Advantech MIC-3393 User manual

User Manual
MIC-3393
6U CompactPCI Intel®Xeon®
Quad/Dual Core Processor Blade

MIC-3393 User Manual ii
Copyright
The documentation and the software included with this product are copyrighted 2009
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. Information provided in this manual is intended to be accurate and reliable. How-
ever, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringe-
ments of the rights of third parties, which may result from its use.
Acknowledgements
All other product names or trademarks are properties of their respective owners.
Product Warranty (2 years)
Advantech warrants to you, the original purchaser, that each of its products will be
free from defects in materials and workmanship for two years from the date of pur-
chase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Advantech, or which have been
subject to misuse, abuse, accident or improper installation. Advantech assumes no
liability under the terms of this warranty as a consequence of such events.
Because of Advantech’s high quality-control standards and rigorous testing, most of
our customers never need to use our repair service. If an Advantech product is defec-
tive, it will be repaired or replaced at no charge during the warranty period. For out-
of-warranty repairs, you will be billed according to the cost of replacement materials,
service time and freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU
speed, Advantech products used, other hardware and software used, etc.) Note
anything abnormal and list any onscreen messages you get when the problem
occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return merchandise
authorization) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a fully-completed Repair and Replacement
Order Card and a photocopy proof of purchase date (such as your sales receipt)
in a shippable container. A product returned without proof of the purchase date
is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid
to your dealer.
Part No. 2002339300 Edition 1
Printed in Taiwan November 2009

iii MIC-3393 User Manual
Declaration of Conformity
CE
This product has passed the CE test for environmental specifications when shielded
cables are used for external wiring. We recommend the use of shielded cables.
FCC Class A
Note: This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Opera-
tion of this equipment in a residential area is likely to cause harmful interference in
which case the user will be required to correct the interference at his own expense.
FM
This equipment has passed the FM certification. According to the National Fire Pro-
tection Association, work sites are classified into different classes, divisions and
groups, based on hazard considerations. This equipment is compliant with the speci-
fications of Class I, Division 2, Groups A, B, C and D indoor hazards.
Technical Support and Assistance
1. Visit the Advantech web site at www.advantech.com/support where you can find
the latest information about the product.
2. Contact your distributor, sales representative, or Advantech's customer service
center for technical support if you need additional assistance. Please have the
following information ready before you call:
–Product name and serial number
–Description of your peripheral attachments
–Description of your software (operating system, version, application software,
etc.)
–A complete description of the problem
–The exact wording of any error messages

MIC-3393 User Manual iv
Warnings, Cautions and Notes
Document Feedback
To assist us in making improvements to this manual, we would welcome comments
and constructive criticism. Please send all such - in writing - to:
[email protected]
Packing List
!MIC-3393 all-in-one single board computer (CPU heatsink and MCH heatsink
included) x1
!Utility and user manual (PDF file) CD-ROM disc x1
!Daughter board for SATA HDD and HDD tray (Assembled) x 1
!Daughter board for CF x1
!Solder-side cover (Assembled) x1
!RJ45 to DB9 cable x1
!Warranty certificate document x1
If any of these items are missing or damaged, contact your distributor or sales repre-
sentative immediately.
Warning! Warnings indicate potentially hazardous conditions, which if not
avoided, could cause personal injury!
Caution! Cautions are included to help you avoid damaging hardware or losing
data. e.g.
There is a danger of a new battery exploding if it is incorrectly installed.
Do not attempt to recharge, force open, or heat the battery. Replace the
battery only with the same or equivalent type recommended by the man-
ufacturer. Discard used batteries according to the manufacturer's
instructions.
Note! Notes provide optional additional information.

v MIC-3393 User Manual
Safety Instructions
1. Read these safety instructions carefully.
2. Keep this User Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a damp
cloth. Do not use liquid or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the equip-
ment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or letting
it fall may cause damage.
7. The openings on the enclosure are for air convection. Protect the equipment
from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting the
equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power source
to avoid damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electrical shock.
13. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
14. If one of the following situations arises, get the equipment checked by service
personnel:
–The power cord or plug is damaged.
–Liquid has penetrated into the equipment.
–The equipment has been exposed to moisture.
–The equipment does not work well, or you cannot get it to work according to
the user's manual.
–The equipment has been dropped and damaged.
–The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE
STORAGE TEMPERATURE MAY GO BELOW -20° C (-4° F) OR ABOVE 60° C
(140° F). THIS COULD DAMAGE THE EQUIPMENT. THE EQUIPMENT
SHOULD BE IN A CONTROLLED ENVIRONMENT.
16. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY
REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE
RECOMMENDED BY THE MANUFACTURER, DISCARD USED BATTERIES
ACCORDING TO THE MANUFACTURER'S INSTRUCTIONS.
The sound pressure level at the operator's position according to IEC 704-1:1982 is
no more than 70 dB (A).
DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech
disclaims all responsibility for the accuracy of any statements contained herein.

MIC-3393 User Manual vi
Safety Precaution - Static Electricity
Follow these simple precautions to protect yourself from harm and the products from
damage.
!To avoid electrical shock, always disconnect the power from your PC chassis
before you work on it. Don't touch any components on the CPU card or other
cards while the PC is on.
!Disconnect power before making any configuration changes. The sudden rush
of power (electrostatic discharge) as you connect a jumper or install a card may
damage sensitive electronic components.
We Appreciate Your Input
Please let us know of any aspect of this product, including the manual, which could
use improvement or correction. We appreciate your valuable input in helping make
our products better.

vii MIC-3393 User Manual
Contents
Chapter 1 Hardware Configuration......................1
1.1 Introduction ............................................................................................... 2
Table 1.1: MIC-3393 Variants...................................................... 2
1.2 Specifications ............................................................................................ 2
1.2.1 CompactPCI Bus Interface ........................................................... 2
1.2.2 CPU .............................................................................................. 3
Table 1.2: Intel processor selection for the MIC-3393................. 3
1.2.3 BIOS ............................................................................................. 3
1.2.4 Chipset.......................................................................................... 3
1.2.5 Memory......................................................................................... 4
Table 1.3: DDR2 200 Pin Registered SO-RDIMM Tested on the
MIC-3393.................................................................... 4
1.2.6 Ethernet ........................................................................................ 4
Figure 1.1 MIC-3393 Ethernet Ports Configuration ..................... 4
1.2.7 Storage Interface .......................................................................... 5
1.2.8 Serial Interface.............................................................................. 5
1.2.9 USB Port ....................................................................................... 5
1.2.10 LEDs ............................................................................................. 5
1.2.11 Watchdog Timer............................................................................ 5
1.2.12 Optional Rear I/O Modules ........................................................... 6
Table 1.4: RIO-3311 Configurations............................................ 6
1.2.13 Optional Extension Modules ......................................................... 6
Table 1.5: MIC-3312 Configurations............................................ 6
1.2.14 Mechanical and Environmental Specifications.............................. 6
1.2.15 Compact Mechanical Design ........................................................ 7
1.2.16 CompactPCI Bridge ...................................................................... 7
1.2.17 I/O Connectivity............................................................................. 8
1.2.18 Hardware Monitor ......................................................................... 8
1.2.19 Super I/O....................................................................................... 8
1.2.20 RTC and Battery ........................................................................... 8
1.2.21 IPMI............................................................................................... 8
1.3 Functional Block Diagram ......................................................................... 9
Figure 1.2 MIC-3393 functional block diagram ............................ 9
1.4 Jumpers and Switches .............................................................................. 9
Table 1.6: MIC-3393 jumper descriptions.................................... 9
Table 1.7: MIC-3393 switch descriptions..................................... 9
Figure 1.3 MIC-3393 jumper and switch locations..................... 10
1.4.1 Clear CMOS (JP7)...................................................................... 10
Table 1.8: JP7 Clear RTC ......................................................... 10
1.4.2 Switch Settings ........................................................................... 11
Table 1.9: SW1 BMC Reset Button & Platform Reset Button ... 11
Table 1.10:SW2-2 & SW4-1 BMC Program or Console ............. 11
Table 1.11:SW3-1 PCI Bridge Master/Drone Mode ................... 11
Table 1.12:SW4 Front COM & RTM COM1/COM2 ports selection
for BMC/SIO UART .................................................. 12
1.4.3 RIO-3311-A1E Switch Setting..................................................... 12
Table 1.13:SW1 External Mini-SAS port/Internal SAS interface 12
1.4.4 MIC-3312-A1E Switch Setting .................................................... 13
Table 1.14:SW1 XMC PCI-Express Selection............................ 13
1.5 Connector Definitions.............................................................................. 13
Table 1.15:MIC-3393 connector descriptions............................. 13
Figure 1.4 MIC-3393 Front Panel Ports, Indicators and Buttons14
Figure 1.5 RIO-3311 Front Panel Ports and Indicators ............. 14
1.5.1 USB Connectors ......................................................................... 14

MIC-3393 User Manual viii
1.5.2 Serial Ports ................................................................................. 14
1.5.3 Ethernet Configuration................................................................ 15
1.5.4 SATA Daughter Board Connector (CNSATA1 and Extension
Module)....................................................................................... 15
1.5.5 System Rest and BMC Reset Button.......................................... 15
1.5.6 VGA Display Connector (Rear I/O)............................................. 15
1.5.7 Mini-SAS Connector (Rear I/O) .................................................. 15
Figure 1.6 SAS Configuration Scenario 1 - Shared Drives........ 15
Figure 1.7 SAS Configuration Scenario 2 - External Drive Array
................................................................................. 16
Figure 1.8 SAS Configuration Scenario 3 - Individual Drives .... 16
1.5.8 XMC / PMC Connectors (Extension Module) ............................. 16
1.6 Safety Precautions.................................................................................. 16
1.7 Installation Steps..................................................................................... 17
1.7.1 CompactFlash Daughter Board Installation Steps...................... 17
Figure 1.9 Complete assembly of MIC-3393A with SATA HDD
daughter board ......................................................... 17
Figure 1.10Loosen screws on the SATA HDD Daughter Board. 18
Figure 1.11Disassemble SATA HDD Daughter Board and Socket
................................................................................. 18
Figure 1.12Assemble CF Daughter Board ................................. 19
1.7.2 MIC-3312 Extension Board Installation Steps ............................ 20
Figure 1.13Complete assembly of MIC-3393C with MIC-3311-A2E
................................................................................. 20
Figure 1.14Assemble MIC-3312-A1E......................................... 21
Figure 1.15Assemble MIC-3312-A2E......................................... 21
1.8 Battery Replacement .............................................................................. 22
1.9 Software Support .................................................................................... 22
Chapter 2 AMI BIOS Setup................................. 23
2.1 Introduction ............................................................................................. 24
Figure 2.1 Setup program initial screen..................................... 24
2.2 Entering Setup ........................................................................................ 25
Figure 2.2 Press <DEL> to run setup........................................ 25
2.3 Main Setup.............................................................................................. 26
Figure 2.3 Main setup screen.................................................... 26
2.3.1 System Time/System Date ......................................................... 26
2.4 Advanced BIOS Features Setup............................................................. 27
Figure 2.4 Advanced BIOS features setup screen .................... 27
2.4.1 CPU Configuration...................................................................... 28
Figure 2.5 CPU configuration .................................................... 28
2.4.2 LAN Configuration ...................................................................... 29
Figure 2.6 LAN configuration..................................................... 29
2.4.3 IDE Configuration ....................................................................... 30
Figure 2.7 IDE configuration...................................................... 30
2.4.4 Super I/O Configuration.............................................................. 31
Figure 2.8 Super I/O configuration ............................................ 31
2.4.5 Hardware Health Configuration .................................................. 32
Figure 2.9 Hardware health configuration ................................. 32
2.4.6 USB Configuration ...................................................................... 33
Figure 2.10USB configuration .................................................... 33
2.4.7 ACPI Configuration ..................................................................... 34
Figure 2.11ACPI setting ............................................................. 34
Figure 2.12Advanced ACPI configuration .................................. 34
2.4.8 AHCI Configuration..................................................................... 35
Figure 2.13AHCI configuration ................................................... 35
2.4.9 Event Log Configuration ............................................................. 36
Figure 2.14 Event log configuration............................................ 36

ix MIC-3393 User Manual
2.4.10 MPS Configuration...................................................................... 37
Figure 2.15 MPS configuration ................................................... 37
2.4.11 Remote Access Configuration .................................................... 38
Figure 2.16Remote access configuration ................................... 38
2.4.12 Trusting Computing..................................................................... 39
Figure 2.17Console re-direction configuration............................ 39
2.5 PCI/PnP Setup ........................................................................................ 40
Figure 2.18PCI/PnP setup.......................................................... 40
2.5.1 Clear NVRAM ............................................................................. 40
2.5.2 Plug and Play O/S....................................................................... 40
2.5.3 PCI Latency Timer ...................................................................... 40
2.6 Boot Setup .............................................................................................. 41
Figure 2.19Boot setup ................................................................ 41
2.6.1 Boot Settings Configuration ........................................................ 42
Figure 2.20Boot settings configuration ....................................... 42
2.7 Security Setup......................................................................................... 43
Figure 2.21Password configuration ............................................ 43
2.8 Advanced Chipset Settings ..................................................................... 44
Figure 2.22Advanced chipset setting.......................................... 44
2.8.1 North Bridge Chipset Configuration ............................................ 45
Figure 2.23North bridge chipset configuration............................ 45
2.8.2 South Bridge Chipset Configuration............................................ 46
Figure 2.24South bridge chipset configuration ........................... 46
2.9 Exit Option............................................................................................... 47
Figure 2.25Exit options ............................................................... 47
2.9.1 Save Changes and Exit .............................................................. 47
2.9.2 Discard Changes and Exit .......................................................... 47
2.9.3 Discard Changes ........................................................................ 47
2.9.4 Load Optimal Defaults ................................................................ 47
2.9.5 Load Failsafe Defaults ................................................................ 48
Chapter 3 IPMI for the MIC-3393 ........................49
3.1 Introduction ............................................................................................. 50
3.2 Definitions ............................................................................................... 50
3.3 IPMI Function List ................................................................................... 50
3.3.1 IPMI Device Global Commands.................................................. 51
Table 3.1: Supported IPMI device global commands ................ 51
3.3.2 BMC Device and Messaging Interfaces...................................... 51
Table 3.2: H8S I2C bus connection to NIC SMBus................... 51
Table 3.3: NIC interrupt ............................................................. 51
Table 3.4: BMC device and messaging commands .................. 51
3.3.3 BMC Watchdog Timer Commands ............................................. 52
Table 3.5: BMC watchdog timer commands.............................. 52
3.3.4 Event Commands ....................................................................... 52
Table 3.6: Event commands...................................................... 52
3.3.5 PEF and Alerting Commands ..................................................... 52
Table 3.7: PEF and alerting commands .................................... 52
3.3.6 SEL Device Commands.............................................................. 53
Table 3.8: SEL device commands............................................. 53
3.3.7 SDR Device Commands ............................................................. 53
Table 3.9: SDR device commands ............................................ 53
3.3.8 FRU Data.................................................................................... 53
Table 3.10:FRU device commands ............................................ 53
3.3.9 Sensor and Threshold Configuration .......................................... 54
Table 3.11:Sensors list ............................................................... 54
Table 3.12:Threshold values of sensors..................................... 55
Table 3.13:Sensor device commands ........................................ 55
3.3.10 Serial Modem Device Commands .............................................. 55

MIC-3393 User Manual x
Table 3.14:Serial modem device commands ............................. 55
Table 3.15: ................................................................................. 55
Table 3.16: ................................................................................. 55
Table 3.17: ................................................................................. 55
3.4 BMC Reset.............................................................................................. 56
Appendix A Pin Assignments............................... 57
A.1 J1 Connector........................................................................................... 58
Table A.1: J1 CompactPCI I/O .................................................. 58
A.2 J2 Connector........................................................................................... 59
Table A.2: J2 CompactPCI I/O .................................................. 59
A.3 J3 Connector........................................................................................... 60
Table A.3: J3 CompactPCI I/O (LAN2/LAN3, 2.16) ................... 60
A.4 J5 Connector........................................................................................... 61
Table A.4: J5 CompactPCI I/O port ........................................... 61
A.5 Other Connectors.................................................................................... 62
Table A.5: CNSATA1 daughter board connector....................... 62
Table A.6: CNSATA1 daughter board connector....................... 62
A.5.1 M/D, PWR, BMC HB, and IDE/Hot-swap LEDs.......................... 62
Appendix B Programming the Watchdog Timer .63
B.1 Watchdog Timer Programming Procedure ............................................. 64
Appendix C FPGA.................................................. 65
C.1 Features.................................................................................................. 66
C.2 FPGA I/O Registers ................................................................................ 66
Table C.1: LPC I/O registers address ........................................ 66
C.2.1 Debug Message.......................................................................... 66
Table C.2: Debug_Code [7:0] (LPC I/O address: 80H).............. 66
C.2.2 General Control and Status Registers........................................ 67
C.2.3 General Purpose Registers ........................................................ 70
C.3 Watchdog Timer...................................................................................... 71
C.3.1 Initial Watchdog .......................................................................... 71
C.3.2 Program Watchdog..................................................................... 72
Appendix D Glossary............................................. 73

Chapter 1
1Hardware
Configuration
This chapter describes how to
configure MIC-3393 hardware.

MIC-3393 User Manual 2
1.1 Introduction
Using Intel 45nm 64-bit Xeon technology with up to four cores at 2.66GHz combined
with the powerful San Clemente chipset, the MIC-3393 blade boosts computing and
I/O performance deploying the latest virtualization, multi-threading and I/OAT accel-
eration techniques. Enhanced Xeon packaging, front side bus parity, onboard, sol-
dered DRAM with ECC support and RASUM features integrated in the 5100MCH
combined with PICMG2.9, IPMI-based management make the MIC-3393 a highly
available and reliable high performance computing engine. The comprehensive I/O
subsystem includes an onboard USB flash disk, a 2.5" SATA HDD or CompactFlash
slot, three advanced Gigabit Ethernet controllers, two UARTs, USB ports and a TPM.
The addition of PCIe links to the RTM further enhances versatility compared to previ-
ous generation blades resulting in best-in-class connectivity.
The RIO-3311 RTM module supports one PS/2 connector with both keyboard and
mouse ports, three USB ports, two RS-232 ports, 2 SATA ports, a PCIe based server
graphics controller with VGA port, a USB port for USB NAND flash module, and alter-
nate cabling for the three Gigabit Ethernet ports of the MIC-3393. In case the SATA
disk drives and SATA RAID support of the ICH9R do not meet performance and reli-
ability requirements, the RIO-3311 SAS version supports a 4-port SAS controller with
RAID and failover support.
The MIC-3393 is outfitted with single slot (4HP) or dual slot (8HP) front panels to
match CPU performance, CPU power dissipation, and system cooling capabilities.
The 8HP version of the blade can be extended with a MIC-3312 mezzanine module
which can carry two XMCs/PMCs or two 2.5" SATA HDDs to support enhanced I/O
modularity and additional mass storage options.
1.2 Specifications
1.2.1 CompactPCI Bus Interface
The MIC-3393 is compliant with PICMG 2.0 Rev. 3.0. It supports a 64-bit / 66 MHz or
33 MHz PCI bus for up to 8 CompactPCI slots at 3.3 V or 5 V VIO. The MIC-3393 is
hot-swap compliant (PICMG 2.1) and conforms to the CompactPCI Packet Switching
Backplane specification (PICMG 2.16) as well as the CompactPCI System Manage-
ment Specification (PICMG 2.9).
The board can be configured as a system master or a drone board. In drone mode it
only draws power from the CompactPCI backplane and is not active on the Compact-
PCI bus. However, PICMG 2.16 is still fully supported in this mode.
Table 1.1: MIC-3393 Variants
Features 'A' model Single Slot
(4HP)
'B' model Dual Slots
(8HP)
'C' model Dual Slots
(8HP)
Slot Width 1 2 2
XMC/PMC knockout - 2 (for MIC-3312-A1E) - (not needed for
MIC-3312-A2E)
CPU Heatsink 8mm Height 25mm Height 25mm Height

3 MIC-3393 User Manual
Chapter 1 Hardware Configuration
1.2.2 CPU
The MIC-3393 supports the 45nm 64-bit technology Intel Xeon Low Voltage (LV) /
Ultra Low Voltage (ULV) processor family with clock frequencies up to 2.66GHz GHz
and a Front-Side Bus (FSB) up to 1333 MHz.
These processors are validated with the Intel 5100 MCH (San Clemente) chipset.
This chipset provides greater flexibility by deploying the latest virtualization, multi-
threading and I/OAT acceleration techniques.
Supported processors are listed in the table below. The forced airflow cooling is
required.
1.2.3 BIOS
Dual 2 MByte SPI flashes contain a board-specific BIOS (from AMI) designed to
meet industrial and embedded system requirements.
1.2.4 Chipset
The Intel 5100 Memory Controller Hub Chipset (Intel 5100 MCH Chipset, formerly
code-named San Clemente) provides excellent flexibility for developers of IT applica-
tions by offering high performance Dual-Independent Bus (DIB) and reduced power
consumption using low-power native DDR2 memory. Features include Intel I/O
Acceleration Technology and Intel Virtualization Technology.
The Intel 5100 MCH Chipset, Intel ICH9R I/O controller, and coupled with the energy-
efficient technology found in Intel's 45nm silicon process enables improved IT appli-
cation performance with excellent power efficiency and value. It delivers outstanding
system performance through high bandwidth interfaces such as PCI Express, Serial
ATA and Hi-Speed USB 2.0.
Table 1.2: Intel processor selection for the MIC-3393
Advantech PN
Intel CPU
Model
Number
CPU
architecture # cores Freq. Cache FSB CPU TDP
Required
airflow for
single-slot
width
Required
airflow for
dual-slot
width
96MPXE-
2.1FA-12M7T
L5408 Harpertown
(45nm)
4 2.13
GHz
12MB 1066 MHz 40W 50CFM 30CFM
96MPXE-
2.66FB-6M7T
L5238 Wolfdale
(45nm)
2 2.66
GHz
6MB 1333 MHz 35W 40CFM 25CFM
96MPXE-
1.86FA-6M7T
L5215 Wolfdale
(45nm)
2 1.86
GHz
6MB 1066 MHz 20W 20CFM 15CFM
96MPXE-
2.4FA-3M7T
L3014 Wolfdale
(45nm)
12.4
GHz
3MB 1066 MHz 30W 50CFM* 30CFM
Note! Strong airflow required for the L3014 CPU is restricted to its thermal
specification (Tc 60°C).
Note! Because power consumption and thermal restrictions vary between dif-
ferent CompactPCI systems, please double check these items before
installing a higher speed CPU not listed in the table above.

MIC-3393 User Manual 4
1.2.5 Memory
The MIC-3393 has 2GB of on-board ECC DDR2 SDRAM. It also has two 200-pin
SO-DIMM sockets that can accommodate an additional 2GB of memory. The follow-
ing table shows a list of SORDIMM modules that have been tested on the MIC-3393.
1.2.6 Ethernet
The MIC-3393 uses two Intel 82574L LAN controllers to provide 10/100/1000 Mbps
Ethernet connectivity (LAN1/ LAN2 or PICMG2.16) and one Intel 82566DM LAN con-
troller which is an external PHY chip built in ICH9R to provide 10/100/1000 Mbps
Ethernet connectivity (LAN3). Optional settings for the source of the Gigabit Ethernet
ports can be selected in the BIOS menu. These are mutually exclusive and can be
set as:
!LAN1/LAN2 of Front I/O (on the MIC-3393)
!LAN1/LAN2/LAN3 of Rear I/O (on the RTM)
!PICMG 2.16
User can access LAN1 via front panel or rear I/O. LAN2 is accessible via front panel,
rear I/O or PICMG 2.16 on backplane. LAN3 can be connected to rear I/O or PICMG
2.16 on backplane. See figure 1.1 for the configuration.
Figure 1.1 MIC-3393 Ethernet Ports Configuration
Table 1.3: DDR2 200 Pin Registered SO-RDIMM Tested on the MIC-3393
Advantech PN Brand Vendor PN Size Speed Depth / Width Memory Chip
96SD2-
1G667ER-VI
Virtium VL493T2863C-E6M 1 GB DDR2 667
(PC2-5300)
128Mb x8 Micron
96SD2-
1G667ER-VI1
Virtium VL493T2863C-E6S 1 GB DDR2 667
(PC2-5300)
128Mb x8 Samsung
Note! Use of single rank, dual die package stack (3.8mm) SORDIMM is
advised.

5 MIC-3393 User Manual
Chapter 1 Hardware Configuration
1.2.7 Storage Interface
The MIC-3393 supports five SATA channels. The SATA1 interface can be routed to
an onboard 2.5" SATA hard disk drive or be transferred to access CompactFlash via
SATA-to-IDE daughter board. On-board HDD occupied same space of CF, so each of
them is optional. The SATA2 and STA3 interfaces are routed to the RTM via the J5
connector. The SATA4 and SATA5 are connected to XTM for extra SATA HDDs
request.
1.2.8 Serial Interface
Two serial ports from SuperIO and one UART from BMC are routed to FPGA to fulfill
several flexible usages. User can access the MIC-3393 or BMC from front or rear
side by setting one DIP switch (SW4). Two serial interfaces are routed to the RTM via
the J3 connector. The other one is designed to serve as a console interface to the
BMC.
1.2.9 USB Port
Seven USB 2.0 compliant ports are provided. Two of them are routed to front panel
connectors; one is routed to an on-board USB flash disk on the MIC-3393. The other
four are routed to the RTM through the J3 connectors, two to the panels of the RTM,
two to the on-board connectors. However, RIO-3311-A1E only supports one on-
board USB port due to space limitation.
1.2.10 LEDs
Four LEDs are provided on the front panel as follows:
!One bi-color LED (blue/yellow) indicates hot swap and HDD activity. The blue
color indicates that the board may be safely removed from the system, and the
yellow color indicates HDD activity.
!One LED provides power status. When the LED is green, it means power is pro-
vided to the board.
!One LED indicates "Master" or "Drone" mode. The green color stands for "Mas-
ter” mode. When the LED is off, the board is in "Drone" mode.
!One LED indicates BMC heart beat. When it flashes (yellow), it means the BMC
is active.
1.2.11 Watchdog Timer
An onboard watchdog timer provides system reset capabilities via software control.
The programmable time interval is from 1 to 255 seconds.

MIC-3393 User Manual 6
1.2.12 Optional Rear I/O Modules
The RIO-3311 is the optional RTM (also known as rear I/O module) for the MIC-3393.
It offers a wide variety of I/O features, such as three RJ45 LAN ports, two COM ports,
one VGA port, two USB2.0 ports, one P/S2 port, and one Mini-SAS port for the RIO-
3311-A1E model. It also comes with on-board features such as USB2.0, SATA, and
SAS interfaces (SATA pin-headers) for the RIO-3311-A1E model. On the other hand,
the RIO-3311-A2E removes SAS interface, but provides an additional USB2.0 con-
nector for the USB flash module. Rear I/O modules are available with two different I/
O options:
1.2.13 Optional Extension Modules
The MIC-3312 is the optional Extension Module (XTM) for the MIC-3393B or the
MIC-3393C, two-slot platform. Extension modules are available with two options:
1.2.14 Mechanical and Environmental Specifications
!Operating temperature: 0 ~ 55°C (-32 ~ 122°F)
!Storage Temperature: -40 ~ 85°„C (-40 ~ 185°„F)
Table 1.4: RIO-3311 Configurations
RTM
Model
Number
Rear Panel On-board Header/Socket/Connector
LAN COM VGA PS/2* USB MiniSAS USB USB
Flash** SATA
SAS
(SATA
interfa
ce)
Slot
Width Conn.
RIO-3311-
A1E 32 11*21 1- 2 4 1 J1,J3, J5
RIO-3311-
A2E 32 11*2- 11 2 - 1 J1,J3, J5
Note! One PS/2 port carries the signals for both K/B and mouse. Y cable is
included.
Note! Use of Advantech EmbCore USB 2.0 Disk Module Type C is recom-
mended.
Table 1.5: MIC-3312 Configurations
XTM Model Number On-board Header/Socket/Connector
XMC/PMC SATA HDD
MIC-3312-A1E 2 -
MIC-3312-A2E - 2
Note! The operating temperature range of the MIC-3393 depends on the
installed processor and the airflow through the chassis.

7 MIC-3393 User Manual
Chapter 1 Hardware Configuration
!Humidity: 95% @ 40°C (non-condensing)
!Humidity (Non-operating): 95% @ 60°C (non-condensing)
!Vibration: 5~500Hz, 2Grms
!Vibration (Non-operating): 5~500Hz, 3.5Grms
!Bump (Non-operating): 15G, 6ms (without on-board 2.5" SATA HDD)
!Altitude: up to 4,000m above sea level
!Board size:
6U/1 slot width (4HP): 233.35 x 160 x 20 mm (9.2" x 6.3" x 0.8")
6U/2 slot width (8HP): 233.35 x 160 x 40 mm (9.2" x 6.3" x 1.6")
!Weight:
6U/1 slot width (4HP): 1.03kg (2.27lb)
6U/2 slot width (8HP): 1.42kg (3.14lb)
1.2.15 Compact Mechanical Design
The MIC-3393 has a specially designed heat sink for the processor to enable fanless
operation. However, forced air cooling in the chassis is still needed for operational
stability and reliability.
1.2.16 CompactPCI Bridge
The MIC-3393 uses a PLX PCI 6540 universal bridge as a gateway to an intelligent
subsystem. When configured as a system controller, the bridge acts as a standard
transparent PCI-X-to-PCI bridge. As a peripheral controller it allows the local
MIC-3393 processor to configure and control the onboard local subsystem indepen-
dently from the CompactPCI bus host processor. The MIC-3393 local PCI subsystem
is presented to the CompactPCI bus host as a single CompactPCI device. When the
MIC-3393 is in drone mode, the PLX PCI 6540 is electrically isolated from the Com-
pactPCI bus. The MIC-3393 receives power from the backplane, supports rear I/O
and supports PICMG 2.16. The PLX PCI 6540 PCI bridge offers following features:
!PCI Interface
–Full compliance with the PCI Local Bus Specification, Revision 2.3
–Supports 3.3V or 5V tolerance I/O
!Transparent and non-transparent bridge function
!64-bit, 33MHz/66MHz asynchronous operation
!Support for 8 Bus Masters
!Usable in CompactPCI system slot or peripheral slot
!10-KB Buffer Architecture for PCI-X-to-PCI-X and PCI-X-to-PCI bridging and
speed conversion
–1-KB downstream Posted Write buffer
–1-KB upstream Poster Writer buffer
–4-KB downstream Read Data buffer
–4-KB upstream Read Data buffer
Please consult the PLX PCI 6540 data book for details.

MIC-3393 User Manual 8
1.2.17 I/O Connectivity
For the MIC-3393, the front panel I/O is provided by two RJ-45 Gigabit Ethernet
ports, one RJ-45 COM port and two USB 2.0 ports. Additionally, two XMC/PMC
knockouts for the MIC-3393B model.
Its on-board I/O consists of one SATA channel which can be connected to either a
daughter board for 2.5" SATA HDD, or a SATA-to-IDE daughter board for Compact-
Flash. Rear I/O connectivity is available via following CompactPCI connectors:
!J3: two Gigabit Ethernet links to the backplane for PICMG 2.16 packet switch,
two COM ports, one PS/2 port (for keyboard/mouse) and six USB ports on the
RTM
!J5: three Gigabit Ethernet LAN ports, one VGA interface, one SAS interface and
two SATA ports on the RTM
1.2.18 Hardware Monitor
One Hardware Monitor (W83627DHG) is available to monitor critical hardware
parameters. It is attached to the BMC to monitor the CPU temperature and core volt-
age information.
1.2.19 Super I/O
The MIC-3393 Super I/O device provides the following legacy PC devices:
!Serial ports COM1 and COM2 are connected to the rear I/O module or front
panel via two multiplexer in the FPGA.
!The PS2 (keyboard/mouse) is routed to the rear I/O module.
1.2.20 RTC and Battery
The RTC module keeps the date and time. On the MIC-3393 model the RTC circuitry
is connected to battery sources (CR2032M1S8-LF, 3V, 210mAH).
1.2.21 IPMI
The MIC-3393 uses the Intelligent Platform Management Interface (IPMI) to monitor
the health of an entire system. A Renesas H8S/2167 microcontroller provides BMC
functionality to interface between system management software and platform hard-
ware. The MIC-3393 implements fully-compliant IPMI 2.0 functionality and conforms
to the PICMG 2.9 R1.0 specification. The IPMI firmware is based on proven technol-
ogy from Avocent. Full IPMI details are covered in Chapter 3.

9 MIC-3393 User Manual
Chapter 1 Hardware Configuration
1.3 Functional Block Diagram
Figure 1.2 MIC-3393 functional block diagram
1.4 Jumpers and Switches
Table 1.6 and table 1.7 list the jumper and switch functions. Figure 1.3 illustrates the
jumper and switch locations. Read this section carefully before changing the jumper
and switch settings on your MIC-3393 board.
Table 1.6: MIC-3393 jumper descriptions
Number Function
JP7 Clear CMOS
Table 1.7: MIC-3393 switch descriptions
Number Function
SW1 BMC Reset/Platform Reset (available on the Front Panel only)
SW2 BMC Firmware Programmable/Console Setting (with SW4
together)
SW3 PCI Bridge Master/Drone Mode
SW4 Front COM & RTM COM1/COM2 ports selection for BMC/SIO
UART, or BMC Firmware Programmable/Console Setting

MIC-3393 User Manual 10
Figure 1.3 MIC-3393 jumper and switch locations
1.4.1 Clear CMOS (JP7)
This jumper is used to erase CMOS data. Follow the procedures below to clear the
CMOS.
1. Turn off the system.
2. Close jumper JP7 (1-2) for about 3 seconds.
3. Set jumper JP7 back to normal.
4. Turn on the system. The BIOS is reset to its default setting.
Table 1.8: JP7 Clear RTC
Closed Clear RTC
Default Open Normal
