AEG BHPV18 User manual

BHPV18
Original instructions

2
2
Important!
It is essential that you read the instructions in this manual before assembling,
operating and maintaining the product.
Subject to technical modifications.

33
15
12
11
10
13
14
9
4
1
5
6
7
8
2
3
ACTUAL
ACTUALAUTO TARGET
MANUAL
17
18
19
20
21
16
1. Handle
2. High volume hose
3. Deflator port
4. Digital gauge
5. Control dial
6. Digital gauge rotating ring
7. High pressure hose
8. High pressure deflator valve
9. LED light
10. Inflator port
11. Sports ball needle
12. Presta valve adapter
13. Tapered raft nozzle
14. High volume nozzle
15. Battery port
16. 12V car adaptor port
17. Power button
18. Mode button
19. LED light button
20. Start/Stop button
21. 12V car adaptor cable

4
4
10
9
13
6

55
Remove the battery pack before
starting any work on the machine
12
11
13
ACTUAL
ACTUALAUTO TARGET
MANUAL
8

6
6
ACTUAL
MANUAL
1
1
2
Remove the battery pack before
starting any work on the machine
click
1
2
When the inflator is connected to the 12 V
car adapter, lay the inflator flat and rotate
the digital gauge 180° for proper display.

77
78-100 %
33-54 %
55-77 %
10-32 %
<10 %

8
8
ACTUALMANUAL
1
2
AUTO TARGET AUTO TARGET ACTUALAUTO
1
1 2 3
2
3
5s
1s 5s 1s
1 2
Press the Power button to switch on the inflator. The default mode is
“high pressure inflation- manual”.
Press and hold the Start/Stop button to start inflating. Release the
Start/Stop button to stop inflating.
Rotate the Control dial clockwise to enter “high pressure inflation- auto” mode. Continue rotating the dial to set the target
pressure. Press the Start/Stop button to start inflating. Press the Start/Stop button again to stop inflating, otherwise the inflator
will automatically stop once the target pressure is met. To switch back to manual mode, rotate the dial counterclockwise.
Press and hold the Mode button to change the display unit. Press the Mode button to cycle through the list of pressure units.
Press and hold the Mode button to set the unit, otherwise the unit will be set after 3 seconds if there is no user input.
Press the Mode button to switch the mode to “high volume inflation”. Press the Start/
Stop button to start inflating. Press the Start/Stop button again to stop inflating.
Inflation will stop after running continuously for 15 minutes, to protect the inflator.

99
1
3
ACTUALMANUAL
4
2
1
2

10
10
1
3
ACTUALMANUAL
4
2
1
2

11 11
ACTUALMANUAL
2
3
23
1
3
2
1
1

12
12
ACTUALMANUAL
1
2
1
2
3

13 13

14
14
BATTERY AND CHARGER
Compatible battery pack
(not included)
Compatible charger
(not included)
L1820R
L1820S
L1825R
L1830R-X5
L1840R
L1850R
L1860R
L1860R-X5
L1890R
AL18G
BL1218
BLK1218
BL18DP2-X5
BL18DPS
BL18S
Use AEG 18V battery and charger only
Read all safety warnings, instructions, illustrations and specifications
provided with this power tool. Failure to follow all instructions listed below
may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
MULTI INFLATOR SAFETY WARNINGS
Risk of bursting. Do not preset the product resulting in its output pressure to be
greater than the marked maximum pressure of the item to be inflated. Do not
use at pressure greater than 150 PSI (10.3 bars).
Make sure the hose is free of obstructions or snags. Entangled or snarled hoses
can cause loss of balance or footing and may be damaged.
Never leave the product unattended with the hose still connected and operating.
To reduce the risk of electrical shock, do not put the product in water or other
liquid. Do not place or store an appliance where it can fall or be pulled into a
tub or sink.
Discontinue use if the product does not function properly or the hose leaks.
Do not attempt to pull or carry the product by the hose.
Store indoors.
Always disconnect the air and power supply before making adjustments and
servicing, or when not in use.
Inspect yearly for cracks, pin holes or other imperfections which could cause the
product to become unsafe. Never cut or drill holes in the product.
Know your inflator. Read operator’s manual carefully. Learn its applications and
limitations, as well as the specific potential hazards related to this tool. Following
this rule will reduce the risk of electric shock, fire, or serious injury.
To reduce the risk of electric shock, do not expose the product to rain. Store
indoors.
Never cut or drill holes in the product.
Use the product only for its intended use. Do not alter or modify the product
from the original design or function.
Do not attempt to modify this product or create accessories or attachments not
recommended for use with the product. Any such alteration or modification is
misuse and could result in a hazardous condition leading to possible serious
personal injury.
Always be aware that misuse and improper handling of the product can cause
injury to yourself and others.
Household use only.
Do not use the product as a breathing device.
Never direct a jet of compressed air toward people or animals. Take care not to
blow dust and dirt towards yourself or others. Following this rule will reduce the
risk of serious injury.
TECHNICAL DATA MULTI INFLATOR BHPV18
Rated voltage 12 V / 18 V
High pressure flow rate 16 L/min
High volume flow rate 525 L/min
High pressure hose length 63 cm
Low pressure hose length 39 cm
Maximum pressure 150 PSI, 10.3 BAR
Weight - not including battery pack 1.17 kg
Measured values determined according to EN 62841.
A-weighted sound pressure level LPA= 77.0 dB(A)
Uncertainty K 3 dB(A)
A-weighted sound power level LwA = 88.0 dB(A)
Uncertainty K 3 dB(A)
Wear ear protectors.
The vibration total values (triaxial vector sum) determined according to EN 62841:
Vibration emission value Ah≤ 2.5 m/s2
Uncertainty K 1.5 m/s2
WARNING
The vibration emission level given in this information sheet has been measured in accordance with a standardised test given in EN 62841 and may be used to compare
one tool with another. It may be used for a preliminary assessment of exposure. The declared vibration emission level represents the main applications of the tool.
However if the tool is used for dierent applications, with dierent accessories or poorly maintained, the vibration emission may dier. This may significantly increase
the exposure level over the total working period.
An estimation of the level of exposure to vibration should also take into account the times when the tool is switched o or when it is running but not actually doing
the job. This may significantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the eects of vibration such as: maintain the tool and the accessories, keep the hands warm,
organisation of work patterns.

15 15
Protect your lungs. Wear a face or dust mask if the operation is dusty. Following
this rule will reduce the risk of serious personal injury.
Do not use the product to spray chemicals. Your lungs can be damaged by
inhaling toxic fumes.
Risk of bursting. Carefully monitor objects during inflation.
To reduce the risk of over inflation, use a reliable pressure gauge periodically
during inflation. The pressure gauge on the inflator is for reference only and is
therefore not binding for exact values.
Allow the product to cool for ten (10) minutes after every ten (10) minutes of
continuous use. Never block the inflating or deflating outlets while operating.
Remove the battery pack before starting any work on the product.
Do not dispose of used battery packs in the household refuse or by
burning them. AEG Distributors oer to retrieve old batteries to protect our
environment.
Do not store the battery pack together with metal objects (short circuit
risk).
Use only System AEG chargers for charging System AEG battery packs. Do
not use battery packs from other systems.
Battery acid may leak from damaged batteries under extreme load or
extreme temperatures. In case of contact with battery acid wash it o
immediately with soap and water. In case of eye contact rinse thoroughly for
at least 10 minutes and immediately seek medical attention.
Ambient temperature range for tool during operation is between 0°C and 40°C.
Ambient temperature range for tool storage is between 0°C and 40°C.
The recommended ambient temperature range for the charging system during
charging is between 10°C and 38°C.
RESIDUAL RISKS
Even when the product is used as prescribed, it is still impossible to completely
eliminate certain residual risk factors. The operator should pay particular and
additional attention to these points in order to reduce the risk of serious personal
injury.
ŶUse the product only for its intended use. Do not alter or modify the product
from the original design or function.
ŶAlways be aware that misuse and improper handling of the product can
cause injury to yourself and others.
ŶNever leave the product unattended with the nozzle attached to the item
being inflated.
ŶDo not continue to use the product or nozzle which leaks air or does not
function properly.
ŶRisk of inflatable bursting.
–Do not operate the product to result in output pressure greater than
marked maximum pressure of item to be inflated.
–Carefully monitor objects during inflation to reduce the risk of over
inflation. Use a reliable pressure gauge periodically during inflation.
SPECIFIED CONDITIONS OF USE
The multi inflator may be used for the following applications.
ŶInflating high pressure items like motorbike/car/bicycle tyres and sport
equipment.
ŶInflating and deflating low pressure items like air mattresses, pool inflatables
and rafts.
Do not use the product for any other purpose.
BATTERIES
Battery packs which have not been used for some time should be recharged
before use.
Temperatures in excess of 50°C (122°F) reduce the performance of the battery
pack. Avoid extended exposure to heat or sunshine (risk of overheating).
The contacts of chargers and battery packs must be kept clean.
For an optimum life-time, the battery packs have to be fully charged, after used.
To obtain the longest possible battery life remove the battery pack from the
charger once it is fully charged.
For battery pack storage longer than 30 days:
s Store the battery pack where the temperature is below 27°C and away from
moisture.
s Store the battery packs in a 30% - 50% charged condition.
s Every six months of storage, charge the pack as normal.
ADDITIONAL BATTERY SAFETY WARNINGS
WARNING! To reduce the risk of fire, personal injury, and product damage
due to a short circuit, never immerse your tool, battery pack or charger in fluid or
allow a fluid to flow inside them. Corrosive or conductive fluids, such as seawater,
certain industrial chemicals, and bleach or bleach containing products, etc., can
cause a short circuit.
Ambient temperature range for battery during use is between 0°C and 40°C.
Ambient temperature range for battery storage is between 0°C and 27°C.
TRANSPORTING LITHIUM BATTERIES
Lithium-ion batteries are subject to the Dangerous Goods Legislation
requirements.
Transportation of those batteries has to be done in accordance with local,
national and international provisions and regulations.
ŶThe user can transport the batteries by road without further requirements.
ŶCommercial transport of lithium-ion batteries by third parties is subject
to Dangerous Goods regulations. Transport preparation and transport
are exclusively to be carried out by appropriately trained persons and the
process has to be accompanied by corresponding experts.
When transporting batteries:
ŶEnsure that battery contact terminals are protected and insulated to
prevent short circuit.
ŶEnsure that battery pack is secured against movement within packaging.
ŶDo not transport batteries that are cracked or leak.
Check with forwarding company for further advice.
BATTERY PACK PROTECTION
The battery pack has overload protection that protects it from being overloaded
and helps to ensure long life. Under extreme stress the battery electronics
switch o the product automatically. To restart, switch the product o and then
on again. If the product does not start up again, the battery pack may have
discharged completely. In this case it must be recharged in the battery charger.
THERMAL OVERLOAD PROTECTION
Overheated cells will reduce performance, run time and life. Overheating
can occur from battery packs being exposed to very hot environments or
from the tool they are powering being over-worked. The control electronics
will automatically shut down the battery pack to protect the cells which in
turn protects the electronics and motor within the tool. The battery pack will
automatically shut itself down again should the temperature condition remain
high when the trigger is pulled again. The system will continue to shut the
battery pack down until the temperature is returned to a safe operating level.
CURRENT OVERLOAD PROTECTION
The control electronics will instantly shut down the battery back when excessive
current draw is detected - protecting both the battery cells and the motor of the

16
16
tool. Releasing the trigger will reset the battery pack each time.
INDIVIDUAL CELL MONITORING
The control electronics constantly check each individual cell and automatically
adjust its charge and discharge requirements accordingly.
This system maximises individual cell life whilst ensuring that the battery pack is
delivering peak performance to the tool at all times.
MAINTENANCE
The ventilation slots of the product must be kept clear at all times.
Use only AEG accessories and AEG spare parts. Should components need to be
replaced which have not been described, please contact one of our AEG service
agents (see our list of guarantee/service addresses).
If needed, an exploded view of the tool can be ordered. Please state the Article
No. as well as the product type printed on the label and order the drawing at your
local service agents or directly at:
Techtronic Industries Australia Pty Ltd
PO Box 1065
Mount Waverley VIC 3149
Tel. no. 1300 234 797
Australia
Techtronic Industries N.Z. Limited
PO Box 12-806
Penrose AUCKLAND 1642
Tel. no. 0800 234 797(0800 AEGPWR)
New Zealand
SYMBOLS
Safety alert
VVolts
Direct current
Indoor use only
Regulatory Compliance Mark (RCM). Product meets
applicable regulatory requirements.
Please read the instructions carefully before starting the
product.
Do not dispose of electric tools together with household
waste material. Electric tools and electronic equipment
that have reached the end of their life must be collected
separately and returned to an environmentally compatible
recycling facility.

Techtronic Industries Australia Pty Ltd
31 Gilby Road, Mount Waverley,
VIC, 3149, Australia
Techtronic Industries N.Z. Limited
Unit C, 70 Business Parade South,
Highbrook, Auckland 2013, New Zealand
www.aegpowertools.com.au
www.aegpowertools.co.nz
20200605v1
AEG is a registered trade mark used under
license from AB Electrolux (publ).
© 2020 Techtronic Cordless GP.
