ADF Web HD67839 Series User manual

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
DALI
/ Ethernet
Document code: MN67839_ENG Revision 1 001 Pagina 1 di 62
User Manual
Revision 1 001
English
DALI / Ethernet - Converter
(Order Code: HD67839-B2-Y, HD67839-B2-N)
for Website information:
www adfweb com?Product=HD67839
for Price information:
www adfweb com?Price=HD67839-B2
Benefits and Main Features:
Very easy to configure
Electrical isolation
Temperature range: -40°C/85°C (-40°F/185°F)
For others DALI products, see also the following links:
Converter DALI to
www adfweb com?Product=HD67822 (KNX)
www adfweb com?Product=HD67831 (R 485)
www adfweb com?Product=HD67832 (BACnet/IP Master)
www adfweb com?Product=HD67833 (BACnet/IP lave)
www adfweb com?Product=HD67834 (CAN)
www adfweb com?Product=HD67835 (CANopen)
www adfweb com?Product=HD67836 (DeviceNet Master)
www adfweb com?Product=HD67837 (DeviceNet lave)
www adfweb com?Product=HD67838 (DMX)
www adfweb com?Product=HD67840 (EtherNet/IP)
www adfweb com?Product=HD67842 (Modbus Master)
www adfweb com?Product=HD67843 (Modbus lave)
www adfweb com?Product=HD67844 (Modbus TCP Master)
www adfweb com?Product=HD67845 (Modbus TCP lave)
www adfweb com?Product=HD67848 (PROFINET)
www adfweb com?Product=HD67849 ( NMP Manager)
www adfweb com?Product=HD67850 ( NMP Agent)
www adfweb com?Product=HD67941 (MQTT)
Do you have an your customer protocol?
www adfweb com?Product=HD67003
Do you need to choose a device? do you want help?
www adfweb com?Cmd=helpme
User Manual

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
DALI
/ Ethernet
Document code: MN67839_ENG Revision 1 001 Pagina 2 di 62
INDEX:
Page
INDEX 2
UPDATED DOCUMENTATION 2
REVISION LIST 2
WARNING 2
TRADEMARKS 2
SECURITY ALERT 3
EXAMPLE OF CONNECTION 4
CONNECTION SCHEME 5
CHARACTERISTICS 6
CONFIGURATION 6
POWER SUPPLY 7
FUNCTION MODES 8
LEDS 9
DALI 10
ETHERNET 11
USE OF COMPOSITOR SW67839 12
NEW PROJECT / OPEN PROJECT 13
SOFTWARE OPTIONS 14
SET COMMUNICATION 16
DALI ACCESS 17
UPDATE DEVICE 18
USE OF DALI CONSOLE SOFTWARE 20
STRUCTURE OF THE SOFTWARE 21
SETUP 22
NETWORK SETTING 24
ETHERNET PROTOCOLS 29
DALI SCI 30
DALI SCI2 33
DALI SCI3 38
DALI SCI4 50
MECHANICAL DIMENSIONS 59
ORDERING INFORMATIONS 60
ACCESSORIES 60
DISCLAIMER 61
OTHER REGULATIONS AND STANDARDS 61
WARRANTIES AND TECHNICAL SUPPORT 62
RETURN POLICY 62
UPDATED DOCUMENTATION:
Dear customer, we thank you for your attention and we remind you that
you need to check that the following document is:
Updated
Related to the product you own
To obtain the most recently updated document, note the “document code”
that appears at the top right-hand corner of each page of this document
With this “Document Code” go to web page www adfweb com/download/
and search for the corresponding code on the page Click on the proper
“Document Code” and download the updates
REVI ION LI T:
WARNING:
ADFweb com reserves the right to change information in this manual about
our product without warning
ADFweb com is not responsible for any error this manual may contain
TRADEMARK :
All trademarks mentioned in this document belong to their respective
owners
Revision Date Author Chapter Description
1 000 15/06/2016 Ff All First Release
1 001 11/03/2019 Ff All Added SCI protocols

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
DALI
/ Ethernet
Document code: MN67839_ENG Revision 1 001 Pagina 3 di 62
ECURITY ALERT:
G ENERAL I NFORMATION
To ensure safe operation, the device must be operated according to the instructions in the manual When using the device, legal and
safety regulation are required for each individual application The same applies also when using accessories
I NTENDED U E
Machines and systems must be designed so the faulty conditions do not lead to a dangerous situation for the operator (i e
independent limit switches, mechanical interlocks, etc )
Q UALIFIED P ER ONNEL
The device can be used only by qualified personnel, strictly in accordance with the specifications
Qualified personnel are persons who are familiar with the installation, assembly, commissioning and operation of this equipment and
who have appropriate qualifications for their job
R E IDUAL R I K
The device is state-of-the-art and is safe The instruments can represent a potential hazard if they are inappropriately installed and
operated by untrained personnel These instructions refer to residual risks with the following symbol:
This symbol indicates that non-observance of the safety instructions is a danger for people that could lead to serious injury or
death and / or the possibility of damage
CE CONFORMITY
The declaration is made by our company You can send an email to support@adfweb com or give us a call if you need it

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
DALI
/ Ethernet
Document code: MN67839_ENG Revision 1 001 Pagina 4 di 62
EXAMPLE OF CONNECTION:

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
DALI
/ Ethernet
Document code: MN67839_ENG Revision 1 001 Pagina 5 di 62
CONNECTION CHEME:
Figure 1: Connection scheme for HD67839-B2

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
DALI
/ Ethernet
Document code: MN67839_ENG Revision 1 001 Pagina 6 di 62
CHARACTERI TIC :
The HD67839 is a DALI / Ethernet - Converter
It has the following characteristics:
Up to 64 devices on DALI bus;
Configurator for DALI network/devices;
DALI 1 and DALI 2 supported;
SCI1, SCI2 protocols supported;
Isolation between DALI – Ethernet, Power Supply - Ethernet Additional isolation Power Supply – DALI for HD67839-B2-N version;
Two-directional information between DALI bus and Ethernet bus;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8…24V AC or 12…35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F]
CONFIGURATION:
You need “DALI Console” software on your PC in order to perform the following:
Configure the DALI network;
Setup the DALI devices (groups, scenes, IDs, …);
Test DALI communication
You need Compositor SW67839 software on your PC in order to perform the following:
Define the parameter of Ethernet line;
Define the parameter of DALI line;
Update the device

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
DALI
/ Ethernet
Document code: MN67839_ENG Revision 1 001 Pagina 7 di 62
POWER UPPLY:
The devices can be powered at 8…24V AC and 12…35V DC For more details see the two tables below
VAC
VDC
Vmin Vmax Vmin Vmax
8V 24V 12V 35V
Consumption at 24V DC:
Device Consumption [W/VA]
HD67839-B2 3 5
HD67839-B2
Caution: Not reverse the polarity power

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
DALI
/ Ethernet
Document code: MN67839_ENG Revision 1 001 Pagina 8 di 62
FUNCTION MODE :
The device has got two functions mode depending of the position of the ‘Dip1 of Dip-Switch A’:
The first, with ‘Dip1 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device
The second, with ‘Dip1 of Dip-Switch A’ at “ON” position, is used for upload the Project and/or Firmware
For the operations to follow for the updating, see ‘UPDATE DEVICE’ section
According to the functioning mode, the LEDs will have specifics functions, see ‘LEDS’ section

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
DALI
/ Ethernet
Document code: MN67839_ENG Revision 1 001 Pagina 9 di 62
LED :
The device has got five LEDs that are used to give information of the functioning status
The various meanings of the LEDs are described in the table below
LED Normal Mode Boot Mode
1: Device State (green) Blinks slowly (~1Hz) Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
2: Ethernet communication
(yellow) Blinks when Ethernet communication is running Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
3: DALI communication
(yellow) Blinks when DALI communication is running Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
4: DALI error (yellow) Turns ON when the DALI device is not present Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
5: Ethernet Link (green) ON: Ethernet cable connected
OFF: Ethernet cable disconnected
ON: Ethernet cable connected
OFF: Ethernet cable disconnected

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
DALI
/ Ethernet
Document code: MN67839_ENG Revision 1 001 Pagina 10 di 62
DALI:
DALI stands for “Digital Addressable Lighting Interface” and it is an interface protocol for digital
communication between electronic lighting equipment (electronic ballasts, transformers, etc )
With the right choice of individual DALI components an extremely wide range of requirements can be met,
from operating the lighting system from a simple light switch to lighting management systems for entire
office complexes with thousands of light sources Using ADFweb com’s DALI converters, any light source,
including incandescent lamps, fluorescent lamps, high-intensity discharge lamps and even LEDs, can be
controlled irrespective of whether they are installed in an office, a restaurant or a street light
Characteristics Description
Medium Shielded Twisted Pair
Topology Linear, Star or mixed
Device power consumption Max 250 mA
DALI voltage 9 5 V – 22 5 V (typical 16 V)
Maximum cable length 300 m (1 5 mm2 wire)
Maximum number of DALI
devices 64
Baud rate 1200 bps
Maximum number of DALI
groups 16
Maximum number of DALI
scenes 16

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
DALI
/ Ethernet
Document code: MN67839_ENG Revision 1 001 Pagina 11 di 62
ETHERNET:
The Ethernet port is used for the Ethernet communication, for programming DALI network and for programming the device
The Ethernet connection must be made using Connector2 of HD67839-B2 with at least a Category 5E cable The maximum length of the
cable should not exceed 100m The cable has to conform to the T568 norms relative to connections in cat 5 up to 100 Mbps To connect the
device to an Hub/Switch is recommended the use of a straight cable, to connect the device to a PC is recommended the use of a cross cable

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
DALI
/ Ethernet
Document code: MN67839_ENG Revision 1 001 Pagina 12 di 62
U E OF COMPO ITOR W67839:
To configure the Converter, use the available software that runs with Windows called SW67839 It is downloadable on the site
www adfweb com and its operation is described in this document (This manual is referenced to the last version of the software present on
our web site) The software works with MSWindows (XP, Vista, Seven, 8, 10; 32/64bit)
When launching the SW67839, the window below appears (Fig 2)
Note:
It is necessary to have installed Net Framework 4
Figure 2: Main window for SW67839

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
DALI
/ Ethernet
Document code: MN67839_ENG Revision 1 001 Pagina 13 di 62
NEW CONFIGURATION / OPEN CONFIGURATION:
The “New Configuration” button creates the folder which contains the entire device’s configuration
A device’s configuration can also be imported or exported:
To clone the configurations of a Programmable “DALI / Ethernet - Converter” in order to
configure another device in the same manner, it is necessary to maintain the folder and
all its contents;
To clone a project in order to obtain a different version of the project, it is sufficient to
duplicate the project folder with another name and open the new folder with the button
“Open Configuration”

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
DALI
/ Ethernet
Document code: MN67839_ENG Revision 1 001 Pagina 14 di 62
OFTWARE OPTION :
By pressing the “ ettings” ( ) button there is the possibility to change the language of the software and check the updatings for the
compositor
In the section “Language” it is possible to change the language of the
software
In the section “Connection Options”, it is possible to check if there are some
updatings of the software compositor in ADFweb com website
Checking the option “Check oftware Update at tart of Program”, the
SW67839 check automatically if there are updatings when it is launched

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
DALI
/ Ethernet
Document code: MN67839_ENG Revision 1 001 Pagina 15 di 62
In the section “Software Settings”, it is possible to enable/disable some
keyboard’s commands for an easier navigation inside the tables contained in
the different sections of the software

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
DALI
/ Ethernet
Document code: MN67839_ENG Revision 1 001 Pagina 16 di 62
ET COMMUNICATION:
This section define the fundamental communication parameters of Ethernet bus
By Pressing the “ et Communication” button from the main window for SW67839 (Fig 2) the
window “Set Communication” appears (Fig 3)
The means of the fields for the “Ethernet” section are:
In the field “IP ADDRE ” the IP address of the converter is defined;
In the field “ UBNET Mask” the SubNet Mask is defined;
In the field “GATEWAY” the default gateway of the Ethernet network is defined This feature
can be enabled or disabled pressing the Check Box field This feature is used for going out of
the net
The means of the fields for the “DALI” section are:
In the field “DALI Console Port” the UDP port used for Ethernet communication is defined;
If the field “ witch off DALI on TimeOut” is checked, the DALI line is switched off if any
Ethernet commands is received in the defined ”TimeOut (ms)”;
If the option “Disable DALI can” is checked, the automatic scanning of DALI side is
disabled The DALI side is scanned only on Ethernet command;
If the option “Enable DALI 2” is checked, DALI 2 functions are enabled (normally used with
DALI sensors, actuators, exc )
Figure
3
:
“Set Communication” window

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
DALI
/ Ethernet
Document code: MN67839_ENG Revision 1 001 Pagina 17 di 62
DALI ACCE :
By pressing the “DALI Access” button from the main window for SW67839 (Fig 2) the window “Select the DALI Device Present in the
Network” appears (Fig 4)
This section is used to define the DALI devices connected to the converter It is enough to check/uncheck the connected/unconnected DALI
devices
Figure
4
:
“DALI Access” window

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
DALI
/ Ethernet
Document code: MN67839_ENG Revision 1 001 Pagina 18 di 62
UPDATE DEVICE:
By pressing the “Update Device” button, it is possible to load the created Configuration into the device; and also the Firmware, if
necessary
If you don’t know the actual IP address of the device you have to use this
procedure:
Turn OFF the Device;
Put Dip1 of ‘Dip-Switch A’ in ON position;
Turn ON the device
Connect the Ethernet cable;
Insert the IP “192.168.2.205”;
Select which operations you want to do;
Press the “Execute update firmware” button to start the upload;
When all the operations are “OK” turn OFF the Device;
Put Dip1 of ‘Dip-Switch A’ at OFF position;
Turn ON the device
If you know the actual IP address of the device, you have to use this procedure:
Turn on the Device with the Ethernet cable inserted;
Insert the actual IP of the Converter;
Select which operations you want to do;
Press the “Execute update firmware” button to start the upload;
When all the operations are “OK” the device automatically goes at Normal Mode
At this point the configuration/firmware on the device is correctly update
Fi
gure 5: “Update device” windows

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
DALI
/ Ethernet
Document code: MN67839_ENG Revision 1 001 Pagina 19 di 62
Note:
When you install a new version of the software, if it is the first time it is better you do the update of the Firmware in the HD67839
device
Note:
When you receive the device, for the first time, you also have to update the Firmware in the HD67839 device
Warning:
If Fig 6 appears when you try to do the Update try these points before seeking
assistance:
Try to repeat the operations for the updating;
Try with another PC;
Try to restart the PC;
Check the LAN settings;
Check the Wi-Fi settings;
If you are using the program inside a Virtual Machine, try to use in the main
Operating System;
If you are using Windows Seven, Vista, 8 or 10 make sure that you have the
administrator privileges;
In case you have to program more than one device, using the "UDP Update", you
have to cancel the ARP table every time you connect a new device on Ethernet For do
this you have to launch the "Command Prompt" and write the command "arp -d" Pay
attention that with Windows Vista, Seven, 8, 10 you have to launch the "Command
Prompt" with Administrator Rights;
Pay attention at Firewall lock
In the case of HD67839 you have to use the software “SW67839”: www adfweb com\download\filefold\SW67839 zip
Figure 6: “ rotection” window

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
DALI
/ Ethernet
Document code: MN67839_ENG Revision 1 001 Pagina 20 di 62
U E OF DALI CON OLE OFTWARE:
To configure DALI network and test the communication, it is possible to use the available software that runs with Windows called “DALI
Console” It is downloadable on the site www adfweb com and its operation is described in this document (This manual is referenced to the
last version of the software present on our web site) The software works with MSWindows (XP, Vista, Seven, 8, 10; 32/64bit)
When launching the DALI Console, the window below appears (Fig 7)
Figure 7: Main window for DALI Console
