7693A Automatic Liquid Sampler Supplies
uick Reference Guide
Agilent Supplies for Agilent Instruments
Agilent Technologies is committed to optimizing
your laboratory's productivity. As part of this
long-term committment, we have designed our
supplies to match our instruments precisely.
You get consistent results and optimum
instrument performance, all day, every day.
For your convenience, the reference list below
contains the most commonly ordered supplies
and parts.
Continued on the next page.
Description Part No. Notes
7693A Replacement Parts and Supplies
Gripper finger caps, 16/pk G4514-60710 eed occasional replacement;
keep a spare set on hand.
Injector mounting post G4513-20561 eeded if one injector is to be moved
between the front inlet and the rear inlet.
Dual parking post for autosampler 05890-61525 Provides a convenient place to park
your injector while performing
inlet maintenance.
eedle support insert, standard G4513-40525 When working frequently with dirty
samples, replace this part regularly to
maintain smooth syringe movement.
eedle support insert, on-column G4513-40529
7693A vial trays with colored labels, 3/pk with 12 label tags (4 colors) G4525A Extra set is very useful for working
on the bench and then exchanging with
racks on autosampler
Vial rack label kit G4525-60701
Vial rack labels kit, red, 3/pk G4525-60702
Vial rack labels kit, yellow, 3/pk G4525-60703
Vial rack labels kit, green, 3/pk G4525-60704
ALS main cable assembly G4514-60610 Provides added convenience in moving
injector between front and rear inlets;
eliminates unplugging and replugging
cable in back of instrument.
Agilent Blue Line Autosampler Syringes for 7693A ALS
Syringe, 1 µL, fixed needle, 23/42/Cone G4513-80229 Plunger in needle design provides
accuracy for small volume injections.
Syringe, 5 µL, fixed needle, 23-26s/42/HP G4513-80206 Fitted plunger, fixed tapered needle.
Syringe, 5 µL, on-column, removable needle, barrel only G4513-80207 For on-column injections; requires needle.
Replacement needle, 0.32 mm on-column, 5 µL syringe, 3/pk G4513-80214
Replacement needle, 0.25 mm on-column, 5 µL syringe, 3/pk G4513-80217

2
Amber screw top vials with write-on spot, 100/pk 5182-0716 Amber for light-sensitive samples.
Blue screw caps, PTFE/red silicone septa, 100/pk 5182-0717
Clear, silanized screw top vials, 100/pk 5183-2070 Silanized for active or "sticky" compounds.
2 mL Wide Opening Crimp Top Glass Vials
on-assembled crimp top convenience pack, 500/pk
Includes clear crimp top vials, silver aluminum crimp caps,
PTFE/red rubber septa in 6 drawer storage box
5181-3400
Clear crimp top vials, 100/pk 5181-3375
Amber crimp top vials with write-on spot, 100/pk 5181-3376 Amber for light-sensitive samples.
Silver-tone aluminum crimp caps, PTFE/red rubber septa, 100/pk 5181-1210
Syringe, 10 µL, PTFE tip, fixed needle, 23-26/42/HP G4513-80203 Recommended for best precision and
accuracy; PTFE-tipped plunger gives
lowest carryover.
Syringe, 10 µL, fixed needle, 23-26s/42/HP G4513-80204 For general use; fitted plunger and
tapered needle
Syringe, 10 µL, PTFE tip, removable needle, 23-26/42/HP G4513-80233 Both plunger and needle can be replaced
for extended use.
Replacement needle for 10 µL syringe, 23-26/42/HP, 3/pk G4513-80231
Syringe, 25 µL, PTFE tip, fixed needle, 23/42/HP G4513-80228
Syringe, 50 µL, PTFE tip, fixed needle, 23/42/HP G4513-80221
Syringe, 100 µL PTFE tip, fixed needle, 23-26s/42/HP G4513-80222
Agilent Blue Line Syringes for Enhanced Sample Handling Carriage (G4521A)
Syringe, 250 µL, PTFE tip, fixed needle, 23/42/HP G4513-60560 250 µL size is more precise at lower
volumes and more versatile.
Syringe, 500 µL, PTFE tip, fixed needle, 23/42/HP G4513-60561 500 µL size is more popular; dispenses
solvent quicker.
For a complete listing of syringes, replacement needles, and replacement PTFE tip plungers,
go to www.agilent.com/chem/syringes
2 mL Wide Opening Snap Top Glass Vials
Pre-assembled clear screw top vial convenience pack, 100/pk
Includes clear screw top vials, blue screw caps, PTFE/red silicone septa
5182-0553
Pre-assembled amber screw top vial convenience pack, 100/pk
Includes amber screw top vials with write-on spot, green screw caps,
PTFE/red silicone septa
5182-0554 Amber for light-sensitive samples.
Pre-assembled clear screw top vial convenience pack, 100/pk
Includes clear screw top vials, blue screw caps, PTFE/silicone septa
5182-0557
on-assembled screw top vial convenience pack, 500/pk
Includes clear screw top vials, blue screw caps, PTFE/silicone septa
in a 6 drawer storage box
5182-0734
on-assembled screw top vial convenience pack, 500/pk
Includes clear screw top vials with write-on spot, blue screw caps,
PTFE/red silicone rubber septa in 6 drawer storage box
5182-0867
Clear screw top vials, 100/pk 5182-0714
Agilent Blue Line Autosampler Syringes for 7693A ALS
Description Part No. Notes
Crimping and Decapping Tools
Electronic crimper, 11 mm, with 4.8v rechargeable battery pack and charger 5062-0207 Ideal for preparing large runs of samples
in crimp vials.
Electronic decapper, 11 mm, with 4.8v rechargeable battery pack and charger 5062-0209 Ideal for sample recovery or recycling
of large quantities of vials.
Manual crimper, 11 mm 8710-0979
Manual decapper, 11 mm 5181-1213
Continued on the next page.

To learn more about Agilent's complete offering
of parts and supplies for your 7693A ALS:
Visit www.agilent.com/chem/7693Asupplies
Contact your local Agilent Representative
Contact your local Agilent Authorized Distributor
Visit www.agilent.com/chem/contactus
to find an Agilent customer center in your country
Agilent Technologies shall not be liable for errors contained
herein or for incidental or consequential damages in
connection with the furnishing, performance, or use of this
material. Information, description, and specifications in this
publication are subject to change without notice.
© Agilent Technologies, Inc. 2009
Printed in U.S.A. August, 2009
5990-4586E
2 mL Wide Opening Snap Top Glass Vials
on-assembled snap top vial convenience pack, 500/pk
Includes clear snap top vials, clear polypropylene snap caps,
PTFE/red silicone septa in a 6 drawer storage box
5182-0547 Crimp caps may also be used on
snap cap vials.
Clear crimp/snap top vials, 100/pk 5182-0544
Amber crimp/snap top vials with write-on spot, 100/pk 5182-0545 Amber for light-sensitive samples.
Green polyethylene caps, clear PTFE/red silicone septa, 100/pk 5182-3457
Microvolume Inserts for Wide Opening Vials
250 µL glass inserts with polymer feet and mandrel interior, 100/pk 5181-1270
250 µL pulled-point glass inserts, 100/pk 5183-2085
400 µL glass flat bottom inserts, 500/pk 5181-3377
Shell Vials
Clear, glass shell vials and caps, 200/pk 5190-1570 ew economical choice for use with
7693A autosamplers.
Wash Vials (also for standards, diluents)
4 mL wash vials with fill markings and caps, 25/pk 5182-0551 Autosampler holds 15 wash vials, but unit
is shipped with a starter pack of 10.
Diffusion caps for 4 mL vials, 12/pk 07673-40180 Eliminates septum coring
with repeated entry.
Septa for 4 mL vials, 144/pk 9301-1031
Vial Accessories
Rack for 12 mm, 2 mL vials, 5/pk 9301-0722 Holds 50 vials
Barcode labels numbered 1 to 1000, 1000/pk 5958-9450
