aidapt VG832B Manual

VG832B/VG866B
Overbed Table
Fixing and Maintenance Instructions
EN

INTRODUCTION
INTENDED USE
Thank you for purchasing the Economy Overbed Table from Aidapt.
These instructions should be read carefully and left with the user of the product for future
reference. Please see our website user manual if you require a larger font.
Please ensure this equipment is installed by a competent person.
VG832B – Overbed Table with Castors Max Weight Load 15kg
VG866B – Overbed Table without Castors Max Weight Load 15kg
DO NOT exceed the weight limit stated – doing so could put you at risk.
The Aidapt Economy Overbed Table is a convenient table for use around the home. This height-
adjustable table has a hardwood upstand and the top can also be set to dierent angles from at to 45º
approximately, as required.
1
Fixing and Maintenance Instructions
BEFORE USE
FEATURES
• Carefully remove all packaging. Avoid using any knives or other sharp instruments as this may
damage the surface of the product.
• Check the product for any visible damage. If you see any damage or suspect a fault, do not use your
product, but contact your supplier for support.
• Ideal for those conned to bed
• Ideal for use around the home
• Height adjustable and angle adjustable to suit most users
• It features a veneer style table top with Book Stoppers
• Maximum load 15kg
PARTS
A. U Base Frame x 1
B. Table Top x 1
C. H Frame x 1
D. Castors x 4
(VG832B ONLY)
E. Thumb Wheel x 2
F. C Shaped Brackets x 4
G. L Tube x 2
H. Screws x 8
I. E-Clips x 2
J. Spanner x 1
(g. 1)
BG
A
C
D
E
F
H J
I

(g. 2)
ASSEMBLY INSTRUCTIONS
Please examine your product for any visible
damage before using/installing. If you see any
damage or suspect a fault, please do not use, but
contact your supplier.
1. Carefully remove all packaging and ensure
all loose tments have been provided. (g. 1)
2. If you have purchased the VG832B (with
castors) follow this step, otherwise move
on to step 3. Locate the pre-punched
castor holes on the base frame (g. 2), align
the castor and screw in with spanner (J)
provided (see g.3). Ensure castors are fully
tightened.
3. Turn the U frame over so that the spigots are facing up. Lower the H frame onto the spigots of U
frame (see g. 4). Ensure the black plastic collars on the H frame are at the top and the spigots on H
frame are facing outwards (see g. 5).
(g. 3)
(g. 4) (g. 5)

4. Align pre-punched holes
in bottom of H frame with
the pre-punched holes in
the spigots of the U frame.
Insert E-clips to lock in
position ensuring it clicks in
place and secure.
(see g. 6 and 7)
5. Place the L shape tube onto the underside of the table top, observing the following
(VERY IMPORTANT)
• The riveted end of L shape tube MUST be placed onto the underside of table top (see g. 8).
• The riveted end of L-Shape tube MUST be placed between pre-drilled holes nearest to the
edge of the table (approximately 10 cm from table edge). (see g. 9 and 10)
ASSEMBLY INSTRUCTIONS CONTINUED
(g. 6) (g. 7)
(g. 8)
(g. 9)
(g. 10)

6. Attach the L shaped tubes using four C-shaped brackets and eight screws. (see g.11) Ensure that
the two C-shaped brackets nearer the edge of table are between the two rivets (see g. 12). Do not
overtighten as this may cause damage to the table.
7. Insert the free ends of L shaped tubes into the H Frame (see g. 13). You may require assistance
to align them correctly. Slowly lower the table top (see g. 13). Ensure you lower both sides at the
same time to prevent binding.
8. Loosely attach two thumbwheels to the small spigots at top of H frame (see g. 14).
ASSEMBLY INSTRUCTIONS CONTINUED
C Bracket MUST be
in between the
two rivets
(g. 12)(g. 11)
(g. 13)
(g. 14)

9. Raise or lower table top to desired height and tighten thumb wheels by turning clockwise to secure
(see g. 15). Ensure height is the same on both sides; otherwise, table will not be level and not safe
for use.
10. To adjust height loosen thumb wheels anti-clockwise (see g. 16) and repeat step 9.
ASSEMBLY INSTRUCTIONS CONTINUED
(g. 15) (g. 16)
OPERATION INSTRUCTIONS
• To adjust the height and/or angle of the table, rst loosen the two short hands screws by turning
them anticlockwise. Adjust the table to suit and secure by turning hand screws clockwise.
• The table is not load bearing and should not be used to support objects over 15kgs (33lbs).
• Do not allow people to lean on the table.
WARNING: The Overbed Table requires a risk assessment before use.
WARNING: The Overbed Table must be checked periodically to ensure it is securely in place,
retighten as required.
WARNING: DO NOT overtighten the screws otherwise this will cause damage to table top.
WARNING. DO NOT EXCEED 15kg weight load.
CLEANING
All of the product components are manufactured from quality materials. However, it is very important
that you only clean your Over Bed Table using a non-abrasive cleaner or mild detergent with a soft cloth
avoid using lime scale remover. Abrasive cleaners or abrasive cleaning pads will seriously damage your
product beyond repair.
If to be disinfected by heat (apart from the wooden table top), one of the following three temperatures
and duration of exposure can be used:
a. a temperature of 90°C for 1 minute
b. a temperature of 85°C for 3 minutes
c. a temperature of 80°C for 10 minutes

SERVICE WARRANTY
Aidapt Bathrooms Ltd guarantees the product free from defects in material and workmanship for a
period of one year.
Should this product be operated under conditions other than those recommended, or any attempts
made to service or modify the product, then the warranty is rendered void.
The product you buy may dier slightly from illustrations. This warranty is in addition to, and does not
aect your statutory rights.
Our guarantee is administered by our retailers.
If your product arrives damaged, you must contact the retailer from whom you bought it. The retailers
contact details will be on the invoice that arrived with the product, or on the email you received when
you placed the order. Do not contact Aidapt Bathrooms Ltd, only your retailer can arrange a replacement
or refund.
If your product fails within the guarantee period, please contact the retailer from whom you bought it.
If you have received your product and require technical help, please call our help desk on 01744 745 020
A copy of the instructions leaet can be downloaded from our website.
IMPORTANT INFORMATION
CARE, MAINTENANCE AND YOUR OBLIGATION
The information given in this instruction booklet must not be taken as forming part of or establishing
any contractual or other commitment by Aidapt Bathrooms Limited or its agents or its subsidiaries and
no warranty or representation concerning the information is given.
Please exercise common sense and do not take any unnecessary risks when using this product; as the
user you must accept liability for safety when using the product.
Please check the Over Bed Table periodically for any signs of damage and if in doubt contact your
supplier.
TECHNICAL INFORMATION
Width 400mm
Length 600mm
Height 610-960mm
Net Weight 6.5kgs

Aidapt Bathrooms Ltd, Lancots Lane, Sutton Oak, St Helens, WA9 3EX
Telephone: [phone] Fax: [phone]
Web: www.aidapt.com Email: [email protected]
