Advantech IDK-1107WP Series User manual

User Manual
IDK-1107WP Series
TFT-LCD 7” WVGA (LED
Backlight) with Projected
Capacitive Touchscreen

IDK-1107WP User Manual ii
Copyright
The documentation and the software included with this product are copyrighted 2016
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. Information provided in this manual is intended to be accurate and reliable. How-
ever, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringe-
ments of the rights of third parties, which may result from its use.
Acknowledgements
AMI is a trademark of American Megatrends Inc.
IBM and PC are trademarks of International Business Machines Corporation.
Intel® Core 2 Quad, Pentium Dual Core and Celeron are trademarks of Intel Corpo-
ration.
WinBond is a trademark of Winbond Corporation.
All other product names or trademarks are properties of their respective owners.
Part No. 2006110710 Edition 1
Printed in Taiwan May 2016

iii IDK-1107WP User Manual
A Message to the Customer
Advantech Customer Services
Each and every Advantech product is built to the most exacting specifications to
ensure reliable performance in the harsh and demanding conditions typical of indus-
trial environments. Whether your new Advantech equipment is destined for the labo-
ratory or the factory floor, you can be assured that your product will provide the
reliability and ease of operation for which the name Advantech has come to be
known.
Your satisfaction is our primary concern. Here is a guide to Advantech’s customer
services. To ensure you get the full benefit of our services, please follow the instruc-
tions below carefully.
Technical Support
We want you to get the maximum performance from your products. So if you run into
technical difficulties, we are here to help. For the most frequently asked questions,
you can easily find answers in your product documentation. These answers are nor-
mally a lot more detailed than the ones we can give over the phone.
So please consult this manual first. If you still cannot find the answer, gather all the
information or questions that apply to your problem, and with the product close at
hand, call your dealer. Our dealers are well trained and ready to give you the support
you need to get the most from your Advantech products. In fact, most problems
reported are minor and are able to be easily solved over the phone.
In addition, free technical support is available from Advantech engineers every busi-
ness day. We are always ready to give advice on application requirements or specific
information on the installation and operation of any of our products.

IDK-1107WP User Manual iv
Product Warranty (2 years)
Advantech warrants to you, the original purchaser, that each of its products will be
free from defects in materials and workmanship for two years from the date of pur-
chase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Advantech, or which have been
subject to misuse, abuse, accident or improper installation. Advantech assumes no
liability under the terms of this warranty as a consequence of such events.
Because of Advantech’s high quality-control standards and rigorous testing, most of
our customers never need to use our repair service. If an Advantech product is defec-
tive, it will be repaired or replaced at no charge during the warranty period. For out-
of-warranty repairs, you will be billed according to the cost of replacement materials,
service time and freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU
speed, Advantech products used, other hardware and software used, etc.) Note
anything abnormal and list any onscreen messages you get when the problem
occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return merchandise
authorization) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a fully-completed Repair and Replacement
Order Card and a photocopy proof of purchase date (such as your sales receipt)
in a shippable container. A product returned without proof of the purchase date
is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid
to your dealer.

v IDK-1107WP User Manual
Warnings, Cautions, and Notes
Warning! Warnings indicate conditions, which if not observed, can cause personal
injury!
Caution! Cautions are included to help you avoid damaging hardware or losing
data. e.g.
There is a danger of a new battery exploding if it is incorrectly installed.
Replace the battery only with the same or equivalent type recom-
mended by the manufacturer. Discard used batteries according to the
manufacturer's instructions.
Note! Notes provide optional additional information.

IDK-1107WP User Manual vi
Safety Instructions
1. Read these safety instructions carefully.
2. Keep this User Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a damp
cloth. Do not use liquid or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the equip-
ment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or letting
it fall may cause damage.
7. Make sure the voltage of the power source is correct before connecting the
equipment to the power outlet.
8. Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
9. All cautions and warnings on the equipment should be noted.
10. If the equipment is not used for a long time, disconnect it from the power source
to avoid damage by transient overvoltage.
11. Never pour any liquid into an opening. This may cause fire or electrical shock.
12. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
13. If one of the following situations arises, get the equipment checked by service
personnel:
The power cord or plug is damaged.
Liquid has penetrated into the equipment.
The equipment has been exposed to moisture.
The equipment does not work well, or you cannot get it to work according to
the user's manual.
The equipment has been dropped and damaged.
The equipment has obvious signs of breakage.
14. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE
STORAGE TEMPERATURE MAY GO BELOW -25° C (-13° F) OR ABOVE 60°
C (140° F). THIS COULD DAMAGE THE EQUIPMENT.
15. This equipment has been tested and found to comply with the requirements for
a Class A digital device.Operation of this equipment in a residential area is
likely to cause harmful interference to radio communications; in such events,
users are required to correct this interference.
16. This equipment is sold without a power cord. Users are advised to purchase a
CCC-certified power cord.
CAUTION: THE COMPUTER IS PROVIDED WITH A BATTERY-POWERED REAL-
TIME CLOCK CIRCUIT. THERE IS A DANGER OF EXPLOSION IF BATTERY IS
INCORRECTLY REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT
TYPE RECOMMENDED BY THE MANUFACTURER, DISCARD USED BATTERIES
ACCORDING TO THE MANUFACTURER'S INSTRUCTIONS.
The sound pressure level at the operator's position according to IEC 704-1:1982 is
no more than 70 dB (A).
DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech
disclaims all responsibility for the accuracy of any statements contained herein.

vii IDK-1107WP User Manual
Contents
Chapter 1 General Description and Features .....1
1.1 Display Characteristics.............................................................................. 2
1.2 Optical Characteristics .............................................................................. 2
1.3 Functional Block Diagram ......................................................................... 4
1.4 Absolute Maximum Ratings ...................................................................... 5
1.4.1 Absolute Ratings of TFT LCD Module .......................................... 5
1.4.2 Absolute Ratings of Environment.................................................. 5
1.5 Outline Dimension..................................................................................... 6
Chapter 2 Electrical Characteristics....................7
2.1 TFT LCD Module....................................................................................... 8
2.1.1 Power Specification ...................................................................... 8
Table 2.1: Power Specification .................................................... 8
2.1.2 Signal Electrical Characteristics.................................................... 8
Table 2.2: Signal Electrical Characteristics ................................. 8
2.2 Backlight Unit ............................................................................................ 9
2.2.1 Parameter Guideline for LED Backlight ........................................ 9
Table 2.3: Parameter Guideline for LED Backlight...................... 9
Chapter 3 Signal Characteristics.......................11
3.1 Signal Description ................................................................................... 12
3.1.1 Signal Description ....................................................................... 12
Table 3.1: Symbol Description................................................... 12
3.1.2 Backlight Signal Description ....................................................... 12
3.2 The Input Data Format ............................................................................ 13
3.2.1 SEL68 ......................................................................................... 13
3.3 Interface Timing ...................................................................................... 14
3.3.1 Timing Characteristics ................................................................ 14
Table 3.2: Timing Characteristics .............................................. 14
3.3.2 Input Timing Diagram.................................................................. 15
3.4 Power ON/OFF Sequence ...................................................................... 15
Chapter 4 Display Connector Definition ...........17
4.1 TFT LCD Signal (CN1): LVDS Connector............................................... 18
Table 4.1: TFT LCD Signal (CN1): LVDS Connector ................ 18
Table 4.2: Pin Assignment......................................................... 18
4.2 LED Backlight Unit (CN2): LED Driver Connector .................................. 18
Chapter 5 Touch Screen.....................................19
5.1 Touch Characteristics ............................................................................. 20
5.2 Optical Characteristics ............................................................................ 20
5.3 Environmental Characteristics ................................................................ 20
5.4 Mechanical Characteristics ..................................................................... 20
5.5 Electronic Characteristics........................................................................ 20
5.6 Mounting Notes ....................................................................................... 21
5.6.1 Mounting ..................................................................................... 21
5.6.2 Caution........................................................................................ 21

IDK-1107WP User Manual viii
5.6.3 Operating .................................................................................... 21
Chapter 6 Touch Controller ............................... 23
6.1 Touch Controller Characteristics............................................................. 24
6.2 Specifications.......................................................................................... 24
Table 6.1: Specifications ........................................................... 24
6.3 OS Driver Support................................................................................... 25
6.4 Circuit board dimension .......................................................................... 25
6.5 Interface .................................................................................................. 26
Appendix A Handling Precautions ....................... 27
A.1 Handling Precautions.............................................................................. 28

Chapter 1
1General Description
and Features

IDK-1107WP User Manual 2
This manual is for the 7” inch color TFT LCD module IDK-1107WP-50WVA1E which
is designed with a wide viewing angle, wide operating temperature, and long life LED
backlights which are well suited to display units for Industrial Applications. An LED
driving board for the backlight unit is included in this panel and the structure of the
LED unit is replaceable. IDK-1107WP-50WVA1E has a built in timing controller and
LVDS interface. The screen format is intended to support the SVGA (800(H) x
480(V)) screen and 16.2M (RGB 8-bits) or 262k colors (RGB 6-bits). IDK-1107WP-
50WVA1E is a RoHS compliant product.
1.1 Display Characteristics
The following table items are display characteristics under 25°C conditions.
1.2 Optical Characteristics
Optical characteristics are measured under stable conditions at 25°C (Room Temper-
ature):
Items Unit Specifications
Screen Diagonal [inch] 7.0 (177.8mm)
Active Area [mm] 152.40(H) x 91.44(V)
Pixels H x V 800x3(RGB) x 480
Pixel Pitch [mm] 0.1905 x 0.1905
Pixel Arrangement R.G.B. Vertical Stripe
Display Mode TN, Normally White
Nominal Input Voltage VDD [Volt] 3.3 typ
Typical Power Consumption [Watt] 3.56 typ.
Weight [Grams] 160 ± 10
Physical Size [mm] 187.6(W) x 126.64(H) x 12.36(D) typ.
Electrical Interface 1 channel LVDS
Surface Treatment Clear, Haze: <2%
Support Color 262K(6-bit) / 16.2M(8-bit)
Temperature Range
Operating
Storage (Non-Operating)
[°C]
[°C]
-20 to +70 (panel surface temperature)
-40 to +80
RoHS Compliance RoHS Compliance
Item Unit Conditions Min. Typ. Max. Note
White Luminance [cd/m2] IF= 80mA (center
point)
400 500 - 4
Uniformity % 5 Points 75% 1,5
Contrast Ratio 500 600 - 3
Response Time
[msec] Rising - 5 10
2[msec] Falling - 11 16
[msec] Rising + Falling - 16 26
Viewing Angle
[degree] Horizontal (Right) 60 70 -
6
[degree] CR 10 (Left) 60 70 -
[degree] Vertical (Upper) 50 60 -
[degree] CR 10 (Lower) 50 60 -

3 IDK-1107WP User Manual
Chapter 1 General Description and Features
Note1 These items are measured by BM-5A(TOPCON) or CA-1000 (MINOLTA) in
the dark room (no ambient light) After 5 minutes operation, the optical prop-
erties are measured at the center point of the LCD screen.
Note2 Definition of Response Time (White-Black)
Note3 Definition of Contrast Ratio
Contrast ratio is calculated with the following formula :
Contrast Ratio (CR)=(White) Luminance of ON ÷(Black) Luminance of OFF
Note4 Definition of Luminance
Measure the luminance of white state at center point.
Note5 Definition of Luminance Uniformity
Measured Maximum luminance [L(MAX)] and Minimum luminance [L(MIN)]
on the 9 points
Luminance Uniformity is calculated with the following formula:
 L =[ L(MIN) / L (MAX) ] X 100%
Note6 Definition of Viewing Angle
Color/Chromaticity Coor-
dinates (CIE 1931)
Red x
Typ
- 0.03
0.645
Typ
+0.03 1
Red y 0.341
Green x 0.312
Green y 0.625
Blue x 0.153
Blue y 0.053
White x 0.313
White y 0.329
Contrast Gamut % 72 - 1

IDK-1107WP User Manual 4
1.3 Functional Block Diagram
The following diagram shows the functional block of the 7 inches Color TFT-LCD
Module:

5 IDK-1107WP User Manual
Chapter 1 General Description and Features
1.4 Absolute Maximum Ratings
1.4.1 Absolute Ratings of TFT LCD Module
1.4.2 Absolute Ratings of Environment
Note 1: Maximum Wet-Bulb should be 38°C and no condensation.
Note 2: The module should be inspected after 1 hour storage in normal conditions
(15~35°C, 45~65%RH).
Item Symbol Min. Max. Unit
Power Supply Voltage Vcc -0.3 +4 [Volt]
Item Symbol Min. Max. Unit
Operating Temperature TOP -20 +70 [oC]
Operation Humidity HOP 85 [%RH]
Storage Temperature TST -40 +80 [oC]
Storage Humidity HST 85 [%RH]

IDK-1107WP User Manual 6
1.5 Dimensions
Black Printing area
R7,00(X4)
[Unit: mm]

Chapter 2
2Electrical
Characteristics

IDK-1107WP User Manual 8
2.1 TFT LCD Module
2.1.1 Power Specification
Note 1: The assembly should be always operated within the above ranges.
Note 2: Measurement condition:
Note 3: The specified power supply current is under the conditions at Vcc=3.3V,
Ta=25± 2oC, fv=60Hz, whereas a power dissipation check pattern below is
displayed.
2.1.2 Signal Electrical Characteristics
Table 2.1: Power Specification
Symbol Parameter Min. Typ. Max. Unit Remark
Vcc Power Supply Voltage 3.0 3.3 3.6 V
IRUSH Rush Current 1.5 A
Power Supply Current White 140 mA 3
Black 170 mA 3
Table 2.2: Signal Electrical Characteristics
Symbol Item Min. Typ. Max. Unit Remark
VTH Differential Input High Threshold - - 100 [mV] VCM=1.2V
VTL Differential Input Low Threshold -100 - - [mV] VCM=1.2V
VCM Common Mode Voltage 1.2 [V]

9 IDK-1107WP User Manual
Chapter 2 Electrical Characteristics
2.2 Backlight Unit
2.2.1 Parameter Guideline for LED Backlight
Following characteristics are measured under a stable condition using an inverter at
25°C (Room Temperature):
Note 1: LED current is measured by utilizing a high frequency current meter as
shown below:
Note 2: The lifetime of LED is defined as the time when it continues to operate under
the conditions at Ta=25±2°C and ILED=600ADC (LED forward current) until
the brightness becomes <=50% of its original value.
Table 2.3: Parameter Guideline for LED Backlight
Parameter Symbol Min. Typ. Max. Unit Remark
Converter Power Supply Voltage Vi10.8 12 13.2 V
Converter Power Supply Current Ii-0.25-A@Vi=12V
(Duty 100%)
Converter Power
Consumption
PLED -3-W@Vi=12V
(Duty 100%)
EN Control Level Backlight on 2.0 - 3.3 V
Backlight off 0 - 0.8 V
PWM Control Level
PWM High
Level
2.0 - 3.3 V
PWM Low
Level
0 - 0.15 V
PWM Control Duty Ratio 20 100 %
PWM Control Frequency fPWM 190 200 210 Hz
LED Life Time LL50,000 Hrs

IDK-1107WP User Manual 10

Chapter 3
3Signal Characteristics

IDK-1107WP User Manual 12
3.1 Signal Description
LVDS is a differential signal technology for LCD interface and high speed data trans-
fer device. The connector pin definition is as below.
Note: “Low” stands for 0V. “High” stands for 3.3V. “NC” stands for “No Connected.”
3.1.1 Signal Description
Note: User's connector Part No.: 076B20-0048RA-G4, Starconn, or equivalent.
3.1.2 Backlight Signal Description
Note: User's connector Part No.: LM123S004HTF13, 4 PIN, UNE.
Table 3.1: Symbol Description
Pin No. Symbol Description
1RX3+ LVDS differential data input Pair 3
2RX3-
3 NC No connected
4 FRC Dithering control setting
When FRC=H, the width of data input 8 bits
When FRC=L, the width of data input 6 bits and set Dx0 and Dx1
to logical low (Default pull low)
5 GND Ground
6RXC+ LVDS differential Clock input Pair
7RXC-
8 GND Ground
9RX2+ LVDS differential data input Pair 2
10 RX2-
11 GND Ground
12 RX1+ LVDS differential data input Pair 1
13 RX1-
14 GND Ground
15 RX0+ LVDS differential data input Pair 0
16 RX0-
17 LR Shift direction of Source Driver IC internal shift register is con-
trolled by this pin as show below:
LR=H SO1 ->…… SO1200 (Default pull high)
LR=L SO1200 ->…… SO1
18 UD Gate Driver Up/Down scan setting
When UD=H, reverse scan
When UD=L, normal scan (Default pull low)
19 VCC_IN Digital power supply (+3.3V)
20 VCC_IN Digital power supply (+3.3V)
Pin No. Symbol Description Note
1V
iConverter input voltage
2 ADJ Backlight adjust
3 EN Enable pin
4V
GND Converter ground
