Advantech MIO-5377 User manual

User Manual
MIO-5377
12th Gen Intel® Core™ i7/i5/i3/
Celeron® Series 3.5" SBC

MIO-5377 User Manual ii
Copyright
The documentation and the software included with this product are copyrighted 2022
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. Information provided in this manual is intended to be accurate and reliable. How-
ever, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringe-
ments of the rights of third parties that may result from its use.
Acknowledgments
Intel® is a trademark of Intel® Corporation.
AMI is a trademark of American Megatrends, Inc.
IBM, PC, PS/2, and VGA are trademarks of International Business Machines Corpo-
ration.
Microsoft Windows®, DirectX® is a registered trademark of Microsoft Corp.
All other product names or trademarks are properties of their respective owners.
For more information on this and other Advantech products, please visit our websites
at: http://www.advantech.com http://www.advantech.com/eplatform
For technical support and service, please visit our support website at: http://sup-
port.advantech.com/
This manual is for the MIO-5377.
Part No. 2006537700 Edition 1
January 2023

iii MIO-5377 User Manual
Product Warranty (2 Years)
Advantech warrants to you, the original purchaser, that each of its products will be
free from defects in materials and workmanship for two years from the date of pur-
chase. This warranty does not apply to any products which have been repaired or
altered by persons other than repair personnel authorized by Advantech, or which
have been subject to misuse, abuse, accident or improper installation. Advantech
assumes no liability under the terms of this warranty as a consequence of such
events.
Because of Advantech’s high quality-control standards and rigorous testing, most of
our customers never need to use our repair service. If an Advantech product is defec-
tive, it will be repaired or replaced at no charge during the warranty period. For out-
of-warranty repairs, you will be billed according to the cost of replacement materials,
service time and freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU
speed, Advantech products used, other hardware and software used, etc.) Note
anything abnormal and list any on-screen messages you get when the problem
occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an return merchandise authori-
zation (RMA) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a fully-completed Repair and Replacement
Order Card and a photocopy proof of purchase date (such as your sales receipt)
in a shippable container. A product returned without proof of the purchase date
is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid
to your dealer.

MIO-5377 User Manual iv
Declaration of Conformity
CE
This product has passed the CE test for environmental specifications. Test conditions
for passing included the equipment being operated within an industrial enclosure. In
order to protect the product from being damaged by electrostatic discharge (ESD)
and EMI leakage, we strongly recommend the use of CE-compliant industrial enclo-
sure products.
FCC Class B
This equipment has been tested and found to comply with the limits for a Class B dig-
ital device, pursuant to part 15 of the FCC Rules. These limits are designed to pro-
vide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interfer-
ence to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful interfer-
ence to radio or television reception, which can be determined by turning the equip-
ment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FM
This equipment has passed the FM certification. According to the National Fire Pro-
tection Association, work sites are classified into different classes, divisions and
groups, based on hazard considerations. This equipment is compliant with the speci-
fications of Class I, Division 2, Groups A, B, C and D indoor hazards.
Technical Support and Assistance
1. Visit the Advantech website at http://support.advantech.com where you can find
the latest information about the product.
2. Contact your distributor, sales representative, or Advantech's customer service
center for technical support if you need additional assistance. Please have the
following information ready before you call:
–Product name and serial number
–Description of your peripheral attachments
–Description of your software (operating system, version, application software,
etc.)
–A complete description of the problem
–The exact wording of any error messages

v MIO-5377 User Manual
Packing List
Before setting up the system, check that the items listed below are included and in
good condition. If any item does not accord with the table, please contact your dealer
immediately.
1 x MIO-5377 SBC
1 x SATA Cable 30 cm (p/n: 1700006291)
1 x SATA Power Cable 35 cm (p/n: 1700031583-01)
1 x USB 2.0 Cable 20 cm (p/n: 1700030406-01)
1 x Audio Cable 20 cm (p/n: 1700019584-01)
2 x COM RS-232/422/485 Cable 20 cm (p/n: 1700030404-01)
2 x COM RS-232 Cable 20 cm (p/n: 1700031582-01)
1 x Cooler (Heatsink) (p/n: 1970005512T001 (1970005548T001))
1 x Startup manual (p/n: 2046537700)
1 x Screw kit (3 x screws for M.2 device & 4 x screws and stand-off for Heatsink/
Cooler)
1 x DeviceOn Package
Optional Accessories
1 x MIO-5377 Heat spreader (p/n: 1970005615T001)

MIO-5377 User Manual vi

vii MIO-5377 User Manual
Contents
Chapter 1 General Information ............................1
1.1 Introduction ............................................................................................... 2
1.2 Specifications............................................................................................ 2
1.3 Block Diagram........................................................................................... 4
Chapter 2 Mechanical Specifications..................5
2.1 Introduction ............................................................................................... 6
2.2 Board Layout: Dimensions ........................................................................ 6
Figure 2.1 MIO-5377 Mechanical Diagram (Top Side) ................ 6
Figure 2.2 MIO-5377 Mechanical Diagram (Bottom Side)........... 6
Figure 2.3 MIO-5377 Mechanical Diagram (Coastline) ............... 7
Figure 2.4 MIO-5377 Mechanical Diagram (with Heatsink) ......... 7
Figure 2.5 MIO-5377 Mechanical Diagram (with Cooler) ............ 7
Figure 2.6 MIO-5377 Mechanical Diagram (with Heatspreader) . 7
2.3 Quick Installation Guide ............................................................................ 8
Figure 2.7 MIO-5377 Cooler Installation...................................... 8
Figure 2.8 MIO-5377 Heatsink Installation .................................. 8
Figure 2.9 MIO-5377 Heatspreader Installation........................... 8
Chapter 3 Jumpers and Connectors ...................9
3.1 Jumpers .................................................................................................. 10
Table 3.1: Panel Voltage Selection Jumper: VDD1................... 10
Table 3.2: AT mode /Load BIOS default: J1.............................. 10
3.2 Connectors.............................................................................................. 11
3.3 Locating Connectors ............................................................................... 12
3.4 Setting Jumpers ...................................................................................... 13
Table 3.3: CANBus Internal Connector: CN3 ............................ 13
Table 3.4: CANBus Internal Connector: CN2 ............................ 13
Table 3.5: I2C Internal Connector: CN8 .................................... 14
Table 3.6: I2C Internal Connector: CN7 .................................... 14
Table 3.7: I2C Internal Connector: CN6 .................................... 14
Table 3.8: Panel Inverter Connector: BL1 ................................. 15
Table 3.9: Smart FAN Internal Connector: FAN ........................ 15
Table 3.10:LVDS Connector: LVDS1 ......................................... 16
Table 3.11:USB 2.0 Dual-Ports Internal Connector: USB 3 ....... 17
Table 3.12:Audio Internal Connector: AUDIO1 .......................... 17
Table 3.13:SATA Power Connector: SATA_P1.......................... 18
Table 3.14:COM-Port Internal Connector 1: COM1 ................... 18
Table 3.15:COM-Port Internal Connector 2: COM2 ................... 19
Table 3.16:COM-Port Internal Connector 3: COM3 ................... 19
Table 3.17:COM-Port Internal Connector 4: COM4 ................... 20
Table 3.18:Front Panel Internal Connector: CN4 ....................... 20
Table 3.19:GPIO Internal Connector: CN5................................. 21
Table 3.20:RTC battery Connector: BAT1.................................. 21
Table 3.21:M.2 Key-E Connector: M2_1 .................................... 22
Table 3.22:M.2 Key-M Connector: M2_2.................................... 24
Table 3.23:M.2 Key-B Connector: M2_B1.................................. 26
Chapter 4 AMI BIOS Setup .................................29

MIO-5377 User Manual viii
4.1 Entering Setup ........................................................................................ 30
4.1.1 Main Setup.................................................................................. 30
4.1.2 Advanced BIOS Features Setup................................................. 31
4.1.3 Chipset Configuration ................................................................. 52
4.1.4 Security....................................................................................... 62
4.1.5 Boot ............................................................................................ 63
4.1.6 Save & Exit ................................................................................. 64
Appendix A ............................................................ 65
A.1 System I/O Ports..................................................................................... 66
A.2 DMA Channel Assignments .................................................................... 67
A.3 1st MB Memory Map............................................................................... 67
A.4 Interrupt Assignments ............................................................................. 67

Chapter 1
1General Information

MIO-5377 User Manual 2
1.1 Introduction
MIO-5377 is powered by 12th Gen Intel® Core™ P/U series processors and offers
Advantech embedded iManager 3.0, SUSI 4.0 and WISE-PaaS/DeviceOn. These
SW solutions help monitor and control system operation effectively and remotely.
MIO-5377 adopts the latest hybrid core design processor to engender improvements
in CPU processing, graphics, security and I/O flexibility.
1.2 Specifications
Platform
Processor i7-1270PE i7-1265UE i5-1245UE i3-1215UE 7305E
Max. Frequency 4.5GHz 4.7GHz 4.4GHz 4.4GHz N/A
Base Frequency 1.8GHz 1.7GHz 1.5GHz 1.2GHz 1.0GHz
Core/Thread 4P+8E/16T 2P+8E/12T 2P+8E/12T 2P+4E/8T 1P+4E/
6T
LLC 18MB 12MB 12MB 10MB 8MB
CPU TDP 28W 15W 15W 15W 15W
Chipset On-package Intel 600 Series Chipset
BIOS AMI EFI 256Mbit
Memory
Technology DDR5-4800
Max. Capacity Up to 64GB
Channel/Socket Dual Channels / 2 Sockets
Graphics
Controller Intel® Iris® Xe Graphics
Max. Frequency 1.35GHz 1.25GHz 1.2GHz 1.1GHz 1.1GHz
Execution Unit 96 96 80 64 48
3D/HW
Acceleration
DX12, OGL4.0, OCL1.2, HW Encode: H.265/HEVC, H.264,
MPEG2, HW Decode: H.265
Display I/F
LCD 1 x LVDS: Dual Channel 18/24-bit, up to 1920 x 1200
HDMI/DP 1 x HDMI 2.0b, up to 4096 x 2160 x 24bpp@60Hz
1 x DP1.4a, up to 4096 x 2304 x 36bpp@60Hz
Multiple Display 4 simultaneous displays via LVDS + HDMI + DP + USB Type-C
Alt. Mode
Ethernet Controller LAN1: Intel i219LM, LAN2: Intel i226
Speed LAN1: GbE; LAN2: 2.5GbE
External I/O
Ethernet 2 x RJ-45
HDMI/DP 1/1
USB Type-C 1 x USB 3.2 Gen2, support DisplayPort1.4a Alt. Mode
USB 3.2 4 x USB 3.2 Gen2 x1 10Gbps
LED Power status, SATA R/W
Power DC-Jack Optional

3 MIO-5377 User Manual
Chapter 1 General Information
* Support by request
** 5G module test with Fibocom FM350 (MediaTek)
Internal I/O
SATA 1 x SATA Gen3 6.0Gbps
USB4 (TBT4) 1 x (Type-C)
USB 2.0 2 x
COM Port 2 x RS-232/422/485, 2 x RS-232 (4-wire), max. 1Mbps
CANBus 2 x CAN2.0
Serial Bus 3 x I2C 1Mbps (default), 1 x SMBus* (optional to I2C1)
Audio Realtek ALC888s, Line-in/Line-out/MIC
GPIO 8-bit general purpose input output I/O
Invertor 12V/5V/3.3V selectable
Fan 12V, 1A (4-wire)
Front Panel Control Power-on, Reset, Buzzer, SATA LED, CaseOpen
Board Feature
Watchdog Timer 65536 level, 0~65535 sec
TPM TPM2.0
iManager 3.0 SW API for Hardware Monitor, Smart Fan Control, Brightness
Control, I2C, GPIO, WDT
Expansion
M.2 E-Key 1 x E-Key 2230 (PCIex1, USB2.0)
M.2 B-Key 1 x B-Key 3042 LTE/3052 5G** w/ Nano SIM, B-Key default 3042
length
M.2 M-Key 1 x M-Key 2280 (PCIex4 Gen.4 NVMe)
Power
Supply Voltage Vin: DC 12V~24V +/- 10%; RTC Battery: Lithium 3V/210mAH
Connector ATX 2x2 pin 90D, optional DC-Jack or ATX 2x2 pin 180D
Power
Management AT, ATX
Environment
Temperature Operating: Standard: 0 ~ 60 °C (32 ~ 140 °F)
Storage: -40 ~ 85 °C (-40 ~ 185 °F)
Humidity Operating: 40 °C @ 95% relative humidity, non-condensing
Storage: 60 °C @ 95%relative humidity, non-condensing
Vibration
Resistance 3.5 Grms
Certification EMC CE, FCC Class B
Mechanical Dimensions 146 x 102 mm (5.7 x 4 in)

MIO-5377 User Manual 4
1.3 Block Diagram
I2C_3
LVDS PTN3460 DDI_A
LAN1 (GbE)
i219LM
M.2 E-Key 2230
PCIex1, USB2.0, I2C
SATA
I2C_3
M.2 M-Key 2280
PCIex4 Gen4 (NVMe)
NanoSIMM.2 B-Key 3042/3052
PCIex1, SATA, USB2.0
PCIex1
LAN2 (2.5G)
i226
PCIex1
SATA Gen 3
I2C
CH-0 CH-1
eSPI
HDMI2.0b
USB4/TBT4
USB Type-C
(USB3.2+DP)
TCP_2
DP1.4 DDI_B
TCP_3
USB3.2 P2 - P3 USB3.2 + USB2.0
TCP_1
USB2.0 P0 - P1 USB2.0
TPM 2.0 SPI
EIO-201
Intel Alder Lake-P
i7/ i5/ i3/ Celeron
15/28W
DDR5-4800
Up to 32GB
DDR5-4800
Up to 32GB Internal I/O
External I/O
PI3HDX1204B1ZHIEX
Retimer
SPI
256M BIOS
COM1 RS-232/422/485
COM2 RS-232/422/485
COM3 RS-232
COM4 RS-232
CAN1
CAN2
I2C_1/SMBus
GPIO 8-bit

Chapter 2
2Mechanical
Specifications

MIO-5377 User Manual 6
2.1 Introduction
MI/O is a compact form factor, new-generation SBC designed with a variety of
mechanical improvements. This chapter includes board dimension and assembly
instructions for standard thermal solutions.
2.2 Board Layout: Dimensions
Figure 2.1 MIO-5377 Mechanical Diagram (Top Side)
Figure 2.2 MIO-5377 Mechanical Diagram (Bottom Side)
0
3.30
58.28
72.28
86.28
142.70 146
0
20.50
23.09
27.20
55.65
88.20
92.70
98.70
102
0
3.30
142.70 146
0
20.50
27.20
92.70
98.70
102

7 MIO-5377 User Manual
Chapter 2 Mechanical Specifications
Figure 2.3 MIO-5377 Mechanical Diagram (Coastline)
Figure 2.4 MIO-5377 Mechanical Diagram (with Heatsink)
Figure 2.5 MIO-5377 Mechanical Diagram (with Cooler)
Figure 2.6 MIO-5377 Mechanical Diagram (with Heatspreader)
0
2
11.20
16.34
0
8.30
26.30
45.58
67.65
85.50
100.60 119.39 130.81 139.50 146 155.88
0
2
11.20
16.34
33.7
0
8.30
26.30
45.58
67.65
85.50
100.60
119.39
130.81
139.50
146
155.88
0
2
11.20
16.34
26
0
8.30
26.30
45.58
67.65
85.50
100.60 119.39 130.81 139.50
146
155.88
0
8.30
26.30
45.58
67.65
85.50
100.60 119.39 130.81 139.50 146 155.88
0
2.25
10.75
16.19

MIO-5377 User Manual 8
2.3 Quick Installation Guide
This section introduces the installation of the heatsink found inside a white box inside
the package. Please assemble it by following the diagram below. Remember to
remove the plastic from thermal pad before assembly.
Figure 2.7 MIO-5377 Cooler Installation
Figure 2.8 MIO-5377 Heatsink Installation
Figure 2.9 MIO-5377 Heatspreader Installation
Remove release paper
Remove release paper
Remove release paper

Chapter 3
3Jumpers and
Connectors

MIO-5377 User Manual 10
3.1 Jumpers
Table 3.1: Panel Voltage Selection Jumper: VDD1
Jumper Short Panel Voltage
1-3 +3.3V (Default)
3-5 +5V
3-4 +12V
Table 3.2: AT mode /Load BIOS default: J1
Jumper Short Panel Functional
1-2
AT/ ATX MODE Selection
1-2 open: ATX mode
1-2 short: AT mode*
3-4
NORMAL_BIOS (Default)
3-4 open: Reserve
3-4 short: Reserve*
5-6
LOAD_BIOS_Default:
5-6 open: Noraml*
5-6 short: Load BIOS Default

11 MIO-5377 User Manual
Chapter 3 Jumpers and Connectors
3.2 Connectors
1 CN10 DC Power Input Connector(90D)
2 CN10_1 DC Power Input Connector(180D)
3 CN11 DC Jack
4 D33 Power & SATA LED
5 LAN1 I219 RJ45 LAN Ports
6 LAN2 I226 RJ45 LAN Ports
7 TYPEC1 TypeC Port (USB3.2/DP)
8 DP1 Display Port Connector
9 HDMI1 HDMI Connector
10 USB1 USB3.2 Connector
11 USB2 USB3.2 Connector
12 CN3 CAN Bus Port 1
13 CN2 CAN Bus Port 0
14 CN8 SOC_I2C Port1
15 CN7 SOC_I2C Port0
16 CN6 EC_I2C Port
17 BL1 Panel Inverter Connector
18 FAN Smart FAN
19 J1 AT mode /Load BIOS default
20 VDD1 Panel Voltage Selection Jumper
21 LVDS1 LVDS Connector
22 USB3 USB2.0 Internal Connector
23 AUDIO1 Audio Internal Connector
24 SATA1 SATA Connector
25 SATAP1 SATA Power Connector
26 TYPEC2 TypeC Port (TBT4)
27 COM1 COM Port Internal Connector 1
28 CN4 Front Panel Internal Connector
29 COM2 COM Port Internal Connector 2
30 CN5 GPIO Internal Connector
31 U14 DDR5 SO-DIMM 5.2mm
32 U15 DDR5 SO-DIMM 9.2mm
33 M2_1 M.2 Key-E Connector
34 COM4 COM Port Internal Connector 4
35 COM3 COM Port Internal Connector 3
36 BAT1 RTC battery Connector
37 M2_2 M.2 Key-M Connector
38 M2_B1 M.2 Key-B Connector
39 SIM1 NANO SIM SLOT

MIO-5377 User Manual 12
3.3 Locating Connectors
