Alto-Shaam 1000-BQ2/192 User manual

D U E T O O N G O I N G P R O D U C T D E V E L O P E N T,S P E C I F I C AT I O N S A R E S U B J E C T TO C H A N G E W I T H O U T N O T I C E .
1000-BQ2/192
HOT HOLDING BANQUET CARTS
ITEM NO. _______________________
ANSI/NSF 4
Stainless steel exterior with four (4) dutch doors and transport handles on each end of the cart. Two side-by-side
vertical compartments, each individually conrolled with an ON/OFF power switch, an adjustable temperature knob, and
a digital display. The unit has a temperature range of 60°F (16°C) to 200°F (93°C) and a temperature display light that
indicates the temperature within the cabinet has reached the desired holding temperature. Eight (8) chrome plated wire
shelves are included. A full-perimeter, wall-friendly bumper is included, along with six (6) 6" (152mm) heavty duty
casters, 2 rigid and 4 swivel with brake. The 125 V.A.C. cabinet includes one (1) high/low power switch and two (2)
electrical cords with plug.
Flexible choice of preplated meal service: This banquet cart will also hold covered meals without plate carriers.
Additional shelves will equip cart to hold preplated meals without covers, trays, and bulk food items in pans.
■■MODEL 1000-BQ2/ 192: obile banquet cart with dutch doors with capacity of 192 meals (10" covered plates)
● HALO HEAT . . . a controlled, uniform heat source that gently
surrounds food for better appearance, taste, and longer holding life.
●Close temperature tolerance and even heat application provides even
heat from top to bottom – side to side.
●Holds preplated food fresh, flavorful, and hot.
●No moisture pans, water or canned heat needed.
●Designed to adapt to any type of banquet holding:
– Covered plates, stacked
– Covered or uncovered plate carriers
– Accepts trays for banquet service
– Additional shelves for full-size and half-size pans (gastronorm pans)
●Dutch doors designed to keep heat in the top portion of the cabinet
while removing plates from the bottom.
●Non-magnetic stainless steel interior resists corrosion.
●Full perimeter, wall-friendly bumper, transport handles, and heavy
duty casters.
W164 N9221 Water Street • .O. Box 450 • Menomonee Falls, Wisconsin 53052-0450 • U.S.A.
HONE: 262.251.3800 800.558.8744 U.S.A./ CANADA FAX: [phone].329.8744 U.S.A. ONLY
www.alto-shaam.com
#48 - 1/08
P R I N T E D I N U .S.A.
S ECIAL INFORMATION:
●Plate covers are not furnished.
●Plate carriers are optional.
●Since plates and plate covers
vary in size, cabinet may not
hold maximum quantity of
meals specified. DC-2868
DC-2869

C A PA C I T Y
480 lbs (218 kg) AXI U
VOLU E AXI U : 300 QUARTS (380 LITERS)
LATES: (without plate carriers)
— 10" (254mm) with covers: 192
— 10-3/4" (273mm) with covers: 160
LARGER DIA ETER ITE S WILL RESULT IN REDUCED PLATE CAPACITIES
ANS: Full-size and half-size pan combinations (per shelf)
— 12" x 20" (530mm x 325mm - GN 1/1): 2
— 12" x 10" (265mm x 325mm - GN 1/2): 4
ADDITIONAL WIRE SHELVES WITH SUPPORT CLIPS WILL ACCO ODATE VARIOUS
CO BINATIONS OF 2-1/2" (65mm), 4" (100mm) OR 6" (150mm) DEEP PANS
SHELF CA ACITY: (per shelf, without covers)
— 10" (254mm) plates: 6
— Shelves maximum: 32 SPACING ON CENTERS 3-5/32" (80mm)
C L E A R A N C E R E Q U I R E M E N T S
Full perimeter bumper accommodates all
clearance requirements.
INSTALLATION REQUIREMENTS
Cart must be installed level. It must not be installed in
any area where it may be affected by steam, grease,
dripping water, high temperatures, or any other
severely adverse conditions.
O P T I O N S & A C C E S S O R I E S
late Carriers, chrome plated (EACH HOLD 4 PREPLATED EALS)
■■Uncovered " " Carriers DC-2868
Plate dia: 10" (254mm) max. • 7-3/4" (197mm) min.
Vertical rung spacing: 2-5/8" (67mm)
CA ACITY: 48 CARRIERS, 192 RE LATED MEALS
■■Covered "C" Carriers DC-2869
Plate dia: 9-3/4" (248mm) max. • 7-3/4" (197mm) min.
Vertical clearance between top and bottom carrier: 11-5/8" (295mm)
CA ACITY: 48 CARRIERS, 192 RE LATED MEALS
■■Shelf & Shelf Supports (for each extra shelf) 1061/ 11533
late Carriers, chrome plated (EACH HOLD 4 PREPLATED EALS)
■■Uncovered "E " Carriers DC-23580
Plate dia: 12-1/2" (318mm) max.• 9-1/2" (241mm) min.
Vertical rung spacing: 2-5/8" (67mm)
CA ACITY: 32 CARRIERS, 128 RE LATED MEALS
■■Covered "EC" Carriers DC-23676
Plate dia: 12-1/2" (318mm) max.• 9-1/2" (241mm) min.
Vertical clearance between top and bottom carrier: 11-5/8" (295mm)
CA ACITY: 32 CARRIERS, 128 RE LATED MEALS
■■Wire Shelf, chrome plated SH-2835
58-7/8" (1494mm)
210.0
O
23-1/4" (590mm)
Electrical Connection
2-1/8" (54mm)
From Top
67-1/2" (1714mm)
68-11/16" (1744mm)
8-1/16" (204mm)
I
o
I
o
I
o
I
o
30-7/16" (773mm)
30-1/16" (762mm)
2-1/8" (54mm)
1000-BQ2/192
HOT HOLDING BANQUET CARTS
(H x W x D)
W164 N9221 Water Street • .O. Box 450 • Menomonee Falls, Wisconsin 53052-0450 • U.S.A.
HONE: 262.251.3800 800.558.8744 U.S.A./ CANADA FAX: [phone].329.8744 U.S.A. ONLY
www.alto-shaam.com
#48 - 1/08 P R I N T E D I N U .S.A.
D U E T O O N G O I N G P R O D U C T D E V E L O P E N T, S P E C I F I C AT I O N S A R E S U B J E C T T O C H A N G E W I T H O U T N O T I C E
WEIGHT
NET 653 lb (296 kg)
SHI 760 lb (345 kg)
CARTON 77" X74" X35"
D I M E N SI O N S :(1956mm x 1880mm x 889mm)
D I M E N S I O N S : H x W x D
EXTERIOR:
67-1/2" x 68-11/16" x 30-7/16"
(1714mm x 1744mm x 773mm)
INTERIOR ER DOOR O ENING:
53" x 56-1/2" x 25-1/2"
(1346mm x 718mm x 648mm)
ELECTRICAL
VOLTAGE HASE CYCLE/HZ AM S kW CORD & LUG INCLUDED
125 1 50/60 NE A L5-20P
POWER SWITCH IN LOW POSITION 16.0 2.0 20A- 125V PLUG
POWER SWITCH IN HIGH POSITION 24.0 AX 3.0 NE A L5-30P
30A - 125V PLUG
208-240 (UL)1 50/60 12.5 3.0 NE A 6-15P
at 208 1 50/60 12.3 2.5 15A - 250V PLUG
at 240 1 50/60 14.2 3.4
230 1 50/60 13.0 3.0 CEE 7/7
220-230V PLUG
15A-125V PLUG
NEMA 5-15P
20 AMP 125 VOLTS
PLUG, NEMA 5-20P
PLUG: NEMA 6-15P
15A, 250V
PLUG, CEE 7/7 (SCHUKO)
16 AMP 250V (#701410)
15A-125V PLUG
NEMA 5-15P
20 AMP 125 VOLTS
PLUG, NEMA 5-20P
PLUG: NEMA 6-15P
15A, 250V
PLUG, CEE 7/7 (SCHUKO)
16 AMP 250V (#701410)
PLUG,CEE 7/7 (SCHUKO)
16AMP 250V (#701410)
15A-125V PLUG
NEMA 5-15P
20 AMP 125 VOLTS
PLUG, NEMA 5-20P
PLUG: NEMA 6-15P
15A, 250V
PLUG, CEE 7/7 (SCHUKO)
16 AMP 250V (#701410)
