)
20
AD(29)
21
Ground
22
AD(26)
23
AD(24)
24
+3.3V
25
IDSEL
26
AD(23)
27
+3.3V
28
AD(20)
29
AD(18)
30
Ground
31
AD(16)
32
C/BE(2)*
33
Ground
34
PMC-RSVD
35
TRDY*
36
+3.3V
37
Ground
38
STOP*
39
PERR*
40
Ground
41
+3.3V
42
SERR*
43
C/BE(1)*
44
Ground
45
AD(14)
46
AD(13)
47
M66EN
48
AD(10)
49
AD(08)
50
+3.3V
51
AD(07)
52
PMC-RSVD
53
+3.3V
54
PMC-RSVD
55
PMC-RSVD
56
Ground
57
PMC-RSVD
58
PMC-RSVD
59
Ground
60
PMC-RSVD
61
ACK64*
62
+3.3V
63
Ground
64
PMC-RSVD
* Indicates that the signal is active low.

VPX4810 PCIe PMC/XMC 3U Carrier
USER’S MANUAL
Acromag, Inc. Tel: [phone] - 10 -
http://www.acromag.com
- 10 -
www.acromag.com
PMC Site Connector J3
This connector contains the additional PCI bus signals required for 64-bit transactions.
PIN
Signal
PIN
Signal
1
PCI-RSVD
2
Ground
3
Ground
4
C/BE(7)*
5
C/BE(6)*
6
C/BE(5)*
7
C/BE(4)*
8
Ground
9
V(I/O)
10
PAR64
11
AD(63)
12
AD(62)
13
AD(61)
14
Ground
15
Ground
16
AD(60)
17
AD(59)
18
AD(58)
19
AD(57)
20
Ground
21
V(I/O)
22
AD(56)
23
AD(55)
24
AD(54)
25
AD(53)
26
Ground
27
Ground
28
AD(52)
29
AD(51)
30
AD(50)
31
AD(49)
32
Ground
33
Ground
34
AD(48)
35
AD(47)
36
AD(46)
37
AD(45)
38
Ground
39
V(I/O)
40
AD(44)
41
AD(43)
42
AD(42)
43
AD(41)
44
Ground
45
Ground
46
AD(40)
47
AD(39)
48
AD(38)
49
AD(37)
50
Ground
51
Ground
52
AD(36)
53
AD(35)
54
AD(34)
55
AD(33)
56
Ground
57
V(I/O)
58
AD(32)
59
PCI-RSVD
60
PCI_RSVD
61
PCI-RSVD
62
Ground
63
Ground
64
PCI-
* Indicates that the signal is active low.

VPX4810 PCIe PMC/XMC 3U Carrier
USER’S MANUAL
Acromag, Inc. Tel: [phone] - 11 -
http://www.acromag.com
- 11 -
www.acromag.com
PMC Site Connector J4
This connector contains the PMC Rear I/O Signals. These signals are routed to the VPX backplane.
PIN
Signal
PIN
Signal
1
Rear Jn4-1/P2-E1
2
Rear Jn4-2/P2-B1
3
Rear Jn4-3/P2-D1
4
Rear Jn4-4/P2-A1
5
Rear Jn4-5/P2-F2
6
Rear Jn4-6/P2-C2
7
Rear Jn4-7/P2-E2
8
Rear Jn4-8/P2-B2
9
Rear Jn4-9/P2-E3
10
Rear Jn4-10/P2-B3
11
Rear Jn4-11/P2-D3
12
Rear Jn4-12/P2-A3
13
Rear Jn4-13/P2-F4
14
Rear Jn4-14/P2-C4
15
Rear Jn4-15/P2-E4
16
Rear Jn4-16/P2-B4
17
Rear Jn4-17/P2-E5
18
Rear Jn4-18/P2-B5
19
Rear Jn4-19/P2-D5
20
Rear Jn4-20/P2-A5
21
Rear Jn4-21/P2-F6
22
Rear Jn4-22/P2-C6
23
Rear Jn4-23/P2-E6
24
Rear Jn4-24/P2-B6
25
Rear Jn4-25/P2-E7
26
Rear Jn4-26/P2-B7
27
Rear Jn4-27/P2-D7
28
Rear Jn4-28/P2-A7
29
Rear Jn4-29/P2-F8
30
Rear Jn4-30/P2-C8
31
Rear Jn4-31/P2-E8
32
Rear Jn4-32/P2-B8
33
Rear Jn4-33/P2-E9
34
Rear Jn4-34/P2-B9
35
Rear Jn4-35/P2-D9
36
Rear Jn4-36/P2-A9
37
Rear Jn4-37/P2-F10
38
Rear Jn4-38/P2-C10
39
Rear Jn4-39/P2-E10
40
Rear Jn4-40/P2-B10
41
Rear Jn4-41/P2-E11
42
Rear Jn4-42/P2-B11
43
Rear Jn4-43/P2-D11
44
Rear Jn4-44/P2-A11
45
Rear Jn4-45/P2-F12
46
Rear Jn4-46/P2-C12
47
Rear Jn4-47/P2-E12
48
Rear Jn4-48/P2-B12
49
Rear Jn4-49/P2-E13
50
Rear Jn4-50/P2-B13
51
Rear Jn4-51/P2-D13
52
Rear Jn4-52/P2-A13
53
Rear Jn4-53/P2-F14
54
Rear Jn4-54/P2-C14
55
Rear Jn4-55/P2-E14
56
Rear Jn4-56/P2-B14
57
Rear Jn4-57/P2-E15
58
Rear Jn4-58/P2-B15
59
Rear Jn4-59/P2-D15
60
Rear Jn4-60/P2-A15
61
Rear Jn4-61/P2-F16
62
Rear Jn4-62/P2-C16
63
Rear Jn4-63/P2-E16
64
Rear Jn4-64/P2-B16

VPX4810 PCIe PMC/XMC 3U Carrier
USER’S MANUAL
Acromag, Inc. Tel: [phone] - 12 -
http://www.acromag.com
- 12 -
www.acromag.com
XMC Connector Pinout
XMC Connector P5
This connector contains eight PCIe lanes as well as all XMC power and control signals. Note that VPRW is 5V on
the VPX4810 carrier. The carrier does not support processor XMC modules (PCI enumeration capabilities).
Pin
A
B
C
D
E
F
1
PCIeT0p
PCIeT0n
+3.3V
PCIeT1p
PCIeT1n
+5.0V
2
GND
GND
TRST#
GND
GND
3
PCIeT2p
PCIeT2n
+3.3V
PCIeT3p
PCIeT3n
+5.0V
4
GND
GND
TCK
GND
GND
5
PCIeT4p
PCIeT4n
+3.3V
PCIeT5p
PCIeT5n
+5.0V
6
GND
GND
TMS
GND
GND
+12.0V
7
PCIeT6p
PCIeT6n
+3.3V
PCIeT7p
PCIeT7n
+5.0V
8
GND
GND
TDI
GND
GND
-12.0V
9
RFU
RFU
RFU
RFU
RFU
+5.0V
10
GND
GND
TDO
GND
GND
GA0
11
PCIeR0p
PCIeR0n
MBIST#
PCIeR1p
PCIeR1n
+5.0V
12
GND
GND
GA1
GND
GND
MPRESENT#
13
PCIeR2p
PCIeR2n
+3.3V AUX
PCIeR3p
PCIeR3n
+5.0V
14
GND
GND
GA2
GND
GND
MSDA
15
PCIeR4p
PCIeR4n
RFU
PCIeR5p
PCIeR5n
+5.0V
16
GND
GND
MVMRO
GND
GND
MSCL
17
PCIeR6p
PCIeR6n
RFU
PCIeR7p
PCIeR7n
RFU
18
GND
GND
RFU
GND
GND
RFU
19
REFCLK+
REFCLK-
RFU
Wake#
Root#
RFU

VPX4810 PCIe PMC/XMC 3U Carrier
USER’S MANUAL
Acromag, Inc. Tel: [phone] - 13 -
http://www.acromag.com
- 13 -
www.acromag.com
VPX Backplane Connector Pinouts
VPX P0 Connector-Power and System Controls
Table 2.2 indicates the pin assignments for the VPX 3U assignments at the P0 connector. The connector
consists of 8 wafers with up to 7 signals on each. The system management bus signals SM0, SM1, SM2, and
SM3 use I2C to implement the Intelligent Platform Management Bus (IPMB) per VITA 46.11. The VPX4810 CAN
NOT BE PLUGGED INTO A 6U VPX SYSTEM DUE TO POWER INCOMPATIBILITIES BETWTEEN THE 3U AND 6U
FORM FACTORS. PLUGGING THE VPX4810 INTO A 6U SYSTEM WILL DAMAGE THE BOARD!
Refer to the VPX specifications for additional information on these signals.
Wafer
Row G
Row F
Row E
Row D
Row C
Row B
Row A
1
+12V
+12V
+12V
NC
+3.3V
+3.3V
+3.3V
2
+12V
+12V
+12V
NC
+3.3V
+3.3V
+3.3V
3
+5V
+5V
+5V
NC
+5V
+5V
+5V
4
SM2
SM3
GND
12V_AUX
GND
SYSRST
NVMRO
5
GAP
GA4
GND
3.3V_AUX
GND
SM0
SM1
6
GA3
GA2
GND
+12V_AU
GND
GA1
GA0
7
TCK
GND
TDO
TDI
GND
TMS
TRST
8
GND
REF_CLK-
REF_CLK+
GND
RES
RES
GND
Note: BOLD ITALIC signals are NOT USED by this carrier board.
VPX P1 Connector –PCIe
The VPX 3U P1 connector contains the high speed PCIe signals. The VPX4810 is compliant to VITA 46.4 with up
to 8 lanes and PCIe.
Wafer
Row G
Row F
Row E
Row D
Row C
Row B
Row A
1
RES
GND
L0-TX-
L0-TX+
GND
L0-RX-
L0-RX+
2
GND
L1-TX-
L1-TX+
GND
L1-RX-
L1-RX+
GND
3
VBAT
GND
L2-TX-
L2-TX+
GND
L2-RX-
L2-RX+
4
GND
L3-TX-
L3-TX+
GND
L3-RX-
L3-RX+
GND
5
SYS_CON
GND
L4-TX-
L4-TX+
GND
L4-RX-
L4-RX+
6
GND
L5-TX-
L5-TX+
GND
L5-RX-
L5-RX+
GND
7
REG_CLK_SE
GND
L6-TX-
L6-TX+
GND
L6-RX-
L6-RX+
8
GND
L7-TX-
L7-TX+
GND
L7-RX-
L7-RX+
GND
9
P1-SE4
GND
L8-TX-
L8-TX+
GND
L8-RX-
L8-RX+
10
GND
L9-TX-
L9-TX+
GND
L9-RX-
L9-RX+
GND
11
P1-SE5
GND
L10-TX-
L10-TX+
GND
L10-RX-
L10-RX+
Note: BOLD ITALIC signals are NOT USED by this carrier board.

VPX4810 PCIe PMC/XMC 3U Carrier
USER’S MANUAL
Acromag, Inc. Tel: [phone] - 14 -
http://www.acromag.com
- 14 -
www.acromag.com
VPX P2 Connector –Rear I/O
The VPX P2 connector contains all of the Rear I/O routing from the PMC J4 connector. This connector consists
of 16 differential wafers with 7 signals each. This pin out is compliant with VITA 46.9 P2w1-P64s. Note that the
backplane connected to the VPX4810 should be VITA 46.9 P2w1-P64s compliant to avoid any possible signal
contentions.
Wafer
Row G
Row F
Row E
Row D
Row C
Row B
Row A
1
NC
GND
Jn4-1
Jn4-3
GND
Jn4-2
Jn4-4
2
GND
Jn4-5
Jn4-7
GND
Jn4-6
Jn4-8
GND
3
NC
GND
Jn4-9
Jn4-11
GND
Jn4-10
Jn4-12
4
GND
Jn4-13
Jn4-15
GND
Jn4-14
Jn4-16
GND
5
NC
GND
Jn4-17
Jn4-19
GND
Jn4-18
Jn4-20
6
GND
Jn4-21
Jn4-23
GND
Jn4-22
Jn4-24
GND
7
NC
GND
Jn4-25
Jn4-27
GND
Jn4-26
Jn4-28
8
GND
Jn4-29
Jn4-31
GND
Jn4-30
Jn4-32
GND
9
NC
GND
Jn4-33
Jn4-35
GND
Jn4-34
Jn4-36
10
GND
Jn4-37
Jn4-39
GND
Jn4-38
Jn4-40
GND
11
NC
GND
Jn4-41
Jn4-43
GND
Jn4-42
Jn4-44
12
GND
Jn4-45
Jn4-47
GND
Jn4-46
Jn4-48
GND
13
NC
GND
Jn4-49
Jn4-51
GND
Jn4-50
Jn4-52
14
GND
Jn4-53
Jn4-55
GND
Jn4-54
Jn4-56
GND
15
NC
GND
Jn4-57
Jn4-59
GND
Jn4-58
Jn4-60
16
GND
Jn4-61
Jn4-63
GND
Jn4-62
Jn4-64
GND
Note: BOLD ITALIC signals are NOT USED by this carrier board.
Rear I/O pin mapping diagram as
defined in VITA 46.9. This product is
complaint to rear I/O routing
P2w1-P64s.

VPX4810 PCIe PMC/XMC 3U Carrier
USER’S MANUAL
Acromag, Inc. Tel: [phone] - 15 -
http://www.acromag.com
- 15 -
www.acromag.com
JTAG Connector –JTAG Header
Pin Number
Description
1
JTAG_TDI
2
JTAG_TDO
3
GND
4
JTAG_TCK
5
JTAG_TMS
6
JTAG_VREF
Board Layout

VPX4810 PCIe PMC/XMC 3U Carrier
USER’S MANUAL
Acromag, Inc. Tel: [phone] - 16 -
http://www.acromag.com
- 16 -
www.acromag.com
Front Panel Layout
VPX4810 Front Panel
On the front panel of air-cooled VPX4810 assemblies, there are 4 port status LED’s. The first LED
(Status A) indicates the VPXLNKA link status which can be Fat Pipe A or Double Fat Pipe A. The second
LED (Status B) indicates the VPXLNKB link status. The third LED (Status C) indicates the PCILNK link
status with the PEX8114 PCIX Bridge. The fourth LED (Status X) on the front panel indicates the
XMCLNK link status of an XMC module installed on to the VPX4810. Note: The Status C will always blink
as “reduced lanes” because of the design. The D status in not available on the VPX4810.
The table below describes what the LED On/Off patterns indicate about the corresponding port states.
Port Status LED On/Off Patterns, by State

VPX4810 PCIe PMC/XMC 3U Carrier
USER’S MANUAL
Acromag, Inc. Tel: [phone] - 17 -
http://www.acromag.com
- 17 -
www.acromag.com
State
LED Pattern
Link is down
Off
Link is up, Gen 2.0 speed, all Lanes are up
On
Link is up, Gen 2.0 speed, reduced Lanes are up
Blinking, 0.5 seconds On, 0.5 seconds Off
Link is up, Gen 1.0 speed, all Lanes are up
Blinking, 1.5 seconds On, 0.5 seconds Off
Link is up, Gen 1.0 speed, reduced Lanes are up
Blinking, 0.5 seconds On, 1.5 seconds Off
Installing and Removing PMC/XMC Modules
The procedure for installing and XMC/PMC module into the VPX4810 series carrier varies depending on the
carrier type.
Please note that if you purchase the VPX4810 and one of Acromag’s PMC or XMC modules separately you may
require one of the following additional hardware kits to complete mounting.
AXM-KIT: This kit contains a blank front panel and 4 screws. It is required for proper installation of any
Acromag Virtex 4, Virtex 5, or Spartan 6 board without an AXM module attached in an air cooled carrier.
PMC-KIT-CC:This kit contains the necessary screws to attach an Acromag PMC/XMC module to the
VPX4810CC or the VPX4810REDI.
VPX4810 Air-Cooled
Step 1: Take your XMC/PMC module and verify that it has a front panel attached and properly screwed into the
XMC/PMC module. If not then install a blank front panel that is available in the AXM- KIT. Set the jumpers on
the VPX 4810 now.
PMC Blank Front Panel
2x M2.5 x 5

VPX4810 PCIe PMC/XMC 3U Carrier
USER’S MANUAL
Acromag, Inc. Tel: [phone] - 18 -
http://www.acromag.com
- 18 -
www.acromag.com
Step 2: Install the PMC/XMC module into the VPX4810 carrier by carefully angling the board so that the front
panel slips though the gap in the metalwork. Once set align the connectors and gently push down until the
connectors are fully inserted.
Step 3: Flip the VPX4810 over and install 4x M2.5 x 5 screws into the locations noted in the picture below.
These correspond to the standoffs and the front PMC panel on the attached module.
Angle board into position.
Press downwards.
4x M2.5 x 5 screws
