ADTRAN jobAid+ PR30 10G PON User manual

jobAid
1
DESCRIPTION
The PR30 Small Form-factor Pluggable (XFP) is a single-
mode fiber XFP that plugs into an ADTRAN optical interface
designed to accept XFPs. The XFP provides a single optical
interface to a physical interface, and is intended for use
with a 10 Gbps Passive Optical Network (PON) Optical Line
Termination (OLT) module. Installed into an appropriate
module, the XFP provides a 10G PON interface to the
supporting system
The XFP OLT Transceiver uses standard 1270 nm/1577
nm optics. The 1270 nm optical burst mode receiver incor-
porates APD/TIA optics for maximum sensitivity. The 10
Gigabit transmitter incorporates a 1577 nm EML DFB laser
assembly.
The following features are supported on this XFP:
■Data rate: 10 Gbps symmetrical (PR30 denotes
symmetrical high-power budget)
■Transmit Wavelength: 1577 nm
■Receive Wavelength: 1270 nm
■Optical distance: 20 km maximum
■Hot Pluggable
CAUTION
!
Due to compliance certification requirements, use only XFPs
supplied by ADTRAN. ADTRAN cannot certify system integrity
with other XFPs.
Small Form-factor Pluggable
PR30 10G PON
OLT Transceiver
INSTALLATION
Before installing the equipment, inspect the XFP. If damage has
occurred during shipping, file a claim with the carrier, and then
contact ADTRAN Customer Support. For more information, refer
to the warranty.
Installation Steps
ToinstalltheXFPintoanappropriatemodule,completethe
followingsteps:
NOTE
Do not remove the protective end cap from the XFP until the fiber
optic cable is ready to be connected.
1. Insert the XFP into the XFP cage on the module. Ensuring
that the latch on the XFP is facing upward, slide the XFP all
the way into the XFP cage until there is an audible “click”.
NOTE
The latch on the XFP is for removal only. When removing the
XFP, rotate the latch away from the XFP. It should easily slide out
of the cage.
2. Do not remove the protective end cap until the optical fiber
connection is made.
NOTICE
We recommend that the protective end cap remain on whenever
the transceiver optical fiber connector is not inserted.
3. Continue the installation and turn-up of the host module
using the instructions in the Job Aid provided with the
module or other system-level documentation available
online at www.adtran.com.
SPECIFICATIONS
Specifications for this XFP are as follows:
■Optical
♦Optical transmit level: +2.0 dBm to +5.0 dBm
♦Optical receive level: –28 dBm to –8 dBm
♦Optical Connectors: SC/UPC
♦Compatible with XFP MSA
Product P/N: 1442548F1
Issue Date: July 2016
Document P/N: 61442548F1-22A
Documentation for ADTRAN products is available for viewing and
download directly from the ADTRAN Support Community website.
Go to: https://supportforums.adtran.com/welcome
Registration is required.
ADTRAN offers training courses on our products, including customized
training and courses taught at our facilities or at customer sites.
For inquiries, go to: http://adtran.com/training
The following related online documents and resources provide additional information for this
product:
SFP/XFP/SFP+ Compatibility Matrix (online tool, go to: http://www.adtran.com/sfp)

261442548F1-22A
EMC Directive and Low Voltage Directive. Standards used to
demonstrate Compliance are EN 300 386 and EN 60950.
■This product is intended for deployment in Central Office type
facilities, EEEs, EECs, and locations where the NEC applies
(for example, Customer Premises).
■This device complies with Part 15 of the FCC rules. Operation
is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.
■Changes or modifications not expressly approved by
ADTRAN could void the user's authority to operate this
equipment.
■This product is designed to meet the following environmental
classes:
♦ETSI EN 300 019-2-1 “Classification of environmental condi-
tions; Storage Class” 1.2
♦ETSI EN 300 019-2-2 “Classification of environmental condi-
tions, Transportation”, Class 2.3
♦ETSI EN 300 019-2-3 “Classification of environmental condi-
tions, Stationary use at weather protected locations”, Class
3.1E
■This product is designed to function without degradation
during exposure to all test severities per Class 3.3 of ETSI EN
300 019-1-3.
■This product meets EU RoHS Directive 2011/65/EU and/or
applicable exemptions. Refer to www.adtran.com for further
information on RoHS/WEEE.
■Environmental
♦Operational Case Temperature Range: –40°C to +85°C
♦Storage Temperature Range: –40°C to +85°C
♦Relative Humidity: up to 95%, noncondensing
SAFETY AND REGULATORY COMPLIANCE
ENGLISH
WARNING
!
Read all warnings and cautions before installing or servicing this
equipment.
CAUTION
C
This product is a Class 1 Laser module that complies with FDA 21
CFR 1040.10 and 1040.11 and IEC 60825-1. This product is NRTL
Listed and CB Certified to all applicable American and European
safety standards. For continued compliance with the above
standards, install only ADTRAN-approved Class 1 Laser
Modules in ADTRAN products. For a list of ADTRAN-approved
SFPs and XFPs, see http:/www.adtran.com/SFP.ADTRAN
cannot certify system integrity with other laser modules.
CAUTION
!
■Electrostatic Discharge (ESD) can damage electronic modules.
When handling modules, wear an antistatic discharge wrist
strap to prevent damage to electronic components. Place
modules in antistatic packing material when transporting or
storing. When working on modules, always place them on an
approved antistatic mat that is electrically grounded.
■This product and the host system are designed and intended
for installation as part of a Common Bonding Network (CBN).
This product and the host system are not designed nor
intended for installation as part of an Isolated Bonding
Network (IBN).
■This product is designed and intended only for deployment in
a DC-C (common) bonding and grounding configuration.
This product is not intended or designed for deployment in a
DC-I (isolated) bonding and grounding system.
■The chassis frame ground terminal must be connected to an
earth ground to ensure that the exposed metal (i.e., front
panels, SFP/XFP modules) on the product is properly
grounded via the backplane connector.
NOTE
■The Gigabit Ethernet port(s) are optical and therefore are not
classified as any type of port as defined in Appendix B of GR-
1089-CORE.
■This product is designed to be deployed in GR-3108-CORE
environmental Class 1 or 2.
■This product is NRTL Listed to the applicable UL Standards.
The product is designed to meet the applicable requirements
of Telcordia GR-63-CORE and GR-1089-CORE.
■This product has also been evaluated to international safety
standards EN 60950-1, AS/NZS 60950.1, and IEC 60950-1. This
product meets the requirements for CE marking under the

61442548F1-22A 3
FRANÇAIS
AVERTISSEMENT
!
Lisez tous les avertissements et mises en garde avant l’installation
de cet équipement ou la réalisation de toute opération de
maintenance.
ATTENTION
C
Ce produit est un module laser de classe 1 qui est conforme à la
FDA 21 CFR 1040.10 et 1040.11 et IEC 60825-1. Ce produit est
NRTL et Certifié CB à toutes les normes de sécurité applicables
américains et européens. Pour maintenir la conformité avec les
normes ci-dessus, installer des modules laser de classe 1 ne
ADTRAN approuvés dans les produits d'ADTRAN. Pour une
liste des SFP et XFP ADTRAN approuvés, voir http:/
www.adtran.com/SFP.ADTRAN ne peut certifier l'intégrité du
système avec d'autres modules laser.
ATTENTION
!
■L'ESD (décharge électrostatique) peut endommager les
modules électroniques. Lors de la manipulation des modules,
portez un bracelet de décharge antistatique pour éviter
d'endommager les composants électroniques. Placez les
modules dans un emballage antistatique lors du transport ou
du stockage. Lorsque vous travaillez sur les modules, placez-
les toujours sur un tapis antistatique certifié muni d'un
branchement de mise à la terre.
■La borne de terre de châssis doit être connecté à une prise de
terre pour assurer que le métal exposé (tels que les panneaux
avant, des modules SFP / XFP) sur le produit est correctement
mis à la terre via le connecteur de fond de panier.
REMARQUE
■Ce produit a été conçu pour répondre aux normes
internationales de sécurité EN 60950-1, AS / NZS 60950,1 et
IEC 60950-1.
■Ce produit est conçu pour répondre aux classes
environnementales suivantes:
♦ETSI EN 300 019-1-1: “Classification des conditions
d'environnement; Entreposage,” classe 1.2
♦ETSI EN 300 019-1-2: “Classification des conditions
d'environnements; Transport,” classe 2.3
♦ETSI EN 300 019-1-3: “Classification des conditions
d'environnements; l'utilisation à poste fixe dans des
endroits protégés contre les intempéries,” classe 3.1E
■L'équipement est conçu pour fonctionner sans degradation
lors des tests à tous les niveaux de sévérité, suivant les
spécifications de la classe 3.3 de l'ETSI EN 300 019-1-3.
■Ce produit est conforme à la directive européenne RoHS 2011/
65/EU et/ou aux exonérations applicables. Reportez-vous à
www.adtran.com pour de plus amples renseignements sur
RoHS/WEEE.
DEUTSCH
WARNUNG
!
Lesen Sie sich alle Warn- und Sicherheitshinweise durch, bevor
Sie dieses Gerät installieren oder warten.
VORSICHT
C
Dieses Produkt ist ein Klasse 1 Laser -Modul, das mit der FDA 21
CFR 1040.10 und 1040.11 und IEC 60825-1 entspricht. Dieses
Produkt wurde NRTL gelistet und CB Certified allen geltenden
amerikanischen und europäischen Sicherheitsstandards. Für die
ständige Einhaltung der oben genannten Normen, installieren Sie
nur ADTRAN zugelassene Klasse 1 Lasermodule in ADTRAN
Produkte. Eine Liste der ADTRAN zugelassene SFPs und XFPs
finden Sie unter http:/www.adtran.com/SFP. ADTRAN kann
nicht die Unversehrtheit des Netzes mit anderen Laser-Module
zertifizieren.
VORSICHT
!
■Elektrostatische Entladung (ESD) können elektronische
Baugruppen beschädigt werden. Beim Umgang mit Modulen ,
tragen Sie eine Antistatikarmband, um Schäden an
elektronischen Bauteilen zu verhindern. Ort -Module in
antistatische Verpackung, beim Transport oder Lagerung. Bei
Arbeiten an Modulen immer legen Sie sie auf einer
zugelassenen antistatische Unterlage, die elektrisch geerdet
ist.
■Der Fahrgestellrahmen Erdanschluß muß zu einer Erde
verbunden werden, um sicherzustellen, dass das freiliegende
Metall (dh Frontplatten, SFP / XFP-Module) auf dem Produkt
richtig über den Backplane-Anschluss geerdet ist.
HINWEIS
■Dieses Produkt wurde entwickelt, um internationalen
Sicherheitsnormen EN 60950-1 erfüllen, AS / NZS 60950,1 und
IEC 60950-1.
■Dieses Produkt wurde entsprechend der folgenden
Umweltklassen entwickelt:
♦ETSI EN 300 019-2-1 “Klassifizierung von Umweltbedin-
gunge”; Storage Class 1,2
♦ETSI EN 300 019-2-2”, Klassifizierung von Umweltbedin-
gungen,Transportation”, der Klasse 2.3
♦ETSI EN 300 019-2-3 “Klassifizierung von Umweltbedin-
gungen, Ortsfester Einsatz, wettergeschützten Standorten”
Klasse 3.1E
■Dieses Gerät funktioniert ohne Leistungsabfall während aller
für Klasse 3.3 von ETSI EN 300 019-1-3 vorgeschriebenen
Belastungstests.
■Dieses Produkt erfüllt die EU RoHS Richtlinie 2011/65/EU
und/oder gültige Ausnahmen. Bitte besuchen Sie
www.adtran.com für ausführlichere Informationen zu RoHS/
WEEE.

CAUTION!
SUBJECT TO ELECTROSTATIC DAMAGE
OR DECREASE IN RELIABILITY
HANDLING PRECAUTIONS REQUIRED
Warranty:ADTRAN will replace or repair this product within the warranty period if it does not
meet its published specifications or fails while in service. Warranty information can be
found online at www.adtran.com/warranty.
Trademarks: Brand names and product names included in this document are trademarks,
registered trademarks, or trade names of their respective holders.
©2016 ADTRAN, Inc. All Rights Reserved.
ADTRAN CUSTOMER CARE:
From within the U.S. 1.888.423.8726
From outside the U.S. +1 256.963.8716
PRICING AND AVAILABILITY 1.800.827.0807
*61442548F1-22A*
