Alpine i509-WRA-JL User manual

Jeep Wrangler
i509-WRA-JL 20220401v1 1/29
Jeep Wrangler
i509-WRA-JL
9” Restyle In-Dash System
Installation Manual
Model: Wrangler JL 2018-Up
Model: Gladiator JT 2020-Up
Note
Design and specifications are subject to change without notice for improvement.
To Ensure Safe Use,Always Follow These Precautions
The installation of this product requires specialized skills and experience. This is an installation that is
challenging and time consuming even for installers with experience. A professional installer would typically
take a minimum of 3-4 hours to complete this installation. We recommend that you have the product installed
by an Alpine authorized dealer.
Before you use this product, be sure to carefully read this installation manual and the separate user's manual
so that you can use the product correctly. Alpine Electronics bears no responsibility for problems that arise as
a result of failure to follow the instructions in the manuals.
This manual includes a number of symbols that are intended to help you use the product safely, to prevent
harm to you and others, and to protect against damage to property. These symbols and their meanings are
listed below. Make sure you fully understand these symbols before you begin reading the main text.
Explanations of Injury and Damage That May Result from Incorrect Use
Warning Ignoring the content marked by this indication and using the product incorrectly is
expected to lead to death or serious injury.
Caution Ignoring the content marked by this indication and using the product incorrectly is only
expected to lead to injury or property damage.
Jeep Model Year
Wrangler JL** 2018 - Up
Gladiator JT** 2020 - Up
** OEM amplified vehicles require the KCX-F200INT (sold separately)
* The specified vehicles have been tested and have met compatibility specs at the time of testing. Compatibility is
not guaranteed if the manufacturer has made production changes to the listed vehicles above.
Introduction
Congratulations on purchasing the i509-WRA-JL. This installation manual is designed to take you through
the step-by-step installation of i509-WRA-JL into a 2018-Up Jeep Wrangler JL or Jeep Gladiator JT 2020-
Up. Please familiarize yourself with the owners manual as this is a challenging installation. If you still have
additional questions please call 1-800-TECH-101.

Jeep Wrangler
i509-WRA-JL 20220401v1 2/29
Forbidden
Indicates actions that are
forbidden (must not be
performed)
Forbidden
Indicates that disassembly is
forbidden.
Mandatory
Indicates actions that are
mandatory (must be performed)
Marks content that should receive
your full attention.
Warning
Do not disassemble or modify the product.
Doing so could lead to an accident, fire, or
electric shock.
Forbidden
Store screws and other small objects where
children cannot reach them. If one of those
small objects is swallowed, consult with a
doctor immediately.
When replacing fuses be sure to
use the fuses with the specified current
rating. Failing to do so could lead to
an accident or fire.
Forbidden
Only connect the product to a 12 VDC negative
ground car. Failing to do so could lead to an
accident or fire.
Mandatory
Since this vehicle has two batteries, discon-
necting the battery is not a good option. Take
caution when testing circuits. Failing to do so
could lead to electric shock or injury.
Do not cut the insulation on a cord and take
power from another device. Doing so could
lead to fire or electric shock.
Forbidden
Do not install the product in a location where
it willl obstruct the driver’s forward view;
interfere with the operation of the steering
wheel, gear shift, or the like; or pose a threat
to passengers. Doing so could lead to an ac-
cident or injury.
Forbidden
When making a hole in the vehicle body, be
careful to avoid damaging pipes, the fuel tank,
electrical wiring, and the like. This kind of
damage could lead to an accident or fire.
When installing and grounding the product, do
not use any of the bolts or nuts of the steering
wheel, brakes, fuel tank, or the like. Doing so
could make the brakes stop working or could
lead to fire.
Forbidden
Do not install the product near the passenger-
side airbag. Doing so could interfere with the
operation of the airbag and lead to an acci-
dent or injury.
Forbidden
Bundle cords so that they don’t interfere with
driving. Wrapping cords around the steer-
ing wheel, gearshift, brake pedal, or the like
could lead to an accident or damage equip-
ment.
Caution
Connect the product properly according to the
instructions. Failing to do so could lead to fire
or an accident.
Forbidden
Do not sandwich cords between the seat
railing or allow them to touch protrusions. Re-
sulting breaks or shorts could lead to electric
shock or fire.
Do not block vents or heat sinks. Doing so
could lead to fire or damage equipment.
Use the accessories according to the instruc-
tions, and attach them securely. Failing to
do so could lead to an accident or damage
equipment.
Forbidden
Do not install the product where it may be ex-
posed to water or in a place with high levels
of humidity or dust. Doing so could lead to fire
or damage equipment.
Forbidden
The installation and wiring of this product re-
quires specialized skills and experience. Have
the product installed by an Alpine authorized
dealer.
Types of Precautions
Mandatory

Jeep Wrangler
i509-WRA-JL 20220401v1 3/29
Tools Required
10mm Socket 8mm Socket 7mm Socket
Wire Cutters Extension Ratchet
#2 Phillips Screwdriver Torx T20 Torx T47
Panel Removal Tools Wire Fishing Tool Cordless Power Drill
Digital Multimeter

Jeep Wrangler
i509-WRA-JL 20220401v1 4/29
Accessory List
Head Unit Box Parts (i509)
i509 Display Unit i509 Source Unit External Bluetooth Mic
AUX/Pre Out Harness GPS Antenna Documents
Alpine
Registration Card
Quick
Reference
Guide
Direct Camera Adapter Display Cable Source Unit HDMI Bracket
Anti-Vibration Foam Screws M5X8LMM x 12
Rear Camera Retention (SGS-BSV1-WJL V2.0)
Camera Module Camera Power Harness Camera Male To Male RCA
Coupler
SGS-BSV1-WJL
FACTORY CAMERA BSV INTERFACE
LVDS INUSB Flash
DIP1:
UP=Wrangler
Down=Gladiator
DIP 2,3,4,5,6,7,8
All up
DIP7:
Down=Firmware Update
VIDEO OUT
Power & CAN
IN
Can1
Can2
Rear Camera RCA
(Not Used)

Jeep Wrangler
i509-WRA-JL 20220401v1 5/29
Accessory List
Installation Kit
i509-WRA-JL Display Bezel Screws M5X10LMM x 2 Lock Washers x 2
Power Inverter Bracket Display Bracket Tuner Bracket
Display Power/Key Harness
iDatalink Maestro Box Parts (ALP-MRR/ALP-HRN-WJL3)
iDatalink Maestro Module USB, HDMI, Aux Interface Maestro Flashing Cable
Main Harness Mini USB To USB For Center
Console Power Chime Speaker
USB Power Adapter

Jeep Wrangler
i509-WRA-JL 20220401v1 6/29
1INSTALL THE WEBLINK PLUG-IN
Go to:
3 CONNECT YOUR MAESTRO MODULE
Use your Maestro module to connect to your PC.
5 PROGRAM YOUR MODULE
Follow the programming steps for your vehicle.
A conrmation email will be sent to you requiring validation.
For existing customers, click log in.
4 LOG INTO WEBLINK
Enter your username and password, then click OK.
6 Once Programing is complete “FLASHING
COMPLETED!” will be displayed.
Proceed to the next page to complete installation.
NOTE: If serial number is invalid, Call ADS at
1-866-427-2999 with the serial number.
Programming The iDatalink Maestro Module
idatalinkmaestro.com and follow the installation steps. The
Maestro module must be programmed specifically for each vehicle
and radio. Take care to enter the correct vehicle information,
factory options, head unit model, and head unit serial number.
The head units serial number is an alphanumeric value which is
found on the head units label, underneath the bar code.
If the plugin is already installed, Click "Continue" and follow the
prompts to open. If Plug in is not installed Click "Get it now" and
follow prompts to downlaod and install the plug-in
2REGISTER A WEBLINK ACCOUNT
Go to:
Sign Up and complete the registration process.

Jeep Wrangler
i509-WRA-JL 20220401v1 7/29
About The Installation
2019 Jeep
Wrangler
Sport Sport S Sport
Altitude
Sahara Rubicon Sahara
Altitude
MOAB
5.0” Touchscreen
Display
Standard Standard Standard Not Available Not Available Not Available Not Available
7.0” Touchscreen
Display
Not Available Not Available Not Available Standard Standard Standard Standard
115V Power
Outlet
Not Available Not Available Not Available Standard Standard Standard Standard
Cold Weather
Group
Not Available Optional Optional Optional Optional Optional Optional
The different trim levels of the Wragler JL and the Gladiator JT come with different options which will make
the installation vary slightly. If the vehicle has the 115V Power outlet or the Cold Weather Group package
then there are different brackets that will need to be used. If your vehicle does not have those then you will
not need to use those. If you are installing the i509-WRA-JL in a Gladiator JT then a few of the steps will vary
slightly so please take notice to this as you go through the installation. Also the screen size in the pictures may
be different if you have the 5.0” display. The following chart shows which options are available on the different
trim levels for the Wrangler JL.
Retained Features
STEERING WHEEL CONTROLS
Two Functions on Each Button ■
Standard and Expanded Radio Functions ■
NAVIGATION OUTPUTS
Accessory Power Output (15A) ■
Parking Brake Output ■
Reverse Light Output ■
Vehicle Speed Pulse Output ■
Foot Brake Output ■
FACTORY AMPLIFIER
Amplifier Turn on ■
Speed Compensated Volume (Premium Audio) ■
Digital Fader (Premium Audio) ■
DSP Settings (Premium Audio) ■
Gain Adjustment (Premium Audio) ■
SECONDARY VEHICLE DISPLAY (IF EQUIPPED)
Audio Information Display ■
Hands Free Info Display ■
Navigation Info Display ■
VEHICLE SETTINGS
Access And Modify Vehicle Settings ■
CLIMATE CONTROL
Climate Display And Control On Radio ■
GAUGES
Selectable Performance Gauges ■
“Track Pack” Gauges ■
Read/Reset Check Engine Codes ■
PARK ASSIST
Retain Parking Assist Chimes ■
Distance Display On Screen ■
VEHICLE INFO
Tire Pressure Display ■
Battery Voltage Display ■
Read/Reset Check Engine Codes ■
Door open Status and Warning ■
ACCESSORIES
OEM Accessory Control Integration ■
ADVANCED CAMERA FEATURES
Front Camera Auto Control
A) Smart Parking
B) Low Speed Trigger
■
Side Camera Auto Control
A) Right Lane Watch
B) Left Lane Watch
■
4X4 Front Camera Control
A) Offroad 4X4 Trigger
■

Jeep Wrangler
i509-WRA-JL 20220401v1 8/29
Factory Unit Disassembly Process
1As a precautionary measure it’s a good idea to
mask out the dashboard and panels to prevent
scratches.
2Unsnap the 6 clips and remove the knee panel
under the steering wheel using a panel removal
tool.
3The locations of the 6 clips from the previous step. 4Unsnap 10 clips, unplug the 2 harnesses, and
remove HVAC panel using a panel removal tool.
5Locations of the clips and harnesses of the HVAC
controls from the previous step.
6Use #2 Phillips Screwdriver to extract (2) screws
from the bottom of the radio bezel.

Jeep Wrangler
i509-WRA-JL 20220401v1 9/29
Factory Unit Disassembly Process (Continued)
7Unsnap 6 clips and remove radio bezel using a
panel removal tool.
8Unsnap the 6 clips and remove the knee panel
under the steering wheel using a panel removal
tool.
9Use #2 Phillips Screwdriver to extract (4) screws
from head unit. Disconnect and remove the radio.
10 Disconnect the harnesses behind the OEM head
unit.
11 The disconnected harnesses from the previous
step. These will be used later to connect to the
main harness in the installation.
12 Open the glove compartment and remove
all contents, push up the glove compartment
travel stop and lower the door, pivot the glove
compartment downward, release latch on left side
of the glove compartment by pushing it upward,
pull the glove compartment upward to remove it
from the pivot.

Jeep Wrangler
i509-WRA-JL 20220401v1 10/29
13 For vehicles with the power inverter remove the
ventilation duct behind the drivers side knee panel
using a panel removal tool to release the one clip
holding it in place. Once the installation of the i509-
WRA-JL tuner is completed the vent can go back
in place.
14 For vehicles with heated seats or the power
inverter the bracket for the module needs to be
removed. Remove the (4) 10mm screws to remove
the bracket. Then remove the (2) 8mm screws lower
and the (2) 10mm screws top to remove the module.
16 Remove the A pillar by removing the (2) 8mm
screws and unclipping the panel. The screws can
be exposed using a panel removal tool.
Factory Unit Disassembly Process (Continued)
15 Remove the two knee panel brackets. Each
bracket is held in by (1) 10mm screw.

Jeep Wrangler
i509-WRA-JL 20220401v1 11/29
19 Unclip 7 clips and remove the center media stack.
17 Loosen the clips around the top panel visor area. 18 Remove panel above drivers door going to the B
pillar.
Factory Unit Disassembly Process (Continued)

Jeep Wrangler
i509-WRA-JL 20220401v1 12/29
Installation Instructions
1Run the GPS antenna Bluetooth microphone
cables up the A pillar along the OEM wiring. Route
as shown on the diagram on page 17.
2Mount the microphone next to the rear view mirror
and run the cable behind the factory panels. Route
as shown on the diagram on page 17.
3Mount GPS antenna near driver side B-pillar as
illustrated on page 17 and run the cable to the
knee panel.
4Route radio cables including Radio Main, Sirius XM,
FM, and Aux in main harness and also the display
cable from radio cavity to knee panel.
5Route vehicle cable in main harness from radio
cavity to glove box and connect it to OBDII
gateway behind the glove box. If the gateway is
fully occupied, unclip 1 connector from it and use
T-harness.
6Attach tuner bracket to tuner using (4) M5X8LMM
supplied screws.

Jeep Wrangler
i509-WRA-JL 20220401v1 13/29
Installation Instructions (Continued)
7If you are using the optional SiriusXM tuner, Cable
tie the module on top of the source unit.
8For vehicles with heated seats or the power
inverter attach the Power Inverter bracket using
the supplied (2) M5X10LMM screws and lock
washers. This will mean you will not use two of the
M5X8LMM screws from the previous page. These
two screws are slightly longer and can make it
through both brackets.
9Use the factory speed clips from the bracket that
was removed from the vehicle and attach them to
the Power Inverter bracket. For the Wrangler JL
use the 2 holes circled in black. For the Gladiator
JT use the 3 holes pointed out by the arrows.
10 After attaching the factory speed clips this is what
the bracket will look like for the Wrangler JL.

Jeep Wrangler
i509-WRA-JL 20220401v1 14/29
Installation Instructions (Continued)
11 Attach the factory Power module to the bracket
using the OEM screws. This is what the power
module will look like for the Wrangler JL.
12 Attach the factory Power module to the bracket
using the OEM screws. This is what the power
module will look like for the Gladiator JT.
14 Use (4) OEM bolts to secure the i509 source
unit tuner bracket to the vehicle. If the vehicle is
equipped with the power inverter it will mount
behind the 2nd cross bar.
15 At the knee panel, connect the main harness,
display harness, GPS antenna, microphone, USB
cable, HDMI, FM adapter, and other adapters to
i509 source unit and secure them.
13 If the vehicle has the heated seat module clip that
into the bottom bracket. The OEM clips on the
module will snap into the bracket.

Jeep Wrangler
i509-WRA-JL 20220401v1 15/29
Installation Instructions (Continued)
17If the vehicle has an OEM amplifier the KCX-
F200INT will need to be purchased separately.
This has 30” of cable so it can be routed behind
the glovebox. It is important to do this so it can
disappate heat properly. The audio settings will
also need to be set to flat as shown on page 29.
18Connect the camera interface module to the violet
or red factory camera plug and put it in right side
of radio cavity. Dip switch 1 will need to be moved
down for the Gladiator JT.
20 Run chime speaker harness from Maestro module
to behind the glove box and attach there.
21Remove the OEM USB from the Center Media
panel by unclipping the clips on the sides.
19 Attach the Maestro to the main harness and tuck it
in left side of radio cavity.
16At radio cavity, connect the main harness, white
FM adapter, and green SiriusXM antenna, and
other adapters to factory harness and secure them.

Jeep Wrangler
i509-WRA-JL 20220401v1 16/29
Installation Instructions (Continued)
22Insert the i509 USB HDMI box into the OEM
Center Media panel. Connect the HDMI and the
two USB cables to the source unit as shown on
page 19.
23Plug in the OEM USB and the USB from the box
to the power adapter. The adaptor needs to be
plugged into the BLACK micro usb.
26 Attach the display and bracket to the vehicle using
the OEM screws from the OEM radio.
25Apply Anti-Vibration Foam to the top of the display.
Attach the display unit to the display bracket using
the (4) M5X8LMM supplied screws.
27Plug in the bezel and and reinstall all the factory
panels.
24WARNING: There are 2 factory micro USB plugs
in the dash behind the media center. One is black
and one is grey. If the supplied adaptor is plugged
into the grey micro USB the factory USB’s will not
charge. When it is plugged into the black plug all
rear USB’s can be used for charging (not data).
Incorrect
Correct

Jeep Wrangler
i509-WRA-JL 20220401v1 17/29
Component Locations
IMPORTANT: Follow the recommended component location shown below. Failure to do so, will result in poor
GPS performance.
Jeep
0
1
2
3
4
567RPM
X1000
MPH
0
10
20
30
40
50
MENU CAM
AUDIO NAV
MEDIA
ENGINE
STAR T
STOP
/////alpine
Add-on Microphone
OBDII Gateway
OEM Camera Module
i509-WRA-JL Source Unit
iDatalink Maestro Module
SAT-Radio Tuner
(Sold Separately)
Harness Route
GPS Antenna Installation
IMPORTANT: Follow the GPS antenna installation procedure shown below. Failure to do so will result in poor
GPS performance for CarPlay, Android Auto, and off-road navigation.
Route from behind
tuner, through
lower dash, and up
the A pillar.
GPS Antenna
Peel the plastic layer
off from the double
side tape of the GPS
antenna and place the
GPS antenna on top of
the driver side roof
frame.

Jeep Wrangler
i509-WRA-JL 20220401v1 18/29
To Vehicle Connectors
iDatalink MAESTRO Module
18-pin Black
Connector
10-pin Green
Connector
(Vehicle signals)
3-pin Black
Connector
(Power)
4-pin Black
Connector
(Data)
To CAN Connector
Blue Power Antenna
Blue/White Amp Turn-on
ACC CAN
SiriusXM
Antenna
Power Harness
Chime Speaker
Display Power/Key Harness
i509
External Microphone
Power
Speaker
52-pin Connector
Bluetooth Mic Input
18-PinChime10-Pin
3-Pin 4-Pin 3-Pin 4-Pin
Blue
Not
Used
Red
Not
Used
Reset
Button
10-Pin
Front
Rear
Rear
Front
AMPLIFIED VEHICLES
Requires the KCX-F200INT (sold separately)
WARNING!
FM
Antenna
(White)
SXM
Antenna
(Green)
Black
Not
Used
To optional
SiriusXM tuner
(sold seperately)
i509D - Display
Main Harness
CAN Connector Bank
SiriusXm
connect
Aux Power
GPS Antenna
USB, AUX, HDMI Interface
SGS-BSV1-WJL
FACTORY CAMERA BSV INTERFACE
LVDS INUSB Flash
DIP1:
UP=Wrangler
Down=Gladiator
DIP 2,3,4,5,6,7,8
All up
DIP7:
Down=Firmware Update
VIDEO OUT
Power & CAN
IN
Can1
Can2
Rear
Camera
(Violet
or Red)
USB
HDMI
Rear Camera Direct Input
To Center Console USB Power connector in vehicle
Aux Power pass through
covered by protective cap
CAN pass through
connection in case bank is
full. Otherwise
not used.
Direct Camera Adapter
Camera Power
RCA Coupler
Dip Switch 1 should be up
for the Wrangler and down
for the Gladiator. The rest of
the switches are not used.
Mini USB To USB
Black
Not
Used
This must be plugged into the black micro USB. See page 16 for details
Front
Rear
Rear
Front
Only 2 connections are
necessary for the OEM
amplied system. Front
(White) connects to Front
(White) from tuner. Rear
(Black) connects to Rear
(Black) towards the vehicle.
The other two connections
are not used.
X
X
PREOUT
USB
CAMERA
ANTENNA
MAIN
REMOTE SXM
DISPLAY
EX KEY
GPS
OUT
IN
Black USB 2.4A Charge & Passes Data
Gray USB 1.5A Charging Only
Front Camera Direct Input
Dash Cam Video In
Dash Cam Data
To Dash Cam
See Page 10
To Optional
Front Camera Rear Camera
Direct Input
Note: optional direct to RCA
adapter can be purchased
on www.pacparts.com
Not Used
This is step 23 on page 16
Aux Remote Out
(Not Used)
Aux Remote In
(Not Used)
Brown
Gray
i509-WRA-JL Wiring Diagram

Jeep Wrangler
i509-WRA-JL 20220401v1 19/29
i509-WRA-JL Wiring Diagram Continued
To Vehicle Connectors
iDatalink MAESTRO Module
18-pin Black
Connector
10-pin Green
Connector
(Vehicle signals)
3-pin Black
Connector
(Power)
4-pin Black
Connector
(Data)
To CAN Connector
Blue Power Antenna
Blue/White Amp Turn-on
ACC CAN
SiriusXM
Antenna
Power Harness
Chime Speaker
Display Power/Key Harness
i509
External Microphone
Power
Speaker
52-pin Connector
Bluetooth Mic Input
18-PinChime10-Pin
3-Pin 4-Pin 3-Pin 4-Pin
Blue
Not
Used
Red
Not
Used
Reset
Button
10-Pin
Front
Rear
Rear
Front
AMPLIFIED VEHICLES
Requires the KCX-F200INT (sold separately)
WARNING!
FM
Antenna
(White)
SXM
Antenna
(Green)
Black
Not
Used
To optional
SiriusXM tuner
(sold seperately)
i509D - Display
Main Harness
CAN Connector Bank
SiriusXm
connect
Aux Power
GPS Antenna
USB, AUX, HDMI Interface
SGS-BSV1-WJL
FACTORY CAMERA BSV INTERFACE
LVDS INUSB Flash
DIP1:
UP=Wrangler
Down=Gladiator
DIP 2,3,4,5,6,7,8
All up
DIP7:
Down=Firmware Update
VIDEO OUT
Power & CAN
IN
Can1
Can2
Rear
Camera
(Violet
or Red)
USB
HDMI
Rear Camera Direct Input
To Center Console USB Power connector in vehicle
Aux Power pass through
covered by protective cap
CAN pass through
connection in case bank is
full. Otherwise
not used.
Direct Camera Adapter
Camera Power
RCA Coupler
Dip Switch 1 should be up
for the Wrangler and down
for the Gladiator. The rest of
the switches are not used.
Mini USB To USB
Black
Not
Used
This must be plugged into the black micro USB. See page 16 for details
Front
Rear
Rear
Front
Only 2 connections are
necessary for the OEM
amplied system. Front
(White) connects to Front
(White) from tuner. Rear
(Black) connects to Rear
(Black) towards the vehicle.
The other two connections
are not used.
X
X
PREOUT
USB
CAMERA
ANTENNA
MAIN
REMOTE SXM
DISPLAY
EX KEY
GPS
OUT
IN
Black USB 2.4A Charge & Passes Data
Gray USB 1.5A Charging Only
Front Camera Direct Input
Dash Cam Video In
Dash Cam Data
To Dash Cam
See Page 10
To Optional
Front Camera Rear Camera
Direct Input
Note: optional direct to RCA
adapter can be purchased
on www.pacparts.com
Not Used
This is step 23 on page 16
Aux Remote Out
(Not Used)
Aux Remote In
(Not Used)
Brown
Gray

Jeep Wrangler
i509-WRA-JL 20220401v1 20/29
Remote Turn-On Lead (Blue/White)
Subwoofer RCA Connectors
Front Output RCA Connectors
Rear Output RCA Connectors
RCA Extension Cable (sold separately)
(Blue/White)
REMOTE ON
(Blue/White)
Subwoofer
REMOTE
Amplier for subwoofer
(sold separately)
To subwoofer input terminal
(Red)
(White)
SUBW
FRONT OUT
REAR OUT
To front input terminal
Amplier 4 ch
(sold separately)
To rear input terminal
Front speaker
Rear speaker
REMOTE ON
(Blue/White)
(Red)
(White)
(Red)
(White)
PREOUT
USB
CAMERA
ANTENNA
MAIN
REMOTE SXM
DISPLAY
EX KEY
GPS
OUT
IN
Connection Of An External Amplifier
There is no way to integrate the factory SiriusXM tuner. Once the radio is removed, the factory SiriusXM is
removed. As the title states, SiriusXM requires a tuner sold separately. This diagram shows how to integrate the
antenna connection. For vehicles with factory SiriusXM connect the adapter to the factory SiriusXM antenna in the
radio cavity. The factory SiriusXM antenna is located on the passenger side B-pillar. For vehicles without factory
SiriusXM use the antenna that is included with the SXV300 SiriusXM Tuner.
Connecting A SiriusXM Module (Sold Separately)
SiriusXm
connect
PREOUT
USB
CAMERA
ANTENNA
MAIN
REMOTE SXM
DISPLAY
EX KEY
GPS
OUT
IN
