AGPtek M08 User manual

01-13 AGPTek M08 Music Player User Maunal
14-26 M08 MP3 Player Bedienungsanleitung
27-39 AGPTek M08Music Player Guía rápido de inicio
40-53 AGPTek M08 Music Player Guida Rapida
54-67 AGPTek M08 Music Player Guide Rapide
68-78 AGPTek M08MP3 プレーヤー 取扱説明書
INDEX
Music.......................................................................................................4
FM radio..................................................................................................6
Folder View............................................................................................ 7
Set............................................................................................................7
Recordings..............................................................................................8
EBook......................................................................................................9
Help and Troubleshooting..................................................................10
Specifications.......................................................................................12

Buttons and controls
1. Display screen
2. “ ”:Play/Pause/Sel
ection button
3. “ ”: Previous/Fast
backward button
4. “ ”: Next/Fast
forward button
5. “M”: Menu button
/Screen lock button
6. Back button
7. Power button
8. Volume +
9. Volume -
10. TF card slot
11. USB port
12. Reset hole
13. Earphone jack

Charge the Player
1. Plug the attached USB cable into the USB port of a computer to
charge the player.
2. Use only the 5V/500mA charger for charging or it may lead to
product failure.
While it is fully charged, disconnect the cable from your device by
pulling it straight outward.
When you start charging, it will show two options: “Charge &
Transfer”and “Charge & Play”. An icon in the top right corner will
show the charging status.
Power On/Off
Hold the power button switch on/off the device. Click to wake
up/turn off the screen while it is working on backstage.

Note: The player will power off automatically if inactive and no
applications operate on backstage for 2 minutes.
Volumn Adjustment
Click button +/- on the left side to increase/decrease the volume.
Main interface
Each time you press the button / , it will bring you to one of
its 9 different functions, including Music, FM radio, Folder View, Set,
Recordings, Pictures, EBook, Video and Last Played(Now Playing)
Music
When there is a Music icon in the main interface, click button
to access to its function. The related list will show, including: All
songs, Last played, Artists, Albums, Genres, Playlists, Create Playlist.

Choose from these menu, and click button to play the music.
Last played: start playing from where you left last time;
Create Playlist: all your favorite songs can be added here.
Rewind/Forward
While it’s on music playing interface, hold the button / to
rewind/fast forward, short press to previous/next music file. Click
button for playing/pause.
Submenu
While it’s on music playing interface, click button M to access to
the submenu.
The related list will show, including “Home”,“Shuffle”,“Repeat”,
“Bookmarks”
,“Play music from” ,“Equalizer” ,“Variable Speed
Playback”,“Sleep timer”,“Delete”“Add to playlist”and“Remove
from playlist”.

1. Bookmarks
Click button M >Bookmarks>Add bookmark /Go to bookmark
/Delete bookmark. Select according to your need.
2. Variable Speed Playback
Click button M >Variable Speed Playback to adjust speed from
-8(Slowest) to +8(Fastest ). Set the playing speed as you need.
3. Delete
Click button M >Delete, then choose yes to delete the audio files
you want.
4. Equalizer
Click button M >Equalizer >Normal, Rock, Funk, Hip hop”,“Jazz”,
“Classical”,“Techno”,“Custom”.
FM radio

Insert the earphone, then select FM frequency from 87.5 to
108.0MHz.
While in the FM radio playing interface, press button Mto enter
the submenu: Home, Start FM radio recording, Presets, Save to preset,
Clear preset, Auto tune, Tuner region, FM recording.
Tune to the radio station you want. Choose Start FM radio
recording to start recording the radio. Click to pause/resume.
Click and choose yes to save the recording and it will back to
the FM radio interface automatically. Click button M to find the
saved recordings in FM recording.
Note: The radio recordings will also be saved in
Recordings >Recordings library.
Folder View
Find Folder View on main screen with button to access to its
function.

Click button M/to choose from the different folders/files. Click
to play/view.
Note: Always put the lyric file and the music file in the same folder.
Set
When there is a Set icon in the main interface, click button to
access to its function. The related list will show, including: Play
mode, Sound settings, Sleep timer, Display settings, Date and time,
Language, Information, Format device, Factory settings, Create
playlist.
Note: when you set “date and time”, use button Mto switch to next
one. For example, “Set time”, after you set the hour, press button M
to switch to set minute.
Recordings

When there is a Recordings icon in the main interface, click button
to access to its function. The related list will show, including:
Start voice recording, Storage, Recordings library, Record format,
Record settings.
- Click button to start recording, click it again to
pause/resume.
- Click the button and choose yes to save the recording.
- Find the saved recordings in Recordings >Recordings library.
Click the button M/ to select from all the recordings you have
saved. Then click the button to play the recordings.
Record format: MP3/WAV/ACT Rec
Record settings > set rec bitrate/VOR(Voice Operated
Recording)/set recording scene
EBook
When there is a EBook icon in the main interface, click button

to access to its function. While reading e-book, press button Mto
enter the submenu: Playsetting(Auto scroll time), Delete ebook,
Bookmark Select, Delete bookmark, Add book mark, Page select.
Note: Only txt format is supported for EBook.
Last Played(Now Playing)
When there is a Last Played(Now Playing) icon in the main interface,
click button to access to its function. The music/radio playing
interface will be shown, and it will resume playing music/radio
from where you left.
Note: When there is no music/radio playing in the backstage, the
Last Played(Now Playing) function will not be available.
Help and Troubleshooting
●Can’t turn on the player
- Please check whether the player is run out of battery, connect the
