The PCL-841 is a special purpose communication card that brings thc
Control Area Network to your PC. With the built-in CAN controller,
the PCL-84 l provides bus arbitration and error detcction with
automatic transmission repeat function. This drastically avoids data
loss and ensures system reliability. The on-board CAN controllers arc
located at different positions in thc memory. You can run both CAN
controllers at the same time, independently. The PCL-84 1 opcrates at
baud rates up to I Mbps and can be installcd directly into thc cxpan-
sion slot of your PC.
Control Area Network
Thc CAN (Control Area Network) is a serial bus systcm cspecially
suitcd for networking “intelligent” 1/0 deviccs as well as sensors and
actuators within a machine or plant. Characterized by its multi-mastcr
protocol, rcal-time capability, error correction, high noise immunity,
and thc cxistencc of many different silicon components, the CAN
serial bus system, originally developed by Bosch for use in automo-
biles, is increasingly being used in industrial automation.
Direct memory mapping
The PCL-84 1 is assigned with memory address, which allows direct
access to the CAN controller. This is the simplest and fastest way of
programming any board in a PC because the board is regarded as
standard RAM.
Optical Isolation Protection
On-board optical isolators protect your PC and equipment against
damage from ground ioops, increasing system reliability in harsh
environments.

Chapter 1 General Information 3
Features
•Operates two separate CAN networks at the same time
•High speed transmission up to I Mbps
•16 MHz CAN controller frequency
• Takes a 4 KB address space, 40 base address adjustable in steps
fromC800HuptoEFOOH
•Optical isolation protection of 1000 VDC ensures system reliability
• Wide IRQ selection for each port includes: IRQ3, 4, 5, 6, 7, 9, 10, 11,
12, 15
•LED indicates Transmit/Receive status on each port
•Direct memory mapping enables speedy access to the CAN
controllers
•C library and examples included
Specifications
•Ports:2
•CANcontroller:SJA-1000
•CANtransceiver:82C250
•Signalsupport:CAN-L,CAN-H
•Memoryaddress:FromC800HtoEFOOH
•IRQ:3,4,5,6, 7, 9, 10,11,12,15
•Isolationvoltage:1000VDC
•Powerconsumption:+5 V @ 400 mAtypical,950mAmax.
•Connectors:Dual DB-9 male connectors
•Operatingtemperature:32 to1 22º F(0 to 50ºC)
•Dimensions:7.25"x 4. 13"(18.4x10.5cm)
•Shippingweight:0.9 lb(0.4kg)

4PCL-841 Series User's Manual

2
Hardware
Installation
CHAPTER

6PCL-841 Series User's Manual
Initial inspection
You should find the following items inside the shipping package (in
addition to this manual):
•PCL-841Dual-port CANInterfaceCard
•C Driver and DataMonitor Utility Diskette
We have carefully inspected the PCL-841 mechanically and electri-
calIy before shipping. It should be free of marks and scratches and in
perfect working order upon receipt.
As you unpack the PCL-841, check it for signs of shipping damage
(damaged box, scratches, dents, etc.). If it is damaged or it fails to
meet specifications, notify our service department or your local
representative immediately. Also notify the carrier. Retain the ship-
ping carton and packing material for inspection by the carrier. After
inspection we will make arrangements to repair or replace the unit.
When you handle the PCL-841, remove it from its protective packag-
ing by grasping the rear metal panel. Keep the anti-vibration packing.
Whenever you remove the card from the PC, store it in this package
for protection.
Warning! Modern electronic devices are very sensitive to damage
from static electricity. Ground yourself before you touch the
card. We recommend that you ~use a grounded wrist strap
and place the card on a static dissipative mat wheneveryou
work with it. At the very least, touch the back of the
grounded chassis of the system unit (metal) before you
handle the board. Avoid contact with materials that hold a
static charge, such as styrofoam. Do not touch the exposed
circuit connectors.

Chapter 2 Hardware Installation 7
Jumper and switch locations

8PCL-841 Series User's Manual
Card configuration
The PCL-841 has two ports, each with one jumper. The jumpers set the
IRQ for the ports, which can be configured separately. A DIP switch
sets the memory base address for each port. The following chart
shows the function of the jumper and the switch (see the previous
page for jumper and switch locations).
Switch and jumper functions
CAN controllers
JP1 Po rt 1
JP2 Port 2
Mennory base address
SW1 Port 1, Port 2
Default settings
Port I is set for COMI (IRQ=12, Memory address=DA00:0000).
Port 2 is set for COM2 (IRQ=IS, Memory address=DA00:0200). ;
If you need to change these settings, see the following sections.
Otherwise, you can simply install the card. Note that you will need to
disable your CPU card’s on-board COM ports, if any, or set them to
alternate addresses/IRQs.

Chapter 2 Hardware Installation 9
Interrupt (IRQ) setup (JP1 and JP2)
Jumpers JPI and JP2 set the interrupts for Port I and Port 2, respec-
tively. You can choose any IRQ from 3 to 15, except 8, 13 and 14.
When you choose IRQs, make sure they are not used for other cards
in the system. The following figures show the card’s default settings.
JP1:Port 1IRQDefault JP2: Port2IRQDefault
Memory base address (SW1)
The memory base address for the PCL-841, which requires 4 KB of
address space, is made up of the memory segment and its associated
offset. The address for the memory segment is set through SWI, a six-
position DIP switch. You can choose any base address from C800 to
EFOO. The following table shows the DIP switch settings and the
corresponding base addresses.
Memory address configUration (SW1)
Address/DIPswitch A12 A13 A14 A15 A16 A17
C800H on on on off on on
C9OOH off on on off on on
CAOOH on off on off on on
CBOOH off off on off on on
CCOOH on on off off on on
CDOOH off on off off on on
CEOOH on off off off on on
CFOOH off off off off on on

10 PCL-841 Series User's Manual
Mennory address configUration (SW1) cont'd
Address/DIP switch A12 A13 A14 A15 A16 A17
DOOOH on on on on off on
D100H off on on on off on
D200H on off on on off on
D300H off off on on off on
D400H on on off on off on
DSOOH off on off on off on
D600H on off off on off on
D700H off off off on off on
D800H on on on off off on
D9OOH off on on off off on
DAOOH on off on off off on
DBOOH off off on off off on
DCOOH on on off off off on
DDOOH off on off off off on
DEOOH on off off off off on
DFOOH off off off off off on
EOOOH on on on on on off
E100H off on on on on off
E200H on off on on on off
E300H off off on on on off
E400H on on off on on off
ESOOH off on off on on off
E600H on off off on on off
E700H off off off on on off
E800H on on on off on off
E9OOH off on on off on off
EAOOH on off on off on off
EBOOH off off on off on off
ECOOH on on off off on off
EDOOH off on off off on off
EEOOH on off off off on off
EFOOH off off off off on off

Chapter 2 Hardware Installation 11
Memory area
Once the memory segment for the base address is selected, the offset
will be automatically assigned for Port 1, Port 2, and hardware reset.
The following table shows the base addresses of the CAN controllers.
Base address (hex) CAN controller
base:0000h - base:00FFh Basic- Port 1
base:0100h - base:01FFh HW reset Basic - Port 1
base:0200h - base:02FFh Basic- Port 2
base:0300h - base:03FFh HW reset Basic - Port 2
base:0400h - base:0FFFh Not used

12 PCL-841 Series User's Manual

3
Software
Programming
CHAPTER

14 PCL-841 Series User's Manual
Library functions
Quick reference table
The following table lists the available functions and their correspond-
ing syntax and descriptions.
Liorary functions
Function Syntax (in C) Description
1caninitHW() Sets IROs
2canExitHW() Releases settings
3canReset() Resets CAN port
4canConfig() Controls CAN port settings
5canNormalR~n() Sets mode
6 canSendMsg() Sends message
7 canReceiveMsg() Reads data
Complete function description
Function 1
Sets an IRQ number for Port I and Port 2.
Command canluitHW(Ulsegment,BYTEIRQI,BYTEIRQ2)
Argument UIsegment,BYTEIRQI,BYTEIRQ2
segment=c000-df00step 0x100
IRQI=PortI IRQnumber0 (polling),
3,4, 5, 6,7,8, 9, 10,11, 12, 14,15
IRQ2=Port2 IRQ number0(polling),
3,4,5, 6, 7,8,9,10,11,12, 14, 15
0: polling
Response l=successful
0=fail

Chapter 3 Software Programming 15
Example
#include "can841.h"
main()
{UlgSegment=0xDA00;
BYTECANl_IRQ,CAN2IRQ;
CANI_IRQ=12;
CAN2_IRQ=15;
if(canluitHW(gSegment, CANI_IRQ,CAN2_IRQ)==0)
printf("HARDWAREINITIALIZATIONERROR!\n");
}
Function 2
Releases all seuings of the CAN card.
Command canExitHW()
Argument None
Response l=successful
0=fail
Example
#include "can84 1.h"
main()
{if(canExitHW()==0)
printf(“CANRELEASE FAIL!\n”);
}
Function 3
Resets CAN port and flushes the TX/RX buffers.
Command int canReset (BYTE port);
Argument BYTEport;
port= port number (0 or 1)
Response l=successful
0=fail

16 PCL-841 Series User's Manual
Example
#include "can84 1 .h"
main()
{if(canReset (0)==0)
printf("RESET PORTI FAIL!n");
}
Function 4
Controls the setting of the CAN port’s acceptance code, acceptance
mask, and bus timing register.
Command canConfig(BYTEport, CAN STRUCTcan);
Argument BYTEport, CAN_STRUCTcan;
port= port number (0 or 1)
can= CAN struct pointer
Response l=successful
0=fail
Example
#include "canB4 1.h"
main()
{CAN_STRUCTcanl, can2;
can 1.acc_code=0;
can1. acc_mask=0xff;
can 1.bt0=0;
can 1.bt I =0x 1 c;
if(canConfig(0,canl)==0)
printf("CANPORTICONFIGUREERROR!\n");
}
Function 5
Sets a CAN port to normal mode for normal operation.
Command canNormalRun(BYTE port);
Argument BYTEport;
port= port number (0 or 1)

Chapter 3 Software Programming 17
Response l=successful
0=fail
Example
#include "can84 1.h"
main()
{if(canNormalRun(0)==0)
printf ("CAN Port I can’t change to Normal Mode!\n");
}
Function 6
Tells the CAN port to send a message.
Command canSendMsg(BYTEport,MSG_STRUCTsendmsg);
Argument BYTEport, MSG_STRUCTsend_msg;
port= port number (O or 1)
send msg= send buffer pointer
Response l=successful
0=fail
Example
#include “can84 1.h” main()
{MSG_STRUCTsmsg 1;
Uli;
smsg1.id=0x015;
smsg l.rtr=0;
smsg l.dlen=8;
for(i=0;i<smsg l.dlen;i++)
smsg l.data[i]=i;
if (canSendMsg(0,smsg 1)==l)
printf("TRANSMISSIONSUCCESSFUL!\n");
{

18 PCL-841 Series User's Manual
Function 7
Read data from CAN port input buffer.
Command int canReceiveMsg (BYTE port, MSG STRUCT
*msg ptr);
Argument BYTEport,MSG_STRUCT *msg ptr;
port= port number (O or 1)
*msg_ptr= input buffer pointer
Response l=message received
0=no message received
Example
#include "can841.h"
main()
{MSG_STRUCTrmsg2;
if(canReceiveMSG,*rmsg2)==1)
{printf("Port2 receive:ID=%3XRTR=%ld
Length=%ld”, rmsg2.id rmsg2.rtr, rmsg2.dlen);
for(i=0; i<rmsg2.dlen;i++)
cprintf (" %2X", rmsg2.data[i]);
}
}

Chapter 3 Software Programming 19
Example program
The following example program, can84 I.lib, implements the sending
and receiving of messages over the CAN controller. The program is
written in C.
#include "can841.h" /*Library function declaration*/
/*------------------------------------------------*/
/* CAN controller interrupt connection */
#define CAN1_IRQ 12 /* 0 means polling */
#define CAN2_IRQ 15 /* 0 means polling */
#define PORT1 0
#define PORT2 1
#define FAIL 0
#define SUCCESS 1
void main(void)
(/* Declare the CAN card segment address. */
UI gSegment=OxDA00;
CAN_STRUCT canl, can2;
MSG_STRUCT smsql, smsg2;
MSG_STRUCT rmsql, rmsg2;
UI i;
if(canInitHW(gSegment,CANl_IRQ,CAN2 IRQ)==FAIL)
{clrscr();
cprintf(“\n\n Hardware Initialization Error.’);
return;
}
/* Reset CAN controller */
canReset(PORT1);
canReset(PORT2);
canl.acc_code=0; /* */
canl.acc mask=Oxff; /* */
canl.btO=03; /* baud rate lMbps */
canl.btl=0xlc;
if(canConfig(PORTl,canl)==FAIL)
{clrscr();
cprintf("\n\n CAN Port %d Configuration Error",1);
return;
{
