Advantech PCIE-1803 User manual

User Manual
PCIE-1803
8-ch, 24-Bit, 128 kS/s Dynamic
Signal Acquisition PCI Express Card

PCIE-1803 User Manual ii
Copyright
The documentation and the software included with this product are copyrighted 2020
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. Information provided in this manual is intended to be accurate and reliable. How-
ever, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringe-
ments of the rights of third parties, which may result from its use.
Acknowledgements
Intel and Pentium are trademarks of Intel Corporation.
Microsoft Windows and MS-DOS are registered trademarks of Microsoft Corp.
All other product names or trademarks are properties of their respective owners.
Product Warranty (2 years)
Advantech warrants to you, the original purchaser, that each of its products will be
free from defects in materials and workmanship for two years from the date of pur-
chase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Advantech, or which have been
subject to misuse, abuse, accident or improper installation. Advantech assumes no
liability under the terms of this warranty as a consequence of such events.
Because of Advantech’s high quality-control standards and rigorous testing, most of
our customers never need to use our repair service. If an Advantech product is defec-
tive, it will be repaired or replaced at no charge during the warranty period. For out-
of-warranty repairs, you will be billed according to the cost of replacement materials,
service time and freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU
speed, Advantech products used, other hardware and software used, etc.) Note
anything abnormal and list any onscreen messages you get when the problem
occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return merchandize
authorization) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a fully-completed Repair and Replacement
Order Card and a photocopy proof of purchase date (such as your sales receipt)
in a shippable container. A product returned without proof of the purchase date
is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid
to your dealer.
Part No. 2001180300 Edition 1
Printed in Taiwan February 2020

iii PCIE-1803 User Manual
Declaration of Conformity
CE
This product has passed the CE test for environmental specifications when shielded
cables are used for external wiring. We recommend the use of shielded cables. This
kind of cable is available from Advantech. Please contact your local supplier for
ordering information.
Technical Support and Assistance
1. Visit the Advantech web site at http://support.advantech.com where you can find
the latest information about the product.
2. Contact your distributor, sales representative, or Advantech's customer service
center for technical support if you need additional assistance. Please have the
following information ready before you call:
–Product name and serial number
–Description of your peripheral attachments
–Description of your software (operating system, version, application software,
etc.)
–A complete description of the problem
–The exact wording of any error messages
Packing List
Before setting up the system, check that the items listed below are included and in
good condition. If any item does not accord with the table, please contact your dealer
immediately.
PCIE-1803 DA&C card
Startup or User Manual
Safety Precaution - Static Electricity
Follow these simple precautions to protect yourself from harm and the products from
damage.
To avoid electrical shock, always disconnect the power from your PC chassis
before you work on it. Don't touch any components on the CPU card or other
cards while the PC is on.
Disconnect power before making any configuration changes. The sudden rush
of power as you connect a jumper or install a card may damage sensitive elec-
tronic components.

PCIE-1803 User Manual iv

v PCIE-1803 User Manual
Contents
Chapter 1 Introduction..........................................1
1.1 Introduction ............................................................................................... 2
1.2 Features .................................................................................................... 2
1.2.1 Auto Calibration ............................................................................ 2
1.2.2 BoardID Switch ............................................................................. 2
1.3 Applications............................................................................................... 2
1.4 Installation Guide ...................................................................................... 3
1.5 Software Overview .................................................................................... 3
1.6 DAQNavi Device Driver Programming Roadmap ..................................... 4
1.6.1 Programming Tools....................................................................... 4
1.6.2 Programming with DAQNavi Device Drivers Function Library...... 5
1.6.3 Troubleshooting Device Driver Errors........................................... 5
1.7 Accessories............................................................................................... 5
1.7.1 Wiring Cables................................................................................ 5
1.7.2 Wiring Boards ............................................................................... 5
Chapter 2 Installation............................................7
2.1 Unpacking ................................................................................................. 8
2.2 Driver Installation ...................................................................................... 8
2.2.1 Device Auto Installation (Recommended)..................................... 8
2.3 Device Setup & Configuration ................................................................... 9
Figure 2.1 The Device Setting of PCIE-1803.............................. 9
Figure 2.2 The Device Setting page .......................................... 10
Figure 2.3 The Device Testing of PCIE-1803 ........................... 11
Chapter 3 Card Settings & Connections...........13
3.1 Overview ................................................................................................. 14
3.2 Switch & Jumper Settings ....................................................................... 14
Table 3.1: Board ID Settings ..................................................... 14
Table 3.2: Keep last status jumper configuration. ..................... 15
3.3 Channel Settings..................................................................................... 15
3.3.1 Analog Input Coupling................................................................. 15
3.3.2 IEPE Excitation ........................................................................... 15
Figure 3.1 Connect an IEPE sensor .......................................... 16
3.4 Signal Connections ................................................................................. 16
Figure 3.2 36-pin I/O Connector Pin Assignments .................... 16
Figure 3.3 19-pin I/O Connector Pin Assignments .................... 17
3.4.1 I/O Connector Signal Description................................................ 17
3.4.2 Analog Input Connections........................................................... 18
Figure 3.4 Connect a floating source......................................... 18
Figure 3.5 Connect a grounded source ..................................... 18
Table 3.3: Recommended analog input channel configuration. 18
3.4.3 Digital Input/Output Connections ................................................ 19
Figure 3.6 Digital Input Channel Connections ........................... 19
Figure 3.7 Digital Output Channel Connections ........................ 19
3.4.4 Trigger......................................................................................... 20
Figure 3.8 Delayed start and stop triggers................................. 20
Figure 3.9 Digital Trigger Signal Connection ............................. 20
Figure 3.10Analog Trigger - Rising Edge ................................... 21
Figure 3.11Analog Trigger - Falling Edge................................... 21
3.4.5 Synchronization for Multiple Cards ............................................. 22

PCIE-1803 User Manual vi
Figure 3.12Synchronization of up to four PCIE-1803 cards by using
specially designed HDMI cable ................................ 22
Figure 3.13Synchronization of more than four PCIE-1803 cards by
using specially designed HDMI cable....................... 22
Table 3.4: Software configuration for synchronization by using
specially designed HDMI cable ................................ 23
Figure 3.14Synchronization of multiple PCIE-1803 cards by using
MDSI cable............................................................... 23
Table 3.5: Software configuration for synchronization by using
MDSI cable............................................................... 23
3.5 Field Wiring Considerations .................................................................... 24
Appendix A Specifications.................................... 25
A.1 Analog Input............................................................................................ 26
A.1.1 Functions .................................................................................... 26
A.1.2 ADC Modulator Oversample Rate .............................................. 26
A.1.3 Maximum Operating Voltage ...................................................... 26
A.1.4 Input Overvoltage Protection ...................................................... 27
A.1.5 AC Coupled Measurement Accuracy.......................................... 27
A.1.6 DC Coupled Measurement Accuracy ......................................... 27
A.1.7 Input Impedance ......................................................................... 27
A.1.8 Common-Mode Rejection Ratio (CMRR) ................................... 28
A.1.9 Frequency Response.................................................................. 28
A.1.10 AC Coupling................................................................................ 28
A.1.11 Idle Channel Noise ..................................................................... 28
A.1.12 Dynamic Range (DR).................................................................. 28
A.1.13 Spurious Free Dynamic Range (SFDR) ..................................... 28
A.1.14 Signal-to-Noise Ratio (SNR)....................................................... 29
A.1.15 Total Harmonic Distortion (THD) ................................................ 29
A.1.16 Total Harmonic Distortion Plus Noise (THD+N) ......................... 29
A.1.17 Crosstalk..................................................................................... 29
A.1.18 Integrated Electronic Piezoelectric Excitation (IEPE) ................. 30
A.1.19 IEPE Fault Detection .................................................................. 30
A.2 Trigger..................................................................................................... 30
A.2.1 Analog Trigger ............................................................................ 30
A.2.2 External Digital Trigger ............................................................... 31
A.2.3 Trigger Output............................................................................. 31
A.3 Timing Signals ........................................................................................ 31
A.3.1 Timing Signal Inputs ................................................................... 31
A.3.2 Timing Signal Outputs ................................................................ 31
A.4 Digital Input/Output ................................................................................. 31
A.4.1 Digital Input................................................................................. 31
A.4.2 Digital Output .............................................................................. 32
A.5 General Specifications ............................................................................ 32
A.5.1 Bus Interface............................................................................... 32
A.5.2 Power Requirements .................................................................. 32
A.5.3 Physical ...................................................................................... 32
A.5.4 Environmental............................................................................. 32
Appendix B Block Diagram................................... 33
B.1 Function Block Diagrams ........................................................................ 34
Figure B.1 Function block diagram - overview........................... 34

Chapter 1
1Introduction
This chapter will provide informa-
tion on the features of the PCIE-
1803 cards, a quick installation
guide, together with some brief
information on software and
accessories.
Sections include:
Features
Applications
Installation Guide
Software Overview
Device Drivers Programming
Roadmap
Accessories

PCIE-1803 User Manual 2
1.1 Introduction
Advantech PCIE-1803 is a high-performance data acquisition module specifically
designed for sound and vibration applications. With eight 24-bit analog inputs per
module and IEPE constant current signal conditioning, Advantech’s PCIE-1803 is
ideal for making precision measurements with microphones, accelerometers, and
other transducers that have very large dynamic ranges. The modules deliver 102 dB
dynamic range and simultaneous sampling on all 8 channels at rates up to 128 kS/s.
1.2 Features
The PCIE-1803 offers the following main features:
8 simultaneous analog input channels
24-bit resolution A/D converter
128 kS/s maximum sampling rate
102 dB dynamic range
IEPE for accelerometers and microphones
Some of the features are described in detail on the following pages.
1.2.1 Auto Calibration
The PCIE-1803 card features software auto calibration. It provides a convenient
method for user calibration processing.
1.2.2 BoardID Switch
The PCIE-1803 has a built-in DIP switch that helps define each card’s ID when multi-
ple PCIE-1803 cards have been installed on the same PC chassis. The BoardID set-
ting function is very useful when building a system with multiple PCIE-1803 cards.
With the correct BoardID settings, you can easily identify and access each card dur-
ing hardware configuration and software programming.
1.3 Applications
The following are some of the possible applications of PCIE-1803 cards:
Noise, vibration, and harshness (NVH) detection
Machine status monitoring
Structure health monitoring
Note! For detailed specifications of the PCIE-1803 card, refer to Appendix A,
Specifications.

3 PCIE-1803 User Manual
Chapter 1 Introduction
1.4 Installation Guide
Before you install your PCIE-1803 card, please make sure you have the following
components:
PCIE-1803 DA&C card
PCIE-1803 Startup Manual
Driver software
Advantech DAQNavi SDK and drivers (Downloaded from Advantech website)
Wiring cables
PCL-108BC-50E (optional)
PCL-10119-1E (optional)
Wiring board
PCLD-8840 (optional)
Personal computer or workstation with a PCI Express interface
Some optional components are also available for enhanced operation: After you get
the necessary components and maybe some of the accessories for enhanced opera-
tion of your multifunction card, you can then begin the installation procedures.
1.5 Software Overview
Advantech offers a rich set of APIs, third-party driver support and application soft-
ware to help fully utilize the functions of your PCIE-1803 cards:
Device Drivers (from Advantech Support Portal)
DAQNavi SDK
Device Drivers
Advantech Device Driver software is included on the companion CD-ROM. It also
comes with all Advantech DA&C cards. Advantech’s device drivers feature a com-
plete I/O function library to help boost your application performance. The Advantech
Device Drivers for Windows 2000, XP, Vista, 7 or Windows 10 work seamlessly with
development tools such as Visual C++, Visual C#, Visual Basic.NET, Borland C++
Builder and Borland Delphi.

PCIE-1803 User Manual 4
1.6 DAQNavi Device Driver Programming Roadmap
This section will provide you with a roadmap to demonstrate how to build an applica-
tion from scratch using Advantech DAQNavi Device Driver with your favorite devel-
opment tools such as Visual Studio.Net, Visual C++, Visual Basic, Delphi and C++
Builder. The step-by-step instructions on how to build your own applications using
each development tool will be given in the Device Drivers Manual. Moreover, a rich
set of example source code is also given for your reference.
1.6.1 Programming Tools
Programmers can develop application programs with their favorite development
tools:
Visual Studio.Net
Visual C++ and Visual Basic
Delphi
C++ Builder
Labview
For instructions on how to begin programming works in each development tool,
Advantech offers a Tutorial Chapter in the DAQNavi SDK Manual for your reference.
Refer to the corresponding sections in this chapter on the DAQNavi SDK Manual to
begin your programming efforts. You can also look at the example source code pro-
vided for each programming tool, since they can get you very well oriented.
The DAQNavi SDK Manual can be found on the companion DVD-ROM. Alternatively,
if you have already installed the Device Drivers on your system, The DAQNavi SDK
Manual can be readily accessed through the Start button:
Start/Programs/Advantech Automation/DAQNavi/DAQNavi Manuals/DAQNavi
SDK Manual
The example source codes can be found under the corresponding installation folder
such as the default installation path:
C:\Advantech\DAQNavi\Examples\
For information about using other function groups or other development tools, please
refer to the Using DAQNavi SDK chapter in the DAQNavi SDK Manual, or the video
tutorials in the Advantech Navigator.

5 PCIE-1803 User Manual
Chapter 1 Introduction
1.6.2 Programming with DAQNavi Device Drivers Function Library
Advantech DAQNavi Device Drivers offer a rich function library that can be utilized in
various application programs. This function library consists of numerous APIs that
support many development tools, such as Visual Studio.Net, Visual C++, Visual
Basic, Delphi and C++ Builder.
According to their specific functions or services, APIs can be categorized into several
function groups:
Analog Input Function Group
Digital Input/Output Function Group
Event Function Group
For the usage and parameters of each function, please refer to the Using DAQNavi
SDK chapter in the DAQNavi SDK Manual.
1.6.3 Troubleshooting Device Driver Errors
Driver functions will return a status code when they are called to perform a certain
task for the application. When a function returns a code that is not zero, it means the
function has failed to perform its designated function. See Device Driver Manual for
detailed information about Error Codes.
1.7 Accessories
Advantech offers a complete set of accessory products to support PCIE-1803 cards.
These accessories include:
1.7.1 Wiring Cables
PCL-108BC-50E
36-pin MINI SCSI to Eight BNC Cable, 50 cm
PCL-10119-1E
HDMI Cable, 1 m
1700030423-01
10 pin Flat Cable, 10cm
PCL-10419-20E
20m, Multi-DAQ sync. HDMI Cable
1.7.2 Wiring Boards
PCLD-8840-AE
20-pin DIN-rail HDMI Cable Wiring Board

PCIE-1803 User Manual 6

Chapter 2
2Installation

PCIE-1803 User Manual 8
2.1 Unpacking
After receiving your PCIE-1803 package, inspect its contents first.
The package should contain the following items:
PCIE-1803 card
Startup Manual
The PCIE-1803 cards harbors certain electronic components vulnerable to electro-
static discharge (ESD). ESD could easily damage the integrated circuits and certain
components if preventive measures are not carefully paid attention to.
Before removing the card from the antistatic plastic bag, you should take following
precautions to prevent ESD damage:
Touch a metal part of your computer chassis with your hand to discharge static
electricity accumulated on your body. Or use a grounding strap.
Touch the anti-static bag to a metal part of your computer chassis before open-
ing the bag.
Hold the card only by the metal bracket when removing it from the bag.
After taking out the card, you should first inspect the card for any possible signs of
external damage (loose or damaged components, etc.). If the card is visibly dam-
aged, please notify our service department or the local sales representative immedi-
ately. Avoid installing a damaged card into your system. Also, pay extra caution to the
following aspects to ensure proper installation:
Avoid physical contact with materials that could hold static electricity such as
plastic, vinyl and Styrofoam.
Whenever you handle the card, grasp it only by its edges. DO NOT TOUCH the
exposed metal pins of the connector or the electronic components.
2.2 Driver Installation
We recommend you install the driver before you install the PCIE-1803 card into your
system, since this will guarantee a smooth installation process.
2.2.1 Device Auto Installation (Recommended)
You can install the PCIE-1803 in any PCI Express slot on your computer. Follow the
steps below to install the module on your system.
1. Turn off your computer and unplug the power cord and cables. TURN OFF your
computer before installing or removing any components on the computer.
2. Remove the cover of the computer.
3. Remove the slot cover on the back panel of your computer.
4. Touch the metal part on the surface of your computer to neutralize the static
electricity that might be on your body.
5. Insert the PCIE-1803 card into a PCI Express slot. Hold the card only by its
edges and carefully align it with the slot. Insert the card firmly into place. Use of
excessive force must be avoided, otherwise the card might be damaged.
Note! Keep the anti-static bag for future use. You may need the original bag to
store the card if you have to remove the card from the PC or transport it
elsewhere.

9 PCIE-1803 User Manual
Chapter 2 Installation
6. Fasten the bracket of the PCI card on the back panel rail of the computer with
screws.
7. Plug in the power cord and turn on the computer.
2.3 Device Setup & Configuration
The Advantech Navigator program is a utility that allows you to set up, configure and
test your device, and later stores your settings on the system registry. These settings
will be used when you call the APIs of Advantech Device Drivers.
Setting Up the Device
1. To set up the I/O device for your card, you must first run the Advantech Naviga-
tor program (by accessing Start/Programs/Advantech Automation/DAQNavi/
Advantech Navigator).
2. You can then view the device(s) already installed on your system (if any) on the
Installed Devices list box. If the software and hardware installation are com-
pleted, you will see PCIE-1803 card in the Installed Devices list.
Figure 2.1 The Device Setting of PCIE-1803

PCIE-1803 User Manual 10
Configuring the Device
Go to the Device Setting to configure your device. Here you can configure not only
the Analog Input of PCIE-1803 but also Digital Input/Output.
Figure 2.2 The Device Setting page

11 PCIE-1803 User Manual
Chapter 2 Installation
After your card is properly installed and configured, you can go to the Device Test
page to test your hardware by using the testing utility supplied.
Figure 2.3 The Device Testing of PCIE-1803
For more detailed information, refer to the DAQNavi SDK Manual or the User Inter-
face Manual in the Advantech Navigator.

PCIE-1803 User Manual 12

Chapter 3
3Card Settings &
Connections
This chapter provides useful
information about how to connect
input and output signals to the
PCIE-1803 cards via the I/O con-
nectors and configure appropriate
settings according the require-
ments.
Sections include:
Overview
Switch & Jumper Settings
Signal Connections
Field Wiring Considerations
Channel Settings

PCIE-1803 User Manual 14
3.1 Overview
Maintaining signal connections is one of the most important factors in ensuring that
your application system is sending and receiving data correctly. A good signal con-
nection can avoid unnecessary and costly damage to your PC and other hardware
devices. This chapter provides useful information about how to connect input and
output signals to the PCIE-1803 cards via the I/O connector.
3.2 Switch & Jumper Settings
Setting the BoardID Switch (SW1)
The PCIE-1803 has a built-in DIP switch (SW1), which is used to define each card's
board ID. You can determine the board ID as shown in Table 3.1. When there are
multiple cards in the same system, this board ID setting function is useful for identify-
ing each card. We set the PCIE-1803 board ID as 0 by default.
* Default Setting
Keep Last Status (CN1)
An on-board jumper is used to configure the status of all output signals after system
hot-reset. User can choose to reset all output signals to the default values after sys-
tem hot-reset, or keep them as the status before hot-reset.
Table 3.1: Board ID Settings
SW11234
BoardID ID3 ID2 ID1 ID0
0* ON ON ON ON
1ONONONOFF
2ONONOFFON
3ONONOFFOFF
4 ON OFF ON ON
5 ON OFF ON OFF
6ONOFFOFFON
7ONOFFOFFOFF
8 OFF ON ON ON
9 OFF ON ON OFF
10 OFF ON OFF ON
11 OFF ON OFF OFF
12 OFF OFF ON ON
13 OFF OFF ON OFF
14 OFF OFF OFF ON
15 OFF OFF OFF OFF
