FWA-6510 Startup Manual 1
Before you begin installing your card, please make sure that
the following items have been shipped:
• One FWA-6510 Internet Security Platform
• One box of accessories
• One warranty certificate
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note 1: Acrobat Reader is required to view any PDF
file.Acrobat Reader can be downloaded at:
www.adobe.com/Products/acrobat/readstep2.
html (Acrobat is a trademark of Adobe)
FWA-6510 Intel® Xeon® E5-2600 Series Processor
based 2U Network Application Platform
Startup Manual
Main Board Functions
• CPU: 2 x Intel® Xeon® E5-2600 processors
• PCH: Intel C600 series chipset
• BIOS: AMI 8Mbit SPI Flash
• QPI: up to 8 GT/s
• Memory: System memory: Support for DDR3
800/1066/1333/1600 memory ECC RDIMM
Primary CPU support 2 DIMMs/channel, up to 8 DIMMs
Secondary CPU support 1 DIMM/channel, up to 4 DIMMs,
Capacity up to 384 GB with 12 slots.
• PCIe Bus:
- PCH: Intel C600 series chipset
- Expansion:
4 x PCIe Gen3 x8 slots connect to NMC modules (2 per
CPU socket)
1 x PCIe Gen3 x8 slot for riser card (primary CPU)
2 x PCIe Gen1 for management boards (PCH)
- Riser card: 1 x PCIe x8 riser card, Supports
• NMC modules: 4 x NMC modules with PCIex8 gen.3
InterfacesMaximum 32 GbE ports or 8 x 10GE ports
• Storage:
- SAS/SATA: 4 x 2.5” hot-swappable SAS/SATA
- Compact Flash: 1 x CFast socket
- USB Flash Disk: 4 x USB 2.0 on-board pinheader for
USB flash disk (DOM)
• System Management: IPMI, Aspeed AST2300 iBMC +
AMI MegaRAC firmware, Supports IPMI 2.0
Supports iKVM
• Dimensions/ Weight: 430 x 558 x 88 mm/ 18Kg
• Power Supply: 720 W 2U (1+1 redundant, 720 W
each),AC 100 ~ 240 V @ 50 ~ 60 Hz, full range, With
PMBus support
• Environment: Operating Non-Operating
• Temperature: 0 ~ 40° C -20° ~ 75° C
(32 ~ 104° F) (-4 ~ 167° F)
• Humidity: 5~85%@40°C 5~95%
(104° F)
Management Ports
• LAN: 2 x Intel 82574L 10/100/1000 Base-T Ethernet
• USB: 2 x USB 2.0 ports on the front
• Serial:1 x RS232 console port by RJ-45 connector on
the front.
• LCD: 16 x 2 character display, 5 buttons
• VGA: Pin header (for debug only)
• TPM: TPM1.2 compliant (Infineon SLB9635TT1.2)
Specications
Packing List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com.tw/support
http://www.advantech.com
For technical support and service, please visit our
support website at:
http://www.advantech.com/support
This manual is for the FWA-6510 series Rev. A
Part No. 2002651000
Print in China
1st Edition,
March 2012

2 FWA-6510 Startup Manual
NMC Modules
• Interface:
- GE Express Module:
Support 4 x 10/100/1000 Base-T ports by RJ45 or SFP
interface
Support 8 x 10/100/1000 Base-T ports by RJ45 interface
- 10GE Express Module:
Support 2 x 10GE ports by SFP+ interface
• Controller:
- GE Express Module:
1,2 x Intel i350-AM4 Quad Ports GE Controllers
- 10GE Express Module:
1 x Intel 82599ES Dual Ports 10GE Controller
• LAN Bypass:
- GE Express Module:
Support 2,4 segment LAN bypass by RJ45 interface
version only
Figure 1A: NMC-0107 4 ports Copper Module
Figure 2A: NMC-0108 4 ports SFP Module
Figure 3A: NMC-0803 8 ports Copper Module
Figure 4A: NMC-1004 2 ports 10G SFP+ Module
Installing the CPUs
1. Locate the CPU sockets on the board.
2. Taking one CPU at a time, remove the protective shield, if
present, and press the load lever and move it until it is clear
of the retention tab, and raise it.
3. Make sure that the alignment triangle on the CPU lines
up with correct corner on the socket, and ease the CPU
into place.
4. Close the load plate and push the load lever back down
until it engages the retention tab.
Specications Installation

FWA-6510 Startup Manual 3
Installing the Memory
The FWA-6510 system provides 12 x DDR3 DIMMs which
can support up to DDR3 800/1066/1333/1600 MHz 384GB.
1. To install the memory, please start to install the memory
from CPU0 with DIMMA1.
Installing the CFast and USB-DOM
1. Position a Cfast Flash disk accordingly in the Compact-
Flash disk socket and push it inward.
2. Remove the screw for the USB-DOM, and put stand-off
and fastened on the same location of screw hole, and then
install the USB-DOM on the pin header of USB, and screw
it again.
Installing the 2.5”SAS/SATA HDD
1. Remove the HDD tray from the front panel of System.
2.Put the 2.5” SAS/SATA HDD above the HDD tray and
position the screws accordingly.
3.Put the whole HDD tray with HDD back to front panel
4.Push the latch switch from left to right side for lock the
HDD tray for fastened.
Installing the Heat sinks
1. Taking one heat sink at one time, apply a small dab of
heat transfer compound to the top of the installed CPU,
and then align it and carefully lower the heat sink into place.
2. Insert and loosely engage each heat sink screw. Then
screw them in carefully to secure the heat sink.
Installing the Riser Cards
1. There is one screw on the base of the chassis.
2. Release the screw and remove the bracket.
3. Take it out.
4. Remove the dummy IO bracket and install the add-on
card.
5. Put the bracket back and screw it back in.
Installation Installation

4 FWA-6510 Startup Manual
Jumpers and Connectors
The board has a number of jumpers that allow you to con-
figure your system to suit your application. The table below
lists the function of each of the jumpers and connectors.
Connector / Jumper List (MB)
CN1 Front Panel Connector
CN2 B/B Conn. 40x2P (Connect to NAMB-
6510MGT)
CN3 WAFER BOX 2x5P for USB CONN
CN4 WAFER BOX 3P for TPM (Physical
Presence)
CN5/6/7/8 PCI-E x8 SMD Slot for PCIe Slot
#6/8/5/7
CN9 WAFER BOX 2x5P for LPC CONN
CN10 PIN HEADER 6x2P for GPIO CONN
CN11 WAFER BOX 2P for HDD Act
CN12 Mini SAS Connector
CN13 IPMB Connector for Power supply
CN14 SSI 24Pin Power Connector
CN15 WAFER BOX 2x7P for VGA CONN
CN16 BOX HEADER 5x2P for BSCAN
(chain1)
CN17 SPI Socket for BIOS(Secondary)
CN18 SPI Socket for BIOS(Primary)
CN19 IPMB Connector
CN20 WAFER BOX 2P for Chassis Intrusion
CN21 BOX HEADER 5x2P for BSCAN
(chain2)
CN22 PIN HEADER 4x1P for Volterra
CN23/CN24 SSI 8 Pin Power Connector
CN25/26/27 PCI-E x1 Straddle Slot for FAN Module
#1/2/3
CN28/29/
30/31
PCI-E x8 Straddle Slot for PCIe Slot
#4/3/2/1
JP1 PIN HEADER 3x1P for CLR RTC
Connector / Jumper List
JP2 PIN HEADER 3x1P for CLR CMOS
JP3 PIN HEADER 3x1P for BIOS Recovery
Mode Jumper
JP4 PIN HEADER 3x1P for BMC UART
Debug
Jumpers and Connectors
Connector / Jumper List (Mgmt)
CN1 RJ45-10/100/1000 Base-T Connector
for HA
CN2 RJ45-10/100/1000 Base-T Connector
for Management Port
CN3 B/B Conn. 40x2P (Connect to NAMB-
6510MB)
CN4 Dual USB Connector
CN5 USB DOM Connector
CN6 WAFER BOX 2x5P for LCM
CN7 CFast Type II Socket
CN8 RJ45 Connector for Console
CN9 USB DOM Connector
CN10 IPMB Connector for HDD Backplane
CN11 WAFER BOX 2x5P for Telco
CASE_OPEN1 WAFER BOX 2P for Chassis Instruc-
tion
SW1 DIP SW for Reset NIC1_82574L
SW2 Push SW for System Power Button
D9 CFast Card Status LED
D10 CFast Access LED
D11 Power LED
D12 Locate LED
D13 Alert LED
JP2: CMOS clear function
Pins Result
1-2 Keep CMOS data*
2-3 Clear CMOS data
*: Default
Keep CMOS data* Clear CMOS data

FWA-6510 Startup Manual 5
CN10 : External GPIO Header
Pins Result
1 VCC
2 GND
3 9554 GPIO0
4 9554 GPIO1
5 9554 GPIO2
6 9554 GPIO3
7 9554 GPIO4
8 9554 GPIO5
9 9554 GPIO6
10 9554 GPIO7
11 GND
12 VCC3
CN1: Front Panel Header
Pins Result
1 VCC
2 GND
3 Power Button
4 Reset Button
5 SMBUS Data
6 SMBUS Clock
7 VCC3
8 HDD ACT LED
CN1/2: RJ45 LAN connector (Mgmt)
LED status :
GbE Link Green (Left)
FE Link Amber (Left)
Action Link Green/Blink (Right)
Software tested list:
1. Linux Debian 2.6.18 kernel
2. Linux Redhat 6.1
This device complies with the requirements in Part 15 of
the FCC rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received,
including interference that may cause undesired opera-
tion.
Jumpers and Connectors Jumpers and Connectors
9 7
8
531
6 4 21012
11
PH_6x2V_S2.00mm
1 81 8
RJ45 for LAN Connectors
1 81 8
←RIGHTLEFT →
Software Installation
Specications

6 FWA-6510 Startup Manual
Board Placement
+
CPU1
CN31 CN1
CN3 CN6 CN4
CN28
D1
D2
CN2
D4
CN11
CN14
CN13
CN20
CN16
CN32
CN15
CN9
CN10
CN8
JP1
JP2
JP3
JP4
SATA1 SATA2
CN29
CN30
CPU2
DIMM H1 DIMM G1 DIMM A1 DIMM A2 DIMM B1 DIMM B2 DIMM D2 DIMM D1 DIMM C2 DIMM C1 DIMM E1 DIMM F1
CN24
CN27
FAN1
CN26
FAN2
CN22
CN25
CN23
CN21
CN19
CN17
CN18
CN5
CN7
SW3

FWA-6510 Startup Manual 7
Board Placement
+
++
CASE_OPEN1
CN3
CN2SW2 CN8CN4
D13
CN11
D11
D12
CN5
CN7
CN10
SW1
CN1
CN9
