Agilent Technologies E2960B Series Installation instructions

Agilent E2960B Series
Hardware and Probing Guide


Notices
© Agilent Technologies, Inc. 2008-2009
Nopartofthismanual maybereproduced
inany form or byany means (including
electronic storage and retrieval or transla-
tion into a foreign language) without prior
agreement andwritten consent fromAgi-
lentTechnologies,Inc.asgovernedby
United States and international copyright
laws.
PrintHistory
E2960-97001, October 2009
E2960-97000, September 2009
Trademarks
Windows2000®,WindowsXP®,and
Microsoft .NET Framework 1.1® are U.S.
registered trademarks of Microsoft Corpo-
ration.
Manual Part Number
E2960-97001
Edition
Sixth edition, February 2015
Available in electronic format only
Agilent Technologies, Inc.
1900 Garden of the Gods Road
Colorado Springs, CO 80907 USA
Warranty
The material contained in this docu-
ment is provided “as is,”andis sub-
ject to being changed, without notice,
in future editions. Further, to the max-
imum extent permitted by applicable
law, Agilent disclaims all warranties,
either express or implied, with regard
to this manual and any information
containedherein, includingbut not
limited to the implied warrantiesof
merchantability and fitness for a par-
ticular purpose. Agilent shall not be
liable for errors or for incidental or
consequential damages in connection
with the furnishing, use, or perfor-
mance of this document or of any
information contained herein. Should
Agilent and the user have a separate
written agreement with warranty
terms covering the material in this
document that conflict with these
terms, the warranty terms in the sep-
arate agreement shall control.
Technology Licenses
The hardware and/or software described in
thisdocument are furnished undera
license and may beused or copied only in
accordance with the terms of such license.
Restricted Rights Legend
Ifsoftware is for use inthe performance of
aU.S.Government prime contract orsub-
contract,Softwareis delivered and
licensedas“Commercialcomputer soft-
ware” as defined in DFAR 252.227-7014
(June 1995), or as a “commercial item” as
definedinFAR 2.101(a) or as “Restricted
computer software” as defined in FAR
52.227-19 (June 1987) or any equivalent
agency regulationor contract clause. Use,
duplicationor disclosureofSoftwareis
subject to Agilent Technologies’ standard
commercial license terms, and non-DOD
Departments and Agencies of the U.S.Gov-
ernment willreceive no greaterthan
Restricted Rights as defined in FAR
52.227-19(c)(1-2) (June 1987). U.S. Govern-
ment users will receive no greater than
Limited Rights as defined in FAR 52.227-14
(June 1987) or DFAR 252.227-7015 (b)(2)
(November 1995), as applicable in any
technical data.
Safety Notices
A CAUTION noticedenotes ahaz-
ard. It calls attention to anoperat-
ing procedure, practice, or the like
that, if not correctly performed or
adhered to, could result in damage
to the product or loss of important
data. Do not proceed beyond a
CAUTION notice until the indicated
conditions are fully understood and
met.
AWARNINGnoticedenotesa
hazard. It calls attention to an
operating procedure, practice, or
the like that, if not correctly per-
formed or adhered to, could result
in personal injury or death. Do not
proceed beyond a WARNING
notice until the indicated condi-
tionsare fully understoodandmet.
CAUTION
WARNING

Safety Summary
Safety Symbols
on Instruments
General Safety
Precautions
The following general safety precautions must be observed during all
phases of operation of this instrument. Failure to comply with these
precautions or with specific warnings elsewhere in this manual violates
safety standards of design, manufacture, and intended use of the
instrument.
Agilent Technologies Inc. assumes no liability for the customer's failure to
comply with these requirements.
Before operation, review the instrument and manual for safety markings
and instructions. You must follow these to ensure safe operation and to
maintain the instrument in safe condition.
General This product is a Safety Class 1 instrument (provided with a protective
earth terminal). The protective features of this product may be impaired if
it is used in a manner not specified in the operation instructions.
All Light Emitting Diodes (LEDs) used in this product are Class 1 LEDs as
per IEC 60825-1.
Environment
Conditions
This instrument is intended for indoor use in an installation category II,
pollution degree 2 environment. It is designed to operate at a maximum
relative humidity of 95% and at altitudes of up to 2000 meters.
Safety Symbol Description
Indicates warningorcaution.Ifyou see this symbol on a product, you must
refertothe manualsforspecific WarningorCaution informationto avoid
personal injury or damage to the product.
Frame or chassis ground terminal. Typically connects to the equipment's
metal frame.
Indicates hazardous voltages and potential for electrical shock.
Indicates that antistatic precautions should be taken.
Indicateshot surface. Please donottouch.
Indicates laser radiation turned on.
CSAisthe Canadiancertification marktodemonstratecompliancewiththe
Safety requirements.
CE compliance marking to the EU Safety and EMC Directives.
ISM GRP-1A classification according to the international EMC standard.
ICES/NMB-001compliance markingtotheCanadianEMC standard.
Agilent E2960B Series Hardware and Probing Guide 3

Before Applying
Power
Ground the
Instrument
Do Not Operate in
an Explosive
Atmosphere
Do Not Remove
the Instrument
Cover
Environmental
Information
Refer to the specifications tables for the ac mains voltage requirements
and ambient operating temperature range.
Verify that all safety precautions are taken. The power cable inlet of the
instrument serves as a device to disconnect from the mains in case of
hazard. The instrument must be positioned so that the operator can easily
access the power cable inlet. When the instrument is rack mounted the
rack must be provided with an easily accessible mains switch.
To minimize shock hazard, the instrument chassis and cover must be
connected to an electrical protective earth ground. The instrument must be
connected to the ac power mains through a grounded power cable, with
the ground wire firmly connected to an electrical ground (safety ground)
at the power outlet. Any interruption of the protective (grounding)
conductor or disconnection of the protective earth terminal will cause a
potential shock hazard that could result in personal injury.
Do not operate the instrument in the presence of flammable gases or
fumes.
Operating personnel must not remove instrument covers. Component
replacement and internal adjustments must be made only by qualified
personnel.
Instruments that appear damaged or defective should be made inoperative
and secured against unintended operation until they can be repaired by
qualified service personnel.
4 Agilent E2960B Series Hardware and Probing Guide

Contents
Safety Summary 3
1 N5306A I/O Module
2 N5322A ExtendedInterface Module
3 N5309A Exerciser Card and Extension Card
N5309A Exerciser Card 16
N5309-66417 ExerciserExtension Card 20
4 N5323A Jammer Card
5 N5315 Solid Slot Interposer Card
6 N5316A Backplane Board for PCIe
7 Soft Touch Midbus Probes
Midbus2.0(FullSize)Probes 40
Overview and Configuration Support 41
Installation Instructions 41
Characteristics 42
Mechanical Design Considerations for Midbus 2.0 Probes 43
Electrical Design Considerations for the Midbus 2.0 Probes 50
N5328A Half Size Midbus Probe 62
SettingUp the Probe 64
FootprintPinoutoftheProbe
64
Mechanical Dimensions 65
Electrical Design Considerations for Midbus Probes 69
Midbus PlacementWithin SystemTopology 69
Load Model 71
Reference Clock Probe 72
Mechanical Design Considerations for the Reference Clock Probe 72
Electrical Design Considerations for the Reference Clock Probe 74
Agilent E2960B Series Hardware and Probing Guide 5

8 N4241F Flying Lead Probe
Resistor Dimensions 78
Lane Mapping 80
Important Points About Using N4241F 81
9 N4241Z ZIF Flying Lead Probe
N5426A ZIF Tip 86
N5426A ZIF Tip Dimensions 87
N5451ALongWired ZIF Tip 88
N5451A Long Wired ZIF Tip Dimensions 89
Trimming Log Wired ZIF Tip Resistor Leads 89
Soldering Resistors to Long Wired ZIF Tips 91
BreakingOff LongWiredZIF TipsfromPackagingStrip 94
ZIFFlyingLeadConnectiontoDUT 95
ZIF Tip Connection to Flying Lead 95
Soldering the ZIF Tip or Long Wired ZIF Tip into a DUT 96
Lane Mapping 102
Important Points About Using N4241Z 103
Index
6 Agilent E2960B Series Hardware and Probing Guide

Agilent E2960B Series
Hardware and Probing Guide
1
N5306A I/O Module
This chapter provides information on the N5306A I/O module used for
PCIe.
Trigger In/Out
LED Display Analyzer Probe
Lane Status
Inter-Module (x16)
Ref Clk Output
10MH z Output
Self-Test Port
Figure1 N5306A I/O Module
As shown in Figure 1, the N5306A I/O module has the following
components:
• LED Display— This component is used to display the diagnostic
information when fatal faults are discovered, and to indicate progress
during the bootstrap. If everything is working properly, then this
component displays the module number, such as 103.
• 10 MHz Output— This component is a reference clock, which is used
for generating timestamps in Protocol Analyzer. This component
delievers 10 MHz output.
• Analyzer Probe— This component is used to connect the midbus probe
module connector with N5306A and N5307A (slot interposer card).
For complete information on midbus probe, refer to Agilent Soft Touch
Midbus Probe, User's Guide.
7


1
N5306A I/O Module
For information on plugging midbus probe module connector with
N5306A Analyzer Probe, refer to Agilent System Protocol Tester,
Installation Guide.
• Self-Test Port— This component is a loopback board, and is used to
connect the midbus probe tip with N5306A. The one side of this
loopback board has a retainer for the probe, and the other side has the
connector for the self-test port. To verify if N5306A I/O module and
midbus probe are working properly, plug in this loopback board into the
self-test port and then watch the lane status.
• Lane Status— This component has 18 LED bullets that displays the
status of the lane by using different colored bullets. Two bullets,
labelled A and B, indicate global status information. Different colors
used to indicate global status information are:
• Grey — This colored bullet means system is not configured.
• Red — This colored bullet means the speed is not detected or the
system is not configured.
• Yellow — This colored bullet represents speed of 2.5 Gb/s
• Green — This colored bullet represents speed of 5 Gb/s.
Other 16 LED bullets, labelled 0 to 15, indicate the status of each lane.
These bullets are:
• Red — This colored bullets means that there are no signals or the
lane is electrically idle.
• Orange — This colored bullet marks the presence of invalid signals
on the lane.
• Green — This colored bullet means that the data on the lane is
deskewed.
• Blinking Green — This colored bullet means that the data on the
lane is skewed. It corresponds to yellow in the Port Overview pane
in the Protocol Analyzer GUI.
• Grey — This colored bullet means that the lane is not configured. For
example, if you are using x4 link width, then first four bullets of the
lane would be green and rest of the bullets would be grey colored
bullets.
• Inter- Module (x16) — This component is used to share information with
another N5306A I/O module in the same chassis. The features of this
component are not yet supported by the System Protocol Tester
platform.
• Ref Clk Output— This components is a reference clock, which N5306A
use to process the data internally. This components delivers 100 MHz
output.
• Trigger In/Out— This component is used to listen to external trigger in
from a different device or send external trigger out to another device.
8 Agilent E2960B Series Hardware and Probing Guide

N5306A I/O Module 1
The following figure shows meaning of the pins of the Trigger In/Out
component.
Figure2 Trigger In/Out Pins
The following are some important points about the Trigger In/Out
component:
• The outputs circuitry is designed to work into open in order to fit to
the LA input that is typically in the K-ohms range.
• Maximum trigger input voltage should not exceed 3.3 V.
• Trigger Out and 10 MHz Out have nominal output level of 2.0 V after
20 ns minimum pulse width.
• Minimum Trigger In duration is ~20 ns.
Use trigger cable to send or receive external trigger in and out events.
Do not directly touch any component on the I/O module. It may be hot.
Componentson the I/O module are sensitivetothe staticelectricity.Therefore, take
necessary anti-static precautions, such as wear a grounded wrist strap, to minimize
the possibility of electrostatic damage.
Agilent E2960B Series Hardware and Probing Guide 9
NOTE
WARNING
CAUTION

1
N5306A I/O Module
10 Agilent E2960B Series Hardware and Probing Guide

Lane Status Analyzer Probe
Agilent E2960B Series
Hardware and Probing Guide
2
N5322A Extended Interface Module
This chapter provides information on the N5322A extended interface
module used for PCIe.
The N5322A extended interface module is used with the N5306A module
to capture the traffic of DUTs that use PCIe power management (L0s, L1,
L2/L3).
The following figure shows the N5322A extended interface module.
Ref Clk Input
To N5306A
Figure3 N5322A Extended Interface Module
As shown in the above figure, the N5322A module has the following
components:
• Ref Clk Input— This component is used as an alternate 100 MHz
reference clock input.
11


2
N5322A ExtendedInterface Module
• Analyzer Probe— This component is used to connect the N5322A
module with the following probe types:
• N4241A Straight
• N4242A Swizzled
• N4243A Split Cable
• N5315A Solid Slot Interposer
• N5317A PCIe Gen1 Probe Connection Cable
• N4241F Flying Leads
• To N5306A— This component is used to connect N5322A with N5306A
using the Extended Interface Module interconnect cable.
Thefollowing figure shows how you can use N5322A and N5306A
modules, and a probe type together.
N5306A module
Figure4 N5322A paired with N5306A
N5322AandN5306Amodulesshouldbeusedasapair.Thatis:
• Use 1 N5306A and 1 N5322A for a x8 setup.
• Use 2 N5306A and 2 N5322A for a x16 setup.
N5322A Module
N4241A Straight
NOTE
12 Agilent E2960B Series Hardware and Probing Guide

N5322A ExtendedInterface Module 2
• Lane Status— This component has 18 LEDs that display the status of
the lane by using different colors. Two LEDs, labelled A and B, indicate
global status information. Different colors used to indicate global status
information are:
• Green — This colored LED means that N5322A and N5306A modules
are connected, the Port Overview pane in Protocol Analyzer is
showing Connected, and also the check box for N5322A in the
Hardware Setup dialog box is selected.
• Yellow — This colored LED means that N5322A and N5306A modules
are connected, the Port Overview pane in Protocol Analyzer is also
showing Connected, but the check box for N5322A in the Hardware
Setup dialog box is not selected.
• Red — This colored LED means that N5322A is not connected with
N5306A.
Other 16 LEDs, labelled 0 to 15, indicate the status of each lane. These
LEDs are:
• Green — This colored LED means that the lane is not in electrical
idle state.
• Grey — This colored LED means that the lane is not configured. For
example, if you are using x4 link width, then first four bullets of the
lane would be green and rest of the bullets would be grey colored
bullets.
• Red — This colored LED means there are no signals or the lane is
electrically idle.
Do not directly touch any component on the N5322A module. It may be hot.
Components on the N5322A module are sensitive to the static electricity. Therefore,
take necessary anti-static precautions, such as wear a grounded wrist strap, to
minimize the possibility of electrostatic damage.
Agilent E2960B Series Hardware and Probing Guide 13
WARNING
CAUTION

2
N5322A ExtendedInterface Module
14 Agilent E2960B Series Hardware and Probing Guide

Agilent E2960B Series
Hardware and Probing Guide
3
N5309A Exerciser Card and Extension
Card
N5309AExerciser Card 16
N5309-66417 Exerciser Extension Card 20
This chapter provides information on the N5309A exerciser card and the
N5309-66417 exerciser extension card used for PCIe.
15


3
N5309A Exerciser Card and Extension Card
N5309A Exerciser Card
The following figure displays the N5309A exerciser card.
Edge Connector
Figure5 N5309A Exerciser Card
Components of the N5309A exerciser card are described below:
• Ref Clk Input— This component can be used as an alternative 100 MHz
reference clock input.
• LED Display — This component displays the module number, such as
module number 10003, to which N5309A is configured. The module
number displayed here scrolls horizontally from right to left.
• Status LEDs (on board)— This component has the following LEDs to
display the status information.
LED Display
16 Agilent E2960B Series Hardware and Probing Guide

N5309A Exerciser Card and Extension Card
3
Figure6 N5309A Exerciser card -Status LEDs
• First 16 LEDs displays the status of the link.
• One LED, separately highlighted on the right, shows the power status
of the board.
• Last three LEDs shows the power status of DUT.
• Edge Connector— This component is used to connect N5308A with a
PCIe Connector on the backplane board, or with a system.
• Trigger Connector— This component is a six-pin header, and is used to
connect the trigger cable (N5306-61604) to enable triggering between
Protocol Exerciser and Protocol Analyzer. In this scenario, the other
end of the trigger cable is plugged into the trigger connector of the
Protocol Analyzer module.
You can also use this connector for cross-triggering with other
instruments, such as Logic Analyzer.
The following figure shows the meaning of the pins in the Trigger
Connector component:
Figure7 Trigger Connector Pins
Agilent E2960B Series Hardware and Probing Guide 17

3
N5309A Exerciser Card and Extension Card
• Power Supply Connector — This component is used to connect N5309A
with the external power supply.
Use the power supply delivered with N5309A only.
• Status LED (on front bracket)— This LED represents the following
different states:
• No light state means there is no link up.
• Green light means there is a link up at the Gen2 speed.
• Blinking green light means there is a link up at the Gen1 speed.
• USB Connector— This component is used to connect N5309A with the
controller PC using the USB cable.
The following figure shows the Trigger Connector, Power Supply
Connector, Link Status LED, and USB Connector components.
Trigger
Connector
Power Supply
Connector
Status LED (on
front bracket)
USB Connector
Figure8 N5309A Exerciser Card
TheN5309AexercisercardalsohastheExtensionCardConnectorcomponentatitstop,
which is used to connect the Exerciser Extension Card with N5309A. For more information
on this component and exerciser extension card, refer to "N5309-66417 Exerciser Extension
Card" on page 20.
For more information on the N5309A exerciser card, refer to:
• Agilent Protocol Exerciser, User's Guide
NOTE
18 Agilent E2960B Series Hardware and Probing Guide

N5309A Exerciser Card and Extension Card
3
Do not directly touch any component on the N5309A exerciser card. It may be hot.
ComponentsontheN5309Aexercisercardaresensitivetothestaticelectricity.
Therefore,take necessaryanti-staticprecautions,suchas wear a grounded wrist
strap, to minimize the possibility of electrostatic damage.
WARNING
CAUTION
Agilent E2960B Series Hardware and Probing Guide 19

3
N5309A Exerciser Card and Extension Card
N5309-66417 Exerciser Extension Card
This chapter provides information on the N5309- 66417 exerciser extension
card used with the N5309A exerciser card for PCIe.
The following figure displays the N5309-66417 exerciser extension card.
Add-in card Connector
ref Clk Input Power Connector
N5309A connector
retention Module
Screw locks
Figure9 N5309-66417 ExerciserExtension Card
Components of the N5309- 66417 exerciser extension card are described
below:
• Ref Clk Input— This component can be used as an alternative 100 MHz
reference clock input.
• Add-in Card Connector— This component is used to connect any
add-in PCIe card at the top of N5309-66417.
• Retention Module— This component is used to connect the midbus
probe, which isthen used for capturing traffic between the N5309A
exerciser card andthe add-in card.
• Power Connector— This component is used to provide power supply to
an add-in card, which is hooked on the N5309-66417 card.
• N5309A Connector — This component is used to connect the
N5309-66417 card with the N5309A exerciser card.
To connect the two cards:
a Insert the N5309A Connector component into the Extension Card
Connector component of the N5309A card.
b Tighten the screw locks of the N5309-66417 card to tightly align it
with the N5309A card.
20 Agilent E2960B Series Hardware and Probing Guide
