Advanced Instruments OsmoPRO Multi-Sample User manual

OsmoPRO®Multi-Sample
Micro-Osmometer
User’s Guide
112005EN Rev3

OsmoPRO® Multi-Sample Micro-Osmometer User’s Guide
2
Copyright
© 2021 Advanced Instruments
This user’s guide is copyrighted by Advanced Instruments with all rights reserved. Under
copyright laws, this guide may not be reproduced in any form, in whole or part, without the prior
written consent of Advanced Instruments. All trademarks are the property of Advanced
Instruments:
• OsmoPRO®
• Hot-Line™
• Protinol™
• Clinitrol™
• Renol™
Advanced Instruments reviewed this guide thoroughly. All material contained within is believed
reliable, but the accuracy and completeness are not guaranteed or warranted, and are not
intended to be representations or warranties concerning the product described.
Hot-Line Technical Service
For any questions or problems regarding the proper operation of the instrument, contact the
Hot-Line Technical Service department by calling one of the following numbers.
• If calling from the US or Canada, dial toll free 1-800-225-4034.
• If calling from outside the US or Canada, dial [phone]
• Or fax to [phone].

OsmoPRO® Multi-Sample Micro-Osmometer User’s Guide
3
Table of contents
Safe use.................................................................................................................................... 5
Symbol conventions ................................................................................................................5
General cautions .....................................................................................................................6
FCC requirements.................................................................................................................... 7
Supplies, parts, and accessories............................................................................................ 8
Interpreting Results ................................................................................................................. 9
1. Installation & setup .............................................................................................................10
1.1 Find a location for the instrument.....................................................................................10
1.2 Unpack the instrument.....................................................................................................10
1.3 Remove the rear panel ....................................................................................................12
1.4 Remove the shipping stops..............................................................................................12
1.5 Load printer paper ...........................................................................................................14
1.6 Install turntable ................................................................................................................15
1.7 Power-up instrument........................................................................................................18
2. System overview.................................................................................................................20
2.1 Intended use....................................................................................................................20
2.2 Principles of freezing point depression.............................................................................20
2.3 Definitions........................................................................................................................22
3. System operation................................................................................................................25
3.1 Main screen .....................................................................................................................25
3.2 Legend information ..........................................................................................................26
3.3 Assistance information.....................................................................................................26
3.4 Main screen navigation....................................................................................................28
4. Testing and calibration .......................................................................................................29
4.1 Testing – loading samples with turntable installed on instrument .....................................30
4.2 Testing – loading samples with turntable removed from instrument .................................32
4.3 Cancelling loading samples .............................................................................................32
4.4 Test in progress...............................................................................................................33
4.5 Load more .......................................................................................................................33
4.6 Calibration .......................................................................................................................34
5. Standards and quality control............................................................................................37
5.1 Standards & controls .......................................................................................................37
5.2 Sample preparation .........................................................................................................37
5.3 Sample handling / pipetting technique .............................................................................37
5.4 Verifying calibration daily .................................................................................................38

OsmoPRO® Multi-Sample Micro-Osmometer User’s Guide
4
6. Results.................................................................................................................................39
6.1 Filters...............................................................................................................................39
6.2 LIS...................................................................................................................................40
6.3 Print.................................................................................................................................40
6.4 Statistics..........................................................................................................................41
6.5 Chart ...............................................................................................................................41
6.6 Export..............................................................................................................................42
7. Settings................................................................................................................................43
7.1 Date & time......................................................................................................................44
7.2 Language ........................................................................................................................45
7.3 Users...............................................................................................................................45
7.4 H/W options.....................................................................................................................47
7.5 Alignment ........................................................................................................................50
7.6 Probe resistance..............................................................................................................52
7.7 Controls ...........................................................................................................................53
7.8 LIS / LAN .........................................................................................................................56
7.9 Service ............................................................................................................................58
7.10 Restrictions....................................................................................................................60
8. Diagnostics..........................................................................................................................61
8.2 Motors .............................................................................................................................62
8.3 Sample probe ..................................................................................................................64
8.4 Barcode ...........................................................................................................................64
8.5 Events .............................................................................................................................65
8.6 Printer..............................................................................................................................67
8.7 LCD .................................................................................................................................68
8.8 Solenoid ..........................................................................................................................69
8.9 Cleaning ..........................................................................................................................69
9. Troubleshooting and service .............................................................................................70
9.1 Routine maintenance.......................................................................................................70
9.2 Troubleshooting...............................................................................................................71
A - Product specifications ......................................................................................................76
B - Performance characteristics ............................................................................................77
C - Known limitations .............................................................................................................78
D - Regulatory notices ............................................................................................................79
E - Warranty & warranty duties ..............................................................................................82
F - Supplemental laboratory information system (LIS) ........................................................85
G - Symbol definitions ............................................................................................................86
H - Product disposal & recycling ...........................................................................................88

OsmoPRO® Multi-Sample Micro-Osmometer User’s Guide
5
Safe use
To reduce the risk of bodily injury, electric shock, fire, and damage to the instrument, read and
observe the precautions in this User’s Guide.
If the product is used in a manner not in accordance with the equipment design, operating
instructions or manufacturer’s recommendations, the operation of the product may be impaired
to the extent a safety hazard is created.
Do not attempt to perform electrical work if you are not fully qualified. This manual is not a
substitute for electrical training.
Symbol conventions
The below list of symbols is for reference only. Not all symbols shown may be used on this
instrument or in the accompanying documentation.
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (service) instructions in the literature
accompanying this product.
The lightning flash with arrowhead symbol within an equilateral triangle is intended to
alert the user to the presence of uninsulated dangerous voltage within the product’s
enclosure. The dangerous voltage may be of sufficient magnitude to constitute risk of
electric shock to persons.
The static symbol within an equilateral triangle is intended to alert the user to the
presence of internal components which could be damaged by static electricity.
This static symbol is intended to alert the user to the presence of a specific component
which could be damaged by static electricity.
This symbol indicates the presence of alternating current (AC).
This symbol indicates the presence of a fuse.
This symbol indicates the presence of protective earth ground.
This symbol indicates the power is ON.
This symbol indicates the power is OFF.
Additional symbol definitions are available in Appendix G.

OsmoPRO® Multi-Sample Micro-Osmometer User’s Guide
6
General cautions
• This product should be operated only with the type of power source indicated on the
product’s electrical ratings label. Refer to the installation instructions included with the
product.
• If the power cord provided is replaced for any reason or if an alternate cord is used, the
cord must be approved for use in the local country. The power cord must be approved
for the product’s listed operating voltage and be rated at least 20% greater than the
ampere ratings marked on the product’s electrical ratings label. The cord end connects
to the product must have an IEC 60320 connector.
• Plug the product into an approved grounded electrical outlet.
• Do not disable the power cord’s grounding plug.
• If an extension cord or power strip is used, make sure the cord or strip is rated for the
product, and the total ampere ratings of all products plugged into the extension cord or
strip do not exceed 80% of the cord’s or strip’s rating limit.
• Route power cords so they are not walked on, tripped on, or pinched by items placed
upon or against them. Pay attention to the plug, electrical outlet, and the point where the
cord exits the product.
• Do not pull on cords and cables. When unplugging cords or cables, grasp the
corresponding connector.
• Do not install or use this product in any area subject to extreme short-term temperature
variations, or locations exceeding the specified operating environment temperatures.
• Never use this product in a wet area.
• To avoid injury or fire hazard, do not operate this product in an explosive atmosphere.
• Do not install or use the product on an unstable, non-level work surface.
• Do not operate this product with the covers removed or unsecured.

OsmoPRO® Multi-Sample Micro-Osmometer User’s Guide
7
FCC requirements
WARNING: Changes or modifications to this unit not expressly approved by Advanced
Instruments could void the user’s authority to operate the equipment.
This equipment was tested and found to comply with the limits for a Class B pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee interference does
not occur in an installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
• Re-orient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from the receiver connection.
• Consult the dealer or an experienced radio TV technician for help.

OsmoPRO® Multi-Sample Micro-Osmometer User’s Guide
8
Supplies, parts, and accessories
To order parts and accessories, contact the Advanced Instruments Customer Service
Department by using one of the following numbers.
800-225-4034 (toll-free within the USA and Canada, 8:00am–4:30pm EST)
[phone] (elsewhere)
[phone] (fax).
Part
Part #
Disposable micro-sample tubes, (500 tubes)
202825
Probe wiper rings (50)
202840
20 µL sampler
240820
Pipette tips (960)
800097
Printer paper (5 rolls)
FLA835
Swab cleaner kit (50)
202850
50 mOsm/kg Calibration Standard (ten 2-mL ampules) 3MA005
850 mOsm/kg Calibration Standard (ten 2-mL ampules) 3MA085
2000 mOsm/kg Calibration Standard (ten 2-mL ampules) 3MA200
Clinitrol 290 Reference Solution (ten 2-mL ampules) 3MA029
Osmolality Linearity Set (5 levels)
3LA028
Protinol Protein-Based Controls (3 levels)
3MA028
Renol Urine Osmolality Controls (2 levels)
3LA085
Evaporation cover
112081
Turntable
112077
Replacement sample probe
112140R
User’s guide USB drive 112005UG
Service manual 112008SM
NOTE: Advanced Instruments cannot guarantee the stated instrument performance
specifications and accuracy of test results unless Advanced Instruments brand consumables
are used with the instrument. Use of consumables from manufacturers other than Advanced
Instruments is not recommended and may adversely affect system calibration, performance,
operation, and accuracy of test results. Sample tubes and wiper rings are single use
consumables; sample cross contamination can occur if sample tubes and wiper rings are
reused. For information on obtaining these standards and Controls, contact Advanced
Instruments or an authorized representative.

OsmoPRO® Multi-Sample Micro-Osmometer User’s Guide
9
Interpreting Results
Data generated using Advanced Instruments standards and reference solutions may be
analyzed according to the accuracy and precision specifications of the instrument (see
Performance characteristics).
Laboratories may choose to employ one, two, or three standard deviations (SD) for accuracy
based on what is relevant in their laboratories. For normally distributed data, approximately 68%
of the individual data values will fall within one standard deviation of the mean, approximately 95%
within two standard deviations, and approximately 99.7% within three standard deviations.
Advanced Instruments
Standards and Reference
Solutions
Precision Accuracy (mOsm/kg H2O)
1 SD 2 SD 3 SD
Clinitrol™ 290 Reference Solution Standard deviation ≤3 mOsm/kg H2O 287-293 284-296 281-299
50 mOsm/kg Calibration Standard
Standard deviation ≤3 mOsm/kg H
2
O
47-53
44-56
41-59
100 mOsm/kg Calibration Standard
Standard deviation ≤3 mOsm/kg H
2
O
97-103
94-106
91-109
200 mOsm/kg Calibration Standard
Standard deviation ≤3 mOsm/kg H
2
O
197-203
194-206
191-209
400 mOsm/kg Calibration Standard
Standard deviation ≤3 mOsm/kg H
2
O
397-403
394-406
391-409
500 mOsm/kg Calibration Standard Coefficient of variation ≤0.75% 496-504 492-508 488-512
850 mOsm/kg Calibration Standard Coefficient of variation ≤0.75% 843 -857 836-864 829-871
900 mOsm/kg Calibration Standard Coefficient of variation ≤0.75% 893-907 886-914 879-921
1000 mOsm/kg Calibration Standard Coefficient of variation ≤0.75% 992-1008 984-1016 976-1024
1500 mOsm/kg Calibration Standard
Coefficient of variation ≤0.75%
1488-1512
1476-1524
1464-1536
2000 mOsm/kg Calibration Standard
Coefficient of variation ≤0.75%
1985-2015
1970-2030
1955-2045
Advanced Instruments
Controls
Expected Levels Expected Ranges
Protinol™ Protein-Based
Controls
240 mOsm/kg H2O
280 mOsm/kg H2O
320 mOsm/kg H2O
233-247 mOsm/kg H2O
273-287 mOsm/kg H2O
313-327 mOsm/kg H2O
Renol™ Urine Osmolality Controls 300 mOsm/kg H2O
800 mOsm/kg H2O
290-310 mOsm/kg H2O
790-810 mOsm/kg H2O
Protinol and Renol specifications are presented as a range. This range was established based
of stability data and approximates a three standard deviation range of results.

OsmoPRO® Multi-Sample Micro-Osmometer User’s Guide
10
1. Installation & setup
WARNING: It is important to read and follow the steps in this section. Read Chapter 2
System Overview before attempting to run tests on the instrument.
1.1 Find a location for the instrument
When choosing a location for the Advanced Instruments OsmoPRO Multi-Sample Micro-
Osmometer, be sure to meet the following criteria:
Adequate space: The dimensions of the instrument are 12” Wide x 13” Deep x 17” High (31 cm
x 33 cm x 43 cm). Be sure to keep the workplace free of debris and allow 6 inches (15 cm) of
clear space on both sides and behind the instrument for fan driven air circulation.
Electric outlet availability: The instrument needs to operate within five feet of a properly
grounded, three-prong electrical outlet capable of continuously supplying 2 amperes at
100-240VAC 50/60Hz. If the instrument is not grounded properly, its operation may be
impaired and it may be a safety hazard. Therefore, be sure to test the outlet and record the
results before operating the instrument.
IN THE CASE OF EMERGENCY: Power to the instrument can be removed by pulling the
detachable power cord from the electrical outlet.
1.2 Unpack the instrument
To unpack the instrument, take the following steps:
• Carefully unpack the instrument, accessories and supplies, and inspect them for
shipping damage. Use the enclosed packing list (Table 1.1) to verify all items were
received.
• Save the shipping boxes and packaging material in case future transport is necessary.
• If any item on the packing list appears to be missing from the shipment, search carefully
through and under all packing materials. If the item is not found, notify your receiving
department immediately. Advanced Instruments is only responsible for items reported
missing within 10 days of a shipment’s arrival.
• If any damaged items are received, save the cartons and packing material in which
those items came for inspection by the insurer. The carrier, dealer, and Advanced
Instruments must be notified within 24 hours for the warranty and insurance to apply.
Have the transportation company inspect items, fill out a “Report of Concealed
Damage,” and file a claim. Notify Advanced Instruments immediately for repair or
replacement.
Complete the online warranty card to register your product.

OsmoPRO® Multi-Sample Micro-Osmometer User’s Guide
11
Quantity
Part No.
Description
1 OsmoPRO OsmoPRO
1
112077
Turntable
1
112081
Evaporation cover
1
112169
Barcode ID tag kit
1
240820
20 µL sampler
1
--------
Power cord (as specified)
1
112005UG
User’s guide - USB drive
1
135007PM
Warranty card
Table 1.1: The OsmoPRO Multi-Sample Micro-Osmometer Packing List and Accessories

OsmoPRO® Multi-Sample Micro-Osmometer User’s Guide
12
1.3 Remove the rear panel
WARNING: When removing the rear panel, be sure to follow these instructions and
warnings.
• Disconnect power from the instrument.
• Use a Phillips head screwdriver to remove the rear panel. See Figure 1.1
• Remove rear panel.
• Performing service or maintenance not detailed in the User’s Guide, with or without a
service manual, should only be done by a qualified service technician.
• Use caution and appropriate personal protective equipment (PPE) when working near
the sample probe to prevent skin punctures or other injuries.
Remove screws from rear access panel
Figure1.1: Rear Panel
1.4 Remove the shipping stops
CAUTION:Do not apply electrical power before removing the cooling assembly and
sample probe shipping stops. Damage to the motors can result.
The OsmoPRO is shipped with two shipping stops. One secures the sample cooling assembly,
and the other secures the sample probe. Remove warning labels attached to the shipping stops
before turning on the power to the instrument by using the following procedure:
• Remove the cooling assembly shipping stop by unscrewing the red-capped thumb screw
from the turntable spindle.
• Lift the aluminum shipping stop straight up to avoid damage to the sample cooling
assembly.
• Secure the red-capped thumb screw in the side hole of the shipping stop and save
assembly for future use. (Figure 1.2)

OsmoPRO® Multi-Sample Micro-Osmometer User’s Guide
13
Figure 1.2: Cooling Assembly Shipping Stop
• Locate the white sample probe shipping stop with a red-capped thumb screw.
• Loosen the thumb screw two full turns.
• Lift the top section of the shipping stop upwards approximately ½”, (13 mm) and then
remove from the instrument (Figure 1.3).
• Reinstall the instrument’s rear panel.
Figure 1.3: Sample Probe Shipping Stop
NOTE: Any reshipment of the OsmoPRO requires reinstallation of the cooling assembly
shipping stop, and the sample probe shipping stop.

OsmoPRO® Multi-Sample Micro-Osmometer User’s Guide
14
Printer
Touchscreen Display
Turntable
Proximity Sensor
Barcode Scanner
USB Port
Figure 1.4: OsmoPRO Front View
1.5 Load printer paper
Install as follows:
• Lift open the printer door at top of instrument (Figure 1.5).
• Unroll 4-6” (15-20 cm) of thermal paper from the roll.
• Hold the roll so paper feeds upwards from the bottom of the roll towards the front of the
instrument, and place the roll into the printer.

OsmoPRO® Multi-Sample Micro-Osmometer User’s Guide
15
Feed paper from bottom
Figure 1.5: Printer Paper Roll
• Gently close the printer door until it snaps shut (Figure 1.6). The unrolled portion of
thermal paper should protrude from the printer slot with the door closed.
Advance paper button
Figure 1.6: Close Printer Door
1.6 Install turntable
• If the turntable is not presently installed on the instrument, place it on a flat surface with
the numbered side visible.
• Place a new probe wiper ring over the center knob of the turntable.
• Align the wiper ring so the wiper ring locating tab is in one of the depressions provided at
turntable position 1 and position 11. Verify all the turntable position numbers are visible
within the radial holes of the wiper ring (Figure 1.7).

OsmoPRO® Multi-Sample Micro-Osmometer User’s Guide
16
Wiper Ring Location Tab
Turntable
Probe Wiper Ring
Figure 1.7: Turntable and Wiper Ring
• Place the evaporation cover (logo side facing up) over the center knob of the turntable
with the squared shaped open slot centered at turntable position 1 (Figure 1.8), and
facing the instrument.
• Grasp the turntable by the center knob and place it on the turntable spindle so the flat
side of the evaporation cover fits into the opening in the instrument cover.
Center knob and turntable Locking Screw
Evaporation Cover
Figure 1.8: Evaporation Cover

OsmoPRO® Multi-Sample Micro-Osmometer User’s Guide
17
• Slowly push the turntable forward and twist slightly until it aligns and drops down over
the mating drive spindle (Figure 1.9). Use care not to strike the probe assembly.
Figure 1.9: Turntable Drive Spindle
• While holding the outer edge of the turntable and evaporation cover with one hand, turn
the knurled turntable locking screw (Figure 1.10) fully clockwise to lock the turntable onto
the drive spindle. Make sure it is secure, but do not over-tighten.
Figure 1.10: Turntable Installed
Turntable Drive Spindle
Turntable Locking Screw

OsmoPRO® Multi-Sample Micro-Osmometer User’s Guide
18
Figure 1.11: Back View
1.7 Power-up instrument
• Connect the power cord to the input module on the instrument’s back panel (Figure 1.11)
and to a power outlet.
• Turn on the instrument by pushing the rocker-style power switch on the instrument’s
back panel to the ( I ) position.
The instrument initially displays the OsmoPRO Splash screen (Figure 1.12). The turntable
moves to the home position, and the message “LOADING PROCESSES” appears in the lower-
right corner of the screen.
Figure 1.12: OsmoPRO Splash Screen
Power Switch
Printer
Exhaust Fans
Serial Number
Power Input Module
USB A Ports
Rear Access Panel
USB B Port
Ethernet Port

OsmoPRO® Multi-Sample Micro-Osmometer User’s Guide
19
The program Main screen (Figure 1.13) displays once the software loads completely.
Figure 1.13: OsmoPRO Main Screen
The Main screen is the starting point for all OsmoPRO software functions (e.g., Loading,
Results, Calibration, Diagnostics, and Settings). These functions described in detail in
subsequent sections.
The left side of the Main screen represents the current status of the turntable. Information
regarding the tube position number, Sample ID, date and time, result, and test progress appears
as the turntable is loaded and tests complete.
• The right side of the Main screen displays the test results.
• The top right corner displays instrument status.
• The Main screen also provides access to information using the two symbols in the
lower-left corner of the screen (see Chapter 3).
NOTE: If the instrument does not power on, or if the behavior while powered on does not match
what is listed in Installation & Setup sections, contact Advanced Instruments Hot-Line Technical
Service.

OsmoPRO® Multi-Sample Micro-Osmometer User’s Guide
20
2. System overview
The OsmoPRO is a 20-position, Multi-Sample Micro-Osmometer designed to process batched
samples with unattended operation. The OsmoPRO features a convenient turntable design for
easy sample loading, and uses a relatively small 20 µL sample volume.
The OsmoPRO provides fast, accurate and precise test results using the industry-preferred
freezing point depression method and is ideally suited for mid- to high-volume laboratories
preferring to automate osmolality batch testing while improving laboratory efficiency and
throughput.
2.1 Intended use
Advanced Instruments Osmometers use the technique of freezing point depression to measure
osmolality. Osmolality is the total solute concentration of an aqueous solution. Osmometers
measure the number of solute particles irrespective of molecular weight or ionic charge. This
information is useful to the following disciplines:
• Clinical, emergency and sports medicine
• Medical research
• Biotechnology and pharmaceutical research and manufacturing
• Food and beverage manufacturing
• Environmental research and monitoring
• Academic research
• Industrial applications
For clinical applications, the OsmoPRO provides osmolality measurement of biological fluids,
and is intended for use by trained healthcare professionals to assist in the diagnosis and
treatment of water and electrolyte imbalances in the general patient population. Osmometers
test virtually any biological fluid including, but not limited to, serum, whole blood, plasma, urine,
feces, sweat, and tissue homogenate. Operation of the instrument is deemed moderate
complexity under CLIA and FDA guidelines.
2.2 Principles of freezing point depression
When a solute is dissolved in a pure solvent, the following changes in the solution's properties
occur:
• Freezing point is depressed
• Boiling point is raised
• Osmotic pressure is increased
• Vapor pressure is lowered
These are the so-called "colligative" or concentrative properties of the solution which, within
reasonable limits, change in direct proportion to the solute concentration (the number of
particles in solution).
