AETEK H40-022-91-120-A-V2 User manual

1. Install the PoE switch in a ventilated and dry place that is free of electromagnetic source, vibration, moisture, and dust.
2. Make sure the ventilation openings on the switch are not blocked.
3. Use CAT5 or 5e UTP/STP cables.
4. AC input (100~240V/AC, 50~60HZ)
5. IP67 rated housing
6. Although housing is IP67 rating , this is not suitable for water jets.
IMPORTANT:
* 1x PoE switch * 1x Quick Installation Guide
* 1x T25 L-wrench
PACKAGE CONTENTS
H40-022-91-120-A-V2
Quick Installation Guide
Outdoor PoE Switch
Link/Act LED PoE LED
8mm
AC Power Cable
CONNECTION
P/N: A625015301G
AC Power Cable Spec.
Wire Size 10~18AWG
Wire Strip Length 8mm
DC
Input
100~240VAC
Power Input
GbE RJ45
PoE Ports GbE SFP Ports
2. Install the cable glands
LAN Cable
4. Tighten the screws5. Fixed pendant wall mount6. Install dome camera
3. Connect the cables1. Loosen the screws
Power cord & Lan cable
(M8x27mm+Spring Washer
+Flat Washer screws) x4pcs
+ +
Use the included M10 hex socket screws to secure the
power box to a pole-mount or corner mount bracket.
3/4” conduit
M8
INSTALLATION
Outdoor PoE switch
H40/H42/H80 Series:
The mounting hole denition is illustrated below. The same
mounting hole pattern apply to all pole-mount and corner-
mount brackets.
AETEK INC.
6F, No.192-1, Lien-Cheng Rd., Chung-Ho, New Taipei City, 235, Taiwan, R.O.C.
|T:+886-2-82452822|W: www.aetektec.com|E:[email protected]
All specications are subject to change without noice.
Copyright © 2022 AETEK INC. All rights reserved.
The cabinet must be grounded using a ground wire between the ground screw and earth ground.
LED DEFINITIONS
Power
PW1/PW2
Green ON Power is on and normal.
SFP port
Green
Green ON Fiber is aeeached.
Grren Flashing Data is being transmitted / received.
LAN ports
Green
Green ON TX link is detected.
Grren Flashing Data is being transmitted or received.
PoE ports
Amber
Amber ON PSE is activated and PD is detected.
Amber OFF PoE OFF
IMPORTANT:
