Advantech HIT-W121 User manual

User Manual
HIT-W121
Computer

Copyright
The documentation and the software included with this product are copyrighted 2011
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. Information provided in this manual is intended to be accurate and reliable. How-
ever, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringe-
ments of the rights of third parties, which may result from its use.
Acknowledgements
Intel and Pentium are trademarks of Intel Corporation.
Microsoft Windows and MS-DOS are registered trademarks of Microsoft Corp.
All other product names or trademarks are properties of their respective owners.
Declaration of Conformity
FCC Class B
Note: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installa-
tion. This equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful inter-
ference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interfer-
ence to radio or television reception, which can be determined by turning the equip-
ment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
fReorient or relocate the receiving antenna.
fIncrease the separation between the equipment and receiver.
fConnect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
fConsult the dealer or an experienced radio/TV technician for help.
Warning! Any changes or modifications made to the equipment which are not
expressly approved by the relevant standards authority could void your
authority to operate the equipment.
Caution! Danger of explosion if battery is incorrectly replaced. Replace only with
the same or equivalent type recommended by the manufacturer. Dis-
pose of used batteries according to the manufacturer’s instructions.
Part No. 2008W15100 Edition 1
Printed in Taiwan March 2011
HIT-W121 User Manual ii

Technical Support and Assistance
1. Visit the Advantech web site at www.advantech.com/support where you can find
the latest information about the product.
2. Contact your distributor, sales representative, or Advantech's customer service
center for technical support if you need additional assistance. Please have the
following information ready before you call:
-Product name and serial number
-Description of your peripheral attachments
-Description of your software (operating system, version, application software,
etc)
-A complete description of the problem
-The exact wording of any error messages
Warning! 1. Packing: Please carry the unit with both hands; handle with care.
2. Maintenance: to properly maintain and clean the surfaces, use only
approved products or clean with a dry applicator.
iii HIT-W121 User Manual

Safety Instructions
1. Read these safety instructions carefully.
2. Keep this User Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a damp
cloth. Do not use liquid or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the equip-
ment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or letting
it fall may cause damage.
7. The openings on the enclosure are for air convection. Protect the equipment
from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting the
equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power source
to avoid damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electrical shock.
13. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
14. If one of the following situations arises, get the equipment checked by service
personnel:
a. The power cord or plug is damaged.
b. Liquid has penetrated the equipment.
c. The equipment has been exposed to moisture.
d. The equipment does not work well, or you cannot get it to work according to
the user's manual.
e. The equipment has been dropped and damaged.
f. The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE
STORAGE TEMPERATURE MAY GO BELOW -20° C (-4° F) OR ABOVE 60° C
(140° F). THIS COULD DAMAGE THE EQUIPMENT. THE EQUIPMENT
SHOULD BE IN A CONTROLLED ENVIRONMENT.
16. If your computer clock loses a significant amount of time or the BIOS configura-
tion resets to default, the battery has no power.
Caution! 1.
2.
3.
4.
HIT-W121 User Manual
Do not replace power adaptor yourself. Please contact a qualified
technician or your retail.
The computer is provided with a battery-powered real-time clock
circuit. There is a danger of explosion if battery is incorrectly
replaced. Replace only with same or equivalent type recom-
mended by the manufacture. Discard used batteries according to
the manufacturer’s instructions
Cleaning: During normal use of the HIT-W121 may become soiled
and should, therefore, be cleaned regularly. Agents: Alcohol or
water.
End of Product: for Environmental protection, please follow
national requirements to dispose of unit.
iv

17. CLASSIFICATION:
-Supplied by Class I adapter
-No applied parts
-Continuous operation
-No AP or APG category
18. Follow national requirements to dispose of unit.
19. Maintenance: To properly maintain and clean the surfaces, use only approved
products or clean with a dry cloth.
20. Contact information:
No.1, Alley 20, Lane 26, Rueiguang Road Neihu District, Taipei, Taiwan 114,
R.O.C
TEL: [phone]
21.
22. This equipment is not to be used as a life support system.
23. Accessory equipment connected to the analog and digital interfaces must be in
compliance with the respective nationally harmonized IEC standards (i.e. IEC
60950 for data processing equipment, IEC 60065 for video equipment, IEC
61010-1 for laboratory equipment, and IEC 60601-1 for medical equipment.)
Furthermore all configurations must comply with the system standard IEC
60601-1-1. Anyone who connects additional equipment to the signal input part
or signal output part is configuring a medical system, and is therefore, responsi-
ble that the system complies with the requirements of the system standard IEC
60601-1-1. The unit is for exclusive interconnection with IEC 60601-1 certified
equipment in the patient environment and IEC 60XXX certified equipment out-
side of the patient environment. If in doubt, consult the technical services
department or your local representative.
24. A user must not allow SIP/SOPs and the patient to come into contact with one
another at the same time.
25. The sound pressure level at the operator's position according to IEC 704-1:1982
is no more than 70dB (A).
DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech
disclaims all responsibility for the accuracy of any statements contained herein.
Note! Attention, please thoroughly consult the accompanying documentation.
Caution! This product: HIT-W121 is only used with the qualified & certificated
power adapter listed below:
Medical: SINPRO ELECTRONICS CO LTD, model: MPU50-107, Output:
16-21Vdc, 50W max (SET UP19Vdc, 2.63A).
ITE: FSP GROUP INC, model: FSP065-RAB, Output: 19Vdc, 3.42A.
ITE: FSP GROUP INC, model: FSP040-RAB, Output: 19Vdc, 2.1A .
ISO 7010-M002 : Refer to instruction manual/booklet
IEC 60878 : Follow operating instructions or Consult instructions for use
Environmental protection
xFollow national requirements to dispose of unit.
v HIT-W121 User Manual

HIT-W121 User Manual vi

Contents
Chapter 1 Introduction........................................ ...
1.1 Overview ... ................................................................................................... ...
1.2 System Configuration... ................................................................................. ..
Chapter 2 Hardware Description ......................... .
2.1 General Specifications ..................................................................................
2.2 Mechanical Specifications... ......................................................................... .
2.2.1 Mechanical Specifications (Terminal) ... ..........................................
2.2.2 Mechanical Drawing for Rear I/O... ..................................................
2.3 External View ... ........................................................................................... ..
2.3.1 Front View... ..................................................................................... .
2.3.2 Side & Bottom View ... ..................................................................... .
2.3.3 Rear View ........................................................................................ .
Chapter 3 Software Description......................... .
3.1 Windows XP Embedded Software Specifications... ...................................
Chapter 4 Design Requirements...................... ...
4.1 Environmental Specifications... ...................................................................
4.2 Reliability... ...................................................................................................
Annex
vii HIT-W121 User Manual

HIT-W121 User Manual viii

1
Chapter
1 Introduction
This chapter briefly introduces the
HIT-W121 product.
fOverview
fSystem Configuration

1.1 Overview
The HIT-W121 Healthcare Infotainment Terminal is Advantech's standard product
with a built-in Windows XP Embedded OS. In addition to providing hospital bedside
patient information, remote monitoring, and care functions, the CPU and the LAN-
enabled architecture of the HIT-W121 terminal also serves as an integrated hospital
gateway device. The HIT-W121 equipped with an Intel Atom 1.6GHz Dual-core pro-
cessor, 11.6" W Full-Flat touch screen, onboard isolated Giga-LAN port and COM port,
plus with other common IO such like USB and Line-in & MIC..etc. which
plays a key
role as a hospital bedside care and monitoring solution. It connects the service calls and
LED light signals of a hospital room through the LAN to the hospital.
HIT-W121 User Manual 2

HIT-W121 User Manual 4

2
Chapter
2 Hardware Description
This Chapter describes the hard-
ware features of the HIT-W121.
fGeneral Specifications
fMechanical Specifications f
External View

2.1 General Specifications
Operating Humidity: 20% to 90% (No Condensation)
Operating Atmospheric Pressure: 700 to 1060 hPa
Storage Humidity: 10% to 95% (No Condensation)
Storage Atmospheric Pressure: 700 to 1060 hPa
Transportation Temperature: Ͳ20кto 60к
Transportation Humidity: 10% to 95% (No Condensation)
Transportation Atmospheric Pressure: 700 to 1060 hPa

2.2 Mechanical Specifications
2.2.1 Mechanical Specifications (Terminal)
fSystem Dimensions: 302.5 (W) x 220.25 (H) x 43.00 (D) mm
fCarton Dimensions: 500 (W) x 385 (H) x 160
fMounting System: VESA 75*75mm standard mounting hole
f
Net Weight: 3 kg
VESA Mount: 75*75 mm or 100*100 mm
SCREWS: M4*10 mm
Caution Use suitable mounting apparatus to avoid risk of injury.
7 HIT-W121 User Manual

2.2.2 Mechanical Drawing for Rear I/O

2.3 External View
2.3.1 Front View
Front View (Terminal)
2.3.2 Side & Bottom View

2.3.3 Rear View
Rear View (Terminal)
9

3
Chapter
3 Software Description
This Chapter describes the soft-
ware features of the HIT-W121.
fWindows XP Embedded
Software Specifications
