ADF Web HD67766-A1 User manual

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
IEC61850 Client /
Modbus TCP Slave
Document code: MN67766_ENG Revision 1.000 Pa e 1 of 28
User Manual
Revision 1.000
En lish
IEC61850 Client / Modbus TCP Slave -
Converter
(Order Code: HD67766-A1)
for Website information:
http://www.adfweb.com/?Product=HD67766
for Price information:
http://www.adfweb.com/?Price=HD67766-A1
Benefits and Main Features
Triple electrical isolation
Two Ethernet ports
Temperature ran e: -40°C/+85°C (-40°F/+185°F)
For others IEC61850 Client devices, see also the followin links:
IEC61850 Client from/to …
www.adfweb.com?Product=HD67765 (Modbus Slave)
www.adfweb.com?Product=HD67767 (BACnet Slave)
www.adfweb.com?Product=HD67768 (CAN)
www.adfweb.com?Product=HD67769 (CANopen)
www.adfweb.com?Product=HD67770 (DeviceNet Slave)
www.adfweb.com?Product=HD67771 (EtherNet/IP Slave)
www.adfweb.com?Product=HD67772 (J1939)
www.adfweb.com?Product=HD67773 (KNX)
www.adfweb.com?Product=HD67774 (MQTT)
www.adfweb.com?Product=HD67775 (NMEA0183)
www.adfweb.com?Product=HD67776 (NMEA2000)
www.adfweb.com?Product=HD67777 (PROFIBUS Slave)
www.adfweb.com?Product=HD67778 (PROFINET)
www.adfweb.com?Product=HD67779 (SNMP Agent)
Do you have an your customer protocol?
See the followin links:
www.adfweb.com?Product=HD67003
Do you need to choose a device? do you want help?
Ask it to the followin link:
www.adfweb.com?Cmd=helpme
User Manual

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
IEC61850 Client /
Modbus TCP Slave
Document code: MN67766_ENG Revision 1.000 Pa e 2 of 28
INDEX
Pa e
INDEX 2
UPDATED DOCUMENTATION 2
REVISION LIST 2
WARNING 2
TRADEMARKS 2
SECURITY ALERT 3
EXAMPLE OF CONNECTION 4
CONNECTION SCHEME 5
CHARACTERISTICS 6
CONFIGURATION 6
POWER SUPPLY 7
FUNCTION MODES 8
LEDS 9
ETHERNET 10
USE OF COMPOSITOR SW67766 11
NEW PROJECT / OPEN PROJECT 12
SOFTWARE OPTIONS 13
SET COMMUNICATION 15
IEC61850 ACCESS 16
UPDATE DEVICE 22
MODBUS MAP 24
MECHANICAL DIMENSIONS 25
ORDERING INFORMATIONS 26
ACCESSORIES 26
DISCLAIMER 27
OTHER REGULATIONS AND STANDARDS 27
WARRANTIES AND TECHNICAL SUPPORT 28
RETURN POLICY 28
Pagina 2 di 28
UPDATED DOCUMENTATION
Dear customer, we thank you for your attention and we remind you that
you need to check that the followin document is:
Updated
Related to the product you own
To obtain the most recently updated document, note the “document code”
that appears at the top ri ht-hand corner of each pa e of this document.
With this “Document Code” o to web pa e www.adfweb.com/download/
and search for the correspondin code on the pa e. Click on the proper
“Document Code” and download the updates.
REVISION LIST
Revision Date Author Chapter Description
1.000 13/03/2019 Nv All First release version
WARNING
ADFweb.com reserves the ri ht to chan e information in this manual about
our product without warnin .
ADFweb.com is not responsible for any error this manual may contain.
TRADEMARKS
All trademarks mentioned in this document belon to their respective
owners.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
IEC61850 Client /
Modbus TCP Slave
Document code: MN67766_ENG Revision 1.000 Pa e 3 of 28
SECURITY ALERT
G ENERAL I NFORMATION
To ensure safe operation, the device must be operated accordin to the instructions in the manual. When usin the device, le al and
safety re ulation are required for each individual application. The same applies also when usin accessories.
I NTENDED U SE
Machines and systems must be desi ned so the faulty conditions do not lead to a dan erous situation for the operator (i.e.
independent limit switches, mechanical interlocks, etc.).
Q UALIFIED P ERSONNEL
The device can be used only by qualified personnel, strictly in accordance with the specifications.
Qualified personnel are persons who are familiar with the installation, assembly, commissionin and operation of this equipment and
who have appropriate qualifications for their job.
R ESIDUAL R ISKS
The device is state-of-the-art and is safe. The instruments can represent a potential hazard if they are inappropriately installed and
operated by untrained personnel. These instructions refer to residual risks with the followin symbol:
This symbol indicates that non-observance of the safety instructions is a dan er for people that could lead to serious injury or
death and / or the possibility of dama e.
CE CONFORMITY
The declaration is made by our company. You can send an email to [email protected]om or ive us a call if you need it.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
IEC61850 Client /
Modbus TCP Slave
Document code: MN67766_ENG Revision 1.000 Pa e 4 of 28
EXAMPLE OF CONNECTION

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
IEC61850 Client /
Modbus TCP Slave
Document code: MN67766_ENG Revision 1.000 Pa e 5 of 28
CONNECTION SCHEME
Figure
1
: Connection scheme for HD67
766
-
A1

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
IEC61850 Client /
Modbus TCP Slave
Document code: MN67766_ENG Revision 1.000 Pa e 6 of 28
CHARACTERISTICS
The HD67766-A1 is a IEC61850 Client / Modbus TCP Slave converter.
It allows the followin characteristics:
Up to 1500 bytes in readin and 1500 bytes in writin ;
Two-directional information between Modbus TCP and IEC61850;
Mountable on 35mm Rail DIN;
Wide power supply input ran e: 8…24V AC or 12…35V DC;
Wide temperature ran e: -40°C / 85°C [-40°F / +185°F].
CONFIGURATION
You need Compositor SW67766 software on your PC in order to perform the followin :
Define the parameters of the IEC61850;
Define the parameters of the Modbus TCP;
Define IEC61850 variables to be read by the Modbus master;
Define IEC61850 variables to be written by the Modbus master;
Update the device.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
IEC61850 Client /
Modbus TCP Slave
Document code: MN67766_ENG Revision 1.000 Pa e 7 of 28
POWER SUPPLY
The devices can be powered between a wide ran e of tensions. For more details see the two tables below.
VAC
VDC
Vmin Vmax Vmin Vmax
HD67766-A1 8V 24V 12V 35V
Consumption at 24V DC:
Device W/VA
HD67766-A1 4
Caution Not reverse the polari
ty power
HD67766-A1

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
IEC61850 Client /
Modbus TCP Slave
Document code: MN67766_ENG Revision 1.000 Pa e 8 of 28
FUNCTION MODES
The device has ot two functions mode dependin of the position of the Dip1 of ‘Dip-Switch A’:
The first, with Dip1 in Off position (factory settin ), is used for the normal workin of the device.
The second, with Dip1 in On position, is used for upload the Project/Firmware.
For the operations to follow for the updatin (see ‘UPDATE DEVICE’ section).
Accordin to the functionin mode, the LEDs will have specifics functions (see ‘LEDS’ section).

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
IEC61850 Client /
Modbus TCP Slave
Document code: MN67766_ENG Revision 1.000 Pa e 9 of 28
LEDS
The device has ot six LEDs that are used to ive information of the functionin status.
The various meanin s of the LEDs are described in the table below.
LED Normal Mode Boot Mode
1: ON [supply volta e ]
( reen)
ON Device powered
OFF Device not powered
ON Device powered
OFF Device not powered
2: Device State ( reen) Blinks slowly (~1Hz) Blinks quickly Boot state
Blinks very slowly (~0.5Hz) update in pro ress
3: IEC61850 comm. ( reen)
ON At least one IEC61850 Server is disconnected
Flashing IEC61850 response
OFF No IEC61850 response
Blinks quickly Boot state
Blinks very slowly (~0.5Hz) update in pro ress
4: Modbus comm. ( reen) Flashing Modbus request
OFF No Modbus request
Blinks quickly Boot state
Blinks very slowly (~0.5Hz) update in pro ress
5: Ethernet1 Tx ( reen) Blinks when is transmittin Ethernet frames Blinks quickly Boot state
Blinks very slowly (~0.5Hz) update in pro ress
6: Ethernet2 Tx ( reen) Blinks when is transmittin Ethernet frames Blinks quickly Boot state
Blinks very slowly (~0.5Hz) update in pro ress

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
IEC61850 Client /
Modbus TCP Slave
Document code: MN67766_ENG Revision 1.000 Pa e 10 of 28
ETHERNET
The Ethernet connection must be made usin Connector3 or Connector4 of HD67766-A1 with at least a Cate ory 5E cable. The maximum
len th of the cable should not exceed 100m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 100 Mbps. To
connect the device to an Hub/Switch is recommended the use of a strai ht cable, to connect the device to a PC/PLC/other is recommended
the use of a cross cable.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
IEC61850 Client /
Modbus TCP Slave
Document code: MN67766_ENG Revision 1.000 Pa e 11 of 28
USE OF COMPOSITOR SW67766
To confi ure the Converter, use the available software that runs with Windows called SW67766. It is downloadable on the site
www.adfweb.com and its operation is described in this document. (This manual is referenced to the last version of the software present on
our web site). The software works with MSWindows (XP, Vista, Seven, 8, 10; 32/64bit).
When launchin the SW67766, the window below appears (Fi . 2).
Note:
It is necessary to have installed .Net Framework 4.
Figure 2: Main window for SW67766

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
IEC61850 Client /
Modbus TCP Slave
Document code: MN67766_ENG Revision 1.000 Pa e 12 of 28
NEW CONFIGURATION / OPEN CONFIGURATION
The “New Configuration” button creates the folder which contains the entire device’s confi uration.
A device’s confi uration can also be imported or exported:
To clone the confi urations of a pro rammable “IEC61850 Client / Modbus TCP Slave -
Converter” in order to confi ure another device in the same manner, it is necessary to
maintain the folder and all its contents;
To clone a project in order to obtain a different version of the project, it is sufficient to
duplicate the project folder with another name and open the new folder with the button
“Open Configuration”.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
IEC61850 Client /
Modbus TCP Slave
Document code: MN67766_ENG Revision 1.000 Pa e 13 of 28
SOFTWARE OPTIONS
By pressin the “Settings” ( ) button there is the possibility to chan e the
lan ua e of the software and check the updatin s for the compositor.
In the section “Lan ua e” it is possible to chan e the lan ua e of the software.
In the section “Connection Options”, it is possible to check if there are some
updatin s of the software compositor in ADFweb.com website.
Checkin the option “Check Software Update at Start of Program”, the
SW67766 check automatically if there are updatin s when it is launched.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
IEC61850 Client /
Modbus TCP Slave
Document code: MN67766_ENG Revision 1.000 Pa e 14 of 28
In the section “Software Settin s”, it is possible to enable/disable some
keyboard’s commands for an easier navi ation inside the tables contained in the
different sections of the software.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
IEC61850 Client /
Modbus TCP Slave
Document code: MN67766_ENG Revision 1.000 Pa e 15 of 28
SET COMMUNICATION
This section define the fundamental communication parameters of two buses,
IEC61850 and Modbus TCP.
By Pressin the “Set Communication” button from the main window for SW67766
(Fi . 2) the window “Set Communication” appears (Fi . 3).
The means of the fields for “IEC61850 Client” are:
In the fields “IP Address” the IP address for IEC61850 side of the converter is
defined;
In the fields “SubNet Mask” the SubNet Mask for IEC61850 side of the
converter is defined;
In the fields “Gateway” the default ateway of the net is defined. This feature
can be enabled or disabled pressin the Check Box field. This feature is used for
oin out of the net;
In the field "VLAN" the identifier for the VLAN is defined;
In the field “Application ID” the Goose identification strin is defined.
The means of the fields for “Modbus TCP Slave” are:
In the fields “IP Address” the IP address for Modbus TCP side of the converter
is defined;
In the fields “SubNet Mask” the SubNet Mask for Modbus TCP side of the
converter is defined;
In the fields “Gateway” the default ateway of the net is defined. This feature
can be enabled or disabled pressin the Check Box field. This feature is used for
oin out of the net;
In the field “Port” the port used for Modbus TCP communication is defined.
Figure 3: “Set Communication” window

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
IEC61850 Client /
Modbus TCP Slave
Document code: MN67766_ENG Revision 1.000 Pa e 16 of 28
Figure 4: “
IEC61850 Client Set Access
” window
IEC61850 ACCESS
By Pressin the “IEC61850 Access” button from the main window for SW67766 (Fi . 2) the window “IEC61850 Client Set Access” appears
(Fi . 4).
This section is used to define the list of IEC61850 variables from/to which take/map the data of Modbus TCP.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
IEC61850 Client /
Modbus TCP Slave
Document code: MN67766_ENG Revision 1.000 Pa e 17 of 28
Figure 5: functional structure
By clickin on “ADD IEC Device”, it is possible to add a new IEC61850 Server. A SCL file has to be selected (the allowed extensions are
.scd, .ssd, .sed, .icd, .iid or .cid). The functional structure of the Server (Lo ical Devices, Lo ical Nodes, Data Objects and Data Attributes)
will be visible (Fi . 5). The last leaves in the branches of the structure are the variables which can be added to the “Variables” section on the
ri ht (Fi . 6).

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
IEC61850 Client /
Modbus TCP Slave
Document code: MN67766_ENG Revision 1.000 Pa e 18 of 28
Figure 6: “Variables” section
The meanin s of the fields are:
In the field “Index” the index of the server to which the IEC61850 variable belon s is defined;
In the field “bType” the data format of the IEC61850 variable is defined;
In the field “fc” the Functional Constraint of the IEC61850 variable is defined;
In the field “Reference” the path of the IEC61850 variable is defined;
In the field “IP Address” the IP Address of the server to which the IEC61850 variable belon s is defined;
In the field “Port” the Port of the server to which the IEC61850 variable belon s is defined;
If the field “On Change” is checked, the IEC61850 variable is sent when the data on Modbus TCP chan es the value (only in write);
If the field “On CMD” is checked, the IEC61850 variable is sent when a Modbus TCP request is received (only in write);

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
IEC61850 Client /
Modbus TCP Slave
Document code: MN67766_ENG Revision 1.000 Pa e 19 of 28
If the field “On Timer” is checked, the IEC61850 variable is sent/read cyclically;
In the field “Time (ms)” the delay in ms between two readin s/writin s of the variable is defined (if “On Timer” is checked);
In the field “Position” the startin byte of the internal memory arrays where savin / ettin the value is defined;
In the field “Start Bit” the startin bit of the byte of the field “Position” is defined (only for BOOLEAN data);
In the field “R/W” the access type of the IEC61850 variable is defined;
In the field “Conversion” the type of conversion of the value is defined (only for FLOAT32/FLOAT64 data);
In the field “Molt Fact” the multiplication factor for the conversion is defined (if “Conversion” is defined as “ItoF/FtoI”);
In the field “Mnemonic” a description of the variable is defined.
Note:
Not all variables can be written. It depends on their Functional Constraints (fc).

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
IEC61850 Client /
Modbus TCP Slave
Document code: MN67766_ENG Revision 1.000 Pa e 20 of 28
Figure 7: “DataSet” section
If they are available in the functional structure, it is also possible to add Datasets (DS) to “DataSet” section (Fi . 7).
In the upper part, there are all the inserted Datasets. The meanin s of the fields are:
In the field “Index” the index of the server to which the IEC61850 Dataset belon s is defined;
In the field “Reference” the path of the IEC61850 Dataset is defined;
In the field “Goose Name” the Goose Name of the IEC61850 Dataset is defined (if “En. Goose” is checked);
If the field “En. Goose” is checked, the Dataset is received as a Goose messa e;
In the field “IP Address” the IP Address of the server to which the Dataset belon s is defined (if “En. Goose” is unchecked);
In the field “Port” the Port of the server to which the Dataset belon s is defined (if “En. Goose” is unchecked);
In the field “Time (ms)” the delay in ms between two readin s of the Dataset is defined (if “En. Goose” is unchecked);
In the field “Mnemonic” a description of the Dataset is defined.
