ADTRAN 3192 HDSL4 Operating instructions

HDSL4 3192 H4TU-C
1221404L1
DSX
ALM
DSL 1
DSL 2
LBK
ESF
/SF
B8ZS
/AMI
H TUC
TX
RX
TX
RX
DSX MON
DSX EQ
HDSL4 3192
H4TU-C
CLEI: T1L133X4_ _
LED STATUS
DSL1/DSL2 ●Green Loop 1/ Loop 2 synchronization achieved and signal is present.
No errors currently detected, and SNR margin ≥6 dB.
●Red Loop 1/ Loop 2 synchronization not achieved, in sync with errors,
or SNR margin ≤6 dB.
DSX ●Green DSX-1 signal present and no errors currently detected.
●Red In framed mode, denotes loss of framing or loss of sync at the
DSX-1 input. In unframed mode, denotes loss of signal DSX-1
input.
ALM ●●Off No T1 alarms are active.
●Red Loss of DSX-1 signal from the network.
●Yellow Loss of DS1 signal from the CPE.
ESF/SF ●●Off Unframed.
●Yellow ESF framing
●Green SF framing
B8ZS/AMI ●Yellow B8ZS line coding.
●Green AMI line coding.
LBK ●●Off No local loopbacks active.
●Yellow Local loopback active.
DSX EQ SPLITTING JACKS
TX DSX-1 transmit toward the local loop (intrusive)
RX DSX-1 receive from the local loop (intrusive)
DSX MONITOR JACKS
TX DSX-1 transmit toward the local loop (nonintrusive)
RX DSX-1 receive from the local loop (nonintrusive)
COMPLIANCE
This product is intended for installation in restricted access locations only and in equipment
with a Type “B” or “E” enclosure.
The DSX-1 interface is intended for connection to intra-building wiring only.
This product provides span powering voltage (negative only with respect to ground, -190 VDC
nominal, GFI protection < 5 mA) and meets all requirements of Bellcore GR-1089-CORE (Class A2)
and ANSI T1.418 Issues 1 and 2.
■ For a complete Installation and Maintenance Practice (P/N 61221404L4-5): [phone], faxback Document 795. Please have your fax number ready. ■
C A U T I O N
C A U T I O N
!
SUBJECT TO ELECTROSTATIC DAMAGE
OR DECREASE IN RELIABILITY.
HANDLING PRECAUTIONS REQUIRED.
utCode Input Output
Installation Code (IC) A –
Telecommunication Code (TC) – X
Power Code (PC) F C
1
2
3
4
5
6
7
8
9
10
A
B
C
D
E
F
H
J
K
L
R1 RX DSX (Out to DSX)
R TX DSX (In from DSX)
GND
R1 HDSL4 Loop 2
-48V
R HDSL4 Loop 1
T TX DSX (In from DSX)
T1 RX DSX (Out to DSX)
RCV LOS (to Alarm Module)
T1 HDSL4 Loop 2
Frame Ground
T HDSL4 Loop 1
Fuse Alarm (to Alarm Module)
H4TU-C EDGE CONNECTOR WIRING
JOBAID
61221404L1-22A
0206
#61221404L1-22A#

HDSL4 TROUBLESHOOTING GUIDE
ADTRAN HDSL4 equipment is designed with troubleshooting-at-a-glance features. The following information
provides suggestions for troubleshooting as a result of LED indications which are indicative of loop trouble.
NOTE: Pressing “ESC” while on any screen will go back to the previous screen.
INDICATIONS AND POSSIBLE CAUSES
DSL LED Yellow
Connect a terminal or PC to the RS-232 (DB-9) craft interface on faceplate. The terminal must be VT100 or
compatible and set for 1.2 to 19.2 kbps, 8 data bits, no parity, 1 stop bit, No Flow control. Select “3”from the
ADTRAN HDSL4 Main Menu Screen and “1”from the Span Status Screen. Verify the following
conditions on the Detailed HDSL4 and T1 Status Screen:
■Margin ≥6 dB
■Pulse Attenuation ≤35 dB (1st segment)
Pulse Attenuation ≤31 dB (2nd/3rd segment)
■No HDSL, ES, SES, or UAS (Performance
History Screen, Main Menu Selection 5)
If the above conditions exist, the circuit should
provide quality service; however, if any of the above
conditions do not exist, a cable problem or excessive
loss situation is probable, and more detailed cable
testing should be done to verify all HDSL4 Loop
Specifications are met. These conditions may also
reflect intermittent cable faults or excessive noise
impairments. If intermittent faults or noise
impairments are suspected, review the Performance
History Screen.
NOTE: The insertion loss reading shown on the Detailed Status Screen is an approximation that is valid for some loops.
Caution should be used when using this value.
HCRC LED Yellow
Indicates four or more HDSL4 CRC errors have occurred within the last 30 minutes. Select “5”from the HDSL4
Main Menu to review the Performance History Screen. If the DSL LED is Yellow, verify the span between the
H4TU-C and the next HDSL4 element (i.e. H4R, H4TU-R) meets HDSL4 Loop Specifications.
HDSL4 DEPLOYMENT GUIDELINES
The first segment of the circuit is defined as the section of the HDSL4 loop between the H4TU-C and the first H4R,
the second segment is between the first H4R and the second H4R (dual repeater designs) or between the H4R and
the H4TU-R (single repeater designs), and the third segment is between the second H4R and the H4TU-R.
NOTE: If dual repeaters are used in the circuit, please refer to the “HDSL4 Deployment Guidelines”section of the Installation
and Maintenance Practice for DC resistance guidelines for span powering.
■Margin ≥6 dB
■Pulse Attenuation ≤35 dB (1st segment)
Pulse Attenuation ≤31 dB (2nd/3rd segment)
■All loops are nonloaded
■Any single bridge tap is limited to 2 kft
■Total bridge tap length is limited to 2.5 kft
■Loop length up to 16 kft (24 AWG) on circuit containing no H4Rs
■Loop length up to 16 kft first segment and 15 kft second segment (24 AWG) on circuit containing one H4R
■Loop length up to 13.5 kft first segment, 14 kft second segment, 15 kft third segment (24 AWG) on circuit containing
two H4Rs
■First segment (or a circuit containing no H4Rs) Insertion Loss ≤46 dB
■Second and third segment Insertion Loss ≤42 dB
■Maximum loop resistance is 1150 Ohms for circuits without an H4R.
■Impulse Noise =50 dBrn as measured using a 50 kb filter
■Wideband Noise =31 dBrn as measured using a 50 kb filter
■Foreign Voltage DC (t-r, t-g, r-g) < 3 VDC
■Insulation Resistance (t-r, r-g, t-g) > 3.5 M
■Longitudinal Noise (Power Influence) < 80 dBrnC
LOOPBACK AND CONTROL CODES
Pattern Description Requires Arming?
1in3 Loop down all units and disarm No
2in5 Arming Pattern, HTU-R will loop up if Smartjack LB is enabled No
3in5 Disarm and loop down all units. Restores LB TMO after D5D6 No
1in6 Network Arming Pattern. If Smartjack LB is Enabled, HTU-R will loop toward Network. No
2in6 H4R LB to Network
3in6 H4R LB to Network
4in6 H4R LB to Customer
5in6 H4R LB to Customer
3in7 H4TU-R LB to Network No
4in7 H4TU-C LB to Network No
5in7 H4TU-R LB to Customer No
6in7 H4TU-C LB to Customer No
3F1E H4TU-C LB to Customer No
3F02 H4TU-R LB to Customer No
3F04 H4R LB to Customer
3F06 H4R LB to Customer
6767 Disable span powering while present Yes
9393 Loop down HTU-C, Repeaters - all loopbacks. Loop down H4TU-R - Cust LB always.
Will only loop down HTU-R Net LB if NIU is disabled. Does not Disarm units if they are armed. No
C741 H4R #1 loop up pattern. 10 bit error injection. Yes
C742 H4TU-R loop up pattern. 20 bit error injection. Yes
C754 H4R #2 loop up pattern. 200 bit error injection. Yes
D3D3 H4TU-C loop up pattern. 231 bit error injection. Yes
D5D5 Query Loopback Pattern (error injection)
H4TU-C: 231 Errors, H4R #1: 10 Errors, H4R #2: 200 Errors, H4TU-R: 20 Errors No
D5D6 Loopback Timeout Override: Disables LB timeout. Restores original LB timeout when unit is
disarmed. Yes
FF48 FDL Arming Pattern (ESF only). Arms all units, H4TU-R will LB to Network if NIU Enabled
(if pattern sources at network). No
FF24 FDL Disarm Pattern (ESF only). Loop down and disarm all units No
FF1E H4TU-C LB to Network. Will not loop up H4TU-C if H4TU-C already in LB to Customer. No
FF02 H4TU-R LB to Network. Will not loop up H4TU-R if any unit already in LB to Customer. No
FF04 H4R LB to Network
FF06 H4R LB to Network
