Advantech IPPC-6192A User manual

User Manual
IPPC-6192A Series
19" SXGA TFT LCD Core 2 Quad
/ Core 2 Duo Industrial Panel PC
with 2 x PCI Slots

IPPC-6192A User Manual ii
Copyright
The documentation and the software included with this product are copyrighted 2011
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice.
No part of this manual may be reproduced, copied, translated or transmitted in any
form or by any means without the prior written permission of Advantech Co., Ltd.
Information provided in this manual is intended to be accurate and reliable. However,
Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringements
of the rights of third parties, which may result from its use.
Acknowledgements
Intel and Pentium are trademarks of Intel Corporation.
Microsoft Windows and MS-DOS are registered trademarks of Microsoft Corp.
All other product names or trademarks are properties of their respective owners.
Product Warranty (2 years)
Advantech warrants to you, the original purchaser, that each of its products will be
free from defects in materials and workmanship for two years from the date of pur-
chase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Advantech, or which have been
subject to misuse, abuse, accident or improper installation. Advantech assumes no
liability under the terms of this warranty as a consequence of such events.
Because of Advantech’s high quality-control standards and rigorous testing, most of
our customers never need to use our repair service. If an Advantech product is defec-
tive, it will be repaired or replaced at no charge during the warranty period. For out-
of-warranty repairs, you will be billed according to the cost of replacement materials,
service time and freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU
speed, Advantech products used, other hardware and software used, etc.) Note
anything abnormal and list any onscreen messages you get when the problem
occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return merchandize
authorization) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a fully-completed Repair and Replacement
Order Card and a photocopy proof of purchase date (such as your sales receipt)
in a shippable container. A product returned without proof of the purchase date
is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid
to your dealer.
Part No. 2003619202 Edition 3
Printed in China February 2012

iii IPPC-6192A User Manual
Declaration of Conformity
CE
This product has passed the CE test for environmental specifications. Test conditions
for passing included the equipment being operated within an industrial enclosure. In
order to protect the product from being damaged by ESD (Electrostatic Discharge)
and EMI leakage, we strongly recommend the use of CE-compliant industrial enclo-
sure products.
FCC Class A
Note: This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Opera-
tion of this equipment in a residential area is likely to cause harmful interference in
which case the user will be required to correct the interference at his own expense.
Technical Support and Assistance
1. Visit the Advantech web site at www.advantech.com/support where you can
find the latest information about the product.
2. Contact your distributor, sales representative, or Advantech's customer service
center for technical support if you need additional assistance. Please have the
following information ready before you call:
–Product name and serial number
–Description of your peripheral attachments
–Description of your software (operating system, version, application software,
etc.)
–A complete description of the problem
–The exact wording of any error messages

IPPC-6192A User Manual iv
Safety Instructions
1. Read these safety instructions carefully.
2. Keep this User Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a damp
cloth. Do not use liquid or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the equip-
ment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or letting
it fall may cause damage.
7. The openings on the enclosure are for air convection. Protect the equipment
from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting the
equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power source
to avoid damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electrical shock.
13. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
14. If one of the following situations arises, get the equipment checked by service
personnel:
a. The power cord or plug is damaged.
b. Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d. The equipment does not work well, or you cannot get it to work according to
the user's manual.
e. The equipment has been dropped and damaged.
f. The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE
STORAGE TEMPERATURE MAY GO BELOW -40° C OR ABOVE 85° C. THIS
COULD DAMAGE THE EQUIPMENT. THE EQUIPMENT SHOULD BE IN A
CONTROLLED ENVIRONMENT.
Safety Precaution - Static Electricity
Follow these simple precautions to protect yourself from harm and the products from
damage.
To avoid electrical shock, always disconnect the power from your PC chassis
before you work on it. Don't touch any components on the CPU card or other
cards while the PC is on.
Disconnect power before making any configuration changes. The sudden rush
of power as you connect a jumper or install a card may damage sensitive elec-
tronic components.

v IPPC-6192A User Manual
Contents
Chapter 1 General Information ............................1
1.1 Introduction ............................................................................................... 2
1.2 Specifications ............................................................................................ 3
1.2.1 General ......................................................................................... 3
1.2.2 Standard PC Functions................................................................. 3
1.2.3 Display .......................................................................................... 3
1.2.4 Audio Functions ............................................................................ 3
1.2.5 PCI bus Ethernet Interface............................................................ 4
1.2.6 Touchscreen Specifications .......................................................... 4
1.2.7 Environmental ............................................................................... 4
1.3 Dimensions ............................................................................................... 5
Chapter 2 System Setup.......................................7
2.1 General ..................................................................................................... 8
2.1.1 PS/2 Mouse & Keyboard............................................................... 8
2.1.2 VGA Port....................................................................................... 8
2.1.3 Serial COM Ports .......................................................................... 8
2.1.4 USB Ports ..................................................................................... 9
2.1.5 Audio Interface.............................................................................. 9
2.1.6 Ethernet ........................................................................................ 9
2.2 Installing SDRAM ...................................................................................... 9
2.3 Installing a CPU ...................................................................................... 10
2.4 Installing a 2.5" SATA HDD..................................................................... 12
2.5 Installing Add-on Cards........................................................................... 13
2.5.1 Add-on Cards Support ................................................................ 13
2.5.2 Installing Add-on Cards............................................................... 13
2.6 Mounting Instructions .............................................................................. 14
2.6.1 Panel Mounting ........................................................................... 14
2.6.2 Rack Mounting ............................................................................ 14
Chapter 3 Jumper Settings & Connectors........15
3.1 Jumper Settings ...................................................................................... 16
3.1.1 Jumpers & Switches ................................................................... 16
Table 3.1: Jumpers & Switches ................................................. 16
3.1.2 Connectors.................................................................................. 16
Table 3.2: Connectors ............................................................... 16
3.1.3 COM4 Settings (J20) .................................................................. 18
Table 3.3: COM4 Settings ......................................................... 18
3.1.4 Clear CMOS (CLRTC1) .............................................................. 18
Table 3.4: Clear CMOS ............................................................. 18
Chapter 4 Intel Chipset .......................................19
4.1 Overview ................................................................................................. 20
4.2 Utilities and Drivers ................................................................................. 20
4.3 Dual Display Setting................................................................................ 21
4.3.1 Touchscreen Installation & Configuration ................................... 22
Chapter 5 AMI BIOS Setup .................................23

IPPC-6192A User Manual vi
5.1 BIOS Setup Program .............................................................................. 24
5.1.1 Legend Box................................................................................. 24
5.1.2 List Box ....................................................................................... 25
5.1.3 Sub-menu ................................................................................... 25
5.2 Main Setup.............................................................................................. 25
5.3 Advanced BIOS Setup ............................................................................ 26
5.3.1 Super I/O Configuration .............................................................. 29
5.3.2 ACPI Configuration ..................................................................... 32
5.3.3 AHCI Configuration..................................................................... 33
5.3.4 APM Configuration...................................................................... 35
5.3.5 Configure Intel AT-d Parameters................................................ 36
5.3.6 Intel AMT Configuration .............................................................. 36
5.3.7 Intel VT-d Configuration.............................................................. 38
5.3.8 Trusted Computing ..................................................................... 39
5.4 Advanced PCI/PnP Settings ................................................................... 40
5.5 Boot Setting Configuration ...................................................................... 42
5.6 Security Setup......................................................................................... 45
5.7 Chipset Setup ......................................................................................... 46
5.7.1 North Bridge Configuration ......................................................... 46
5.7.2 South Bridge Configuration......................................................... 48
5.8 Exit Menu ................................................................................................ 49
Appendix A IO & Connector Pin Assignments ... 51
A.1 CN1, CN2 LVDS ..................................................................................... 52
Appendix B System Assignments........................ 61
B.1 System I/O Ports..................................................................................... 62
Table B.1: System I/O Ports ...................................................... 62
B.2 DMA Channel Assignments .................................................................... 62
Table B.2: DMA Channel Assignments ..................................... 62
B.3 Interrupt Assignments ............................................................................. 63
Table B.3: Interrupt Assignments .............................................. 63
B.4 1st MB Memory Map............................................................................... 63
Table B.4: 1st MB Memory Map ................................................ 63
B.5 PCI Bus Map........................................................................................... 63
Table B.5: PCI Bus Map ............................................................ 63
Appendix C Watchdog Timer................................ 65
C.1 Overview ................................................................................................. 66
C.2 Watchdog Timer Programming ............................................................... 66

Chapter 1
1General Information

IPPC-6192A User Manual 2
1.1 Introduction
The IPPC-6192A is an Industrial Panel PC with front USB access, supports the pow-
erful Intel Core 2 Quad/Core 2 Duo, high speed DDR3 memory, two expansion PCI
slots and slim type DVD-RW. The processor and chipset combination form the foun-
dation of vPro, Intel’s next generation digital office platform, offering remote out-of-
band manageability, improved security, and energy efficient performance. Two SATA
hard driver interface with RAID 0,1 support provides data security. The flat-sealed
front panel design also allows easier cleaning and liquid run off. Also the control box
has a gull-wing design for easy component installation and maintenance.
Sturdy Structure
The whole system is protected by a firm solid structure. The front panel is made of
sturdy aluminum and has strengthened glass. It is shock resistant, and complies with
NEMA4/IP65.
Easy Maintenance
The rear cover with gull open design above the motherboard. Thus users can easily
maintain the CPU, HDD, SDRAM and DVD-RW drive. Jumpers can be easily set
without removing the rear cover.
High Performance
The IPPC-6192A supports Intel LGA775 socket. It supports Core 2 Quad up to
2.8GHz or Core 2 Duo up to 3.0GHz
Friendly HMI
Systems in the IPPC-6192A series are equipped with a 19" LCD screen, which pro-
vides high resolution display quality. The result is vivid, bright, and sharp quality
images. The panel PC is perfectly suited for Windows OS. The touchscreen version
enables simple operation, making the Panel PC a solid industrial digital controller
interface. In addition friendly HMI design of the IPPC-6192A series offers front USB
access port and reset key for various requirements.

3 IPPC-6192A User Manual
Chapter 1 General Information
1.2 Specifications
1.2.1 General
Dimensions (W x H x D):
Front Panel: 481.92 x 355.87 x 26 mm
Control Box: 362 x 285 x 112.2 mm
Cut out Dimensions: 454 x 338 mm
Weight: 16.6 Kg (36.5 lb)
Power Supply: 350 W
Input Voltage: 100Vac-240VAC , 50/60Hz , 7-3.5A
Output Voltage: +3.3V@ 16.0A, [email protected],[email protected],
[email protected],[email protected],[email protected]A
Storage: 2 x 2.5" SATA HDDs with RAID 0/1 support
1.2.2 Standard PC Functions
CPU: Socket LGA775 Core 2 Quad up to 2.8GHz or Core 2 Duo up to 3.0GHz
BIOS: AMI 4MB Flash BIOS
North Bridge: Intel Q45
South Bridge: Intel ICH10D0
Chipset: Intel Q45 GMCH / ICH10D0
2nd Level Cache: Depends on CPU from 2MB to 12MB
RAM: Two DDR3 240pin slots up to 2 x 2GB 1066/1333 MHz SDRAM NON-
ECC, NON-REG
Serial Ports: 2 x RS-232(COM1/COM2) , 1 x RS-232/422/485 (COM4)
Universal Serial Bus (USB) Port: Supports up to 5 x USB (2.0) ports
PCI Bus Expansion Slots: 2 x half-length PCI slots
Watchdog Timer: 255-level interval timer, setup by software, Super I/O inte-
grated, SMSC controller
Battery: 3.0 V @ 196 mAH lithium battery
1.2.3 Display
Backlight Life: 50,000 hrs
Contrast Ratio: 1300:1
Display Size: 19”
Display Type: SXGA TFT LCD
Luminance: 300 cd/m2
Max. Colors: 16.7M
Max. Resolution: 1280 x 1024
Viewing Angle (H/V): 178/178
1.2.4 Audio Functions
Chipset: Integrated in Intel Q45 ICH10D0 South Bridge
Audio Codec: HD audio Realtek ALC888
Audio Interface: Mic in, Line in, Line out

IPPC-6192A User Manual 4
1.2.5 PCI bus Ethernet Interface
Chipset: Intel 82567-LM Gigabit LAN (IAMT), Intel 82574L Gigabit LAN
Ethernet Interface: 10/100/1000Base-T x 2
1.2.6 Touchscreen Specifications
Type: Analog resistive 5-wire
Lifespan: 36 million, writing rate is 250g at 2 times/s
Light Transmission: >80%
Controller: RS-232 interface (COM3)
Power Consumption: +5.5 V @ 20 mA
Software Drivers: Supports Windows 7, Windows XP
1.2.7 Environmental
Operating Temperature: 0 ~ 50°C (32 ~ 122°F)
Storage Temperature: -20 ~ 60°C (-4 ~ 140°F)
Relative Humidity: 5~85% @ 40°C (non-condensing)
Shock: 30 G peak acceleration (11 ms duration)
Power MTBF: 100,000 hrs
Certifications: CE, CCC, FCC Class A, UL, BSMI

5 IPPC-6192A User Manual
Chapter 1 General Information
1.3 Dimensions
285.00 [11.22]
133.00 [5.24]
445.92 [17.56]
18.01 [0.71]
481.94 [18.97]
384.60 [15.14]
36.00 [1.42]
23.50 [0.93]
7.00 [0.28]
99.47 [3.92]362.00 [14.25]
21.04 [0.83]

IPPC-6192A User Manual 6

Chapter 2
2System Setup

IPPC-6192A User Manual 8
2.1 General
Before you start the computer, please follow these procedures for set up:
1. Check and adjust jumpers on the motherboard (see Chapter 3)
2. Install DDR3 SDRAM
3. Install a CPU
4. Install add-on cards
5. Connect the wires, cables and accessories
6. Mount the computer
7. Program the BIOS settings
8. Install an operating system.
2.1.1 PS/2 Mouse & Keyboard
If you wish to use a full-size desktop keyboard and PS/2 mouse with your panel PC,
follow these instructions:
1. Be sure the panel PC is turned off.
2. Attach the keyboard adapter to the 5-pin purple port on the rear bottom side of
the rear cover.
3. Attach the mouse adapter to the 5-pin green port on the rear side of the cover.
2.1.2 VGA Port
An external VGA-compatible device may be connected to the system via 15-pin
external port on the rear of the unit. The panel PC simultaneously supports an exter-
nal monitor in addition to its own LCD display.
2.1.3 Serial COM Ports
You can easily attach a serial device to the panel PC, such as an external modem or
mouse. Follow these instructions:
1. Make sure the panel PC and any other peripherial devices you mayhave con-
nected to the panel PC are turned off.
2. Attach the interface cable of the serial device to the panel PC's serial port. If
necessary, attach the other end of the interface cable to your serial device. Fas-
ten any retaining screws.
3. Turn on any other peripheral devices you may have connected to the panel PC,
and then turn on the panel PC.
4. Refer to the manual(s) which accompanied your serial device(s) for instructions
on configuring your operating environment to recognize the device(s).
5. Run the BIOS setup program to set the I/O address and IRQ, and configure the
jumper settings to change the mode of the COM ports (refer to section 3.3).
Warning! 1. Switch off and unplug every time you access its interior.
2. The motherboard inside the system is composed of many delicate
ICs, chips and other integrated circuit components. These compo-
nents are easily damaged by static shock.
When you begin to install components, please:
- Avoid touching the metal parts of the motherboard.
- Use anti-static ring when handling CPU or SDRAM module.
- Put SDRAM modules and the CPU inside an anti-static bag or a simi-
lar place before installation.

9 IPPC-6192A User Manual
Chapter 2 System Setup
2.1.4 USB Ports
An external USB device may be connected to the system via the 4-pin USB ports
located on the rear side of the system unit.
1. Connect the external device to the system.
2. The USB ports support hot plug-in connection. You should install the device
driver before you use the device.
2.1.5 Audio Interface
The audio interface includes three jacks: microphone-in, line-out and line-in. Their
functions are:
Microphone-in: Use an external microphone to record voice and sound.
Line-out: Output audio to external devices such as speakers or earphones. The
built-in speaker will not be disabled when the line-out jack is connected to exter-
nal audio devices.
Line-in: Input audio from an external CD player or radio.
1. Connect the audio device to the system.
2. Install the driver before you use the device.
2.1.6 Ethernet
To install Ethernet for your system:
1. Connect the Ethernet cable.
2. Turn on the panel PC.
3. Run the Ethernet driver to connect up to the network.
2.2 Installing SDRAM
The Panel PC system provides two 240pin DDR3 SDRAM sockets. If you only uses
one memory, please insert it into the first slot (near CPU).
1. Unlock the back cover and open it.
2. Push the two white eject levers on each side of the DIMM outward until they are
separated from the black vertical posts.
3. Insert the memory module into the socket at an angle of 90 degrees.
4. Push the two eject levers toward the vertical posts at each end of the socket
until the module is upright.

IPPC-6192A User Manual 10
2.3 Installing a CPU
The CPU can be upgraded to improve system performance. The system provides
Socket LGA775 architecture which supports Intel Core 2 Quad up to 2.8GHz and
Intel Core 2 Duo up to 3.0GHz.
1. Unlock the back cover and open it.
2. Remove the CPU cooler.
3. Insert the CPU with the correct orientation. The notched corner of the CPU (with
the white dot) should point toward the end of the lever. The end of the lever is
the blank area where one hole is missing from the corner of the square array of
pin holes. An arrowhead printed on the motherboard points to the end of the
lever.
4. Slide the CPU in gently. It should insert easily. If not, pull the lever up a little
more and make sure the pins of the CPU correspond with the holes of the
socket. DO NOT USE EXCESSIVE FORCE!
5. Press the lever down. The plate will slide forward.
6. Place the heat sink on top of the CPU, secure with heat sink clip.
7. Connect the CPU's cooling fan power connector.
8. Put back the rear cover and screw it back.

11 IPPC-6192A User Manual
Chapter 2 System Setup
Warning! Always disconnect the power cord from your panel PC when you are
working on it. Do not make connections while the power is on, because
sensitive electronic components can be damaged by the sudden rush of
power. Only experienced electronics personnel should open the panel
PC.

IPPC-6192A User Manual 12
2.4 Installing a 2.5" SATA HDD
You can attach two enhanced Serial Advanced Technology Attachment (SATA) hard
disk drives to IPPC-6192A's internal controller which uses PCI local bus interface.
The following instructions are for installation:
1. Unscrew the back cover and open it.
2. Remove four screws and take off HDD bracket.
3. Insert the HDD into the bracket (see figure )
4. Put the HDD bracket into the Chassis and fasten the four screws.
5. Then attach the HDD flat cable and power cable.
6. Close the rear cover

13 IPPC-6192A User Manual
Chapter 2 System Setup
2.5 Installing Add-on Cards
2.5.1 Add-on Cards Support
This system supports two PCI expansion cards.
2.5.2 Installing Add-on Cards
The following procedures will instruct you to install the PCIe riser card provided in the
accessory box.
1. Detach the five screws on the back to open the lid.
2. Remove the PCI riser card by loosing the 2 screws which fix the card to the
bracket. Then find the PCIe riser card from the accessory box and fix it to the
bracket with 2 screws.

IPPC-6192A User Manual 14
3. Replace the back cover and fix it with 5 screws.
4. This system supports two PCI expansion cards.
2.6 Mounting Instructions
There are two ways to mount the system: panel mounting or rack mounting.
2.6.1 Panel Mounting
1. Take the four mounting brackets out of the accessory box.
2. Attach the four mounting brackets by inserting the screws into the keyhole slots
on the cover of the monitor.
3. Use the screws to secure the brackets to the cover. Tighten the screws to
secure the monitor to the back panel.
2.6.2 Rack Mounting
Please order IPPC-6192A-RMKE option kit to install to a 19" industrial rack.
