ADC Adtemp 418N User manual

Thank you for choosing an ADC®AdtempTM digital stick thermometer. Your new thermometer is designed
to provide accurate temperature measurements. Adtemp thermometers meet or exceed all relevant in-
ternational performance standards.
Device Description and Intended Use
This device is intended to measure human body temperature in children and adults. It has a compact
size and digital display and can be used in a professional or household environment.
Parts and Assembly
AdtempTM 418N
Digital Fever Thermometer
Instructions for Use
Multifunction
Button
LCD Display
Probe
Tip
Flexible Tip
(Do not bend beyond a 45° angle)

Symbol Definitions
The following symbols are associated with your thermometer.
General Warnings
A warning statement in this manual identifies a condition or practice which, if not corrected
or discontinued immediately, could lead to patient injury, illness, or death.
WARNING:
This instrument is designed for oral, rectal, or axillary use only.
WARNING: High prolonged fever requires medical attention, especially for young children. Please contact your physician.
WARNING: Keep out of reach of unsupervised children. Components may be harmful if swallowed.
WARNING: Stop using the thermometer if it operates erratically or if the display malfunctions.
WARNING: Rectal temperatures vary by approximately 0.9°F/0.5°C.
WARNING: Avoid taking temperature for 30 minutes after physical exercise, bathing, dining, or drinking hot
or cold beverages.
WARNING: Allow the thermometer to warm naturally to room temperature before using. Performance may be
affected if operated or stored outside stated temperature and humidity ranges or if the patient's
temperature is below the ambient (room) temperature.
WARNING: After using, clean the thermometer and store in case. Clean the unit by wiping it with a dry cloth
and disinfecting the probe with isopropyl (rubbing) alcohol. See cleaning instructions for additional details.
CAUTION: Keep thermometer away from direct sunlight, moisture, extreme temperatures, or dust.
CAUTION: Do not boil, bite, bend, drop, or disassemble the thermometer.
CAUTION: Do not open the unit except to replace the battery.
CAUTION: Do not use this device close to strong electromagnetic fields, such as mobile telephones.
CAUTION: Dispose of batteries in accordance with locally applicable regulations, not with domestic waste.
How to Use
NOTE: Be sure probe tip is clean before using.
1. Disinfect the probe with isopropyl (rubbing) alcohol before using.
2. Press and release the multifunction button. You will hear a short beep then all
segments will display (Figure 1) for 1 second with red backlight for 0.5 seconds
and then green backlight for 0.5 seconds. This is a function check indicating the unit is working properly.
3. Display will then show the last reading memory with a red or green backlight (depending on the temperature)
for 3 seconds. When the scrolling dash “-” displays, you can start measurement.
4. When measurement is complete you will hear a long beep (1 second) and see a green backlight when
the temperature is between 89.6°F (34°C) to 99.3°F (37.4°C). You will hear four beeps and see a red
backlight when the temperature is between 99.5°F (37.5°C) to 109.2°F (42.9°C). If the temperature
is higher than 109.2°F (42.9°C), you’ll hear two beeps, see the “H” icon and a red backlight, and
hear four additional beeps.
5. The reading will automatically be stored in memory, but we recommend you manually record the
temperature and time for reference.
6. The unit will automatically turn off in about 5 minutes. To prolong battery life, press the multifunction
button to turn off the device manually.
Symbol Definition
Important warning/caution
Operating instructions
Manufacturer’s information
Not made with natural rubber latex
Phthalate free
Authorized European representative’s information
Lot number
LATEX
Symbol Definition
Meets essential requirements of European
Medical Device Directive 93/42/EEC
Multifunction button
Auto detection error
Temperature is higher than measuring range
Memory indication
Low battery indication
M
0044
Figure 1

Ensuring Accurate Temperature Measurement
We recommend using probe covers (Figure 2) with all digital stick thermometers.
NOTE: This model uses “predictive” technology. Average measurement time is ap-
proximately 8 seconds for oral, rectal or underarm use. Actual times may vary de-
pending upon individual, ambient room conditions and method used.
Oral Use: (ages 4 years and older): Place probe under patient’s tongue
(Figure 3) and close mouth. The peak temperature should be reached in about
8 seconds. Opening the mouth or improper placement of the probe tip may
affect read time.
Rectal Use: Lubricate the probe cover with a water-soluble jelly for easier
insertion; do not use petroleum jelly, as it may cause an inaccurate reading.
Gently insert the tip of the probe no more than 1/2 inch into the rectum.
STOP if you meet any resistance. The sensing unit is on the very tip of the
probe and there is no need to insert the probe deep into the rectum.
Dispose of the used probe cover and clean the thermometer as recommended.
Axillary Use: Wipe armpit with a dry towel. Place the probe in the patient’s
armpit (Figure 4) and keep the patient’s arm pressed firmly against the body.
The time required for an accurate underarm temperature may be 12 seconds
or longer depending on placement of the probe and closure of the arm against the body.
Switching Temperature Modes
From the off position, press and hold the multifunction button until the display
appears with flashing scale (F°/C°) (Figure 5). Press it again to switch
between °F or °C. Power off automatically after switch is complete.
Special Features
Last-Temperature Memory: Press the multifunction button to turn on. The last reading will display with
a green backlight (temperature lower than 99.5°F / 37.5°C) or red backlight (higher than 99.5°F /
37.5°C) for 1 second.
Battery Replacement
1. When the symbol “ “ appears in the lower right of the display, the battery needs to be replaced.
2. Turn battery cover to unlock position and remove.
3. Remove old battery and replace 3V (CR2032) battery with the positive (+) side
facing up.
4. Replace the battery cover on the thermometer and turn to lock position.
Cleaning and Disinfecting
Do not use corrosive detergent to clean the unit.
Clean and disinfect the thermometer before and after each use.
• Use of probe covers is recommended to help avoid spreading germs, and to keep the thermometer clean.
The thermometer should be cleaned after use even when probe covers are used.
• Wipe probe with a clean cloth dipped in a disinfectant solution such as 70-75% isopropyl (rubbing)
alcohol solution or soap and water.
• Wipe off disinfectant residue.
Care and Storage
• Do NOT drop or crush, as this may damage the thermometer.
• Do NOT dismantle or modify device other than replacing battery.
• Store unit in protective case while not in use. Do NOT store the device in an extreme environment
with direct sunlight or high/low temperatures, or in a location with high humidity or severe dust.
• The manufacturer recommends verifying the accuracy by an authorized laboratory every two years.
Figure 4
Figure 3
Figure 2
Figure 5

IB p/n 93-418N-00 rev 4 (3/8/2021) Printed in China
Mfg. for: ADC®
55 Commerce Drive, Hauppauge, NY 11788
Inspected in the USA
Made in China
tel: [phone]
toll free: 1-800-232-2670
fax: [phone]
www.adctoday.com
email: [e-mail]
ONBO Electronic (Shenzhen) Co., Ltd.
No. 138 Huasheng Road
Langkou Community, Dalang Street
Longhua District, Shenzhen, China
Microlife UAB
P
.Lukšio g. 32
08222 Vilnius, Lithuania
0044
EC REP
IP22: Protected against solid foreign objects of 12.5 mm di-
ameter and greater. Protected against vertically falling
water drops when the device is tilted up to 15°.
Specifications
Standards:
Complies with EN 12470-3, ASTM E 1112-00, ICE 60601-1-11, IEC 606061-1, and IEC 60601-1-2
Limited Warranty
ADC warrants its products against defects in materials and workmanship under normal household use and
service as follows:
1. Warranty service extends to the original retail purchaser only and commences with the date of delivery.
2. Your Adtemp Digital Stick Thermometer is warranted for two years from date of purchase.
What Is Covered: Replacement of parts and labor.
What Is Not Covered: Transportation charges to ADC. Batteries where supplied. Damages caused by
abuse, misuse, accident, or negligence. Incidental, special, or consequential damages. Some states do not
allow the exclusion or limitation of incidental, special, or consequential damages, so this limitation may not
apply to you.
To Obtain Warranty Service: Send item(s) postage paid to ADC, Attn: Repair Dept., 55 Commerce Dr.,
Hauppauge, NY 11788. Please include your name and address, phone no., proof of purchase, and a brief
note explaining the problem.
Implied Warranty: Any implied warranty shall be limited in duration to the terms of this warranty and in no
case beyond the original selling price (except where prohibited by law). This warranty gives you specific legal
rights and you may have other rights which vary from state to state.
For Australian Consumers: Our goods come with guarantees that cannot be excluded under the Aus-
tralian Consumer Law. You are entitled to a replacement or refund for a major failure and compensation for
any other reasonable foreseeable loss or damage. You are also entitled to have the goods repaired or re-
placed if the goods fail to be of acceptable quality and the failure does not amount to a major failure. Visit
www.adctoday.com to view this instruction booklet in other languages.
Size: 5.31”L x 1.14”W x 0.59”H
(13.49cm L x 2.90cm W x 1.49cm H)
Weight: 0.77 oz (22 g) with battery
Display: LCD, Liquid Crystal Display
Battery: 3V (CR2032) lithium-metal
Battery Life: Estimated 2,000 uses
Measurement Oral 8 Seconds / Rectal 8 Seconds
Time: / Axillary 8 Seconds
Measurement 93.2°F to 111.0°F
Range: (34.0°C to 43.9°C)
Accuracy: 93.2°F to 107.6° F ±0.2°F
Technical: (34°C to 42°C ±0.1°C)
107.6°F to 111.0°F ±0.4°F
(42°C to 43.9°C ±0.2°C)
Operation 50°F to 104°F (10°C to 40°C)
Environment: Humidity: 15-95% (non-condensing)
Storage -13°F to 131°F (-25°C to 55°C)
Environment: Humidity: 15-95% (non-condensing)
Measurement Real measurement with
Mode: predictive method
Audible Alarm: 1 beep at start-up. Continuous beep
at measurement completion
Auto Turn Off: In approximately 5 minutes
Read the instruction manual carefully before using
this device, especially the safety instructions, and
keep the instruction manual for future use.
Type BF applied part
Batteries and electronic devices must be
disposed of in accordance with the locally
applicable regulations, not with domestic
waste.
