AEC NS Series User manual

NS Series
Uninterruptible Power Supply
User Manual
NS1500/2200/3000-1T
SAVE THIS MANUAL
This manual contains important instructions that should be followed during
installation, operation, and storage of this UPS. Please read these
instructions carefully before installation and start-up of the UPS.

Rev. 11/2005
Table of Contents
1. Introduction ________________________________________________________1
2. Safety Instructions __________________________________________________4
3. Installation _________________________________________________________6
3.1 Unpacking_______________________________________________________6
3.2 Installation ______________________________________________________6
4. Operation __________________________________________________________7
4.1 Control Panel ____________________________________________________7
4.2 Turn On the UPS__________________________________________________7
4.3 Turn Off the UPS__________________________________________________7
4.4 LED Indicators ___________________________________________________8
4.5 Control Panel Buttons_____________________________________________8
4.6 Audible Alarms__________________________________________________10
4.7 Communications Interface ________________________________________11
5. Storage ___________________________________________________________15
6. Troubleshooting____________________________________________________16
6.1 General Problems _______________________________________________16
7. Specifications______________________________________________________18
FCC Part 15 NOTICE: Pursuant to section 15 of the FCC rules, this product has been tested and thereby
complies with the conditions of a Class B digital device, which have been established for offering
sufficient protection against dangerous interference for installation in a residential area. Installation and
use of the equipment should comply with the instructions provided in order to avoid such interference
due to the amount of radio frequency energy that is radiated and generated by the equipment. In spite
of this, we cannot assure that a certain amount of interference may not occur in some installations. If, by
turning on and off, it can be deduced that your radio or television reception is found to be influenced by
harmful interference from the equipment, it is recommended to use one of the following preventive
measures: Place the receiving antenna in a separate location or orientation. Ensure a greater distance is
achieved between the receiver and the equipment. Ensure that your equipment is connected to an outlet
on a separate circuit than the receiver. Contact a technician experienced with radio and TV or a dealer
for further assistance.

User Manual NS1500/2200/3000-1T
1. Introduction
The NS series UPS are advanced true On-Line uninterruptible power supplies
which produce reliable and pure sine-wave power to equipment, ranging from
computers and telecommunication systems to industrial automated equipment.
The On-Line design enables the UPS to adjust and filter power fluctuations
continuously and automatically under normal power conditions. During a power
failure, it can provide immediate back-up power from the batteries without any
interruption. When an overload or UPS malfunction occurs, the system will
automatically transfer to bypass mode and continue supplying output equipment
with utility power. When the overload is removed, the UPS will automatically
transfer back to inverter mode. Malfunctions may be resolved by restarting the
UPS. All the transferences are achieved within 4 ms without interruption.
Nomenclature
Front & Rear Panel of NS2200
1 Rev. 11/2005
Control Panel

User Manual NS1500/2200/3000-1T
Front & Rear Panel of NS1500
Rear Panel of NS1500
2 Rev. 11/2005
Control Panel

User Manual NS1500/2200/3000-1T
3 Rev. 11/2005
Standard Outlets of NS1500
Standard Outlets of NS2200/NS3000

User Manual NS1500/2200/3000-1T
4 Rev. 11/2005
2. Safety Instructions
This manual contains important instructions that should be followed during
installation, operation, maintenance, and storage of this UPS.
IMPORTANT SAFETY WARNINGS AND INFORMATION
WARNING! DO NOT USE FOR LIFE-SUPPORT EQUIPMENT
•DO NOT use this UPS for applications in which a malfunction or failure of the UPS
would cause failure or alter the performance of a life-support equipment.
WARNING! RISK OF ELECTRICAL SHOCK
•The outlet receptacles may be electrically live even when the UPS is disconnected
from the AC power source.
•This UPS contains potentially hazardous voltages. Do not open the UPS. There
are no user-serviceable parts inside.
•For service personnel, the battery and input circuits are not isolated. High voltage
may exist between the battery terminal and ground; use an electric meter to check
the voltage before beginning any repairs.
•Apart from battery replacement, all maintenance and service work should be
performed by qualified service personnel.
•Turn off the UPS and unplug it from the AC power source before battery replacement.
•Do not connect your UPS to an outlet that is not properly grounded.
•Do not remove the ground connection from the UPS’ power plug.
UPS LOCATION PLACEMENT AND CONNECTION
•Install the UPS in a clean indoor environment, away from excess moisture or heat,
dust or direct sunlight, flammable gases or fumes.
•Place and operate the UPS where the surrounding temperature range is from 32°F to
104°F (0 - 40°C). Optimal battery life is obtained if the temperature does not exceed
86°F (30°C).
•Keep the UPS on a flat, stable surface with adequate space around it for proper
ventilation. Do not block the vents.
•The UPS must be powered from a single phase grounded wall outlet; not a surge
protector or power strip. Avoid storage locations that are excessively humid, near
water, near heat sources or in direct sunlight.
•Do not plug appliances such as electric heaters, toasters and vacuum cleaners into
the UPS.

User Manual NS1500/2200/3000-1T
5 Rev. 11/2005
•Do not connect inductive loads, such as laser printers, to the UPS.
BATTERY WARNING
•This UPS contains a sealed lead-acid battery. DO NOT open the battery.
•DO NOT short or bridge the battery terminals with any object.
•Once the battery has reached the end of its life, ensure that they are properly
disposed. REFER TO YOUR LOCAL LAWS AND REGULATIONS FOR BATTERY
DISPOSAL REQUIREMENTS.

User Manual NS1500/2200/3000-1T
6 Rev. 11/2005
3. Installation
3.1 Unpacking
Examine the packing carton for damage. Notify the carrier immediately if damage is
present. Retain the package for future use.
3.2 Installation
1. Before making any connection and switching on the UPS, please check the
following conditions: (1) your AC power source should be 120 volts and 60Hz and
(2) all the equipment connected to the UPS does not exceed the maximum output
power of the UPS (as indicated on the UPS rear panel and specifications shown
in Section 7).
2. Connect the power cord of the UPS to a working, grounded AC wall socket.
3. Charge the batteries for 8 hours before use. When the power cord is plugged
into the wall outlet and AC power is available, the UPS will automatically recharge
its batteries. You may use the UPS immediately without recharging, but the
backup time may be less than the rating.
4. Connect the power cord of your equipment to the output receptacles of the UPS.
Check the type of power cord before
connecting the plug to the outlet. The
power cord plug should mate with the
outlet.

User Manual NS1500/2200/3000-1T
7 Rev. 11/2005
4. Operation
4.1 Control Panel
4.2 Turn On the UPS
1. Turn on the utility power to the UPS.
2. Turn on the input switch from the rear panel.
3. The UPS begins its auto-start sequence. This takes about ten seconds.
4. When the LINE and INVERTER LEDs are lit, the UPS will be ready for use.
4.3 Turn Off the UPS
1. Press ON/OFF button. The INVERTER LED will turn off and the BYPASS LED
turns on.
2. Turn off the input switch from the rear panel. All LEDs will turn off.

User Manual NS1500/2200/3000-1T
8 Rev. 11/2005
4.4 LED Indicators
FAULT – UPS is abnormal.
CHARGER – Charger is working.
PFC OL – Input current too large due to low input utility power.
GREEN – UPS is in green mode.
LINE – Utility power is normal. Input relay is in closed state.
BOOST – Booster is working. (During start up and DC mode)
INVERTER – Inverter is working.
BYPASS – Load is supplied with utility power when the input relay is in closed state.
LOAD 25/50/75/100% – Output load at 25, 50, 75, 100%.
BATTERY 25/50/75/100% – indicates the status of the batteries.
100% – Battery is fully charged.
75% – Battery is in normal voltage state.
50% – Battery is going to enter low voltage state.
25% – Battery is going to enter cut-off state.
The battery voltage level for each LED indication is as follows:
NS1500 NS2200 NS3000
100% >52.8V >79.2V >105.6V
75% 49.6V~52.8V 74.4V~79.2V 99.2V~105.6V
50% 44.0~49.6V 66.0~74.4V 88.0~99.2V
25% 42.0~44.0V 63.0~66.0V 84.0~88.0V
4.5 Control Panel Buttons
ON/OFF –
1. When utility power is available, the UPS can be turned on or shut off by
pressing the ON/OFF button.
2. When the UPS is operating normally in the inverter mode, pressing the
ON/OFF button will be change the UPS to BYPASS mode. The UPS will
stop supplying power to the connected equipment if the utility power is
unstable.
FUNCTION (TEST) –
While the UPS is working under normal status, pressing the Function Button will
test the batteries for 10 seconds. The batteries, instead of the utility power,
will supply power to all circuits. If the UPS switches back to Normal Mode after

User Manual NS1500/2200/3000-1T
9 Rev. 11/2005
10 seconds, then the batteries are good. If it does not, then the batteries need
to be replaced. Contact your sales representative for assistance.
SET – When the utility power is unstable, pressing this button will silence the audible
alarm. The low voltage warning cannot be silenced.
Special settings
1. By pressing the FUNCTION and SET buttons at the same time for 1 second, the
LED-indicators for BATTERY and LOAD will enter into a special setting mode
with a short audible beep.
2. The indicators represent bits for enabling/disabling green mode and changing
the output voltage of the UPS. Please see the table below.
LED Indicator Bit Name Bit Def.
BATTERY 100% Bit 7 Bit Status*
BATTERY 75% Bit 6 Not defined
BATTERY 50% Bit 5 Not defined
BATTERY 25% Bit 4 Not defined
LOAD 100% Bit 3 Green Mode
LOAD 75% Bit 2 Not defined
LOAD 50% Bit 1 O/P Voltage
LOAD 25% Bit 0 O/P Voltage
*Bit Status (Bit 7) Definitions
Bit Name Bit 7 - LED off (0), LED on (1)
Bit 3 0 - Enable Green Mode
1 - Disable Green Mode
Bit 1, Bit 0
00 - 100VAC output
01 - 110VAC output
10 - 115VAC output
11 - 120VAC output
WARNING!
NEVER change the output voltage settings when the UPS is
powering connected equipment.
3. When entering the special settings, the LED-indicators start from Bit 0 (LOAD
25%) and its status is displayed in Bit 7 (BATTERY 100%). Pressing the
FUNCTION button will scroll up one bit up to Bit 6 and then back to Bit 0.
4. After selecting the targeted Bit, press the SET button to change the status shown
in Bit 7.

User Manual NS1500/2200/3000-1T
10 Rev. 11/2005
5. When finished, press the FUNCTION and SET buttons at the same time for 1
second to exit the special functions settings. A short audible beep will sound
and return the control panel to its normal display.
6. New settings for Green Mode will take effect immediately. For safety
concerns, restart the UPS after changing the output voltage.
4.6 Audible Alarms
The audible alarms are designed into two segments. Each segment can exist alone or
at the same time as the other.
First segment:
Output Overload – long beep for few seconds with related LED.
Battery Low during discharging – short beep continuously.
System Abnormal – long beep for few seconds with related LED.
Utility Abnormal – two short beep continuously.
Charger Abnormal – long beep continuously.
Second segment:
UPS Overheating – 5 short beep continuously.
PFC Over Current – 6 short beep continuously.
Utility Voltage Error – 3 short beep continuously.
Utility Frequency Error – 4 short beep continuously.

User Manual NS1500/2200/3000-1T
11 Rev. 11/2005
4.7 Communications Interface
Protocol of communicating transmission as follows:
BAUD RATE - 2400 bps
DATA LENGTH - 8 bits
STOP BIT - 1 bit
PARITY – NONE
4.7.1 SPECIAL CABLE (UPSilon 2000)
4.7.2 PC CABLE
PIN# (UPS) PIN Definition
(UPS) PIN Definition (PC) PIN# (PC)
2 Transmitted data Received data 2
3 Received data Transmitted data 3
4 DTE Ready DTE Ready 4
5 Signal Ground Signal Ground 5
(A) RS232 ISOP interface Card
NOTE: An SNMP card will not work with the standard RS232 card which comes with the
NS series UPS. If you want to use an SNMP card, then the RS232 card must be
replaced by a RS232 ISOP card.
Software UPSilon 2000
9 pin Cables SPECIAL Cables
Non-standard
Supported MS-Windows 95/98/NT/2000/Me/XP
Novell NetWare v3.x, v4.x, v5.x Linux / FreeBSD
PIN# (UPS) PIN Definition
(UPS) PIN Definition (PC) PIN# (PC)
9 Transmitted data Received data 2
6 Received data Transmitted data 3
1 DTE Ready DTE Ready 4, 8
7 Signal Ground Signal Ground 5

User Manual NS1500/2200/3000-1T
12 Rev. 11/2005
(B) RS232 Interface Card
Software UPSilon 2000
9 pin Cables SPECIAL Cables
Non-standard PC Cables standard
Supported MS-Windows 95/98/NT/2000/Me/XP
Novell NetWare v3.x, v4.x, v5.x Linux / FreeBSD
J3
J4
J5
RS232 Card
J6
(C) Optional DB9 ISOP Interface Card

User Manual NS1500/2200/3000-1T
13 Rev. 11/2005
(A) PIN Definition of DB9 for Mechanical Dry Contact interface
(Optional DB9 ISOP interface card)
(B) SPECIAL CABLE (RUPS 2000)
Software RUPS2000
9 pin Cables SPECIAL Cables Non-standard
Supported Windows 3.1, 95, 98, NT, 2000, Me, XP
Novell NetWare 3.1x, 4.x, 5.x / MS-DOS / Linux
J3 FAULT
J6
J7
J5
J4 LOW BAT
DB9 ISOP
Card
J2 REMOTE
SHUTDOWN
J9
Function J# PIN of J# Definition
For LED PanelSELECT
LED/LCD
PANEL J9 For LCD Panel
PIN# of DB9 FUNCTION
1
2 BATTERY LOW
3
4
5
POWER
FAILURE
6
7 REMOTE SHUTDOWN UPS
8
9 FAULT
PIN# (UPS) PIN# (PC)
5 1
4, 7 3
2 8

User Manual NS1500/2200/3000-1T
14 Rev. 11/2005
(D) DB9 interface card
(A) Pin Definition of DB9 for NOVELL Interface: (Optional DB9 interface card)
PIN # of DB9 Function explanation I/O
2 POWER FAILURE - normally open state, will
become closed during active state. OUTPUT
3 POWER FAILURE - normally closed state, will
become open during active state. OUTPUT
4 Reference GND for pin 2, 3, and 5. OUTPUT
5 BATTERY LOW - normally open state, will
become closed during active state. OUTPUT
6 Remote shutdown UPS - keep this pin at high voltage (+5V~+12V). Needs 500 ms to shut
down UPS. Activates at battery mode. INPUT
8 FAULT - normally open state, will become
closed during UPS fault. OUTPUT
(B) SPECIAL CABLE (RUPS 2000)
PIN# (UPS) PIN# (PC)
5 1
4, 7 3
2 8

User Manual NS1500/2200/3000-1T
15 Rev. 11/2005
Software RUPS2000
9 pin Cables SPECIAL Cables Non-standard
Supported Windows95,98,NT,2000,ME,XP
Novell Net Ware3.1x,4.x,5.x /MS-DOS / Linux
J1
J2
J3
J4
J5
J6
DB9 Card
J7
J9 J10
Function J# PIN of J# Definition
FAULT J9 RY1 Normal open
LOW BAT J10 RY2 Normal close
J12
Function J# PIN of J# Definition
For LCD Panel
SELECT
LED/LCD PANEL J12 For LED Panel
5. Storage
1. Before storing, charge the batteries for at least 24 hours.
2. Be sure that the UPS is switched off and that no cable is connected to the
interface port.
3. Store the UPS in a dry location with a storage temperature within -4°F to 113°F
(-20°C to 45°C).
4. If the unit is to be stored for an extended period of time, then the batteries must be
recharged once every three months. Connect the UPS to an AC power source
for a minimum of 48 hours. If the batteries are not recharged, then it may suffer
permanent loss of capacity.

User Manual NS1500/2200/3000-1T
16 Rev. 11/2005
6. Troubleshooting
Please follow the guidelines below for trouble shootings in advance:
1. Check UPS input plug and wiring.
2. Check UPS input voltage.
When contacting service personnel, please have the following information:
1. Date of occurrence.
2. Model number and serial number.
3. Describe the problem in detail.
6.1 General Problems
Problem Possible Cause Action Code
Fuse at rear panel blown Replace fuse 0101
No AC input Check utility power 0102
UPS fault Call for service 0103
UPS will not turn on
when connected to
utility power Battery damaged Call service to replace battery 0104
Fuse at rear panel blown Replace fuse 0201
No AC input Check utility power 0202
UPS no reaction
while AC is
connected, yet DC
starts after pushing
power on/off switch UPS fault Call for service 0203
AC voltage or frequency
abnormal Check utility power 0301
UPS operates in DC
mode although utility
power exists AC detecting circuit failed Call for service 0302
UPS still in bypass
mode after disabling
green mode function
UPS still in POWER OFF
status
Press power ON/OFF button, an
audible beep will sound and the
UPS reverts to normal 0401
UPS is proceeding controlling
process Wait for a while to operate the UPS 0501
Buttons on front
panel don’t work Buttons damaged Call for service 0502
Press TEST key in
AC mode, but the
UPS goes back to
AC mode in less than
10 seconds
Internal batteries need
replacement Call for service to replace batteries 0601
UPS abnormal Call for service 0701
FAULT LED lit Output load abnormal or short
circuited Check load 0702
Batteries need replacement Call for service to replace
batteries 0801
Batteries not fully charged Charge the batteries 0802
UPS does not
provide expected
backup time
Battery charger damaged Replace charger and charge the
batteries, if necessary 0803
LINE LED flickers AC grounding wire abnormal Check grounding wire with assistance of power engineering
services 0901

User Manual NS1500/2200/3000-1T
17 Rev. 11/2005
Problem Possible Cause Action Code
After AC connected
to UPS, alarm
sounds short and
fast beeps and UPS
shut down
AC abnormal Check utility power 1001
AC noise or environment noise Check utility power or battery
wires 1101
After starting the
UPS, alarm sounds
short beeps
continuously, then
the UPS shuts down UPS PSDR PCB abnormal Call for service center 1102
Internal overheating Check the ventilation 1201
Five short beep
continuously Fan failure Call for service to replace the fan 1202
Four short beep
continuously PFC over load protect in action due to low AC input check input AC power or release some load 1301
AC input is abnormal due to
input voltage and UPS goes into
DC mode
Disconnect inputAC power and
check 1401
LINE LED not lit after
connection to utility
power and BOOST,
INV LED lit with three
short beep
continuously Input switch not turn on Turn on the input switch 1402

User Manual NS1500/2200/3000-1T
18 Rev. 11/2005
7. Specifications
The principal operating characteristics of the NS series UPS at 77°F (25°C) ambient
operating temperature are shown below.
MODEL NS1500-1T NS2200-1T NS3000-1T
INPUT
Voltage 80~138V 80~138V 80~138V
Frequency 50/60±5Hz
OUTPUT
Power 1500VA/1050W 2200VA/1540W 3000VA/2100W
Voltage
100V
110V
115V
120V
100V
110V
115V
120V
100V
110V
115V
120V
Frequency 50/60Hz (auto tracking)
Voltage regulation ±2%
Frequency stability ±0.5%
Transient Response
±
8% for 100% step-load response (linear load).
Distortion (THD) <3% at linear load
Overload Capacity 2 min. max. at 110%~145%. Immediate at 150%
Auto transfer to UPS when overload is removed.
Crest ratio 3:1
AC/AC Efficiency >86%
Transfer Time Zero for Line failures or recoveries.
<4 msec. for UPS to Bypass or reverse.
Green Mode Load under 30W Load under 60W Load under 90W
Audible Noise ≤45dBA
BATTERY
Voltage(Cells) 48V(4pcs) 72V(6pcs) 96V(8pcs)
Type/Weight 12V7AH(sealed lead-acid) / 5.5 lbs. (2.5kgs) / pc
Backup Time 6min. typical for full load.
15min. for half load.
Recharge Time 8 hours to 90% capacity.
CONTROL PANEL
Buttons ON/OFF, FUNCTION and SET
Indicators Fault, Charger, PFC OL, Green, Line, Boost, Inverter, Bypass,
Load 25/50/75/100%, Bat 25/50/75/100%.
Audible Alarms DC Mode, Low Battery, Voltage Error, Frequency Error, Charger Fail
High Temperature, Overload, Fault, PFC Overload.
COMMUNICATIONS INTERFACE
Standard RS232C
Optional SNMP, DB9 connector for digital signals.
MECHANICAL
Dimension (WHD) 5.9” x 10.4” x 17.7”
(150 x 265 x 450mm) 7.6” x 12.7” x 17.9” (193 x 323 x 455mm) 7.6” x 12.7” x 19.1” (193 x 323 x 485mm)
Weight 41.9 lbs. (19kgs) 67.2 lbs. (30.5kgs) 83.7 lbs. (38kgs)
ENVIRONMENT
Temperature 32°F~104°F (0°C~40°C) for operating
-4°F~113°F (-4°C~45°C) for storage
Humidity 0%~95% (non-condensing)
Note: Specifications subject to change without notice.
