Akai ATT05U User manual

37
Professional Belt Drive USB Turntable
ATT05U
37-47
GB

38
1. Read Instructions – All the safety and operating
instructions should be read before this product is
operated.
2. Retain Instructions
－The safety and operating
instructions should be retained for future reference.
3. Heed Warnings
－All warnings on the appliance
and in the operating instructions should be adhered
to.
4. Follow Instructions －All operating and use
instructions should be followed.
5. Water and Moisture
－The appliance should not
be used near water - for example, near a bathtub,
washbowl, kitchen sink, laundry tub, in a wet
basement, or near a swimming pool, and the like.
6. Carts and Stands
－The appliance should be used
only with a cart or stand that is recommended by the
manufacturer.
A
n appliance and cart combination
should be moved with care. Quick
stops, excessive force, and uneven
surfaces may cause the appliance
and cart combination to overturn.
7. Wall or Ceiling Mounting －The product should
not be mounted to a wall or ceiling.
8. Heat
－The appliance should be situated away
from heat sources such as radiators, heat registers,
stoves, or other appliances (including amplifiers)
that produce heat.
9. Power Sources – This product should be operated
only from the type of power source indicated on
the rating label. If you are not sure of the type of
power supply to your home, consult your product
dealer or local power company. For products
intended to operate from battery power, or other
sources, refer the operating instructions.
10. Grounding or Polarization – This product may be
equipped with a polarized alternation-current line
plug (a plug having one blade wider than the
other). This plug will fit into the power outlet only
one way. This is a safety feature. If you are
unable to insert the plug fully into the outlet, try
reversing the plug. If the plug should still fail to fit,
contact your electrician to replace your obsolete
outlet. Do not defeat the safety purpose of the
polarized plug.
11. Power-Cord Protection －Power-supply cords
should be routed so that they are not likely to be
walked on or pinched by items placed upon or
against them, paying particular attention to the
cord in correspondence of plugs, convenience
receptacles, and the point where they exit from
the appliance.
12. Cleaning - The appliance should be cleaned only
as recommended by the manufacturer.
Clean by wiping with a cloth slightly damp with
water. Avoid getting water inside the appliance.
13. For AC line powered units - Before returning
repaired unit to user, use an ohm-meter to
measure from both AC plug blades to all exposed
metallic parts. The resistance should be more
than 100,000 ohms.
14. Non-use Periods －The power cord of the
appliance should be unplugged from the outlet
when left unused for a long period of time.
15. Object and Liquid Entry－Care should be taken
so that objects do not fall and liquids are not
spilled into the enclosure through openings.
16. Damage Requiring Service－The appliance should
be serviced by qualified service personnel when:
A. The power-supply cord or the plug has been
damaged; or
B. Objects have fallen, or liquid has been spilled
into the appliance; or
C. The appliance has been exposed to rain; or
D. The appliance does not appear to operate
normally or exhibits a marked change in
performance; or
E. The appliance has been dropped, or the
enclosure damaged.
17. Servicing －The user should not attempt any
service to the appliance beyond that described in
the operating instructions. All other servicing
should be referred to qualified service personnel.
18. Ventilation – Slots and openings in the cabinet are
provided for ventilation and to ensure reliable
operation of the product and to protect it from
overheating, and these openings must not be
blocked or covered. The openings should never
be blocked by placing the product on a bed, sofa,
rug, or other similar surface. This product should
not be placed in a built-in installation such as a
bookcase or rack unless proper ventilation is the
manufacturer’s instructions have been adhered to.
19. Attachments – do not use attachments not
recommended by the product manufacturer as
they may cause hazards.
20. Accessories – Do not place this product on an
unstable cart, stand, tripod, bracket, or table. The
product may fall, causing serious injury to a child
or adult, and serious damage to the product. Use
only with a cart, stand, tripod, bracket, or table
recommended by the manufacturer, or sold with
the product. Any mounting of the product should
follow the manufacturer’s instructions, and should
use a mounting accessory recommended by the
manufacturer.
21. Lightning – For added protection for this product
during a lightning storm, or when it is left
unattended and unused for long periods of time,
unplug it from the wall outlet and disconnect the
antenna or cable system. This will prevent
damage to the product due to lightning and
power-line surges.
22. Replacement Parts – When replacement parts
are required, be sure the service technician has
used replacement parts specified by the
manufacturer or have the same characteristics as
the original part. Unauthorized substitutions may
result in fire, electric shock, or other hazards.
23. Safety Check – Upon completion of any service
or repairs to this product, ask the service
technician to perform safety checks to determine
that the product is in proper operating condition.
IMPORTANT SAFETY INSTRUCTIONS

39
CAUTION: To reduce the risk of electric shock, do not remove
any cover. No user-serviceable parts inside. Refer servicing to
qualified service personnel only.
The lightning flash with arrowhead symbol within the equilateral triangle is intended to alert the use
to the presence of un-insulated “dangerous voltage” within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric shock.
The exclamation point within the equilateral triangle is intended to alert the user to the presence of
important operation and maintenance (servicing) instructions in the literature accompanying this
appliance.
CAUTION
To prevent electric shock, do not use this polarized plug with an extension cord, receptacle or other outlet
unless the blades can be fully inserted to prevent blade exposure.
＊LINE VOLTAGE SELECTION
Just for dual voltage mode only!
Because power supplies vary from location to location we
have incorporated a selectable power supply.
 The desired voltage may be set with the VOLTAGE
SELECTOR switch located under the platter. (use a
flat head screw driver).
 Do not force the VOLTAGE SELECTOR switch as this
may cause damage.
 If the VOLTAGE SELECTOR switch does not move
smoothly, please contact a qualified service technician.
＊ Check for the following parts included in the package with the main unit:
 Platter
 Slipmat
 Headshell
 Cartridge
 USB cable
 45 rpm adaptor
 Counter weight
 Instruction manual
 RCA cable
 Disc
 Transparent Dust cover
＊
VERY IMPORTANT!!
Do not forget to attach rubber belt to motor for correct operation. After placing
the Turntable Platter onto the turntable through the Center Spindle, move
one of the large windows on the Platter to top right corner. Attach rubber
belt around motor. (Rubber belt is already attached to the underside of the
Turntable Platter.)
＊Notes:
1) Do not connect the AC power plug before assembly has been completed.
2) Before turning the power on, make sure once again all the connections and power voltage settings are
correct. Always turn off the power when connecting or disconnecting.
3) Read this manual carefully before using the unit .Be sure to store the manual in a safe place for future
reference.
IMPORTANT SAFETY INS
TRUCTIONS
DO NOT OPEN
RISK OF ELECTRIC SHOCK
BEFORE USE

40
1. Remove the main unit with the packing from the box and remove the packing.
2. Set the 45-rpm adaptor on the main unit.
3. Set the turntable platter onto the center spindle.
4. Set the slip mat on the platter.
5. Installation of cartridge:
When installing a cartridge, refer to the operating instructions of that cartridge.
During installation, attach the stylus protector to guard the stylus tip from damage.
(a) Connect the lead wires to the cartridge terminals. The terminals of most cartridges are color-coded.
Connect each lead wire to the terminal of the same color.
White (L+)…………………………… Left channel+
Blue (L-) ..................... …………… Left channel-
Red (R+) ......................………….. Right channel+
Green (R-) ................………………. Right channel-
(b) Install the cartridge to the headshell and tighten it with screws provided with the cartridge.
6. Insert the headshell into the front end of the tonearm, then turn the lock nut counterclockwise with the
headshell firmly held horizontally.
7. Slide counterweight onto tonearm. Twist it lightly and it will screw onto the rear shaft of the tonearm.
8. Adjustment of horizontal “zero” balance and stylus pressure:
(a) Remove the stylus protector from the headshell, do not touch the stylus tip during the adjustment.
(b) Set the cueing lever to the lowered position.
(c) Release the tonearm clamp and lift the tonearm from the arm rest to free it.
(d) Rotate the counterweight until the tonearm is approximately balanced horizontally (floats freely).
(e) Refasten the tonearm with the tonearm clamp.
(f) Hold the counterweight stationary with one hand and rotate only the stylus-pressure ring to bring the
number "0" of the ring into alignment with the center line on the tonearm rear shaft.
(g) Rotate the counterweight including the stylus-pressure ring counterclockwise until the scale shows the
value corresponding to the pressure of the stylus used. Should you use a separate Stylus, please
follow the manufacturer’s instructions.
9. Set the anti-skating control knob to the same value as the stylus pressure.
10. Install the transparent dust cover to the main unit’s dust cover hinges.
• Do not place the unit in a location where it will be exposed to direct sunlight or near a heating appliance.
• Do not place the unit in a location where there is high humidity or a lot of dust.
• Cartridge may pick up slight sound pressures or vibrations of the speakers coming along the floor or through
the air resulting in feedback or “howling” sound. Find a location which is very stable and vibration free.
• The legs have functions for adjusting the height of the unit itself. Adjust the legs to stabilize the
main body horizontally.
ASSEMBLY
PLACEMENT

41
Before connecting the unit it is advised that you also consult your current equipment instruction manual.
IMPORTANT: Be sure to turn off the equipment before you make changes to the different connections.
1. Connect the power cord to an AC outlet.
2. Connect the RCA cable to the PHONO input of your AMPLIFIER.
Output terminals Amplifier(Receiver)
L (White) L Channel
R (Red) R Channel
GND (Spade) GND
NOTE:

Be sure to connect the ground terminal firmly to the amplifier or receiver.
 If this connection is not made or is loose, a power source "HUM" will result.
 You can also use a line input by setting the phono / line switch at the rear of the turntable to line.
3. Connect PC via USB cord.
1. Turn the On/Off Switch clockwise to turn on the power, the speed indicator and the strobe-illuminator,
which is located beneath the On/Off switch, will light up.
2. Place a record on the slip mat. When playing a 45-rpm record with a large center hole, place the 45-rpm
adapter on the center spindle.
3. Set the speed to match the record.
4. Remove the stylus protector from the Headshell Stylus and then release the Tonearm clamp.
5. Set the cueing lever to the up position.
6. Press the Start/Stop Button; the turntable platter will start to rotate.
7. Move the tonearm over the desired groove.
8. Set the cueing lever to the down position, the tonearm will descend slowly onto the record and begin
playing.
9. When play is finished, raise the cueing lever, move the tonearm onto the Tonearm clamp.
10. Press the Start/Stop Button to stop the platter from rotating. Turn the On/Off Switch counterclockwise to
turn off the power.
＊SUSPEND PLAY
Set the cueing lever to “UP” position during play, the stylus tip of the cartridge will be lifted from the record.
CONNECTIONS
OPERATIONS
PC

42
 As long as the pitch control is in center “detent” click position, the turntable is operated at selected speed.
 The speed can be increased or decreased by 10% by the pitch control.
 An incorrect adjustment done on purpose can also be used to have the turntable rotate extremely slow or
fast.
 The strobe dots at the edge of the turntable are used for speed monitoring.
 Clean the stylus periodically with a soft brush to prevent the accumulation of dust.
 When sound becomes distorted or noisy, check the stylus. If the stylus is worn out, replace it with a new one.
 From time to time, the transparent dust cover and turntable cabinet should be wiped down with a soft, dry cloth.
 Volatile materials should not be used, such as: alcohol, thinner, benzine etc. They may remove the paint or
damage the luster.
1. 45-rpm Adaptor
This adapter allows you to play standard 7” EP vinyl
records with large center holes. Place the adapter
on the CENTER SPINDLE 7" records.
2. Turntable Platter
This platter connects directly to the center spindle.
The platter and center spindle holds a vinyl record
perfectly center. The platter also spins the record
at a consistent speed.
3. Strobe Indicators
The PLATTER has four rows of indicators. These
indicators are used to visually detail various stages
of pitch. The indicators are illuminated by the
STROBE INDICATOR PILOT LAMP. Each row
may appear to stand still at different pitch levels.
Note: The use of heavy fluorescent lighting directly
above the turntable will defeat the STROBE
LAMP PILOT LAMP affect indicator accuracy.
CONTROLS OVERVIEW
CHANGING THE SPEED
MAINTENANCE
1
3
4
6
5
7
13
14
15
16
17
18
9
811 12
10
23 2421 22
19
2
20

43
4. Center Spindle
This spindle holds the turntable PLATTER records
stable and centered.
5. Strobe Indicators Pilot Lamp
This is lamp specially designed to pulse a beam of
light at the STROBE INDICATORS on the turntable
PLATTER. This will give the illusion that indicators
are not spinning at certain speeds.
6. Power Switch
This is a rotary power switch. To turn main power
on turn the switch in a clockwise direction. To turn
main power off turn the switch in counterclockwise
direction.
7. Start/Stop Button
This over sized push button controls platter motion.
When the unit is turned on the platter will not
automatically begin to spin. Pressing the button
once will engage the high torque motor and spin
the platter, pressing this again will stop the platter.
8. Headshell
The included HEADSHELL is used to connect your
stylus with the tone arm.
9. Headshell Locking Nut
After attaching the headshell to the tonearm, this
locking nut will securely hold the headshell to the
tonearm.
10. S-Shaped Tone Arm
The tonearm is the mechanism that holds the HEAD-
SHELL and stylus allowing it to glide across a record.
11. 33-RPM Speed Select Button
Engaging this button will rotate the platter at 33
revolutions per a minute (RPMs). A function LED
will glow when this function is activated.
12. 45- RPM Speed Select Button
Engaging this button will rotate the platter at 45
RPMs. A function LED will glow when this function
is activated.
13. Pitch Control Slider
This slider is used to adjust the playback pitch
percentage (platter speed).
14. Tone Arm Lever
This lever is used to safely elevates the tone arm
above a record surface without endangering a
records surface.
15. Tone Arm Clamp and Rest
Use this rest to safely hold the tonearm in position
during non use and transportation.
16. Anti-skate Knob
The anti-skate applies inward force to the tonearm
to prevent outward skipping across the record due
to the centrifugal force cause by platter rotation.
The anti-skate value should be equally to that of
the stylus counterweight pressure.
17. Stylus-Pressure Ring
＊The counterweight scale must face toward the
DJ.
18. Extra Stylus Holder
This cut out has been designed to safely store an
extra stylus headshell.
19. Counterweight
Use the counterweight to balance the tone arm and
to adjust the stylus pressure.
20. Hinge For Dust Cover
21. USB Socket (USB cable limit within 3m)
After connecting the Turntable to the computer
via USB, you can record your vinyl to your hard
disk using the included Audacity software.
22. Phono/Line Selector
This switch is used to change the mode of phono
output or line output.
23. Ground Connector
This ground connection is designed to reduce the
humming and popping noises associated with
magnetic phono cartridges. Be sure to connect the
turntable ground lead to any available ground
terminal on the same mixer the input signal leads
are connected to
24. RCA output Jacks
The output is able to switch to PHONO output or
LINE output. For example: These jacks are used
to send a low voltage "phono" level output signal
to a mixers "phono" input jacks. Turntables should
be connected to “Phono” inputs on a mixer. The
red colored RCA jack represents the right channel
input and the white represents the left channel
input.
CONTROLS OVERVIEW

44
Audacity is free software, licensed under the GNU General Public License (GPL). More information as well as
open source code can be found on the CD included or on the web at http://audacity.sourceforge.net/
* Please ensure you have installed the software before starting.
Setting up your PC to work with Audacity
1. Connect an input source to the unit.
2. Connect the USB lead to your computer.
3. Install the Audacity recording software.
4. Open the Audacity program.
5. Select Preference from the Edit tab in the Audacity Menu.
6. Select Audio I/O tab at the top left.
 Under Playback, Device, select your internal sound card.
 Under Recording, Device, select USB Audio CODEC.
 Under Recording, Channels, select 2 (Stereo).
 Check the box marked Play other tracks while recording new one.
 Check the box marked Software Playthrough.
AUDACITY SOFTWARE OV
ERVIEW

45
Recording Albums with Audacity
1. Saving a project
 Audacity writes all the changed and recorded audio to a directory called Projectname_data, which is
located right where you saved the project file itself.
 Thus, select Save project as from your Audacity File tab and choose a location and filename for your
project.
 Please note that when you startup Audacity fresh, only the “Save As...” menu option is available.
2. How to record
 Set your USB turntable up to play the song or album you want to record.
 Click on the red Record button
e
to begin recording.
 Lower tone arm on USB turntable onto album and track you want to record.
 Click on the blue Pause button to pause the recording. Press it again to continue.
 Click on the yellow Stop button.
That's it. You can now play around with your recording and explore the editing capabilities of Audacity.
Remember that you can use the Undo function almost without limits while the project is open.
NOTE: CD's cannot be burned directly from the Audacity application. Other CD burning applications should be
used.
AUDACITY
SOFTWARE OVERVIEW

46
GENERAL
Model: ATT05U Professional Belt Drive USB Turntable
Dimensions: 450(W) x 350(D) x 145(H)mm
Weight: 4.4Kgs
Power supply: Dual Voltage: AC 115V~60Hz/230V~50Hz, User Selectable
Power consumption: 8W
Standard test condition: Ambient Temperature: 23 +/- 2 degC
Relative Humidity: 65% +/- 5%
NOTE: Measurements can be carried out between 5 degC to 35 degC and 45% to 85% relative humidity.
TURNTABLE SECTION:
Type 2-speed full manual
Motor DC motor
Driving Method Belt drive
Turntable Platter 330mm dia. Plastic
Speeds 331/3and 45rpm
Wow and Flutter Less than 0.25% WRMS (JIS WTD) with 331/3rpm
S/N Ratio More than 50dB (DIN-B)
Pitch Controls +/- 10%
Starting Time Less than 1 sec with 331/3
Braking Time Less than 1 sec. with 331/3
Time for Speed Change Less than 1 sec. from 331/3 to 45 rpm
Less than 1 sec. from 45 to 331/3rpm
Speed tolerance at pitch=0 Within +/-1.3%
USB Function USB rec. Function
A/D, D/A 16BIT 44.1KHz or 48KHz USB SELECTABLE
Computer interface USB 1.1 compliant, WINDOWS XP or MAC OSX
TONEARM SECTION:
Type Static balanced S-shaped tonearm with detachable headshell
Effective Arm Length 220 mm
Tracking Error Angle Less than 3 degree
Applicable Cartridge Weight 6~10g
Anti-skating Range 0-4g
Phono Output Level
Line Output Level
1.5~3.6 mV at 1KHz 5cm/sec (HP-4005)
90~216mV at 1KHz 5cm/sec (HP-4005)
Frequency Response 20Hz-20KHz
Channel Separation More than 15dB
Channel Balance Within 2.5dB at 1KHz
Needle Pressure range 3~4g
High of cue(first track) 6~10.5mm
Descend of cue 1~3sec
EQ AMP
Output 150mV +/-4dB (IN: 2.5 mV 1KHz)
RIAA 20Hz~20KHz +1/-3dB (IN: 1.5 mV 1KHz)
NOTE:
Corrosion, oxidation, battery-leakage and any other gradually acidic defect of this nature will invalidate the guarantee.
SPECIFICATION
