ADTRAN SOOTAK8J Series User manual

jobAid
DESCRIPTION
TheSmallForm‐FactorPluggable(SFP)GigabitEthernet,
Single‐FiberisabidirectionalSFPthatplugsintoan
OpticalLineTerminal(OLT)designedtoacceptSFPs.The
SFPprovidesasingleopticalinterfacetotheGigEphysical
interface.InstalledintoanappropriateOLT,theSFP
providesaGigabitEthernetinterfacetothesupporting
system.
NOTE
Toensurecompatibility,refertothedocumentation
providedwiththeOLT.
NOTICE
InadeploymentconsistingofanOLTwitha1442180G2
SFPinstalled;theNetworkUnit(ONT)shouldhavea
complementary1442180G1SFPinstalled.
ThefollowingfeaturesaresupportedontheSFP:
♦1000Base‐LX1490nmTransmitter
♦1000Base‐LX1550nmReceiver
♦Opticaldistance:80kmmaximum
CAUTION
!
Duetocompliancecertificationrequirements,onlySFPs
suppliedbyADTRANshouldbeused.ADTRANcannot
certifysystemintegritywithotherSFPs.
OLT
1442180G1 1442180G2
ONU
Rx: 1490 nm
Tx: 1550 nm
Rx: 1550 nm
Tx: 1490 nm
Small Form-Factor Pluggable
1490nm TX 1550nm RX 80km
Operational Specifications
♦OpticalSpecifications:
◊Transmitwavelength:1490nm
◊Receivewavelength:1550nm
◊Opticaltransmitlevel:–2dBmto+3dBm
◊Opticalreceivelevel:–25dBmto–3dBm
◊Opticaldistance:80km
◊Opticalconnectors:LC
♦ExtendedEnvironmentalSupport:
◊Operationaltemperaturerange:–40°Cto+70°C
◊Storagetemperaturerange:–40°Cto+85°C
◊Relativehumidityto95%,noncondensing
INSTALLATION
Priortoinstallation,inspecttheSFP.Ifdamagehasoccured
duringshipping,fileaclaimwiththecarrier,andthen
contactADTRANCustomerSupport.Formoreinfor‐
mation,referto“Warranty”.
ToinstalltheSFPintoanappropriatemodule,completethe
followingsteps:
1. InserttheSFPintotheSFPcageonthecircuitboardof
thehostmodulewiththelatchhandlefacingoutward.
SlidetheSFPallthewayintothecage.
NOTE
ThelatchontheSFPisforremovalonly.Whenremoving
theSFP,rotatethelatchawayfromtheSFP,theSFPshould
slideeasilyoutofthecage.
2. ExertadequatepressuretoensuretheSFPis
completelyseatedintheSFPcage.
3. Donotremovetheconnectorpluguntiltheoptical
fiberconnectionismade.
NOTICE
Itisrecommendedthattheconnectorplugremainon
wheneverthetranscieveropticalfiberconnectorisnot
inserted.
4. Continuetheinstallationandturn‐upofthehost
moduleusingtheinstructionsintheJobAidprovided
withthemodule,orusingtheInstallationand
MaintenancePractice(I&M)availableonlineat
www.adtran.com.
CLEI: SOOTAK8J_ _
Product P/N: 1442180G2
Issue Date: November 2010
Document P/N: 61442180G2-22A

C A U T I O NC A U T I O N !
SUBJECT TO ELECTROSTATIC DAMAGE
OR DECREASE IN RELIABILITY.
HANDLING PRECAUTIONS REQUIRED.
Warranty: ADTRAN will replace or repair this product within the warranty period if it does not
meet its published specifications or fails while in service. Warranty information can
be found online at www.adtran.com/warranty.
©2010 ADTRAN, Inc. All Rights Reserved.
ADTRAN CUSTOMER CARE:
From within the U.S. 1.800.726.8663
From outside the U.S. +1 256.963.8716
PRICING AND AVAILABILITY 1.800.827.0807
*61442180G2-22A*
SAFETY AND REGULATORY COMPLIANCE
CAUTION
!
ElectrostaticDischarge(ESD)candamageelectronic
modules.Whenhandlingmodules,wearanantistatic
dischargewriststraptopreventdamagetoelectronic
components.Placemodulesinantistaticpackingmaterial
whentransportingorstoring.Whenworkingonmodules,
alwaysplacethemonanapprovedantistaticmatthatis
electricallygrounded.
TheSFPisNRTLListedtotheapplicableULstandards.
TheSFPmeetsorexceedsalltheapplicablerequirements
ofNEBS,TelcordiaGR‐63‐CORE,andGR‐1089‐CORE.The
SFPisintendedfordeploymentinCentralOfficetypefacil‐
ities,EEEs,EECs,andlocationswheretheNECapplies(for
example,CustomerPremises)andisintendedtobe
installedbytrainedservicepersonnel.InstalltheSFPinan
ADTRANproductlocatedinarestrictedaccesslocation.
ThisdevicecomplieswithPart15oftheFCCrules.
Operationissubjecttothefollowingtwoconditions:
1. Thisdevicemaynotcauseharmfulinterference
2. Thisdevicemustacceptanyinterferencereceived,
includinginterferencethatmaycauseundesired
operation.
Changesormodificationsnotexpresslyapprovedby
ADTRANcouldvoidtheuserʹsauthoritytooperatethis
equipment.
CAUTION
!
♦ PerGR‐1089‐COREtheADTRANsystemthattheSFPis
beingdeployedinisdesignedandintendedfor
installationaspartofaCommonBondingNetwork
(CBN).TheADTRANsystemthattheSFPisbeing
deployedinisnotdesignednorintendedforinstallation
aspartofanIsolatedBondingNetwork(IBN).
♦ PerGR‐1089‐CORESection9,theSFPdoesnothavean
internalDCconnectionbetweenbatteryreturnand
frameground.TheSFPcanbeinstalledinaDC‐I
(isolated)orDC‐C(common)configuration.For
installationswhereothercardsorthehostsystemhave
internalconnectionsbetweenbatteryreturnandframe
ground,thesystemwouldbeintendedfordeployment
onlyinaDC‐Cconfiguration.
♦ TheADTRANsystemchassisframegroundterminal
mustbeconnectedtoanearthgroundtoensurethatthe
metalenclosureoftheSFPisproperlygroundedviathe
backplaneconnector.
CAUTION
C
TheXFPisaClass1LaserProductandcomplieswiththe
LaserSafetyrequirementsofFDA21CFR1040.10and
1040.11,andIEC60825‐1and‐2.TheXFPisNRTLlisted
andCBCertifiedtoallapplicableAmericanandEuropean
safetystandards.
Forcontinuedcompliancewiththeabovelasersafety
standards,onlyapprovedClass1modulesfromour
approvedvendorlist,locatedontheADTRANwebsite,
shouldbeinstalledinADTRANproducts.
NOTE
TheGigabitEthernetport(s)areopticalandthereforeare
notclassifiedasanytypeofportasdefinedinAppendixB
ofGR‐1089‐COREIssue5.
TheSFPisdesignedtomeetthefollowingenvironmental
classes:
♦ETSIEN300019‐1‐1“Classificationofenvironmental
conditions;Storage,”Class1.2
♦ETSIEN300019‐1‐2“Classificationofenvironmental
conditions,Transportation,”Class2.3
♦ETSIEN300019‐1‐3“Classificationofenvironmental
conditions,Stationaryuseatweather‐protected
locations,”Class3.3
Theequipmentisdesignedtofunctionwithoutdegra‐
dationduringexposuretoalltestseveritiesperClass3.3of
ETSIEN300019‐1‐3.
TheSFPmeetstheEU’sRoHSDirective2002/95/ECand/or
applicableexemptions.Refertowww.adtran.comfor
furtherinformationonRoHS/WEEE.
