ADTRAN 1184561P4 User manual

jobAid
1
DESCRIPTION
TheSmallForm‐FactorPluggableGigabitEthernet,Copper
(SFPGC)plugsintoADTRANGigabitEthernetmodules
designedtoacceptSmallForm‐factorPluggables(SFPs).Installed
intoanappropriatehostmodule,theSFPGCprovides1000Mbps
fullduplexdata‐linkswith5‐levelPulseAmplitudeModulation
(PAM)signaloverunshieldedtwisted‐pairCat5cable.
NOTE
Toensurecompatibility,refertothedocumentationprovided
withthehostmodule.
ThefollowingfeaturesaresupportedontheSFPGC:
♦Upto1.25Gbpsbidirectionaldatallinks
♦100metermaximumdistanceovershieldedtwisted‐pairCat5
cable
CAUTION
!
Duetocompliancecertificationrequirements,useonlySFPs
suppliedbyADTRANwiththehostmodule.ADTRANcannot
certifysystemintegritywithotherSFPs.
Operational Specifications
♦Operationaltemperaturerange:–40°Cto+65°C
♦Operationalaltituderange:–197feet(–60meters)to13,000
feet(3,962meters)
◊From–197feet(–60meters)to6,000feet(1,800meters)the
operatingtemperatureisderatedby1.6°C/1,000feet.
◊From6,000feet(1,800meters)to13,000feet(4,000meters)
theoperatingtemperatureisderatedby1.4°C/1,000feet.
♦Storagetemperaturerange:–40°Cto+100°C
♦Relativehumidityto95%,noncondensing
Small Form-Factor Pluggable Gigabit
Ethernet, Copper
INSTALLATION
ToinstalltheSFPGCintoanappropriatemodule,completethe
followingsteps:
1. InspecttheSFPGC.Ifdamaged,fileaclaimwiththecarrier
andthencontactADTRANCustomerService.
2. Removetheblacksafetycapfromtheconnectorofthe
SFPGC.
3. InserttheSFPGCintothereceptacleonthecircuitboardof
thehostmodule,withthemanufacturer’slabelfacing
outward.SlidetheSFPGCallthewayintothereceptacle.
4. Usingthumbandforefinger,firmlysqueezethereceptacle
andSFPGCtogether,toensureaproperconnection.
NOTE
ThelatchontheSFPisforremovalonly.
5. Continuetheinstallationandturn‐upofthehostmodule
usingtheinstructionsintheJobAidorInstallationand
MaintenanceGuide(I&M)providedwiththatmodule.Both
areavailableonlineatwww.adtran.com.
PROVISIONING
TheSFPGCisnotdirectlyprovisionable.ToprovisiontheSFPGC,
accessthemenusystemofthehostmodule.Refertothe“Provi‐
sioning”sectionoftheJobAidorI&Mprovidedwiththehost
moduleforprovisioningdetails.
COMPLIANCE
CAUTION
!
♦ ElectrostaticDischarge(ESD)candamageelectronicmodules.
Whenhandlingmodules,wearanantistaticdischargewrist
straptopreventdamagetoelectroniccomponents.Place
modulesinantistaticpackingmaterialwhentransportingor
storing.Whenworkingonmodules,alwaysplacethemonan
approvedantistaticmatthatiselectricallygrounded.
♦ TheSFPGCisNRTLListedtotheapplicableULstandards.The
SFPGCmeetsorexceedsalltheapplicablerequirementsof
NEBS,TelcordiaGR‐63‐CORE,andGR‐1089‐CORE.The
SFPGCisintendedfordeploymentinCentralOfficetype
facilities,EEEs,EECs,andlocationswheretheNECapplies
(ex.CustomerPremises).InstalltheSFPGCinanADTRAN
productlocatedinarestrictedaccesslocation.
ThisdevicecomplieswithPart15oftheFCCrules.Operationis
subjecttothefollowingtwoconditions:
1. Thisdevicemaynotcauseharmfulinterference
2. Thisdevicemustacceptanyinterferencereceived,including
interferencethatmaycauseundesiredoperation.
ChangesormodificationsnotexpresslyapprovedbyADTRAN
couldvoidtheuserʹsauthoritytooperatethisequipment.
CLEI: SIPQ0CUF_ _
Product P/N: 1184561P4
Issue Date: May 2010
Document P/N: 61184561P4-22C
C A U T I O N
C A U T I O N
!
SUBJECT TO ELECTROSTATIC DAMAGE
OR DECREASE IN RELIABILITY.
HANDLING PRECAUTIONS REQUIRED.
For more information, refer to the Installation and Maintenance Guide (P/N 61184561P4-5)
available online at www.adtran.com.
Warranty: ADTRAN will replace or repair this product within the warranty period if it does not
meet its published specifications or fails while in service. Warranty information can
be found online at www.adtran.com/warranty.
©2010 ADTRAN, Inc. All Rights Reserved.
ADTRAN CUSTOMER CARE:
From within the U.S. 1.800.726.8663
From outside the U.S. +1 256.963.8716
PRICING AND AVAILABILITY 1.800.827.0807
*61184561P4-22C*
WARNING
!
TheGigabitEthernetportisclassifiedasType2orType4,as
definedinAppendixBofGR‐1089‐COREIssue4,andissuitable
forconnectiontointra‐buildingorunexposedwiringorcabling
only.Donotmetallicallyconnectthisporttointerfaceswhich
connecttotheOutsidePlant(OSP)ortotheOSPwiring.The
GigabitEthernetportisdesignedforuseasanintrabuilding
interfaceonly(Type2orType4portsasdescribedinGR‐1089‐
COREIssue4)andrequiresisolationfromexposedOSPcabling.
TheadditionofPrimaryProtectorsisnotsufficientprotectionin
ordertoconnectthisinterfacemetallicallytoOSPwiring.The
GigabitEthernetportissuitableforconnectiononlytoshielded
intra‐buildingcablinggroundedatbothends.
CAUTION
!
♦ PerGR‐1089‐COREtheADTRANsystemthattheSFPisbeing
deployedinisdesignedandintendedforinstallationaspartof
aCommonBondingNetwork(CBN).TheADTRANsystem
thattheSFPisbeingdeployedinisnotdesignednorintended
forinstallationaspartofanIsolatedBondingNetwork(IBN).
♦ PerGR‐1089‐CORESection9,theSFPGCdoesnothavean
internalDCconnectionbetweenbatteryreturnandframe
ground.TheSFPGCcanbeinstalledinaDC‐I(isolated)orDC‐
C(common)installation.Forinstallationswhereothercardsor
thehostsystemhaveinternalconnectionsbetweenbattery
returnandframeground,thesystemwouldbeintendedfor
deploymentonlyinaDC‐Cinstallation.
♦ TheADTRANsystemchassisframegroundterminalmustbe
connectedtoanearthgroundtoensurethatthemetal
enclosureoftheSFPGCisproperlygroundedviathe
backplaneconnector.
TheSFPGCisdesignedtomeetthefollowingenvironmental
classes:
♦ETSIEN300019‐1‐1“Classificationofenvironmental
conditions;Storage,”Class1.2
♦ETSIEN300019‐1‐2“Classificationofenvironmental
conditions,Transportation,”Class2.3
♦ETSIEN300019‐1‐3“Classificationofenvironmental
conditions,Stationaryuseatweather‐protectedlocations,”
Class3.3
Theequipmentisdesignedtofunctionwithoutdegradation
duringexposuretoalltestseveritiesperClass3.3.
