DESCRIPTION
The Small Form-Factor Pluggable 11.3 Gigabit Ethernet XFP, 1550
nm, Temperature Hardened (XFP) optical transceiver is a fully
duplex serial electric, serial optic device with both transmit and
receive functions contained in a single module that provides a
high speed serial link at 10 Gb/s. Installed into an appropriate
host module, the XFP provides a 10 Gigabit interface to the
supporting system.
The transmit side of the XFP converts serial NRZ electrical date at
the10 Gb/s line rate to a standard compliant optical signal. The
receive side of the XFP converts the incoming DC balanced serial
NRZ optical data at the 10 Gb/s line rate into serial electrical data.
NOTE
To ensure compatibility, refer to the documentation provided
with the host module.
FEATURES
The following features are supported on the XFP:
1550 nm optical signals for up to 40 km reach
Case temperature hardened range from –40°C to 85°C
Low power consumption (<3.5 W max)
Excellent EMI performance
Small Form-Factor Pluggable
11.3 Gigabit Ethernet XFP, 1550 nm,
Temperature Hardened
CAUTION
!
Due to compliance certification requirements, only use XFPs
supplied by ADTRAN with the host module. ADTRAN cannot
certify system integrity with other XFPs.
INSTALLATION
Before installation, inspect the XFP. If damage has occurred
during shipping, file a claim with the carrier, and then contact
ADTRAN Customer Support. For more information, refer to
“Warranty”.
Installation Guidelines
The following are guidelines for this installation.
The latch on the XFP is for removal only. When removing the
XFP, rotate the latch away from the XFP. The XFP should slide
easily out of the cage.
It is recommended that the connector plug remain on
whenever the transceiver optical fiber connector is not
inserted.
Installation Steps
To install the XFP, complete the following steps:
1. Insert the XFP into the SFP cage on the circuit board of the
host module with the latch handle facing outward. Slide the
XFP all the way into the cage.
2. Exert adequate pressure to ensure the XFP is completely
seated in the XFP cage.
3. Do not remove the connector plug until the optical fiber
connection is made.
4. Continue the installation and turn-up of the host module.
CLEI: BVL3AWWD_ _
Product P/N: 1442941F1
Issue Date: June 2014
Document P/N: 61442941F1-22B
Documentation for ADTRAN Carrier Networks products is available for
viewing and download directly from the ADTRAN Support Community
website.
Go to: https://supportforums.adtran.com/welcome
Registration is required.
ADTRAN offers training courses on our products, including customized
training and courses taught at our facilities or at customer sites.
For inquiries, go to: http://adtran.com/training
The following documents provide additional information for this product:
SFP/XFP/SFP+ Compatibility Matrix and Engineering Guide

C A U T I O N
C A U T I O N
!
SUBJECT TO ELECTROSTATIC DAMAGE
OR DECREASE IN RELIABILITY.
HANDLING PRECAUTIONS REQUIRED.
Warranty: ADTRAN will replace or repair this product
within the warranty period if it does not meet
its published specifications or fails while in
service. Warranty information can be found
online at www.adtran.com/warranty.
©2014 ADTRAN, Inc. All Rights Reserved. *61442941F1-22B*
ADTRAN CUSTOMER CARE:
From within the U.S. 1.800.726.8663
From outside the U.S. +1 256.963.8716
PRICING AND AVAILABILITY 1.800.827.0807
SPECIFICATIONS
Optical Specifications:
oTransmit Wavelength: 1530 to 1565 nm
oReceive Wavelength: 1270 to 1600 nm
oData rate: 9.95 Gb/s to 11.35 Gb/s
oOptical transmit level: –1.0 to +2.0 dBm
oOptical receive level: –15.0 to –1.0 dBm
oOptical distance: 40 km maximum
oOptical connectors: LC
Extended Environmental Support:
oOperational temperature range: –40°C to +65°C
oStorage temperature range: –40°C to +85°C
oRelative humidity to 85%, noncondensing
SAFETY AND REGULATORY COMPLIANCE
WARNING
!
Read all warnings and cautions before installing or servicing this
equipment.
CAUTION
C
The XFP is a Class 1 Laser Product and complies with the Laser
Safety requirements of FDA 21CFR 1040.10 and 1040.11, and
EN60825-1 and -2. The XFP is NRTL listed and CB Certified to all
applicable American and European safety standards.
For continued compliance with the above laser safety standards,
only approved Class 1 modules from our approved vendor list,
located on the ADTRAN website, should be installed in ADTRAN
products.
CAUTION
!
Electrostatic Discharge (ESD) can damage electronic modules.
When handling modules, wear an antistatic discharge wrist
strap to prevent damage to electronic components. Place
modules in antistatic packing material when transporting or
storing. When working on modules, always place them on an
approved antistatic mat that is electrically grounded.
The XFP meets or exceeds all the applicable requirements of
NEBS, Telcordia GR-63-CORE, and GR-1089-CORE. The XFP
is intended for deployment in Central Office type facilities,
EEEs, EECs, and locations where the NEC applies (for
example, Customer Premises). The XFP is to be installed in
ADTRAN products in Restricted Access Locations only, and
installed by trained service personnel.
Per GR-1089-CORE, the ADTRAN system in which the XFP is
being deployed is designed and intended for installation as
part of a Common Bonding Network (CBN). The ADTRAN
system in which the SFP is being deployed is not designed nor
intended for installation as part of an Isolated Bonding
Network (IBN).
Per GR-1089-CORE Section 9, the XFP does not have an
internal DC connection between battery return and frame
ground. The XFP can be installed in a DC-I (isolated) or DC-C
(common) installation. For installations where other cards or
the host system have internal connections between battery
return and frame ground, the system would be intended for
deployment only in a DC-C installation.
The ADTRAN system chassis frame ground terminal must be
connected to a reliable earth ground to ensure that the metal
enclosure of the XFP is properly grounded via the backplane
connector.
NOTE
The Gigabit Ethernet port(s) are optical and therefore are not
classified as any type of port as defined in Appendix B of GR-
1089-CORE.
This product is designed to be deployed in GR-3108-CORE
environmental Class 1, 2, & 3.
This device complies with FCC 47 CFR Part 15, Class B. Operation
is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.
Changes or modifications not expressly approved by ADTRAN
could void the user's authority to operate this equipment.
The XFP is designed to meet the following environmental classes:
ETSI EN 300 019-1-1 “Classification of environmental
conditions; Storage,” Class 1.2
ETSI EN 300 019-1-2 “Classification of environmental
conditions, Transportation,” Class 2.3
ETSI EN 300 019-1-3 “Classification of environmental
conditions, Stationary use at weather-protected locations,”
Class 3.3
The equipment is designed to function without degradation
during exposure to all test severities per Class 3.3.
This product meets EU RoHS Directive 2002/95/EC and/or
applicable exemptions. Refer to www.adtran.com for further
information on RoHS/WEEE.
